a&p instruments UX 3081 User manual

Operating instructions for moisture analysers
UX 3081
UX 3081WQ
a&p instruments, Kluckhofer Weg 61, D-32657 Lemgo, Tel.:[phone], Fax.: 977820
E-Mail: [e-mail], Internet: www.apinstruments.de Seite 1
2023
Basic information
Intended use
ULTRA X moisture analysers are solely designed to quickly measure moisture and dry matter in solid,
viscous and fluid substances using thermogravimetric analysis. A sample is weighed while being dried
by infra-red heat.
Common features for all ULTRA X devices:
Short measurement time, gentle and even drying of samples, high reproducibility
Automatic or time-controlled measurement shut-off
UX 3081/ 3081WQ
Special device for extra large samples,
e.g. in the chipboard industry
2 temperature-controlled ceramic heaters
Temperature range: 40 – 220 °C/ 300 °C
Stainless steel drying tray 240 x 110 mm
UX 3011/ 3011Q/ 3011HQ
Temperature-controlled infra-red heater 250 W/ 375 W
Temperature range: 40 – 200 °C/ 360 °C/600 °C
Stainless steel drying tray 111 mm diameter
UX 3031
Special device for gypsum industry
2 temperature-controlled heaters for separate measurement of
free and chemically bound moisture in gypsum products
Temperature range: 40 – 360 °C
Stainless steel drying tray 111 mm diameter

Operating instructions for moisture analysers
UX 3081
UX 3081WQ
a&p instruments, Kluckhofer Weg 61, D-32657 Lemgo, Tel.:[phone], Fax.: 977820
E-Mail: [e-mail], Internet: www.apinstruments.de Seite 2
Contents
Search term page
Accessories, supplied 4/6/ 14
Assigning a device ID 9
Automatic mode 7
Automatic shut-off 7
Buttons 6
Calibrating the scale 11
Care and maintenance 17
Changing the print ribbon 5
Communication 18
Consumables 14
Data interface 14
Date and time 10
Display 6
Error description and solution 16
Features 1
ID number 9
Installation site 4
Intended use 1
Interface description 14
Loading the printing paper 5
Maintenance and care 17
Measuring moisture 13
Menu 6/ 15
Menu lock 11
Menu settings 7
Packaging 4
Parameter setting 7
Ports 6
Printer options 9
Program memory 12
Safety instructions 3
Screen 6
Setting the measurement unit 8
Setting the temperature 7
Start-up 4
Technical data 18
Timer 8
Transport 4
Warranty 4

Operating instructions for moisture analysers
UX 3081
UX 3081WQ
a&p instruments, Kluckhofer Weg 61, D-32657 Lemgo, Tel.:[phone], Fax.: 977820
E-Mail: [e-mail], Internet: www.apinstruments.de Seite 3
Safety instructions
Always transport the device in an upright position
and protect it from impact.
Always operate the device on a
level surface, using a vibration-free base.
Avoid draughts.
Never touch the (luminous) heater when it is hot,
as there is a risk of injury!
Always disconnect the plug from the mains supply before
performing any work on the device (e.g. changing the heater)!
Repairs should only be carried out by a qualified technician.
Please take extra care when using flammable samples!
You may need to contact the manufacturer for advice.
Please be careful not to drop any sample particles
next to the tray support plate.
Carefully remove any particles with
a vacuum cleaner.
Only use accessories specifically designed for use with ULTRA X devices.
Do not move the device during measurement, as this will result in measuring errors.
Do not leave any substances in the measuring tray, if they are not being measured.
Devices should only be shipped in the original packaging using the original packaging material.
ULTRA X moisture analyzers are stand-alone units and are not designed to be used in continuous
production runs. Any such use is at your own risk.
!
!
!

Operating instructions for moisture analysers
UX 3081
UX 3081WQ
a&p instruments, Kluckhofer Weg 61, D-32657 Lemgo, Tel.:[phone], Fax.: 977820
E-Mail: [e-mail], Internet: www.apinstruments.de Seite 4
Warranty
a&p instruments undertakes to repair faulty devices within the warranty period, free-of-charge, if the defect is
a manufacturing fault. This warranty covers the repair of spare parts and working hours required. It does not
cover normal wear-and-tear and soiling and staining of the device. a&p instruments will not accept any
freight costs.
This warranty does not apply to:
improper use of the device,
use of the device for purposes other than those stated by a&p instruments,
mechanical damage or damage caused by fluids or sample matter,
incorrect set up or wrong electrical wiring,
mechanical damage of the load cell e.g. as a result of being overloaded
Transport, packaging, installation site
Please check the packaging and device for any damage upon delivery.
Please retain the original packaging in case you need to return the goods to a&p instruments.
Please only use the original packaging when returning the goods.
Accessories supplied:
Tray holder 2 trays Tray tongs Mains cable
Start-up
1. 1. Place the device on a stable, vibration-free surface, as level as possible and
protected from draughts. The most suitable locations are the corners of a room,
rooms with only one entrance and heavy tables on concrete floors.
Remove the protective film from the front foil.
1. 2. Swing the heater back until the resistance.
1. 3. Place the tray holder on the device:
First place the tray holder carefully on the two pins, the distance
between the housing and the tray holder should be approx. 1.5
– 2 mm. Do not exert to much power on the balance!
Then put on the shielding plate unit.
To remove the tray holder, first carefully lift up the
shielding plates and then carefully pull out the tray
holder in the middle with very slight tilting
movements, do not exert too much power!
3081
für 3081 2x
3081
!

Operating instructions for moisture analysers
UX 3081
UX 3081WQ
a&p instruments, Kluckhofer Weg 61, D-32657 Lemgo, Tel.:[phone], Fax.: 977820
E-Mail: [e-mail], Internet: www.apinstruments.de Seite 5
1. 4. Next place one of the two drying trays supplied on
the tray holder using one or two sets of tongs.
The notch in the reflector tray acts as an access
gap for easy positioning of the tray.
1. 5. Check that the voltage indicated on the type plate matches the local mains voltage.
1. 6. The power cable is inserted into the
device’s power jack and a suitable
earthed mains supply. After the power
supply has been connected, the
device can be switched on or off using
the on/ off button on the back of the device.
Once the device is switched on, the current
software version is shown, followed by the
weight display.
1. 7. In order to prevent weighing system measuring errors, the device should be switched on 20 minutes
before being used to allow for heat compensation. If weight values vary in the display’s milligram range
during this period, this is considered normal within this phase. If the device is switched off using the reset
(on/ off) button, it does not require a warm-up period, if switched on again with the same button.
1 8. ULTRA X moisture measuring devices are supplied, so that in most cases substances can be measured
immediately. If you are not satisfied with the result, the measurement parameters can be adjusted:
Printer
Open Cover: Change Paper Line feed
Hold the green glowing putton
and lift the plastic cover
The ULTRA X Thermo paper is stable for 10 years.

Operating instructions for moisture analysers
UX 3081
UX 3081WQ
a&p instruments, Kluckhofer Weg 61, D-32657 Lemgo, Tel.:[phone], Fax.: 977820
E-Mail: [e-mail], Internet: www.apinstruments.de Seite 6
Operation
Display and buttons
Tare button for setting the Button for accessing and percentage purity
weight readout back to zero scrolling through the menu only for UX 3031
Button for resetting the Button for accessing and programm memory
processor programme scrolling through the menu (otional)
Button for exiting menu Button for confirming entries residue on ignition
levels only for UX 3011G
Ports:
Menu
Menu settings
The device’s Preferences menu can be accessed using the ‘up’ or ‘down’ button.
In this instruction manual, it is assumed that the ‘down’ button follows the menu item sequence.
The menu is operated using a standard structure:
UP or DOWN Set parameters
SET Confirmation of menu level and if required, return to previous menu level
ESC Return to previous menu level and exit from menu
If you confirm a wrong entry with ‘set’, press ‘esc’ and ‘set’ to reselect and change the menu item.
temp. C°
mode
time
value (weight) unit
P1
P2
P3
off
on
up
T
set
down
esc
off
on
T
esc
up
set
down
P1
P2
P3
Factory settings
:
Temperature: 3081 3081WQ
40 – 200°C 105 – 360 °C
Automatic shut-off with parameters:
Weight loss 50 mg/ Query interval 45 secs / Start of query 5 mins
Buzzer switched on when measuring process is complete
down
reset
reset
Power supply
Print Conection
for separat Printer
Interface RS 232
USB-Interface
Power supply switch

Operating instructions for moisture analysers
UX 3081
UX 3081WQ
a&p instruments, Kluckhofer Weg 61, D-32657 Lemgo, Tel.:[phone], Fax.: 977820
E-Mail: [e-mail], Internet: www.apinstruments.de Seite 7
Temperature control
Value is stored
Value is stored
The temperature that is set on the device relates to
the thermal radiation that hits the sample to be dried.
The thermal radiation is an electromagnetic wave for
the transmission of energy. As this energy creates heat in the sample, the moisture evaporates from the
sample. The temperature is used to set the energy that allows the moisture to evaporates from the material
(more temperature is more energy).
The set temperature is not to be equated with the temperature to which the material or the environment heats
up.- The material or ambient temperature is a consequence of the drying process, not the cause of the drying.
Automatic shut-off or timer
The automatic mode dries the sample until a constant weight is reached and then switches off the heater.
The following settings
can be defined here:
1. Weight loss in mg
a value should be defined here which corresponds to approx. 0.1 % of the original sample e.g. original
sample 10 g = 10 mg
When the weight loss <= the mg weight specified here within the interval period defined below, the
measurement is completed, if at least the start of query time limit has expired.
2. Query interval in secs.
an interval should be selected here, so that the sample is not dried for too short a period but also not for
far too long. A period of 20 to 30 secs is normally adequate. None /10-99 secs can be selected.
set
down
up
set
down
up
esc
set
down
up
esc
down
set
set
set
set
down
up
set
esc
down
up
set
esc
down
esc
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
.
.
temp. C° time
mode value (weight) unit
.
.
temp. C° time
mode value (weight) unit
.
.
temp. C° time
mode value (weight) unit
.
.
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
!
!

Operating instructions for moisture analysers
UX 3081
UX 3081WQ
a&p instruments, Kluckhofer Weg 61, D-32657 Lemgo, Tel.:[phone], Fax.: 977820
E-Mail: [e-mail], Internet: www.apinstruments.de Seite 8
3. Start of query in minutes
Specify the drying period required for the samples without automatic mode. The factory-set 3 minutes
are usually adequate. This value should be increased for extremely low temperatures, so that the device
does not switch itself off prematurely. This affects the UX 3031 in particular, when free moisture is being
measured at 45°C. You can select 1-99 mins.
The timer setting is the same as described for the quartz heater.
It is possible to select a drying time of 1 – 180 mins
The automatic settings are the same as described for radiant heaters.
Measurement
unit
During measurement, the device optionally displays:
% moisture
% dry matter (TS) Example: 50 % moisture = 100 % Atro
% moisture Atro ( ), i.e. moisture related to the dry matter 25 % moisture = 33.3 % Atro
Dry matter (TS) in g/1000g 75 % moisture = 300 % Atro
Weight loss g (V)
Residual weight g (R) (current weight)
down
up
set
down
up
set
esc
esc
down
set
set
down
up
esc
set
down
up
set
esc
set
set
esc
down
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit mode value (weight ) unit
temp. C° time
mode value (weight) unit
temp. C° time
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit mode value (weight ) unit
temp. C° time
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit

Operating instructions for moisture analysers
UX 3081
UX 3081WQ
a&p instruments, Kluckhofer Weg 61, D-32657 Lemgo, Tel.:[phone], Fax.: 977820
E-Mail: [e-mail], Internet: www.apinstruments.de Seite 9
Printer options
For devices without a printer, the number of prints must be set to ‘1’!
to 9
It is possible to select no printout or every 10 – 99 secs.
Data output for external printer (other manufacturer)
Using line feed sends an additional LF via the interface (factory
setting without LF).
Device ID number
Enter a number up to 9999 to
identify the device
Each digit can be selected separately.
down
up
down
up
down
up
set
set
set
esc
down
set
esc
down
esc
set
down
up
set
esc
down
set
set
down
esc
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit

Operating instructions for moisture analysers
UX 3081
UX 3081WQ
a&p instruments, Kluckhofer Weg 61, D-32657 Lemgo, Tel.:[phone], Fax.: 977820
E-Mail: [e-mail], Internet: www.apinstruments.de Seite 10
Date and time
Use ‘up’/ ‘down’ to set the date and press ‘set’.
Use ‘up’/ ‘down’ to set the month and press ‘set’
Use ‘up’/ ‘down’ to set the year and press ‘set’
Use ‘up’/ ‘down’ to set the hour and press ‘set’
Use ‘up’/ ‘down’ to set the minutes and press ‘set’
The date and time are shown on the printout
Buzzer Use ‘up’/ ‘down’ and ‘set’
to activate or deactivate the buzzer, then press
. ‘set’ followed by ‘esc’.
Calibrating the scales
Tray carrier and tray must be on the balance!
Follow the menu instructions and use a F1 weight to calibrate the scales.
Tray being used
must be empty.
If the display shows switch the power switch off and on, and try it again.
The reason for this, please look at “potential errors” on page 15
down
set
down
up
set
set
temp. C° time
mode value (weight) unit
set
set
down
set
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
set
temp. C°
mode value (weight)
time
unit
temp. C° time
mode value (weight) unit
temp. C°
mode value (weight)
time
unit
temp. C° time
mode value (we ight) unit
temp. C° time
mode value (weight) unit
temp. C°
mode value (weight)
time
unit

Operating instructions for moisture analysers
UX 3081
UX 3081WQ
a&p instruments, Kluckhofer Weg 61, D-32657 Lemgo, Tel.:[phone], Fax.: 977820
E-Mail: [e-mail], Internet: www.apinstruments.de Seite 11
Language
The first two letters on the second line stand for Automatic (A) and Timer (T).
You can also lock the menu to prevent accidental changes to drying parameters.
The ‘CAL’ menu option can still be accessed when the menu is locked.
The menu can be locked or unlocked as shown below:
Press and hold the ‘set’ button for 5 secs:
Position Enter 5-digit 5x
Under scored pin etc.
oder
Position Enter 5-digit 5x
Under scored pin etc.
If you forget the PIN, you can obtain a new one from a&p instruments.
temp. C° time
mode value (weight) unit
set
up
down
set
set
up
down
set
set
down
up
set
esc
esc
mode value (weight) unit
temp. C° time
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
temp. C°
mode value (weight)
time
unit
temp. C° time
mode value ( weight) unit
temp. C°
mode value (weight)
time
unit
temp. C° time
mode value (weight) unit
set
set
time
mode value (weight) unit

Operating instructions for moisture analysers
UX 3081
UX 3081WQ
a&p instruments, Kluckhofer Weg 61, D-32657 Lemgo, Tel.:[phone], Fax.: 977820
E-Mail: [e-mail], Internet: www.apinstruments.de Seite 12
Saving drying parameters in the program memory
If your device has a program memory, appears in the top left of the display
"QP" for type UX3081 and UX3081WQ and a number of1-9.
depending on which heater the program memory was activated for from the manufacturer,
here for the infra-red heater.
time
mode value (weight) unit
UX 3081WQ
g0,000A
QP1
The standard parameters are set fom the manufacturer at the program memory place 1 .
The different drying parameters can be saved or be changed with button .
Drying parameters are: temperature and the parameters of the automatic or the timer. P2
mode value (weight) unit
UX 3081
g0,000A
QP2
P2 set
up
down
modemode value (weight)value (weight) unitunit
Memory
Menory
automatic 2automatic 1
Here you can choose between the 9 memory places.
Then the menu set the temperature, the weight loss, the query interval and the query start.
All other parameters and settings are not saved individually to the memory place.
set
set
set
set
set
set
set
set
set
set
1)
esc
1)
esc
1)
esc
up
down
up
down
up
down
up
down
down
down
down
down
down
time
time
time
time
time
mode
mode
mode
mode
mode
value (weight)
value (weight)
value (weight)
value (weight)
value (weight)
unit
unit
unit
unit
unit
Menu HP2
Menu HP2
Automatic
Automatic
Automatic
Temperature
Auto/Timer IR
Weight loss mg
Interval sec.
Start after min.
time
time
time
time
time
mode
mode
mode
mode
mode
value (weight)
value (weight)
value (weight)
value (weight)
value (weight)
Ceramikh.
200
Automatic
30 mg
20 s
10 min
Temperature
Auto/Timer IR
Weight loss mg
Interval sec.
Start after min.
unit
unit
unit
unit
unit
-
-C
4 x
Changes for the quartz heater to the unit of measurement, printer settings, data output, device ID, date and time,
Buzzer and language, same as temperature and the parameters of the automatic system affect all prog ram
memories at the same time.

Operating instructions for moisture analysers
UX 3081
UX 3081WQ
a&p instruments, Kluckhofer Weg 61, D-32657 Lemgo, Tel.:[phone], Fax.: 977820
E-Mail: [e-mail], Internet: www.apinstruments.de Seite 13
Moisture analysis process
The device should be connected to the mains supply and switched on with a drying tray. A weight value is
displayed.
Set scales to zero using the ‘tare’ button,
display ‘0.000 g’.
Evenly distribute approx. 50 - 200 g
sample matter in the tray and wait
for the readout to stop.
1.
2. Swing the heater over the sample, switch on the
heater switch and the drying phase begins.
Header data is now printed for devices with a built-in
printer. The sample is dried until it has reached a
constant weight; the heater then switches off
automatically. The time and measurement value is
printed for devices with a printer.
If you do not wish to make any measurements,
please always ensure that the heater is swung back
to its rearmost position!
3. Measurement values are displayed for the entire length of timethe heater is positioned above the sample.
The device should not be moved from its position during measurement, as this causes measurement errors.
The external printer prints the following
at the start of the measurement:
Model, device ID,
date, time,
heater temperature,
timer or shut-off parameters, initial weight.
And after the device has finished measuring, once the
heater has been swung back to its rearmost position:
Measurement value,
measurement time,
substance,
initials
Please ensure drying trays have cooled down before using for measurement.
If the measurement ends before
it is complete,
the display shows: to sample weight.
For substances which are difficult to remove from the
tray after being dried, we recommend using foil trays,
which can be made quickly and economically from
aluminum foil using the ULTRA X foil press.
esc
glow if
heater is on
flashes if
measurement
ends
LED´s are off
if switch „off“
red
green
!
time
mode value (weight) unit
time
mode value (weight) unit

Operating instructions for moisture analysers
UX 3081
UX 3081WQ
a&p instruments, Kluckhofer Weg 61, D-32657 Lemgo, Tel.:[phone], Fax.: 977820
E-Mail: [e-mail], Internet: www.apinstruments.de Seite 14
Data interface
Weighing data, temperature and drying data are also shown on the display via a standard USB flash drive and
serial interface.
Depending on the model, a separate UX 3092 printer or a computer can be connected to the device.
Interface description
Model: V24 RS 232 serial data transmission and USB flash drive
Transmission rate: 9600 baud
Number of bits 8 data bits
1 stop bit
Parity check none
Handshake none
Data transmission using a USB flash drive
If the computer receiving the data has an internet connection, the system automatically installs a driver
and creates a COM interface, as soon as the computer is connected to the moisture analyser.
If this is not the case, the driver must be manually installed in the device manager.
Special software is required for transmitting data to a PC:
ULTRA X DataBridge
Data can be exported in four different data formats: . xls; .PDF.
The software is extremely easy to install and use:
Connect devices, place CD in PC, the installation is self-explanatory.
Accessories: Order no.: Application:
Stainless-steel drying tray 10000282 Sample containers (supplied)
Tray tongs 10000230 for lifting the tray ( 2supplied)
Mains cable H1000190 Mains connection (supplied)
Consumables:
Printing paper 58 mm 10000234 for printer
Aluminum foils 260 x 130 H1000013 to protect the drying tray
Foil press 230 x 110 10000063 to forming the aluminum foils
Spare Parts:
Ceramic heater 250W 10000405 for 3081
Ceramic heater 400W 10000318 for 2081WQ
1 2 3 4 5
5 4 3 2 1
6 7 8 9
9 8 7 6
Data cable
Moisture balance - DataChannel
ca. 2 m

Operating instructions for moisture analysers
UX 3081
UX 3081WQ
a&p instruments, Kluckhofer Weg 61, D-32657 Lemgo, Tel.:[phone], Fax.: 977820
E-Mail: [e-mail], Internet: www.apinstruments.de Seite 15
Overview of menu setup via the UP button
M e n u
Menu language
Language, GERMAN
Menu CAL
„ Calibrate? Set or esc“ <set>
„If scales are empty, press set!“ <set>“
„Please wait“; „Add 500 g weight, press set“ <set>
„Please wait“; „Remove 500g weight, then wait“
„CAL completed! Press set“ <set>
Menu buzzer
Buzzer activated / deactivated
Menu date + time
Date. Day . Month . Year Time Hours : Minutes
Menü ID
Device ID 9999
Device ID, 0000
Menu data output
Data output, without LF / with LF
Menu printer
Printer, Number of print copies
Number of print copies, _ Print copies
Printer, Interval
Printout, every __ secs
Menu Measurement unit
Measurement unit, moisture
Menu Auto/ Timer
Auto/ Timer quartz, Automatic mode
Automatic mode, weight loss mg
weight loss mg, __ mg
Automatic mode, Interval secs
Interval secs, __ secs
Automatic mode, Start mins
Start mins, __ mins
Auto/ Timer radiant heater, Timer
Auto/ Timer radiant heater, __ mins
Menu Temperature
Temperature, Ceramic heater

Operating instructions for moisture analysers
UX 3081
UX 3081WQ
a&p instruments, Kluckhofer Weg 61, D-32657 Lemgo, Tel.:[phone], Fax.: 977820
E-Mail: [e-mail], Internet: www.apinstruments.de Seite 16
Potential errors
Error
Reason
Solution
Display
Display blank: Initial load too small or large,
Tray support and / or tray missing
Place empty drying dray on centre of
tray support,
Location with too much disturbance Place on a vibration-free surface
Draught Protect from draughts
Area around tray support is dirty
Carefully clean area around tray support
Scale is faulty Contact a&p instruments
Scale without power Contact a&p instruments
Scale is not connected to control card Contact a&p instruments
Scale is faulty Contact a&p instruments
Scale continuing to run: Location with too much disturbance Place on a vibration-free surface
Draught Protect from draughts
Area around tray holder is dirty Carefully clean area around tray holder
Scale is faulty Contact a&p instruments
Menu
Drying parameters cannot be
entered, only
Menu is locked Unlock menu lock,
contact the person responsible or
a&p instruments
Menu lock cannot be
unlocked
5-digit pin for unlocking menu lock is
incorrect
Contact a&p instruments at
[e-mail]
Scale
Scale cannot be tared Weight within minus range Switch off device, place empty tray on
balance and switch on again
Weight difference less than 16 mg
or more than 16 mg
Less than 16 mg set to zero, press
button briefly
More than 16 mg tare, press and hold
Scale cannot be calibrated: Initial load
too small or large, tray holder
and / or tray missing.
Place empty drying dray on centre of
tray holder,
Location with too much disturbance Place on a vibration-free surface
Draught Protect from draughts
Area around tray holder is dirty Carefully clean area around tray holder
Scale setting is incorrect Contact a&p instruments
Scale is faulty Contact a&p instruments
System error
Calibration process has stopped
Disconnect device from mains
and switch
on again.
temp. C° time
mode value (weight) unit
temp. C° time
mode value (weight) unit
time
mode value (weight) unit
time
mode value (weight) unit

Operating instructions for moisture analysers
UX 3081
UX 3081WQ
a&p instruments, Kluckhofer Weg 61, D-32657 Lemgo, Tel.:[phone], Fax.: 977820
E-Mail: [e-mail], Internet: www.apinstruments.de Seite 17
Error
Reason
Solution
M
easuring
Heater will not switch on: Heater is faulty Change heater
Temperature sensor is faulty Contact a&p instruments
Infrared heater will not
switch off
S202S01 relay is faulty Contact a&p instruments
Automatic shut-off is set incorrectly Check shut-off settings
Timer is set incorrectly Check timer settings
Measurement not completing:
Shut-off settings incorrect Check shut-off settings
Timer settings incorrect
Printer
No printout Printer is faulty or Contact a&p instruments
no data transmission Contact a&p instruments
No linefeed Linefeed button or printer is faulty Contact a&p instruments
No connection to printer Contact a&p instruments
Printout invisible No thermal paper Use the thermal paper from a&p
Printing unit or printer board is faulty Contact a&p instruments
Printout too light Printing unit is dirty Contact a&p instruments
Care and maintenance
Please ensure that no pollutants enter the device.
Always keep the area around the tray holder clean.
Do not use compressed air to clean the device.
Do not overload the scales, max. 400 g.
Protect device from moisture and impact.
For ideal care and maintenance, we recommend taking out a service contract.

Operating instructions for moisture analysers
UX 3081
UX 3081WQ
a&p instruments, Kluckhofer Weg 61, D-32657 Lemgo, Tel.:[phone], Fax.: 977820
E-Mail: [e-mail], Internet: www.apinstruments.de Seite 18
Technical data
Scale:
Weight range 400g
Resolution 0.1 g
Sample volume max. 360 cm³
Weighing tray 240 x 110 mm
For moisture analysis:
Initial weight any weight from approx. 5 g, recommended from 10 g
Heater capacity Ceramic heater 2x 250 watts (3081)
2x 400 watts (3081 WQ)
Automatic shut-off Automatic drying to a constant weight, using 3 factors for I heaters and Q heaters,
which can be set separately:
Query start, query interval, weight loss/ query interval
Temperature Ceramic heater adjustable from 40°C to 180 °C (3081)
105°C to 360 °C (3081QW)
Measuring units % moisture
% dry matter
% ATRO moisture
g solid matter/ kg
Reading accuracy 0.1% readable
Communication:
Data terminal V24 RS 232/ USB
Data output all weight and measuring data meet GLP requirements with a start time, optional variable
interval printout, date, time, total measuring time etc.
Using ULTRA X DataBridge software can be transmitted to a PC as a
.xls file in Microsoft Excel,
.PDF file.
For operating the device:
Mains connection 230 V 2%/ + 15 %
Mains frequency 48-63 Hz
Power input 250 watts – 850 watts, depending on the model
Dimensions approx. B 385 x D 275 x H 420 mm
Weight approx. 9 kg/ 15 kg (3081 model)
Technical data subject to change without notice
ULTRA X moisture analysers are stand-alone units and not suitable for use in continuous production runs. We shall not accept
any liability for incorrect readings!

Operating instructions for moisture analysers
UX 3081
UX 3081WQ
a&p instruments, Kluckhofer Weg 61, D-32657 Lemgo, Tel.:[phone], Fax.: 977820
E-Mail: [e-mail], Internet: www.apinstruments.de Seite 19
Accessories: Order no.: Use:
AV drying tray, large 10000288 Sample carriers
(2 trays supplied)
Tray tongs 10000230 for lifting the tray
(supplied)
Mains cable H1000019 Mains connection
(supplied)
Calibration weight F1 200 g 10000403 for calibrating the
scales
Aluminium foil 130 mm x 260 mm H1000013 for placing on the drying tray
Foil press 10000062 for shaping aluminium foil
Software DataBridge for transmitting data to a PC
Consumables:
Printing paper 58 mm 10000234 for printer
thermal, stable for 10 years
Ceramic heater 250 W 10000405 Spare part
Ceramic heater 400 W 10000318 Spare part

Operating instructions for moisture analysers
UX 3081
UX 3081WQ
a&p instruments, Kluckhofer Weg 61, D-32657 Lemgo, Tel.:[phone], Fax.: 977820
E-Mail: [e-mail], Internet: www.apinstruments.de Seite 20
