AAF ArrestAll AR 1-3 FB User manual

THE WORLD LEADER IN CLEAN AIR SOLUTIONS
AAF®INTERNATIONAL
INSTALLATION, OPERATION
AND MAINTENANCE MANUAL
ArrestAll®

2
ArrestAll
© 2015 American Air Filter Company, Inc. Any use of the text or images
this document contains, without permission of American Air Filter
Company, Inc., is prohibited. ArrestAll, AAF, REDClean, REDFiltration,
and Reliable Efficient Durable are registered trademarks of American Air
Filter Company, Inc. d/b/a AAF International.
REV 1
TO ORDER SPARE & REPLACEMENT PARTS
Call 1-800-477-1214
Email: [e-mail]
Parts Sales
Power & Industrial
AAF International
9920 Corporate Campus Drive
Suite 2200
Louisville, KY 40223-5000
USA
Internet: http://www.AAFParts.com

3
ArrestAll
© 2015 American Air Filter Company, Inc. Any use of the text or images
this document contains, without permission of American Air Filter
Company, Inc., is prohibited. ArrestAll, AAF, REDClean, REDFiltration,
and Reliable Efficient Durable are registered trademarks of American Air
Filter Company, Inc. d/b/a AAF International.
TABLE OF CONTENTS
1INTRODUCTION........................................................................................................................... 5
2SAFETY.............................................................................................................................................. 5
2.1 Safety statement................................................................................................................. 5
2.2 Safe working practices and staff training............................................................ 5
2.3 Dust explosions.................................................................................................................... 6
2.4 Electrical hazards................................................................................................................ 8
2.5 Rotating equipment........................................................................................................... 8
2.6 Safety guards ........................................................................................................................ 8
3GENERAL PRODUCT INFORMATION ................................................................................ 8
3.1 Description.............................................................................................................................. 8
3.2 Purpose and intended use............................................................................................. 9
3.3 Normal Operation................................................................................................................ 9
3.4 Sizes............................................................................................................................................ 9
3.5 Filter elements.................................................................................................................... 11
3.6 Weights................................................................................................................................... 12
4PRODUCT SHIPMENT.............................................................................................................. 13
4.1 How the product ships................................................................................................... 13
4.2 Items that ship separately.......................................................................................... 13
5PRODUCT RECEIPT AT THE DESIGNATED DELIVERY POINT .......................... 13
5.1 Responsibilities of the customer or customer’s agent............................... 13
5.2 Receiving................................................................................................................................ 13
5.3 Inspection on arrival....................................................................................................... 13
5.4 Damaged goods.................................................................................................................. 13
5.5 Missing goods...................................................................................................................... 14
6UNLOADING AND HANDLING............................................................................................ 14
6.1 Unloading............................................................................................................................... 14
7STORAGE AND PROTECTION.............................................................................................. 15
8SITE PREPARATION................................................................................................................ 15
8.1 Locating equipment......................................................................................................... 15
8.2 Foundations.......................................................................................................................... 16
8.3 Anchoring............................................................................................................................... 16
9ASSEMBLY AND INSTALLATION ...................................................................................... 17
9.1 Introduction......................................................................................................................... 17

4
ArrestAll
© 2015 American Air Filter Company, Inc. Any use of the text or images
this document contains, without permission of American Air Filter
Company, Inc., is prohibited. ArrestAll, AAF, REDClean, REDFiltration,
and Reliable Efficient Durable are registered trademarks of American Air
Filter Company, Inc. d/b/a AAF International.
9.2 Assembling and installing the structure............................................................. 17
9.2.1 Funnel Bottom Units........................................................................................................................................17
9.2.2 Flat and Cart Bottom Units.........................................................................................................................18
9.2.3 Bin Vent Units.......................................................................................................................................................18
9.2.4 Installation of the filter elements..........................................................................................................19
9.2.5 Installation of accessories...........................................................................................................................22
9.2.6 Electrical connections......................................................................................................................................23
9.2.7 Compressed air connections......................................................................................................................24
9.2.8 Ductwork Installation......................................................................................................................................24
10 EXPLOSION VENTS.................................................................................................................. 24
10.1 Installation of the explosion vent........................................................................... 24
10.2 Servicing................................................................................................................................. 25
10.3 Safety distance................................................................................................................... 25
11 START-UP & OPERATION..................................................................................................... 25
11.1 Start-up checklist.............................................................................................................. 25
11.2 Normal operation.............................................................................................................. 26
12 MAINTENANCE ........................................................................................................................... 27
12.1 Record Keeping .................................................................................................................. 27
12.2 Fan and Motor Replacement....................................................................................... 27
13 TROUBLESHOOTING................................................................................................................ 28
14 RECOMMENDED SPARE PARTS LIST.............................................................................. 31

5
ArrestAll
© 2015 American Air Filter Company, Inc. Any use of the text or images
this document contains, without permission of American Air Filter
Company, Inc., is prohibited. ArrestAll, AAF, REDClean, REDFiltration,
and Reliable Efficient Durable are registered trademarks of American Air
Filter Company, Inc. d/b/a AAF International.
1INTRODUCTION
This document contains the information necessary to properly receive,
assemble, install, operate, and maintain the AAF®ArrestAll®filter system and
filters. The purchaser, installer, and operator of the filter system MUST read and
comply with this document in its entirety prior to installation of the equipment and
its operation. Failure to comply with the requirements of this manual may void the
product warranty. The information and guidelines contained in this manual are not
exhaustive, and additional or different precautions, measures, training, etc. may
be needed depending on the specific circumstances.
CAUTION
These instructions are specific to the AAF ArrestAll filter system and filters.
All ancillary tasks including, but not limited to, electrical and mechanical
work, equipment handling, and safety procedures must be performed in
accordance with industry accepted practice and all relevant local, state, and
federal government codes, laws, and policies.
2SAFETY
2.1 Safety statement
The air cleaning equipment supplied by AAF International ranges from very
large multiple-component assemblies which require significant and complex,
rigging, handling and assembly on-site, to small compact assemblies that are
easily handled and maneuvered. In addition to size, many of the dust collectors
will require electrical connections, compressed air connections, and will feature
high speed rotating equipment.
At all times, when dealing with industrial equipment such as dust collection
equipment personnel safety must be the highest priority of all involved, from
riggers, installers, operators, users, and maintenance personnel. Those
responsible on-site shall review the details of the equipment beforehand and
develop a plan for dealing with all stages of the installation from receipt of the
equipment on-site to start-up, commissioning, and hand-over. All applicable
health, safety, and environmental (“HSE”) rules, regulations and legislation shall
be fully complied with at all times.
2.2 Safe working practices and staff training
AAF International is fully committed to the safety of its employees and those
of its customers. In this spirit the following guidelines are offered for the
consideration of those responsible:

6
ArrestAll
© 2015 American Air Filter Company, Inc. Any use of the text or images
this document contains, without permission of American Air Filter
Company, Inc., is prohibited. ArrestAll, AAF, REDClean, REDFiltration,
and Reliable Efficient Durable are registered trademarks of American Air
Filter Company, Inc. d/b/a AAF International.
All personnel shall receive safety training specific to the site, the task, and the
conditions under which the work will be conducted.
All personnel shall be equipped with appropriate safety apparel and
equipment, such as clothing, footwear, hard-hats, gloves, ear protection, eye
protection, and safety harness.
All personnel involved in any stage of the process shall have been trained for
the tasks in which they will be involved and at all times shall be under the direct
supervision of experienced supervisors and managers.
All personnel shall be equipped with appropriate tools and equipment to safely
and efficiently complete their task.
Adequate lighting shall be supplied at all times while work is being conducted.
A work perimeter shall be set up to define the limits of the area within which
the work will be conducted and outside which there will be no threat to the safety
of personnel or plant. The perimeter shall be taped-off and marked appropriately
to prevent accidental ingress of uninvolved personnel or equipment. When the
work area impedes into existing access ways or traffic routes for which no practical
alternative is available, barriers, wardens and flaggers shall be employed to safely
control crossing traffic and personnel.
At any time only those personnel directly involved in completing the task at
hand shall be allowed within the work perimeter.
2.3 Dust explosions
Dust explosions constitute a serious industrial hazard and may result in
death, serious injury, and/or devastating property damage. It is the responsibility
of the user to identify the nature of the dust and whether or not it poses an
explosive hazard and to properly mitigate this hazard. Except as otherwise
expressly provided in writing, AAF makes no representation or warranty in
connection with explosion hazard equipment, including, but not limited to, the
necessity or effectiveness of explosion hazard equipment or to the design,
installation, operation, and performance of such equipment. The basic standard for
dealing with explosive dust applications is from the National Fire Protection Agency
(“FPA”), NFPA 69: Standard on Explosion Prevention Systems. This standard
applies to the design, installation, operation, maintenance, and testing of systems

7
ArrestAll
© 2015 American Air Filter Company, Inc. Any use of the text or images
this document contains, without permission of American Air Filter
Company, Inc., is prohibited. ArrestAll, AAF, REDClean, REDFiltration,
and Reliable Efficient Durable are registered trademarks of American Air
Filter Company, Inc. d/b/a AAF International.
for the prevention of explosions by means of various methods. The user shall be
fully conversant with the provisions of NFPA 69 and shall comply in full with all of
its requirements.
By its very nature AAF equipment is intended to be used to capture airborne
particulate matter, otherwise known as dust. There are various methods for
dealing with a dust explosion in a dust collector. These can include, but are not
limited to, the use of properly designed explosion vents, explosion suppression
systems, or flameless vents. The user shall understand which method is being
used and who is responsible for the design and supply of the equipment required.
When an explosive dust has been properly identified to AAF, the dust collector may
be structurally designed to withstand the internal pressure generated during the
explosive event and fitted with an explosion vent, or with multiple vents, designed
to safely discharge the pressure and the resulting fireball. The user shall review
the purchase order and the documents referenced within it to determine if
explosion protection equipment has been supplied by AAF International. Where
this is the case, review the appropriate sections of this manual that deal with the
installation, operation and maintenance of the equipment ordered.
When explosion protection systems are supplied by multiple vendors, it is
the responsibility of the user to coordinate between suppliers to ensure that the
equipment supplied by each vendor will work together to achieve the required
protection. For instance, if an explosion suppression system is being supplied by
parties other than AAF, it is incumbent on the user to ensure that the dust
collection equipment has been ordered to resist the internal pressure defined by
the suppression equipment supplier.
Dust collectors fitted with explosion vents must not be located indoors, unless
properly designed in accordance to NFPA regulations. The equipment shall be
oriented so that the vent will discharge to an unoccupied zone. Such a zone will be
prohibited to personnel and shall not include critical equipment or services such as
fuel storage tanks, flammable materials, fire hydrants, power distribution or
electrical control equipment, or similar. If the vent(s) is located on the side(s) of
the equipment the vent discharge area shall be isolated with barriers erected to
prevent the parking of vehicles, pedestrian use, or use of the area for temporary
storage. Warning signs shall be posted. Include diagrams showing the distribution
of a typical dust explosion discharge.

8
ArrestAll
© 2015 American Air Filter Company, Inc. Any use of the text or images
this document contains, without permission of American Air Filter
Company, Inc., is prohibited. ArrestAll, AAF, REDClean, REDFiltration,
and Reliable Efficient Durable are registered trademarks of American Air
Filter Company, Inc. d/b/a AAF International.
2.4 Electrical hazards
Before doing any work on the AAF equipment make sure that all potential
electrical hazards have been identified and that all electric current connected to
the equipment, and to any connected or associated equipment, has been properly
disconnected and securely locked-out to prevent accidental reconnection prior to
completion of the work. All electrical work shall be done in full accordance with the
current edition of NFPA 70, the National Electrical Code, and all other applicable
laws, rules, and regulations. All electrical work shall be performed by a licensed
electrician. Only original AAF parts shall be used as replacements for ongoing
maintenance and repair.
2.5 Rotating equipment
The ArrestAll can include a fan which is installed on the top of the dust
collector, either on top of the collector or as an integral fan. The fan wheel rotates
at a nominal speed of 3,600 rpm and has the potential to cause severe injury. The
fan wheel could be accessed from inside the cabinet through the air inlet and from
outside the cabinet through the fan discharge. All due care should be exercised to
avoid any contact with the operating fan. Under no circumstances should the fan
ever be allowed to operate when any of the access panels on the dust collector, or
the silencer, have been removed. The fan must be disconnected and locked out
prior to the performance of any maintenance work, see paragraph 2.4.
2.6 Safety guards
The dust collector cabinet prevents access to the fan inlet. All access panels
shall remain bolted in place while the fan is operating. Prior to the removal of any
access panels, the electrical power to the collector shall be disconnected and
locked out, see paragraphs 2.4 and 2.5. After electrical power is disconnected, the
fan wheel will continue to rotate for a period of time before coasting to a stop. Do
not access the fan until the fan wheel has come to a complete stop.
3GENERAL PRODUCT INFORMATION
3.1 Description
The ArrestAll self-contained dust collector is a compact and efficient unit
designed to control intermittent, low to medium volume, dry, dust sources. It is
cleaned off-line, meaning that it cleans once the fan is turn off. The unit includes
an air mover and can be relocated as required.
Each collector is furnished with fan assembly, housing, filter cartridge(s),
and an automatic shaker mechanism for filter cleaning. Based on size, they are

9
ArrestAll
© 2015 American Air Filter Company, Inc. Any use of the text or images
this document contains, without permission of American Air Filter
Company, Inc., is prohibited. ArrestAll, AAF, REDClean, REDFiltration,
and Reliable Efficient Durable are registered trademarks of American Air
Filter Company, Inc. d/b/a AAF International.
available as a bin vent, flat bottom, cart bottom, and funnel bottom arrangements.
The size range is from 1,000 to 12,000 ACFM.
3.2 Purpose and intended use
The ArrestAll is intended for intermittent dust collection and is best suited for
dry free flowing dusts. Examples of such applications would be woodworking
shops, small sanding booths, cement, clay, etc. It is not intended for dust
collection that is continuous, heavy dust loads, or for small particulate.
3.3 Normal Operation
Dust laden air is drawn into the inlet where it turns vertically 90 degrees,
causing the heavier particles to fall into the collection container below. The fine
particles are drawn to the fabric pockets and trapped on the surface, forming a
dust cake which increases efficiency. The clean air flows from the pockets into the
fan and is discharged. The collected dust is periodically removed from the fabric
pockets by an automatic shaker system.
3.4 Sizes
There are 12 unique ArrestAll sizes, ranging from an AR1-3 through an AR6-
25. The first number in the name designation is the number of filters in the unit,
the second number is the fan horsepower. This means an AR4-20 has 4 filters and
a 20HP fan.
The standard funnel bottom design is available on all unit sizes, as is the bin
vent design. The Dust Drawer design is only available on the AR1-3 as a standard
design. The Dust Cart is only available on the AR1-3 through the AR3-15L as a
standard design.
The following page is the fan performance curve for each size unit. Contact
AAF International for assistance in sizing the right ArrestAll for your application.

10
ArrestAll
© 2015 American Air Filter Company, Inc. Any use of the text or images
this document contains, without permission of American Air Filter
Company, Inc., is prohibited. ArrestAll, AAF, REDClean, REDFiltration,
and Reliable Efficient Durable are registered trademarks of American Air
Filter Company, Inc. d/b/a AAF International.
*15L and 15H are both 15HP fan motors but have different wheel widths

11
ArrestAll
© 2015 American Air Filter Company, Inc. Any use of the text or images
this document contains, without permission of American Air Filter
Company, Inc., is prohibited. ArrestAll, AAF, REDClean, REDFiltration,
and Reliable Efficient Durable are registered trademarks of American Air
Filter Company, Inc. d/b/a AAF International.
3.5 Filter elements
The ArrestAll filter has been designed to maximize airflow and efficiency. The
pocket and separator geometry minimizes differential pressure (see Figure 1). The
one-piece construction adds strength and sealing integrity to achieve up to 99+%
efficiency on general industrial dust by weight.
Figure 1. ArrestAll filter design
The ArrestAll filter design minimizes internal turbulence and differential
pressure. Air flows vertically inside the filter pockets, guided by the corrugated
spacers. This produces a laminar flow into the horizontal fan inlet cone.

12
ArrestAll
© 2015 American Air Filter Company, Inc. Any use of the text or images
this document contains, without permission of American Air Filter
Company, Inc., is prohibited. ArrestAll, AAF, REDClean, REDFiltration,
and Reliable Efficient Durable are registered trademarks of American Air
Filter Company, Inc. d/b/a AAF International.
3.6 Weights
Fan weight not included. See Sales Drawing for full weight.
Model Style* No. of
Cartridges
Approx. Weight
lb
kg
AR 1-3
FB
1
615
279
AR 1-3
BV
1
465
211
AR 1-3
DD
1
550
249
AR 1-3
DC
1
660
299
AR 2-5
FB
2
935
424
AR 2-5
BV
2
680
308
AR 2-5
DC
2
1020
463
AR 2-7.5
FB
2
990
449
AR 2-7.5
BV
2
735
333
AR 2-7.5
DC
2
1070
485
AR 2-10
FB
2
1000
454
AR 2-10
BV
2
745
338
AR 2-10
DC
2
1080
490
AR 3-10
FB
3
1250
567
AR 3-10
BV
3
800
363
AR 3-10
DC
3
1300
590
AR3-15
FB
3
1430
8986
AR3-15
BV
3
980
445
AR3-15
DC
3
1480
671
AR 4-10
FB
4
1400
635
AR 4-10
BV
4
1030
467
AR 4-15L
FB
4
1500
680
AR 4-15L
BV
4
1130
513
AR 4-15H
FB
4
1500
680
AR 4-15H
BV
4
1130
513
AR 4-20
FB
4
1530
694
AR 4-20
BV
4
1150
522
AR 6-20
FB
6
1960
889
AR 6-20
BV
6
1443
655
AR 6-25
FB
6
2070
939
AR 6-25
BV
6
1550
703
*Style = Funnel Bottom (FB), Bin Vent (BV), Dust Drawer (DD), Dust Cart (DC)

13
ArrestAll
© 2015 American Air Filter Company, Inc. Any use of the text or images
this document contains, without permission of American Air Filter
Company, Inc., is prohibited. ArrestAll, AAF, REDClean, REDFiltration,
and Reliable Efficient Durable are registered trademarks of American Air
Filter Company, Inc. d/b/a AAF International.
4PRODUCT SHIPMENT
4.1 How the product ships
The AR ArrestAll collector is packaged for domestic transit and shipped FOB
factory. The AR ArrestAll funnel bottom units are shipped as three major
components: the fan, the funnel bottom section, and the cartridge housing
section. The bin vent, cart bottom, and the dust drawer units ship as two major
components: the fan and the complete housing assembly.
4.2 Items that ship separately
To save the customer money, AAF International may ship items separately.
The customer will be notified which equipment ships separately when the order is
placed. Items that ship separately should be set aside in an area that is clean, dry,
and in a place where damage to the equipment will not occur.
5PRODUCT RECEIPT AT THE DESIGNATED DELIVERY POINT
5.1 Responsibilities of the customer or customer’s agent
Ensure all loading/unloading equipment and safety equipment is on site at
the time of delivery. Safe and efficient operation of the collector depends on
proper installation. Know proper laws, codes and regulations before installation
starts.
5.2 Receiving
Remove crates, tarps, shipping straps, etc. along with any loose items or
equipment before unloading the AAF ArrestAll.
5.3 Inspection on arrival
The AAF ArrestAll is normally shipped by truck and should be checked for
damage that may have occurred in route. Compare the collector(s) received to the
description and/or drawing of the collector(s) ordered. Immediately report any
differences or missing items from the order to AAF International. Remove loose
items or components before lifting the collector from the truck.
A qualified installation and service company should complete installation of
the collector and accessories.
5.4 Damaged goods
If there is any visible damage to the packaging or the equipment notify the
carrier and AAF before proceeding further and, if appropriate, file an immediate

14
ArrestAll
© 2015 American Air Filter Company, Inc. Any use of the text or images
this document contains, without permission of American Air Filter
Company, Inc., is prohibited. ArrestAll, AAF, REDClean, REDFiltration,
and Reliable Efficient Durable are registered trademarks of American Air
Filter Company, Inc. d/b/a AAF International.
claim with the carrier against such damage. Be aware that damage to packaging
may indicate hidden damage to the product that is not immediately discernable.
Digital color photographs must be taken of any damage to the packaging
and the equipment immediately on discovery. The nature of any damage must
also be documented in writing. Adequate documentation will be critical to support
any claims.
Contact AAF International for claim filing procedure.
5.5 Missing goods
Any missing goods should be noted on the delivery receipt, and the carrier
and AAF notified immediately. Contact AAF International for claim filing procedure.
6UNLOADING AND HANDLING
6.1 Unloading
Failure to lift the collector correctly can result in severe personal injury,
property damage, or even death.
-Use clevises, not hooks, on lifting sling.
-Use of spreader bars is recommended on all lifting slings.
-Check the drawings of the specific ArrestAll ordered for dimensions and
weights to ensure proper lifting and installation equipment.
-All units are shipped in an upright position. Lifting lugs are provided on
the cartridge section as well as the fan for ease of handling (Figure 2).
Spreader bars should be used on the housing. Fork truck handling should
be sufficient for the funnel section.
-All lifting operations must be made in compliance with the relevant HSE
legislation.

15
ArrestAll
© 2015 American Air Filter Company, Inc. Any use of the text or images
this document contains, without permission of American Air Filter
Company, Inc., is prohibited. ArrestAll, AAF, REDClean, REDFiltration,
and Reliable Efficient Durable are registered trademarks of American Air
Filter Company, Inc. d/b/a AAF International.
Figure 2. Lifting Lugs
7STORAGE AND PROTECTION
DO NOT store the ArrestAll dust collector outdoors prior to installation. Items
that ship separately should be set aside in an area that is clean, dry, and in a
place where damage to the equipment will not occur.
8SITE PREPARATION
8.1 Locating equipment
The dust collector site location must take into account the wind and seismic
loadings. See collector specifications to ensure proper site location.
Ensure local laws, codes and regulations are followed for the materials being
collected. Noise levels should be considered when selecting the proper location of
the ArrestAll.
Locate the ArrestAll in a location so that maintenance to the collector can be
handled easily. See collector drawing for cartridge clearance.
In the case of hazardous dust, consult your local authorities, laws, codes, or
regulations for the location of the unit. Unit location will be determined by system
design, space availability, and access requirements. Access to the front of the unit
is necessary for dust removal and cartridge replacement. Top access is required

16
ArrestAll
© 2015 American Air Filter Company, Inc. Any use of the text or images
this document contains, without permission of American Air Filter
Company, Inc., is prohibited. ArrestAll, AAF, REDClean, REDFiltration,
and Reliable Efficient Durable are registered trademarks of American Air
Filter Company, Inc. d/b/a AAF International.
for motor, fan, and ancillary component service. Side access is required for shaker
motor and control access.
Explosion vents, if furnished, are located on the side opposite the access
door. It is recommended per NFPA that the vent(s) be ducted outside and away
from any area containing personnel or equipment. Duct flanges can be match
drilled to the collector housing wall, but they must be supported separately from
the unit.
The unit can be located indoors or outdoors. Rain hoods are included in the
design of the ArrestAll to prevent water from gathering on the top of the door
gasket.
8.2 Foundations
The foundation must be level and adequate to support the collector’s
operating weight including dust load, discharge devices, wind load if applicable,
plus any auxiliary equipment if applicable.
8.3 Anchoring
The AR ArrestAll collector is designed for installation on a flat surface. Units
must be suitably anchored.
Anchor holes are provided at the base of the support legs on the funnel
bottom units (Figure 3), and anchor clips are provided on the cart bottom (Figure
4). Flat bottom units can be installed by drilling holes in the bottom of the units.
Holes drilled in the flat bottom base should be gasketed or caulked to prevent air
bypass.
Figure 3. Anchoring – Funnel Bottom
Figure 4. Anchoring – Cart Bottom

17
ArrestAll
© 2015 American Air Filter Company, Inc. Any use of the text or images
this document contains, without permission of American Air Filter
Company, Inc., is prohibited. ArrestAll, AAF, REDClean, REDFiltration,
and Reliable Efficient Durable are registered trademarks of American Air
Filter Company, Inc. d/b/a AAF International.
9ASSEMBLY AND INSTALLATION
9.1 Introduction
Safe and efficient operation of the ArrestAll depends on proper installation.
AAF recommends that the ductwork going into the collector be as straight as
possible, with at least 5 diameters of straight run recommended.
Authorities with jurisdiction should be consulted before installing the
ArrestAll to ensure local installation laws, codes, regulations and procedures are
followed.
A qualified installation and service agent must complete installation and
service of the dust collector and equipment.
Ensure all covers from shipping and loose materials are removed from the
collector before installation. Failure to do so can result in failure of the dust
collector.
Ensure the hardware on the dust collector assemblies are properly installed
and tight before installation.
9.2 Assembling and installing the structure
9.2.1 Funnel Bottom Units
Self-tapping screws and caulk are provided for installation of the funnel
bottom section to the cartridge section (Figure 5). Assemblies can be bolted-up
from the outside of the unit; interior access is not required. See the field
installation drawing for additional detail. The fan is bolted to the top of the unit
using the provided hardware. Fan discharge orientation can be varied to suit
owner’s requirements. See the fan installation drawing for additional detail.

18
ArrestAll
© 2015 American Air Filter Company, Inc. Any use of the text or images
this document contains, without permission of American Air Filter
Company, Inc., is prohibited. ArrestAll, AAF, REDClean, REDFiltration,
and Reliable Efficient Durable are registered trademarks of American Air
Filter Company, Inc. d/b/a AAF International.
Figure 5. Funnel bottom Installation.
9.2.2 Flat and Cart Bottom Units
These units are fully assembled at the factory except for the fan. Fan
discharge orientation can be varied to suit owner’s requirements. See the fan
installation drawing for additional detail.
9.2.3 Bin Vent Units
To prevent possible damage to the unit from ponding water, it is
recommended that curbing be used on any bin vent installation (Figure 6).

19
ArrestAll
© 2015 American Air Filter Company, Inc. Any use of the text or images
this document contains, without permission of American Air Filter
Company, Inc., is prohibited. ArrestAll, AAF, REDClean, REDFiltration,
and Reliable Efficient Durable are registered trademarks of American Air
Filter Company, Inc. d/b/a AAF International.
Figure 6. Bin Vent Units
9.2.4 Installation of the filter elements
To change the primary filters, follow these steps:
1. Open cartridge access door. (Door may be lifted off for easier access.
2. Loosen the shaker comb adjustment bolt and pry apart the shaker comb locking
channel (Picture 1).
3. Release the cartridge locking levers (2 per cartridge) by pushing each
toward the center of the unit (Picture 2).

20
ArrestAll
© 2015 American Air Filter Company, Inc. Any use of the text or images
this document contains, without permission of American Air Filter
Company, Inc., is prohibited. ArrestAll, AAF, REDClean, REDFiltration,
and Reliable Efficient Durable are registered trademarks of American Air
Filter Company, Inc. d/b/a AAF International.
4. Remove the complete cartridge assembly from the unit (Picture 3).
5. Inspect gasket on septum for damage. It is recommended that the gasket
be replaced whenever new cartridges are installed. Glue the gasket to the
underside of the septum around the edges of the opening. The gasket
splice should be located to the front of the unit.
6. Remove the shaker comb, retainer, and insert assemblies from the old
cartridge assembly. Inspect for damage. Do not throw these items away.
You will need them to assemble the new cartridge.
7. Remove the old pocket assembly from the frame assembly. Discard the
old pocket assembly.
