  9. A LED Brida User manual

A LED Brida User manual

Important: Please read the instruction manual carefully prior to installation and keep it for future reference.
Mounting: Wall or Ceiling
Light features:
Ra: >80
Life Time: 5 years
Light Source: LED SMD2835
Input: 220V-240V 50/60Hz
OPERATING MANUAL
Brida - Sensor CCT
Installation
a. Cut off the power. Thread the input cable through the
rubber plug to the fixture. Connect the L, N wire
referring to the wiring diagram.
b. Knock the rawl plugs into the pre-drilled holes on ceiling
/wall. Wear plastic washers on self-tapping screws and
tighten them to fix the fixture on ceiling/wall.
Unscrew the diffuser anticlockwise.
Vertically remove the diffuser and PCBA.
2
Colour Temperature Code
30K
35K
40K
CCT(K)
3000
3500
4000
Lumen
2070
2160
2196
Colour Temperature
Warm White
Natural White
Cool White
Code
1
290
55
C0/180,110.1
C30/210,110.5
C60/240,109.5
C90/270,108.9
Accessories
No.
1
2
3
4
5
6
7
Usage
Fix light
Rawl plug
Vandal proof
screw tool
Plastic washer
Pic.
Fix cable clip
Cable clip
Cable clip
8
Qty.
3
3
1
3
2
1
1
4 Plastic plug
Ordering Code
Brida Sensor CCT
Power
(W)
Function
Description
Product
Fitting Series
18Brida
Sensor DIM,
color temperature
selectable, power
switchable
4. Contact an authorised technical service centre for any repairs possibly required use only original spare parts.
5. Do not touch LED while installing or maintaining.
6. Sealing the entrance hole with glue after install is needed.
7. The light source contained in this luminaire shall only be replaced by the manufacturer or his service agent or a
similar qualified person.
RoHS
IK10IP65
Hvid / Sort
A LED A/S Hammeren 6, DK-6800 Varde www.aled.dk +45 71995354
CCT:
1 2
1 2
I
II
III
3000K
3500K
4000K
Electric Current Power
300mA 11W
350mA
500mA
13W
18W
Instruction for Light Source Disassembly
1 2
3 4
* This product contains a light source of energy efficiency class <D>
Unscrew the diffuser anticlockwise and vertically
take it out.
Disconnect the DC power cable from the driver.
On the reverse of diffuser, use the screwdriver to
pry the clips to release the PCBA, then twist the
PCBA anticlockwise.
Take out the PCBA (light source) from the diffuser.
Hvid Sort
1980
2030
2070
3
Install the cable clip.
4
5
Mount the diffuser onto the base with screws. Install the plastic plugs to hide the screws.
6
Connect the DC cable.
Wiring
L
N
L N
1. Cut off the main power first.
2. Don’t touch LEDs while maintaining or cleaning.
3. Don't use chemicals to clean the fixture.
Environmental protection: waste electrical products should not be disposed of with household waste. Please recycle
where facilities exist. Check with your local authority or retailer for recycling advice.
Maintenance
Caution
1. The product must be installed by professional technicians and power supply must be cut off before installation.
2. The diameter for AC input wire is 0.75mm² (complying with 60245 IEC57), which complies with the latest IEE
electrical standards or national standards.
3. Do not touch the electronic circuit and its components.
Sensor Setting Options
Sensitivity can be adjusted by selecting the combination
on the DIP switches for different applications.
I – 5s
II – 90s
III – 3min
IV – 10min
Hold-time refers to the time period that the light remains
100% on if no more movement is detected.
Daylight sensor
Different daylight threshold can be preset on DIP switches.
Light will always turn on upon movement if daylight sensor
is disabled.
I – 100%
II – 50%
100%
50%
1
I – Disable
II – 50Lux
III – 10Lux
IV – 2Lux
Disable
50Lux
10Lux
2Lux
4 5
5s
90s
3min
10min
2 3
Sensitivity
Hold-time
2~50Lux
Hold-time
5s~30min
ceiling mounting pattern (m)
6m
12m
I – 0s
II – 10s
III – 10min
IV – +∞
This is the time period that the light remains at a low level
before it is completely turned off.
6 7
0s
10s
10min
+∞
Stand-by dim level
Light can be dimmed to different levels after hold-time. I – 10%
II – 30%
10%
30%
8
Stand-by time
Stand-by period
0s~+
8
Detection Pattern
1
2
3
4
5
6
1 212 34 43
6 6545 34 23 987612 543211
)m(gnitnuomllaW)m(gnitnuomgnilieC
height (m)
height (m)
high sensitivity area low sensitivity area high sensitivity area low sensitivity area
