USER’S MANUAL
AOD/ATS 260 metal case (touch) computer
Back with and without cover
A1Touch Solution BV  : [phone]
 : [phone]
Hogeweg 21
NL-6367 BA Voerendaal : [e-mail]
The Netherlands  :www.A1TouchSolution.nl

Page 2
Contents:
1. (Touch) Computer User’s Manual
1.0. Connection to the computer
1.1. Installation
1.2. Features
1.3. Plug and play function
1.4. Safety Precaution
1.5. OSD (On-Screen-Menu)
1.6. OSD Menu
1.7. Specifications
1.8. Contents of the retail package
1.9. Troubleshooting

Page 3
1.(Touch) Computer User’s Manual
1.0 Connection To the Computer:
1.1 Installation
•Mount the unit in position as desired.
You can adjust the connection for your PC environment via I/O panel of computer:

Page 4
•Connect 220v to the computer
1.2 Features
•AOD 260 has 26” LCD and support up to 75Hz.
•Mini ITX format Computer with quad core Intel J1900 2.0 Ghz processor Passive cooled !
•Second connection external monitor via DVI (Digital) possible.
•Microphone and speaker integration possible (option).
•You can adjust brightness, contrast, horizontal & vertical positions by OSD
•menus and use auto adjust function for instant adjustment.
•High-qualified LCD Controller inside
•Robust design and power saving mode
•100% compatible with Windows PC environment without the installation of
•driver CD or software program.
1.3 Plug and Play Function
AOD260 is installed with OS on demand. These units are completely installed with activation completed
and with latest drivers for plug and play functionality.
1.4 Safety Precaution
We strongly recommend that you carefully read this User’s Manual before operating
your computer. FOLLOW INSTRUCTIONS in this manual.
Please read and comprehend all using directives before use this machine.
•Power
Use the type of power indicated on the marking label.
•Adapter
Only use an adapter designed of the LCD monitor.
•Plug
Do not remove any of the prongs of the monitor's three-pronged power plug.
Disconnect the power plug from the AC outlet if you will not use it for an indefinite period of time.
•Power and extension cord
•Use the proper power cord with ground conductor
Do not overload wall outlets or power cords. Ensure that the total of all units plugged
into the wall outlet does not exceed 7 amperes.
Do not allow anything to rest on the power cord. Do not locate this product where persons will walk on
the cord.
•Care and maintenance
Slots and openings in the cabinet are provided for ventilation. Do not block or cover these openings.
Do not push objects of any kind into cabinet slots or openings. The screen surface is easily
scratched. Do not use paper towels to clean the display. Avoid touching it with your fingers, pens, or
pencils.
•Turn off the AC adapter and the monitor over long periods when not in use.

Page 5
1.5 OSD (On-Screen-Menu)
menu select down up power
Button Function Status
POWER Power ON or OFF ON/OFF
LED Indicate working status
Green: On
Red: Stand-by
Orange: No signal
UP Launch OSD Menu or
add value Move to OSD Menu
DOWN
Launch OSD Menu or
add value Move to OSD Menu
SELECT Select OSD Menu
MENU On /Off OSD Menu
1.6 OSD Menu
OSD Menu
Description
Remarks
Brightness Adjust the brightness of the screen
Contrast Adjust the contrast of the screen
H.Position
Adjust the horizontal position of the
screen’s image
Only
usable on
analog
mode
V.Position
Adjust the vertical position of the screen’s
Phase Adjust the focus of the screen’s image
Clock
Adjust the horizontal size of the screen’s
Auto adjust
Automatically adjust the horizontal position,
vertical position, horizontal size, and phase
window’s
Color
Color
temp
User
Reddish
Bluish
Control the temperature of the color
Red Control the intensity of the color of screen’s
(usable when color temperature is USER
mode.)
Only
usable on
analog
mode
Green
Blue
Auto color
Adjust the color balance of the screen

Page 6
OSD
Language
English
French
German
Spanish
Italian
Korean
Japanese
Select one of the seven language
Usable in
all Mode.
OSD H. Posi. Select OSD MENU horizontal position
OSD V. Posi. Select OSD MENU vertical position
OSD Timer
OSD MENU disappear from over the screen
after setting time
Transparency Adjust the transparency of the OSD menu
Misc.
Language
English
French
German
Spanish
Korean
Select one of the five language
Usable in
all Mode.
Recall Initialize the current mode & setting value
Input
select
Analog Analog signal (RGB)
Digital DVI digital signal
Audio Audio ON/Off select
Volume Adjust volume level

Page 7
1.7 Specifications
Name: AOD / ATS 26" (touch)Computer Q1900B
Color:
Black powder Coated (other colors on request)
Model:
26.0 inch / 660.87 mm TFT active matrix LCD
Type:
LG-Phillips / LC260EUN
Resolution (max):
FULL HD 1920 x 1080 WUXGA
Color:
10-bit (D), 1.06 B kleuren
Pixel:
0.3 mm x 0.3 mm
Brightness:
400 cd/m²
Contrast ratio:
1000:1
Viewing angle:
89°/89° horizontal & 89°/89° vertical
Response time
8 ms
Active area:
477 (H) x 300 (V) mm
Computer specs:
Type computerboard
Intel Q1900B Quad core 2Ghz, passive cooled
Chipset
No seperate chipset
Memory
2 x DDR3/DDR3L SO-DIMM Slots
Processor
Intel Q1900B Quad core 2Ghz processor
Flashmodule/ Harddisk
Sata SSD and SATA Harddisk.possible
VGA
Intel® 7th generation (Gen 7) graphics
LAN (RJ-45)
• PCIE x1 Gigabit LAN 10/100/1000 Mb/s
• Realtek RTL8111GR
• Supports Wake-On-WAN
• Supports Wake-On-LAN
Audio
5.1 CH HD Audio (Realtek ALC662 Audio Codec)
IDE, SATA, Flash
2 x SATA2 3.0 Gb/s Connectors, supporting NCQ, AHCI and
Hot Plug
Hardware Monitor + Power Management
Temperature, Voltage, Case open function, Watch Dog timer
(manufacturing option)
Operating system
Windows 7, 8, 10 Linux, Win CE, XPe.
I/O system:
1 x On/Off switch
1 x VGA
1 x DVI
4 x USB 2.0
1 x PS/2 Keyboard
1 x PS/2 Mouse
2 x RS232,422,485 COM ports
2 x RJ45 LAN ports 10/100Mb Ethernet (internet connection.
Standard)
1 x Mic-in
1 x Line-in
1 x Line-out
Internal I/O:
1 x Mini-PCI socket
1 x PCI-Express x1 slot
Energy requirements
50W normal use; 96 W max.; 5 W stand by.

Page 8
Power
220V internal
Weight
16 Kg
Mounting:
VESA 200x100mm; (No bracket included in delivery;
See: mounting_brackets)
Dimensions system(B x H x D)
650x388x99 mm
Options:
Functionality:
With or without touch
- without touch:
Acrylic or glass
- with touch:
Type of Touch:
5 wire resitive, Surface Accoustic Wave or Projected
Capacitive
Not sure what to use? Call us at [phone] or send
us contactform
- 5 wire resistive :
-Standard non-glare.
-Touchable with finger, glove and stylus.
-Single touch
-activation force less than 40 gramm.
- SAW:
-Standard glare.
-Touchable with finger and glove.
-Single touch
-activation force less than 85 gramm.
- Projected Capacitive:
-Standard glare.
-Touchable with finger, glove and pcap stylus.
-10 points touch
-activation force less than 1 gramm.
External protection:
Standard IP44 or IP65 or higher (not for SAW)
Memory capacity:
No memory (standard), 2, 4 or 8 Gb SoDimm
Storage capacity Sata:
No strage (standard), Harddisk 250/500 Gb or SSD in
60/120/240 or 480 Gb.
Operating system:
NO OS (standard), Win7 embedded WSP7 multilangual,
Win7Pro, Win8Home and Pro, Win10Home and Pro.
Input equipment:
None (standard) or wireless keyboard/mouse

Page 9
1.8 Contents of Package
Computer system
AC/DC Adapter Power cord Drivers cd Other Cables (option)
1.9 Troubleshooting
TO REDUCE THE RISK OF ELECTRIC SHOK, DO NOT REMOVE COVER.
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONELLE.
•The system does not respond after you turn on the system :
-Make sure that the monitor is turned on via OSD button.
-Turn off the power and check the system’s power cord, AC adapter,
for proper connection.
•Appear the “ No Input the Signal" :
-Check the connecting of the vga cable on I/O panel computer and power on computer.
•Appear the “ Input Not the Supported" :
-Input signal are insuperable, reset the video mode and adjust video driver settings.
•The appearance is not at the screen center.:
-Use “AUTO ADJUST”, refer to the Controls section.
•The characters on the screen are too dim or too bright
-Choose fit color temperature, use “AUTO COLOUR ADJUST or manually adjust
“RGB ADJUSTMENT, refer to the Control section.
