A&A Tech EMS DAQ R02.01 Installation instructions

Operators and Maintenance Manual
Measuring module EMS DAQ R02.01
Page
1/18
Copyright:
Auto & Aero Technologies Sp. z o.o.
Mazowiecka 10/5, 20-723 Lublin, Poland
■email: [email protected] ■www.aatech.pl
Operators and Maintenance Manual
Measuring module
EMS DAQ R02.01
Rev. 01 –May 2017

Operators and Maintenance Manual
Measuring module EMS DAQ R02.01
Page
2/18
Copyright:
Auto & Aero Technologies Sp. z o.o.
Mazowiecka 10/5, 20-723 Lublin, Poland
■email: [email protected] ■www.aatech.pl
Table of Contents
Introduction ..................................................................................................3
1. General information ..............................................................................5
2. Handling in transport and storage ........................................................6
3. Installation.............................................................................................6
3.1. Environmental specifications.......................................................6
3.2. Dimensions ..................................................................................7
3.3. Mounting .....................................................................................7
3.4. Power and wiring .........................................................................7
4. Operation and maintenance ...............................................................10
4.1. Measured signals .............................................................................10
4.2. Signal analysis ..................................................................................10
4.3. Additional functionalities...........................................................13
4.4. Readout of module records .......................................................13
5. Service, diagnostics and repairs ..........................................................14
5.1. Service life..................................................................................14
5.2. Checks ........................................................................................14
5.3. Cleaning and conservation.........................................................14
5.4. Troubleshooting.........................................................................15
5.5. Repairs .......................................................................................15
5.6. Re-programming ........................................................................16
5.7. Spare parts.................................................................................16
6. Warranty .............................................................................................16

Operators and Maintenance Manual
Measuring module EMS DAQ R02.01
Page
3/18
Copyright:
Auto & Aero Technologies Sp. z o.o.
Mazowiecka 10/5, 20-723 Lublin, Poland
■email: [email protected] ■www.aatech.pl
Introduction
This engine monitoring module EMS DAQ R02.01 is intended for ultralight,
microlight, homebuilt and experimental aircraft. This module is not
certified by the FAA and EASA. Fitting of this module to a certified aircraft
is subject to the rules and conditions pertaining to such in your country.
Please check with your local aviation authorities if in doubt.
This engine monitoring module EMS DAQ R02.01 is an element of the
Integrated Avionics System that measures the following engine operation
parameters:
a) Engine speed;
b) Rotor speed;
c) Inlet air pressure;
d) Inlet air temperature;
e) Oil pressure;
f) Oil temperature;
g) Cylinder head temperature;
h) Exhaust gases temperature;
i) Fuel level;
j) Pitch and roll trim position.
The purpose of EMS DAQ R02.01 type measuring module is to collect input,
analyse it in terms of threshold levels, and record selected information.
Measured values are communicated to the pilot by means of the following
displays type EEM MOT 01 FE….
Functionalities of the module include:
a) analysing and recording instances of crossing thresholds of
operating parameters,
b) providing records and statistics on how often, to what extent and
for how long parameter values were outside the desired range;

Operators and Maintenance Manual
Measuring module EMS DAQ R02.01
Page
4/18
Copyright:
Auto & Aero Technologies Sp. z o.o.
Mazowiecka 10/5, 20-723 Lublin, Poland
■email: [email protected] ■www.aatech.pl
c) recording flight time: from last engine start, and the total engine
operation time (HOOBS).
The module is designed to work with ROTAX 912 UL, 912 ULS and 914
engines. A list of signals processed by the module together with sensor
types is presented in Table 1.
Tab. 1 Sensors providing input for EMS DAQ R02.01 Module
No.
Parameter
Sensor
1
Engine speed
BRP TRIGGER COIL KIT
264087 1
2
Rotor speed
Autonics PR08-1.5DN
3
Inlet air pressure
Bosch 0 281 002 976
4
Oil pressure
BRP 456180 1
5
Oil temperature
BRP TEMPERATURE
SENSOR 965531 1
6
Cylinder head
temperature
BRP TEMPERATURE
SENSOR 965531 1(2
sensors)
7
Exhaust gases
temperature
BPR THERMO COUPLE
NICR-NI K 966370 1 (2
sensors)
8
Inlet air
temperature
Bosch 0 281 002 976
9
Fuel level
Vdo 224-011-020-372g
10
Trim pitch and roll
Signal from actuator
Linak La 12
1 Standard sensor for ROTAX engine
The module’s casing made of black ABS is splash-proof. Cables connecting
sensors with printed circuit board of the device enter the casing via screw
connection terminal blocks. The opening is sealed by means of sealing
foam tape pasted to both parts of the casing.
Hardware identification plates are located in the front of the casing (Fig. 1)
and inside (on circuit board).

Operators and Maintenance Manual
Measuring module EMS DAQ R02.01
Page
5/18
Copyright:
Auto & Aero Technologies Sp. z o.o.
Mazowiecka 10/5, 20-723 Lublin, Poland
■email: [email protected] ■www.aatech.pl
Fig. 1. EMS DAQ R02.01 module (complete casing and casing with lid removed)
1. General information
This manual contains binding information, guidelines and warnings for safe
handling and maintenance of this particular instrument before installation,
during installation and in its operating phase. This document does not
contain rules and guidelines on operation of aircraft instruments at large.
Read the manual thoroughly before turning on the instrument and
precisely follow the instructions to install and configure it. This manual
does not replace instructions on installation, maintenance and operation
of this device in a particular airframe - these are to be prepared by the
user. Instructing the pilots and maintenance personnel on operation of the
instrument is also the responsibility of the user.
Operation of this device is the sole responsibility of the pilot in command
(PIC) of the aircraft. This person must be proficient and carry a valid and
relevant pilot’s license. This person has to make themselves familiar with
the operation of this module and the effect of any possible failure or
malfunction. Under no circumstances does the manufacturer condone
usage of this instrument for IFR flights.
This manual defines the scope of maintenance measures the user is
authorised to conduct on their own. Any repairs or modifications outside
this scope conducted by the user or contracted to a third party, as well as

Operators and Maintenance Manual
Measuring module EMS DAQ R02.01
Page
6/18
Copyright:
Auto & Aero Technologies Sp. z o.o.
Mazowiecka 10/5, 20-723 Lublin, Poland
■email: [email protected] ■www.aatech.pl
using non-original parts and subassemblies voids the warranty, relieves the
supplier from any liability, making the device lose the status of the product
of Auto & Aero Technologies Sp. z o.o. with all the resulting consequences.
2. Handling in transport and storage
1. The EMS DAQ R02.01 module is bubble-wrapped to protect it
against vibration and other physical damage, and packed in a
cardboard box together with the warranty card.
2. The display must be stored and transported assuring that:
othe ambient temperature stays in the range of 10 40°C
othe ambient relative humidity stays in the range of 1090 %,
safe from condensation.
3. The display should be protected from water.
3. Installation
3.1. Environmental specifications
The EMS DAQ R02.01 module has been designed to be installed in engine
compartment of ultralight aircrafts of ceiling not exceeding 3 000 m
(10 000 ft). Acceptable ranges of operating parameters are listed below:
Operating temperature: -20 oC 50 oC
Short-term operating temperature: -25 oC 60 oC
Humidity: 0 95 %, no condensation;
Ambient air pressure: 45 105 kPa;
Vibrations: <5 g at frequencies below 150 Hz;

Operators and Maintenance Manual
Measuring module EMS DAQ R02.01
Page
7/18
Copyright:
Auto & Aero Technologies Sp. z o.o.
Mazowiecka 10/5, 20-723 Lublin, Poland
■email: [email protected] ■www.aatech.pl
3.2. Dimensions
Outline dimensions of the device are: 80 x 120 x 28 mm (width x height x
depth), Weight: 160 g.
Fig. 2. EMS DAQ R02.01 module outline drawing
3.3. Mounting
The EMS DAQ R02.01 Module should be installed vertically using mounting
holes (shown in Figure 2). The module should be located in a part of the
engine compartment sheltered from splashes of water of other liquids, as
close as possible to sensors and the battery.
3.4. Power and wiring
The EMS DAQ R02.01 module is powered from the aircraft power system.
Power specifications: nominal supply voltage 12V, acceptable supply
voltage range 8 ÷ 30V, current < 80mA.

Operators and Maintenance Manual
Measuring module EMS DAQ R02.01
Page
8/18
Copyright:
Auto & Aero Technologies Sp. z o.o.
Mazowiecka 10/5, 20-723 Lublin, Poland
■email: [email protected] ■www.aatech.pl
The module is connected to the system by means of screw connection
terminal blocks attached to printed circuit plate inside the casing. A
schematic diagram of the connection is shown in Figure 3.
The power supply requires 0.75 mm2wires.
Sensor connection requires 0.5 mm2wires.
Thermocouple wires should be attached directly to the module’s
connector.
Data bus (RS0, RS1, RS2) requires twisted pair wires (2 x 0.5mm2) according
to DIN VDE 0814. Twisting should continue to the pins of the connector.
Power grounding to the battery clamp by means of a cable as short as
possible (no longer than 0.5m).
Power, sensor and data bus wires are to be connected to the device with
the lid removed, and placed with care so that the sealing tape of the lid
and the case fit tightly.

Operators and Maintenance Manual
Measuring module EMS DAQ R02.01
Page
9/18
Copyright:
Auto & Aero Technologies Sp. z o.o.
Mazowiecka 10/5, 20-723 Lublin, Poland
■email: [email protected] ■www.aatech.pl
Fig. 1 EMS DAQ R02.01 Module connections

Operators and Maintenance Manual
Measuring module EMS DAQ R02.01
Page
10/18
Copyright:
Auto & Aero Technologies Sp. z o.o.
Mazowiecka 10/5, 20-723 Lublin, Poland
■email: [email protected] ■www.aatech.pl
4. Operation and maintenance
The module is to be connected to EEM MOT 01 FE… displays by RS485
(line RS0) and AUX AVS 01 module (line RS1) and diagnostic connector
(line RS03).
4.1. Measured signals
The type and value range of signals measures by the Module are listed in
Table 2.
Tab. 2 Signals processed by EMS DAQ R02.01 Module
No.
Parameter
Measurement range
Accuracy
1
Engine speed
0 6500 rpm
± 10 rpm
2
Rotor speed
0 500 rpm
± 1 rpm
3
Inlet air temperature
0,3 4 bar abs.
± 0,1 bar
4
Oil pressure
0 10 bar
± 0,1 bar
5
Oil temperature
-20 200°C
± 2°C
6
Cylinder head temperature
-20 200°C
± 2°C
7
Exhaust gases temperature
-50 950°C
± 5°C
8
Inlet air temperature
-20 200°C
± 2°C
9
Fuel level
10 120 l
± 1 l
10
Trim pitch and roll
0 10 V
± 0,1V
11
Flight time
± 1 s
12
Total engine running time (HOOBS)
± 1 min
4.2. Signal analysis
The EMS DAQ R02.01 Module analyses and records instances and duration
of the signals’ exceeding threshold values for selected engine parameters

Operators and Maintenance Manual
Measuring module EMS DAQ R02.01
Page
11/18
Copyright:
Auto & Aero Technologies Sp. z o.o.
Mazowiecka 10/5, 20-723 Lublin, Poland
■email: [email protected] ■www.aatech.pl
listed in Table 3. The records of threshold crossing contain the following
information:
a) Type of occurrence;
b) Number of occurrences of each type;
c) Moment of occurrence defined by the number of system’s starts from
the fact of installing the system until the occurrence, total operation
time of the system from its last start until the occurrence, and total
engine operation time (HOOBS) until the occurrence.
Tab. 3 Types of threshold crossings recorded by EMS DAQ R02.01 Module
No.
Signal
Threshold levels
1
Engine speed
> 5500 rpm, if present for more than 5 min
2
Engine speed
> 5800 rpm
3
Rotor speed
> 450 rpm
4
Inlet air pressure
> 46 inHg
5
Oil pressure
< 1 bar, if engine speed greater than 900
RPM
6
Oil pressure
> 7 bar, if engine speed greater than 900
RPM
7
Oil temperature
> 130°C
8
Oil temperature
> 130°C, if present for more than 15 min
9
Oil temperature
> 150°C
10
Oil temperature
< 50°C, if rotor speed greater than 200
RPM
11
Cylinder head
temperature –sensor 1
> 110°C
12
Cylinder head
temperature –sensor 1
> 110°C, if present for more than 30 min
13
Cylinder head
temperature –sensor 1
> 120°C
14
Cylinder head
temperature –sensor 2
> 110°C
15
Cylinder head
temperature –sensor 2
> 110°C, if present for more than 30 min
16
Cylinder head
temperature –sensor 2
> 120°C

Operators and Maintenance Manual
Measuring module EMS DAQ R02.01
Page
12/18
Copyright:
Auto & Aero Technologies Sp. z o.o.
Mazowiecka 10/5, 20-723 Lublin, Poland
■email: [email protected] ■www.aatech.pl
The occurrences of threshold crossing are recorded separately according to
their type. The system remembers four last occurrences. Information on
them is downloadable by means of a diagnostic connector, a converter,
and a dedicated software. These logs (all or selected) can be cleared by the
supplier of the aircraft and by the user.
The EMS DAQ R02.01 Module analyses and records statistics of selected
parameters of engine and aircraft operation. These parameters are listed
in Table 4. For each parameter, four value ranges are defined. The module
records the following data:
a) Number of instances of a parameter entering a specific range,
b) Total duration of a parameter assuming values from a specific
range.
The data are recorded separately for each parameter and for each of four
value ranges. Information on the statistics is downloadable by means of a
diagnostic connector, a converter, and a dedicated software (not supplied
with the device). The statistical records (all or selected) can be cleared
from the module only by the supplier of the aircraft.
Tab. 4 Statistics of engine and aircraft operation parameters analysed and
recorded by EMS DAQ R02.01 Module.
No.
Signal
Thresholds of value ranges
I
II
III
IV
1
Engine speed (rpm)
from 5500
to 5600
from 5600
to 5700
from 5700
to 5800
above
5800
2
Rotor speed (rpm)
from 400
to 425
from 425
to 450
from 450
to 475
above
475
3
Inlet air pressure
(bar)
from 1,40
to 1,45
from 1,45
to 1,50
from 1,50
to 1,55
above
1,55
4
Inlet air
temperature (°C)
from 50
to 55
from 55
to 60
from 60
to 65
above
65
5
Oil pressure (bar) –
if engine speed
>900 rpm
from 0,0
to 1,0
from 1,0
to 2,5
from 5,0
to 7,0
above
7,0
6
Oil temperature (°C)
poniżej 0
from 0
from 20
from 40

Operators and Maintenance Manual
Measuring module EMS DAQ R02.01
Page
13/18
Copyright:
Auto & Aero Technologies Sp. z o.o.
Mazowiecka 10/5, 20-723 Lublin, Poland
■email: [email protected] ■www.aatech.pl
to 20
to 40
to 60
7
Oil temperature (°C)
(if rotor speed >
200 rpm)
poniżej 0
from 0
to 20
from 20
to 40
from 40
to 60
8
Cylinder head
temperature –
sensor 1 (°C)
from 100
to 110
from 110
to 120
from 120
to 130
above
130
9
Cylinder head
temperature –
sensor 1 (°C)
from 100
to 110
from 110
to 120
from 120
to 130
above
130
10
Cylinder head
temperature –
sensor 2 (°C)
from 850
to 875
from 875
to 900
from 900
to 925
above
925
11
Cylinder head
temperature –
sensor 2 (°C)
from 850
to 875
from 875
to 900
from 900
to 925
above
925
12
Linear acceleration
(g) 1
from 2
to 4
from 4
to 8
from 8
to 12
above
12
1if connected to AUX AVS 01
4.3.Additional functionalities
Connecting the module to AUX AVS 01 communication module enables the
system to analyse linear acceleration and to adjust brightness of EEM MOT
01 FE… monitor displays (digital data about brightness level send form AUX
AVS 01 to each monitors).
4.4.Readout of module records
To access records of engine and aircraft operating parameters, the EMS
DAQ R02.01 Module needs to be connected to data bus RS2 (Figure 3) by
means of RS485->USB converter. A software enabling data transmission
can be downloaded from www.aatech.pl.

Operators and Maintenance Manual
Measuring module EMS DAQ R02.01
Page
14/18
Copyright:
Auto & Aero Technologies Sp. z o.o.
Mazowiecka 10/5, 20-723 Lublin, Poland
■email: [email protected] ■www.aatech.pl
5. Service, diagnostics and repairs
5.1. Service life
a) TBO of the module is not defined.
b) In the case of failure or error, the module must not be used any
more.
5.2. Checks
The following checks are recommended:
1) At pre-flight check:
a. Turn on the power to check if operational (the EEM MOT 01
FE… monitors should display data);
2) After 100 hours of flight:
a. Check the instrument’s electric connections:
Remove the lid of the monitor casing;
Check if wires sit firmly in screw connection terminal
blocks,
Check for wire damage as frayed insulation;
Place wires flatly and in parallel in the case to avoid
overlapping at the exit from the casing,
Attach the lid.
b. Turn on the power on to check if operational (check if EEM
MOT 01 FE… monitors display data);
c. Read/download EMS DAQ R02.01 records.
5.3. Cleaning and conservation
The casing is to be buffed with water-damped soft cloth. Optionally, if very
dirty, can be cleaned with cloth sparingly damped with mild soap solution.
Caution: avoid spilling liquids over the device.

Operators and Maintenance Manual
Measuring module EMS DAQ R02.01
Page
15/18
Copyright:
Auto & Aero Technologies Sp. z o.o.
Mazowiecka 10/5, 20-723 Lublin, Poland
■email: [email protected] ■www.aatech.pl
5.4. Troubleshooting
a) If information is not displayed on some of the monitors (type FE…)
when power is applied (Fig. 8), check connection inside
measurement module. Check:
power connection; ensure that your power supply is
capable of supplying at least 8 volts, and no more than
30 V.
data bus connection (RS0);
Fig. 3. Indication of no connection to measurement module
a) If the system does not react to brightness adjustment, check
connection with AUX AVS 01 (RS1);
b) In the case of the module’s failure or malfunction, turn power off
and on again.
c) If the above does not solve the problem, the module needs to be
replaced.
d) A defective module must not be used.
5.5. Repairs
Repairs and inspections of the module can be conducted only by its
manufacturer.

Operators and Maintenance Manual
Measuring module EMS DAQ R02.01
Page
16/18
Copyright:
Auto & Aero Technologies Sp. z o.o.
Mazowiecka 10/5, 20-723 Lublin, Poland
■email: [email protected] ■www.aatech.pl
The module does not contain any user-serviceable parts. Unauthorized
repairs or modifications may result in permanent damage to the
equipment and void the warranty.
If the module fails, return the device to the Manufacturer with description
of the failure circumstances and symptoms.
5.6. Re-programming
Modifications to the module’s settings can be introduced by means of
service software provided by the Manufacturer and the dedicated
diagnostic interface.
The instrument’s firmware updates are to be conducted on the basis of the
bulletins published by the Manufacturer. The updates can be introduced
by means of service software provided by the Manufacturer and the
dedicated diagnostic interface.
5.7. Spare parts
The module does not contain any user-serviceable parts. The user is not
allowed to disassemble it nor replace any subassemblies.
6. Warranty
1. Auto & Aero Technologies Sp. z o.o. warrants this product to be free
from defects in materials and workmanship.
2. Auto & Aero Technologies Sp. z o.o. warrants proper operation of the
product if it is used in accordance with its intended purpose and in
accordance with the Operators and Maintenance Manual.
3. Auto & Aero Technologies Sp. z o.o. warrants this product for 12
months from date of purchase.
4. Auto & Aero Technologies Sp. z o.o. will, at its sole option, repair or
replace any components that fail in normal use. Such repairs or
replacement will be made at no charge to the customer for parts or

Operators and Maintenance Manual
Measuring module EMS DAQ R02.01
Page
17/18
Copyright:
Auto & Aero Technologies Sp. z o.o.
Mazowiecka 10/5, 20-723 Lublin, Poland
■email: [email protected] ■www.aatech.pl
labour. The customer is, however, responsible for any transportation
cost. The repair or replacement will be completed within 30 days from
delivery of the product to Auto & Aero Technologies Sp. z o.o.
However, if the failure is possible to be eliminated by means of
updating the product’s firmware, and if Auto & Aero Technologies Sp.
z o.o. provides the customer with appropriate service tools, the
Customer will conduct firmware update by themselves.
5. Any warranty repair will extend the warranty for the time of the
repair.
6. If a valid warranty claim is lodged within months 7 to 12 after date of
purchase, the warranty extends for a further 6 months after
completion of the warranty repair.
7. This warranty does not cover failures due to:
a) mechanical damages and damages resulting from them,
b) unauthorised repairs,
c) damage caused by abuse or misuse,
d) unauthorised alterations to hardware or software.
8. The warranty does not cover claims that arise from the product
parameters unless they are different from values declared by Auto &
Aero Technologies Sp. z o.o.
9. The warranty does not cover activities that belong to normal
operation such as cleaning and conservation, operation checks, and
periodic inspections according to the Operators and Maintenance
Manual.
10. The Customer loses all rights arising from the warranty if the product’s
protective seals are found to be tampered with.
11. The rejection of Auto & Aero Technologies Sp. z o.o. to conduct
a warranty repair voids the warranty.

Operators and Maintenance Manual
Measuring module EMS DAQ R02.01
Page
18/18
Copyright:
Auto & Aero Technologies Sp. z o.o.
Mazowiecka 10/5, 20-723 Lublin, Poland
■email: [email protected] ■www.aatech.pl
The information in this document is subject to change without notice and should
not be construed as commitment by Auto & Aero Technologies Sp. z o.o.
These technical data and the information embfromied therein are the property of
Auto & Aero Technologies Sp. z o.o., and shall not, without prior written permission
of Auto & Aero Technologies Sp. z o.o., be disclosed in whole or in part to third
parties. This statement shall be included on any reprfromuction of these data, in
whole or in part. The Manual must remain with the engine/aircraft in case of sale.
Copyright 2017 © - all rights reserved.
Other names in this documentation are used purely for ease of identification and
may be trademarks of the respective company or owner.
Approval of translation has been done to best knowledge and judgement - in any
case the original text in English language is authoritative.
