7starlake SKY12-P06 User manual

1
SKY12-P06
Sunlight Readable 1000 (up to 1300) Nits
NVIS Support, Dimmable Backlight < 1%
Anti-Scratch 7H (G.F.G.) Resistive Touch
Soft Touch Button /w programmable
function keys
IP65 Certified
MIL-STD 461/1275 18V~36V DC Input
Dual vision mode military display
with programmable function keys

2
Safety Information
Electrical safety
To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before
relocating the system.
When adding or removing devices to or from the system, ensure that the power cables for the
devices are unplugged before the signal cables are connected. If possible, disconnect all power
cables from the existing system before you add a device.
Before connecting or removing signal cables from the motherboard, ensure that all power
cables are unplugged.
Seek professional assistance before using an adapter or extension cord. These devices could
interrupt the grounding circuit.
Make sure that your power supply is set to the correct voltage in your area.
If you are not sure about the voltage of the electrical outlet you are using, contact your local
power company.
If the power supply is broken, do not try to fix it by yourself. Contact a qualified service
technician or your local distributor.
Operation safety
Before installing the motherboard and adding devices on it, carefully read all the manuals that
came with the package.
Before using the product, make sure all cables are correctly connected and the power cables
are not damaged. If you detect any damage, contact your dealer immediately.
To avoid short circuits, keep paper clips, screws, and staples away from connectors, slots,
sockets and circuitry.
Avoid dust, humidity, and temperature extremes. Do not place the product in any area where it
may become wet.
Place the product on a stable surface.
If you encounter any technical problems with the product, contact your local distributor.
Statement
All rights reserved. No part of this publication may be reproduced in any form or by any means,

All product specifications are subject to change without prior notice

3
Table of content
1. Product Introduction
1.1 Scope of delivery
1.2 Overview
2. Components
2.1 Location
2.2 Ruggedness
2.3 Power supply
2.4 Display Panel
2.5 Video signal inputs
3. Specification
3.1 Display
3.2 Interface
3.2.1 DC-In
3.2.2 USB
3.2.3 DVI
4. Operations Introduction
5. Maintenance

4
Chapter 1: Product Introduction
1.1 Product Outlook
1.2 ME dimension

5
Chapter 2: Components
2.1 Location
A clean and moisture free environment is preferred. Make room for air circulation. Avoid areas with:
Sudden or extreme changes in temperature.
Extreme heat.
Strong electromagnetic fields.
Dust or high humidity.
If it is necessary to work in a hostile environment, please regularly maintain your display by cleaning dust,
water, etc. to keep it in optimal condition.
2.2 Ruggedness
The display is designed with rugged features such as vibration, shock, dust and rain/water protection.
However, it is still necessary to provide appropriate protection while operating in harsh environments.
NEVER immerse the unit in water. Doing so may cause permanent damage. All connectors will corrode if
exposed to water or moisture. Corrosion is accelerated if the system’s power is ON. Please take proper
water-resistant measures for cable connections.
The DC jack and cables are sealed and may be operated with water splashing while attached. All port
covers should be in place when no cable is attached.
2.3 Power supply
The display can be powered via DC-IN (9~36V)
Optional:12~40V DC-IN (150W max) MIL-STD-461, MIL-STD-1275
2.4 Display Panel
The panel of the SKY series is a 4:3,1024 x 768 XGA panel with typical up to 1300 cd/m2 brightness, a
contrast of 900:1 and a LED backlight.
2.5 Brightness
The brightness of the display can be changed by simple pressing the brightness up/down keys in normal
operational mode.
2.6 Video signal inputs
The SKY12 series is equipped with the following video signal interfaces:
-DVI (single link DVI signal) (primary)

6
Chapter 3: Specification
12.1” TFT LCD Display & Resistor Touch screen
Resolution
1024x768 XGA
Brightness
1000 Nits (Optional:1300 Nits) 
Aspect Ratio
4:3
Contrast Ratio
900
Touch Panel
Glass-Film-Glass 5-Wire resistor touch panel (Optional)
System SPEC
Dual Mode
Day Mode: Ultra-Brightness 1300 nits; Night Mode: NVIS (Dimmable under 1% Nits)
Function key
7 Soft Touch Buttons, including :
3 for OSD (Brightness +, Brightness-, Blackout);
3 for Programmable;
1 for power button (On/Off)
DC-IN
18V ~ 36 V, 28Vdc
Connectors
DC-IN
Amphenol TV07RW-11-54P
IO Ports
X1:DVI (Amphenol TV07RW-13-35S);
X2:2xUSB (Amphenol TV07RW-13-98S)
Applications
Applications
Marine, Naval, Ground and Airborne environment.
Physical
Dimension
310 x 280 x 90 mm (W x D x H)
Weight
TBD
Finish
Anodic aluminum oxide
Chassis
Aluminum Alloy, Corrosion Resistant.
Ingress Protection
IP65 Dust /water Proof
MIL Compliance
MIL-STD-810G (Operation Test)
Low Temp.
Method 502.5 Procedure 2
Exposure(24h x 3 cycle) at -10℃min.
High Temp.
Method 501.5 Procedure 2
60ºC for 2 hrs after temperature stabilization.
Humidity
Method 507.5 Procedure 2
RH -95%. Test cycles: ten 24-hrs , functional test after 5th and
10th cycles
Vibration
Method 514.6 Category 20
10-500Hz 1.04Grms Test duration: 1 hr x 3 axis (total 3 hrs)
Shock
Method 516.6 Procedure 1
20G, 11mSec, 3 per axis
MIL-STD-810G (Non-Operating Tests)
Low Temp.
Method 502.5
Exposure(24h x 7 cycle) at -20℃min.
High Temp.
Method 501.5 Procedure 1
71ºC for 2 hrs after temperature stabilization.
Vibration
Method 514.6 Category 24
200 to 2000Hz Test duration: 1hr per axis; rms = 7.7 gs
Shock
Method 516.6 Procedure 1
20G, 11mSec, 3 per axis

7
MIL-STD-461E
CE102
Basic curve, 10kHz - 30 MHz
RE102-4, (1.5 MHz)
(1.5 MHz) -30 MHz - 5 GHz
RS103
1.5 MHz - 5 GHz, 50 V/m equal for all frequencies EN 61000-4-2: Air discharge: 8 kV,
Environmental Qualifications
Regulatory
CE ,FCC Compliance
Operation Temp.
-10~+70 °C (Optional: -40~+70°C, with smart heater solution)
Storage Temp.
-15~+85 °C
Green Product
RoHS, WEEE compliance
3.2 Interface
3.2.1 DC-In
3.2.2 USB
3.2.3 DVI

8
Chapter 4: Operation Introduction

9
Chapter 5: Maintenance
This chapter includes regular cleaning and maintenance procedures. Follow all the recommendations in
this chapter in order to ensure long product lifecycle. This equipment is extremely rugged and does not
require a lot of maintenance. Remember that electrical equipment should be handled with care and used
accordingly to its specifications.
5.1 Cleaning the Display Screen
Wipe the screen with a clean, soft, lint-free cloth. This removes dust and other particles. Do not
useacetone, ethyl alcohol, toluene, ethyl acid or methyl chloride to clear the panel. It may
permanently damage the display screen.
You can apply a small amount of non-ammonia; non-alcohol based glass cleaner onto a clean, soft,
lint-free cloth and wipe the screen.
Never spray or pour any liquid directly on the screen or case.
Do not use water or oil directly on the display screen. If droplets are allowed to drop on the screen,
permanent staining or discoloration may occur.
5.2 Cleaning the Casing
Use the following procedure to clean the equipment.
Caution/ Attention
Always turn off the device and disconnect other peripherals before cleaning and
maintenance procedures.
Before Cleaning:
•Make sure the device is turned off.
•Disconnect the power cable from any AC outlet.
When Cleaning:
•Wipe dust off the outside casing with a cloth slightly moistened with water or mild ammoniabased
cleaning solution. Do not use this cloth on a display screen!
•Do not use an abrasive cleaner or high-pressure washer on the screen.
•Do not rub the unit with a dry cloth. This action can result in a static charge being built up and cause a
spark. Always use damp cloth while cleaning the unit.
Warning!/ Avertissement!
POTENTIAL ELECTROSTATIC CHARGE HAZARD

10
