A&S SlimLine User manual

A&S SlimLine
User Manual
Cordless Handheld
Vacuum Cleaner

Contents
Contents
Important Safety Instruction
Technical Parameters of the Product
Product Components
Machine Operation Instruction
Precautious for Use
Cleaning and Maintenance
Machine Storage
1
2
3
4
5
8
8
9
Common Troubleshooting
10
1
A&S SlimLine

Important Safety Instruction
Please read the instructions carefully before use
Power Supply
Battery
l
l
l
l
l
l
l
2
A&S SlimLine
Application Range
Others
l
l
l
l
This product is charged by using a 100-240 V AC charger. Do not use other grade of
charging devices.
Once the charging wire/adapter is damaged, do not use this product, immediately contact
our after-sales department for change of charging device; unplug the charger by hand
carefully holding the charger adapter. Do not pull, twist or bend the charger forcibly.
When the power is plugged/unplugged, keep both hands dry, otherwise, electric shock
may be caused; when this product is not used for a long time, turn off the power supply
switch, and unplug the power supply plug.
Any operation that does not correspond to the instruction manual may result in serious
personal injury or damage to the product itself
Prohibit the use of others charger except original charger for charging, otherwise it will
cause damage to the product; after fully charged, unplug the charger in order to avoid
overcharging, shorten battery life, reduce performance; do not disassemble or replace the
battery by yourself; do not place the battery in the fire to avoid explosion.
Do not short-circuit the battery terminals or reversely charge the battery; do not open the
battery case; do not store the battery in a damp, hot place.
Do not clean the battery with benzyne or thinner and other solvents; stop using the
battery if the temperature is abnormal or leakage occurs; and do not squeeze and strike
the battery, otherwise, the battery may be heated and catch fire.
This product is only suitable for the family environment. Do not use this product in the
industrial environment or outdoors; Do not use this product to vacuum clothes, fingers, or
head hair directly on the human body; this product is the electronic product. Please avoid
the machine from rain, water or use in humid places (such as bathroom, toilet, laundry
room, etc.), in order to avoid the machine circuit failure; Do not use this product in poten-
tially hazardous environments.Such as: gas stations, oil depots, chemical plants and other
flammable and explosive fields; and do not use this product to remove unextinguished
soot, burning cigarette butts or matches, in order to avoid a fire.
Do not use this product to remove flammable or highly volatile liquids, such as gasoline,
kerosene, paint, detergent, alcohol, incense water, carpet cleaners, floor cleaners, etc.
Do not use this product to remove toner or toner used in laser printers and copiers, in order
to avoid fire or explosion.
Keep this product away from children, elderly, mental disabled person; do not ride/sit on
this product.
Keep this product away from heat sources such as baking ovens, fireplaces, etc, to avoid
the deformation damage of the machine shell.
l

3
A&S SlimLine
A&S SlimLine
Brush Nozzle
Flat Nozzle
Storage Seat
Adaptor
0.63KG
20 minutes
Technical Parameters
of the Product
Product Type Handheld Cordless Vacuum
Cleaner
Product Model H100
Rated voltage of
the motor 14.8V Power of the motor 100W
Voltage and
parameters of the
charger
Input circuit
Frequency
Output power
Noise ≤65dB
Suction power0.15L 10000 PaDust Capacity
What’s in the Box:
5
2200mAh

4
A&S SlimLine
Product Components
Adaptor
Charging Indicator
Light
ON/OFF Button
Charging
Hole
Dust Cup
Release Button
Dust Pouring
Lock Latch
LED Lamp
Dust Cup
Brush Nozzle
Flat Nozzle
Storage
Seat

5
A&S SlimLine
Machine Operation Instruction
1) Connect a charging plug into a machine hole (Figure 1)
2) Place the whole machine onto the storage seat
Figure 1
Figure 2
Figure 3

6
A&S SlimLine
3) Insert the plug into the 100-240 V AC jack. The charging light is on, which indicates
the normal charging (Figure 4)
4) Four lights are always on, indicating fully charged.
5) Connect the flat nozzle and the whole machine. Push the switch, and the indicator
light is on, indicating the normal use (Figure 5)
Figure 4
Figure 5
6) Connect the brush with the whole machine. Push the switch, and the indicator light
is on, indicating the normal use (Figure 6)
Figure 6

7
A&S SlimLine
7) After the use, pour the garbage in the dust cup into a dustbin. Press the dust pouring
button as shown in Fig. 6, and the dust cup cover is automatically popped up to pour
the dust.
8) Push the switch button backwards, and the LED lamp is always on. Push the switch
button again for closing, and the LED lamp flashes.

8
A&S SlimLine
1 2 3
4 5
Precautions for Use
l
l
l
Cleaning and Maintenance
l
l
l
l
Please charge for 5 hours before using the new product twice, to sufficiently activate the internal
energy of the battery.
After the voltage drop of the battery pack, the first blue light at the front right side of the power switch
flashes, indicating the low battery level; and at this time, charge the product.
If the product is not used for a long time, the energy inside the battery pack may be reduced. Please
charge the battery every six months for one to two cycles.
All daily maintenance must be done after the power plug of the charger is unplugged.
Frequently clear the garbage in the dust barrel to avoid the faults of the dust collector.
When the machine is not used for a long time, store the machine in the dry and dark place. Do not
place the machine under hot sun or in a wet environment.
The power switch of the machine is off, clean it with a dry cotton cloth (do not use water or neutra-
reagent), and prevent water or reagent from entering the host and causing damage.

9
A&S SlimLine
Machine Storage
1) When the vacuum cleaner is not in use, as shown in (Figure 17) Put the charger
in the charging slot

Possible causes Solutions
The machine
does not work
lThe battery power
is insufficient
lThe power switch
is not turned
lCharge the battery
lTurn on the power switch
The suction
power of the
machine is
reduced
lThe dust box is full
Port of the machine
is blocked
lfilter net is blocked
by the dust
lClear the dust box
lRemove the blockage at
the suction
lClean the filter net
There is dust
blown out
during the use
lFilter in the dust barrel is
l Forgot to install HEPA
filter
lStop using immediately
and replace with a new filter
l Stop using the machine
immediately.
Temperature
control
protection of
the battery
pack
lProtection due to overhigh
ambient temperature
in summer
lStop using the machine
immediately. Reuse it after
the temperature is lowered.
Common Troubleshooting
1) When encountering the following general problems, users can troubleshoot accordingly.
Notes: once the following problems are discovered, close the switch immediately to prevent
the damage of the machine or prevent other harms.
Warnings: All plastic bags in the packaging box of this vacuum cleaner cannot be
used as toys. Please keep plastic bags away from infants and children, in order to
avoid accidents.
l
10
A&S SlimLine
