AAG Bear MOT4001 Operating instructions
Programming Guide
IMPORTANT - PLEASE NOTE:
All Bear awning motors require isolation during installation and for
subsequent servicing. It is highly recommended that each awning is fitted
with a 3-pin plug and connected to an external GPO or similar accessible
isolation point. Hard wiring is to be avoided where possible.
August 2019
Rev D 2
TABLE OF CONTENTS PAGE #
1.0 Scope 2
2.0 General Specifications 2
3.0 Remote & Motion Sensor Configurations (inc. P2 location) 3
4.0 Blind Types 6
5.0 Set Upper and Lower Blind Limits on Motor 6
6.0 Pair Remote with Motor 7
7.0 Set Solar Sun & Wind Sensor 7
8.0 Set the Number of Channels on Remote 7
9.0 Adding a Remote/Channel 8
10.0 Solar Sun & Wind Sensor Display 8
11.0 Adding Connector Hub (Bridge) 9
1.0 Scope:
This specification relates to the Bear Motors and their respective accessories to provide operation remotely.
The following pages provide images and flow charts to aid in setting up various requirements for Bear
Remotes, RTS Wall Switches, Solar Sun & Wind Sensor, Motion Sensor and Connector Hub.
2.0 General Specifications:
Code
Description
Application
MOT4001
Bear 20/26 RTS Motor
Suits awning type- eZip, Vertishade, Straight Drop
MOT4002
Bear 40/15 RTS Manual Override Motor
Suits FAA up to 6 metre width
MOT4003
Bear 80/15 RTS Motor
Suits FAA over 6 metre width
MOT4004
Bear 1 Channel Remote
Suits single awning
MOT4014
Bear 1 Channel Remote (2016)
Suits single awning
MOT4024
Bear 1 Channel Remote (2018)
Suits single awning
MOT4006
Bear 15 Channel Remote
Suits multiple awnings up to 15 (can be operated
individually or altogether
MOT4016
Bear 15 Channel Remote (2016)
Suits multiple awnings up to 15 (can be operated
individually or altogether
MOT4026
Bear 15 Channel Remote (2018)
Suits multiple awnings up to 15 (can be operated
individually or altogether
MOT4007
Bear RTS Wall Switch 1 Channel
Wall mounted suits single awning
MOT4017
Bear RTS Wall Switch 1 Channel (2016)
Wall mounted suits single awning
MOT4009
Bear RTS Wall Switch 15 Channel (2016)
Wall mounted suits multiple awnings up to 15 (can
be operated individually or altogether
MOT4029
Bear RTS Wall Switch 15 Channel (2018)
Wall mounted suits multiple awnings up to 15 (can
be operated individually or altogether
MOT4008
Bear Sun & Wind Sensor
Solar Powered, programmed via remote
MOT4018
Bear Motion Sensor
Suits FAA, battery powered RTS
MOT4058
Bear Connector Hub
Awning control via APP, 2.4GHz Wifi required
Bear Motor
Product Specification
Rev D 3
3.0 Remote Configurations:The images below demonstrate where the important function buttons are for each
style of remote. Including Up/Down/Stop/P1/P2.
OLD STYLE REMOTE (PRE 2016)
NEW STYLE REMOTE 2016
Rev D 4
NEW STYLE REMOTE 2018
RTS WALL SWITCHES OLD & NEW STYLE 2016/2018
NOTE: All motors are to be wired with individual wall switches. When a new remote, e.g. 15 channel remote,
is to be set to the motor that specific motor will need to be powered OFF and ON.
Rev D 5
MOTION SENSOR 2019
PAIRING INSTRUCTIONS
Step 1: Awning power should be ON. If remote is multi-channel, select channel and extend awning.
Step 2: Slide Motion Sensor cover off, install batteries and check Dial Switch is set to ‘0’ (zero).
Step 3: Within 5seconds press the Multi-Function button (sensor will beep once, motor 6 times). On paired
remote, press P2 twice.
Step 4. Rotate Dial Switch to ‘5’. Press Multi-Function button. Awning should retract.
Step 5: Rotate Dial Switch to ‘9’. Press Multi-Function button. Awning should extend.
Step 6: Set sensitivity. ‘1’ = Most Sensitive, ‘9’ = Least Sensitive. (Suggest starting with ‘2’).
Step 7: Install sensor backing plate onto inside of the awning front rail. Check “UP” arrow direction first.
Step 8: Install sensor to backing plate. (NOTE: awning may retract when clicked into place, so be ready to
stop with remote if required).
Step 9: Check sensitivity by shaking the awning front rail to simulate wind. Fine tune by adjusting Dial
Switch. (NOTE: when triggered, sensor will attempt to retract awning 3x times within approx. 5
seconds. User can stop with remote. Sensor will become active again after 45 seconds).
Rev D 6
4.0 Blind Types
5.0 Set Upper & Lower Blind Limits
Rev D 7
6.0 Pair Remote with Motor
7.0 Set Solar Sun & Wind Sensor
8.0 Set Number of Channels for Remote
(Up to fifteen channels are available on a Multi-Channel Remote. This instruction hides the unused channels.
The hidden channels can be shown again by changing the number of channels).
Rev D 8
9.0 Adding a Remote/Channel
10.0 Solar Sun & Wind Sensor Settings
10.2 Wind
10.1 Illumination
It is recommended that this function is disabled. Set to ‘0’ (zero).
Awning should not be operating unattended.
Rev D 9
11.0 Adding a Connector Hub (Bridge)
11.1 Plug in Connector Hub (Bridge) to power using a USB Charger (NOT SUPPLIED). You can plug into
your computer; however, the Hub will not work when the computer is OFF.
11.2 If you have a QR Reader already installed on your phone, go to step 11.3. If not, install a free QR
Reader App on your Phone/iPad (if one is not already installed – find in the Apple App Store or
Android Play Store). This app will be able to read the QR Code. OR search directly for the App which
is called “Connector” – Motor that Talks Back
11.3 In the box find the Quick Start Guide and use the QR Reader App to scan the relevant Apple or
Android QR Code. This will take you to the App store.
Rev D 10
11.3 continued…
Install the Connector App onto your phone/iPad.
11.4 Now you can scan Step 2 on the Quick Start Guide which will open a link to You Tube with further
video instructions or follow the below steps.
11.4a Create an account
https://www.youtube.com/watch?v=0wSZBWld7KM
11.4b Once signed in go to the Connector app go to Location and add a name
Rev D 12
11.4f Add New Device via Remote into your chosen room
https://www.youtube.com/watch?v=mdxx8mYC60c
11.4g Click on the added Device and you can now Open and Close the blind via your phone.
Share the settings on your phone with other people, by going to Location/Settings and “Add New
Guest”. The person you wish to share with also needs to install the Connector App and create an
account.
11.4h You can also add Timers to open/close the blind at select times of the day/night.
11.4i You can also connect with Google Assistant https://www.youtube.com/watch?v=ReInHRGYtoE
Google Home https://www.youtube.com/watch?v=42AWeNGXPGo
Amazon Alexa (https://www.youtube.com/watch?v=R-mfXrCeKhY
Siri https://www.youtube.com/watch?v=T4wuwZVYUxQ
