NETBOX Starfish
4.
3.
Installation Guide
For dimensions
Please refer to the back.
2.1.
Part List
NETBOX Starfish x 1
NETBOX Starfish Fixing Sleeve x 1
NETClip x 3
Pan Head Philip Screw (M2, 9x9.5) x 3
Fix the sleeve to the NETBOX Starfish by
fastening the 3 screws
Place the NETBOX Starfish into the pre-cut
80mm grommet hole
Secure the NETBOX Starfish into position by
inserting the 3 NETClips. Ensure the NETclips
are pushed until the end
Secure cable and insert into power source
or data outlet if required. NETBOX Starfish
is ready to use
