THE HEPA-AIRE

PORTABLE AIR SCRUBBER
Model PAS1200
1. First Stage 1" Coarse/Particulate Pre-filter
(P/N F621)
2. Second Stage 2" Pleated Pre-filter
(P/NH502)
3. OptionalThird Stage 2" High Capacity
Carbon Filter (P/N VL1002).
4. Final Stage 99.97% HEPA Filter
(P/NH610C-99)
5. MotorizedImpeller
6. 8" Rear Wheels
7. 360°Swivel Casters
8. PrefilterAccess Door
9. HEPA FilterAccess Panel
10.ControlPanel
11.ExhaustOutlet

2
HEPA-AIRE

Portable Air Scrubber
Model: PAS1200
Instruction Manual
©Abatement Technologies 2003 All Rights Reserved. No reproduction of any portion of this work is permitted
withoutthe express writtenpermission ofAbatementTechnologies,Inc.
READ AND SAVE THESE INSTRUCTIONS!
Note: 1. Read and understand all operating instructions before using the PAS1200 Portable Air
Scrubber.
2. Save this manual for future reference.
This instruction manual provides important information on the use of the HEPA-AIREPortable Air
Scrubber (PAS) - model PAS1200. These instructions must be carefully followed in order to operate
the unit safely and correctly. If there are any questions regarding the use of the unit, please contact
Abatement Technologies immediately at 800-634-9091 U.S. or 905-871-4720 Canada.
Abatement Technologies strongly urges users of air filtration units and related accessories to follow
the most recent guidelines and/or standards published by the Occupational Safety and Health
Administration, Environmental Protection Agency, and all other federal, state, provincial and local
regulations.
GENERAL INFORMATION
The PAS1200 is a multi-use air filtration device, equipped with pre-filters and a HEPA filter that are
capable of filtering many airborne contaminants. An optional carbon pre-filter for capturing low
concentrations of odors, vapors, gases, and volatile organic compounds, collectively known as OVG,
is also available.
Types of contaminants captured by particulate pre-filters, HEPA filter, or carbon filters:
• Dirt
• Dust
• Drywall dust
• Saw dust
Note: To capture low concentrations of OVG, a Vapor-Lockcarbon filter must be used.
The PAS1200 is capable of providingparticulate and odor,vapor, gas filtrationwith final stagefiltration
throughaHigh EfficiencyParticulateAir(HEPA) filter.ThePAS1200incorporatesa seriesof particulate
filters which successively remove larger size to smaller size particles from the air. In addition to
providing HEPAfiltration, the PAS1200 is primarily used in a negative pressure or recirculation mode.
A negative pressure condition is created in order to confine contaminated airborne particles. This
condition exists when the static pressure inside the room containing the unit is lower relative to the
pressureof theenvironment outsidethe room.Thestaticpressuredifferentialiscreated andmaintained
by continuously exhausting air out of a given room at a faster rate than air enters the room from all
othersources. Intherecirculationmode,allofthefilteredair isexhausted backinto theroom containing
theunit.
Standard Air Cleaning Stages (filters supplied with the unit)
The PAS1200 comes equipped with two progressively efficient particulate pre-filters mounted in the
pre-filter compartment, and a final stage HEPA filter, located in the lower section of the cabinet:
• Low concentrations of OVG
•Low concentrations of Volatile
Organic Compounds (VOC)
• Unpleasant nuisance odors
• Lung-damaging particles
• Metal fumes
• Smoke
• Mold and fungal spores

3
•The first-stage 1"-deep, coarse particulate pre-filter (F621) is designed to capture particles
100 microns or larger.
•The second-stage 2"-deep, pleated pre-filter (H502) is designed to capture particles 10
microns or larger.
•Each HEPA filter (H610C-99) is tested & certified to capture at least 99.97% (9,997 out of
10,000) 0.3-micron particles.
Note: The particulate filters in the PAS1200 do not remove odors, vapors or gases, including volatile
organic compounds.
Optional Vapor-Lock Carbon Filters (must be purchased separately)
Vapor-Lockpleated, high-capacity, carbon filters (part # VL1002) are available for capturing OVG.
This 2"-deep filter can be used as a third-stage pre-filter, to reduce airborne OVG by chemically
bonding the OVG molecules to the surface area of the carbon granules, via a process known as
adsorption. The VL1002 filter also provides a similar level of particulate filtration efficiency to the
H502pre-filter.
Effective carbon adsorption is dependent upon the amount of carbon & exposed carbon granule
surfaces, and the dwell (contact) time the OVG molecules have with the carbon granules.
Operating the unit at lower speed settings to increase dwell time can therefore improve OVG
adsorption, though it is highly unlikely that all of the OVG will be removed in one pass of air through
the unit. Operating the unit in the recirculation mode can increase effectiveness, by exposing OVG
particles to multiple passes through the Vapor-Lock filter.
It is almost impossible to provide accurate estimates to two commonly asked questions: “how
much time will it take to capture all of the OVG?”, and “how do I know when a carbon filter should be
replaced?” Unfortunately, unknown factors, such as concentration levels, fresh-air intake volume,
temperature, and humidity prevent establishment of any more accurate ‘rule of thumb’ than one’s
sense of smell. Since off-gassing of adsorbed OVG can occur when the adsorption capacity of the
filter is reached, replace the carbon filter as soon as odor breakthrough is sensed. More detailed
information on carbon adsorption can be found in an article titled: “Activated Carbon: How Is It
Used? How Does It Work?” which can be found on the Links and Articles page of the Mold
Abatement, Restoration & Renovation products section of theAbatement Technologies website,
www.abatement.com.
TO DETERMINE THE REQUIRED NUMBER OF PORTABLE AIR SCRUBBERS
Note: The Mold Abatement, Restoration & Renovation section of theAbatement Technologies
website, www.abatement.com, includes a handy Air Change Calculator for all PAS models.This
calculator provides users with a simple way to determine how many units are needed to provide a
given number of air changes per hour (ACH) in any size containment area, and eliminates the need
for user calculations. Simply enter the dimensions of the containment area, theACH required, and
select a built-in safety factor (SF) , to compensate for potential losses due to filter loading, inlet and
exhaust collars, ducting, etc. (Please note that use of a SF is recommended, but not required). The
calculator does the rest.
To determine the number of units required without using the Air Change Calculator, proceed as
follows:
1. Calculate the volume inside containment (V), in cubic feet, by multiplying the length of the
area (L) x the width of the area (W) x the ceiling height (H), in feet.
2. Determine the minimumACH required in the job specification.

4
3. Select a safety factor (SF). Most users build-in between 10% (SF = 1.1) and 25% (SF =
1.25), or more. If you don’t wish to use a SF, proceed to Step 4.
4. Calculate the minimum total airflow required (Total CFM), as follows:
Total CFM = (V xACH x SF) ÷60.
5. # Units Required = Total CFM ÷CFM rating for the Unit.
6. Always round up to the next whole number. For example, if the minimum requirement is 2.1
units, 3 units are recommended, not 2.
Example 1:
How many 900 CFM units are needed to provide at least 6ACH in a 25’ x 30’x 10’ containment area,
with a 20% safety factor?
V = 25 x 30 x 10 = 7,500 Cubic Feet
Total CFM = (7,500 x 6 x 1.2)÷60 = 900 CFM
Minimum # PAS Units Req’d = 900 CFM ÷900 CFM (airflow of unit) = 1 Unit Required
Example 2:
How many 900 CFM units are needed to provide at least 5ACH in a 50’ x 42’x 10’ containment area,
with a 25% safety factor?
V = 50 x 42 x 10 = 21,000 Cubic Feet
Total CFM = (21,000 x 5 x 1.25) ÷60 = 2,188 CFM
Minimum # Units = 2,188 ÷900 = 2.4 = 3 Units Required
Note: This example illustrates the importance of a Safety Factor. If no SF were used, only 1,750
CFM (2 units) would be required.
PAS1200 TRANSPORT
Note: The PAS1200 can be transported in the horizontal position. If extremely poor road conditions
exist, or excessive shock and vibration are expected, take precautionary measures by padding the
unit to provide impact absorption during transport.
Caution: Always use caution when moving the PAS1200 inside a building or home. The unit weighs
85 pounds. Older structures with weakened floors or staircases may require special considerations
for safe transport.
ELECTRICAL REQUIREMENTS
1. The PAS1200 requires a minimum of 110 volts AC, 60 Hz to operate properly; however,
maximum airflow performance requires 120 volts AC, 60 Hz.
2. Due to momentary start-up current surge, the unit requires a 15 amp circuit that is free of other
loads.
3. Extension cords used for the PAS1200 must be UL listed, heavy duty No. 14/3AWG industrial
grade 3-wire type. Use of larger numerical gauge (lower capacity wire) power cord(s) may result
in electrical shock, fire hazards and/or damage to unit. The cord(s) must be in good condition
and in continuous lengths (no splicing) and should not exceed a total of 50 feet in length. Make
certain that any extension cords used do not reduce power to the unit to less than 110 volts. Use
of a voltmeter to confirm adequate voltage is recommended.
4. Check to ensure that any circuit to which the unit is connected is protected by a 15 ampere
circuit breaker.The unit itself is equipped with a 10 amp circuit breaker.

5
5. The PAS1200 should be connected to a three-prong, properly grounded electrical outlet equipped
with a Ground Fault Circuit Interrupt (GFCI) device. A GFCI is an electrical safety device that will trip
the circuit and stop the flow of electricity if leakage of current is detected.
Important Note: The GFCI on the PAS1200 control panel only detects leakage of current
from the unit or an electrical device plugged into the GFCI. The PAS1200 should be
plugged into a GFCI receptacle at the power source to protect the power cord and the unit.
This GFCI will trip the circuit if it detects leakage of current from the power cord or unit.
6. To avoid personal injury, fire hazards and/or damage to the PAS1200 electrical system and power
cord, do not connect or disconnect the power cord to an electrical outlet unless the motorized
impeller is “OFF”.
REQUIREMENTS FOR SAFE OPERATION
1. Never allow unauthorized individuals or children to operate the unit at any time.
2. AbatementTechnologies urgesanyoneoperating thePAS1200to wearthe proper personalprotective
equipment and follow safe work practices in accordance with federal, state, provincial and employer
regulations.
3. Check the condition of power cord(s) before using them. Damaged cords can cause fatal electric
shock and/or motorized impeller failure.
4. Power cord(s) should never be exposed to water, heat, sharp, or abrasive objects; in addition, they
should never be kinked or crushed. Avoid tightly wrapping the cords to prevent kinking of the internal
wires.Always replace damaged power cords immediately.
5. Never pull the unit by the power cord.
6. Avoid running over power cords with utility equipment and vehicles.
Important Safety Instructions
a. Do not operate any unit with a damaged cord or plug. Discard unit or return it to an
authorized service facility for examination and/or repair.
b. Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or similar
coverings. Do not route cord under furniture or appliances. Arrange cord away from
traffic area and where it will not be tripped over.
Caution: As with any piece of electrical equipment, always make sure that the unit is turned “OFF”
prior to connecting the power cord to an electrical outlet or disconnecting it from an electrical outlet.
Failure to do so will cause “arcing”, and could result in personal injury, fire hazards and/or damage to
the unit. Do not disconnect the power cord from supply receptacle while the unit is operating.
Warning: To reduce risk of electrical shock, do not expose this unit to water or rain. Do not touch
the electrical outlet or power cord(s) with wet hands or while standing on a wet or damp surface.
Warning: Risk of electrical shock! Can cause injury or death! Turn unit “OFF” and disconnect
power cord from supply receptacle before replacing the HEPA filter and before cleaning or
servicing the unit.
Warning: The PAS1200 is equipped with an automatic restart motorized impeller that will restart
without warning after a temporary power interruption or recovery from a thermal overload (over-
heating) condition. Keep clear of the motorized impeller at all times to reduce the risk of injury.
Warning: To reduce risk of fire or electrical shock, do not use the PAS1200 with any solid state
speed control device. Do not use in a cooking area.
Caution: The PAS1200 is designed for indoor use only.
CAUTION: For General Ventilating Use Only. Do Not Use To Exhaust Hazardous Or Explosive
Materials And Vapors.

6
Warning:Abatement Technologies air filtration systems are not intrinsically safe for use in hazardous
environments. Always consult a certified industrial hygienist before using them. Do NOT use this
equipment in any atmosphere that is or may be immediately dangerous to life or health (IDLH),
combustible, flammable, explosive, oxygen deficient, and/or contains odors, vapors, gases or
particulates that exceed permissible exposure levels. Such atmospheres may require the use of
intrinsically safe equipment, specific engineering controls, and personal protective equipment in
accordance with Occupational Safety and Health Administration (OSHA), Environmental Protection
Agency (EPA), Canadian Standards Association (CSA), and other federal, state, provincial and local
regulations.
Warning: This equipment is not classified as “intrinsically safe” and should not be used in the
following hazardous locations as defined by the Underwriters Laboratories: Class I Division 1,
Class I Division 2, Class I Zone 0, Class I Zone 1, Class I Zone 2, Class II Division 1, Class II
Division 2, Class III Division 1, Class III Division 2. Refer to the UL web site: http://www.ul.com/
hazloc/define.htm.
Warning: Do not use this unit near sparks, open flames or other possible sources of ignition.
PAS1200 CONTROL PANEL
1. Power Cord - Hardwired, 10 foot power cord for
connection to electrical outlet.
2. Speed Control Switch - Serves as the power
switch and provides a variable adjustment to the
speed of the motorized impeller.
3. Power Indicator - Green light that indicates speed
control switch is “ON” and system is connected to
power source.
4. Hour Meter- Provides a count of the total operating
hours.
5. Filter Change Indicator - Primary – Amber light that indicates excessive restriction on air intake or
loading of the pre-filter(s) and that filter change procedures should be followed.
6. Filter Change Indicator - HEPA- Amber light that indicates excessive restriction on air exhaust or
loading of the HEPA filter and that filter change procedures should be followed.
7. Circuit Breaker - 10 amp circuit breaker that provides protection for the unit’s electrical components.
8. GFCI Receptacle - Electrical safety device that will trip and stop the flow of electricity if leakage of
current is detected from the unit or an electrical device plugged into the GFCI receptacle. The PAS1200
can supply a total of 7 amps of electrical power for additional equipment that is connected to the GFCI
receptacle. Do not exceed this 7 amp limit.
Note: If the equipment connected to the GFCI receptacle draws more than a total of 7 amps, the circuit
breaker on the control panel and/or the building breaker will trip. This condition can be remedied only by
reducing the total amperage draw.
BEFORE OPERATING THE UNIT, NOTE THE FOLLOWING:
The rear axle, 2 rear wheels, 2 bushings for securing the wheels to the axle and anAllen wrench are packed
in a separate box that is included with the PAS1200. Place the axle through the circular opening in the lower
rear section of the cabinet and center the axle. Slide the wheels and bushings onto the axle and tighten the
bushings in place using the Allen wrench. Refer to FigureA.
Inspect and tighten any HEPA filter retaining nuts that may have loosened during transportation. Inspect the
filters for any material or structural damage prior to use and replace any damaged filters before operating the
unit. Whenremovingany filterspriorto operation,alwaysput thembackin placewithairflow indicatoronfilter
housing oriented in the proper direction (if applicable).

7
As with any air filtration system, external airflow losses not attributable to the air filtration unit will
reduce the airflow of the system. The following recommendations can minimize airflow losses created
by external static resistance.
1. Always use the minimum length of ducting possible with the fewest possible number of turns
and bends.
2. Rigid metal ducting creates less turbulence and consequently less airflow loss than flexible
ducting. Regardless of the type of ducting used, rigid, “sweep-type’, radiused connections
should be used for all turns and bends.
3. If flexible ducting is used, it must be kept as taut as possible to avoid flattening.
LOCATION OF THE UNITS AND MODES OF OPERATION
1. Negative Pressure - used to help ensure that airborne contaminants do not escape from a
contained area, by maintaining negative (lower) air pressure within that area compared to
adjacent areas. This is generally accomplished by placing the unit inside the containment
area and exhausting filtered air from the unit out of the area. The filtered air must be
exhausted outside of the containment area, either directly to the outdoors, or into another
part of the building. To maintain negative pressure, the air exhaust must exceed the air
supply by the greater of: 10% or 100 CFM. To achieve this differential, the air supply volume
to the area may have to be reduced. Negative pressure levels should be continuously
monitored.
2. Recirculation -used to reduce concentrations of airborne contaminants in a room or area
by continuously cleaning the air and exhausting it back into the same room or area.
3. Positive Pressure - used to help prevent airborne contaminants from entering a
containment area, by keeping that area under positive pressure compared to adjacent
spaces, so any air leakage will be an outflow of clean air, and not inflow of contaminated air.
This pressure differential can be established by:
a. placing the unit inside the containment area, and using it to pull air into the area by
attaching flex duct between the inlet collar and a location outside of the containment
area.
b. placing the unit outside of containment area, and using it to push HEPA-filtered air
into the area through flex duct attached between the outlet collar and a location inside
the area.
To ensure that the proper pressure differential is maintained, the volume of HEPA-filtered air
supplied to the area must be the greater of: 10% or 100 CFM higher than the volume of air
exhausted from it by the HVAC system. Positive pressure levels should be monitored
continuously.
Important Note: Do not operate the unit unless the pre-filter(s) and HEPA filter are installed,
and the filter access door and panel are in place and closed.
DAISY CHAINING
“Daisy Chaining” refers to the operation of multiple units on one circuit, with only one of the units
plugged into a 120V/15A electrical power supply receptacle. Each subsequent unit is plugged into
one of the GFCI receptacles on the prior unit, up to the maximum number allowed based on the
amperage draw per unit. The National Electrical Code limits the total amperage draw of devices
operating on one circuit to 80% of full load, which means that the total amperage draw on a 120V/
15A circuit, including the unit plugged into the building electrical power supply receptacle, must not
exceed 12 amps.
A total of three PAS1200 units can be “Daisy Chained” on a 15 amp circuit, including the unit
plugged into the building electrical power supply receptacle.

TO START UNIT
1. Check to make sure that the Speed Control Switch is in the “OFF” position. Plug power cord into
a 120 volt AC, 60Hz, 15 amp supply circuit.
2. Turn Speed Control switch clockwise past the click at the “HIGH” setting to turn power “ON”.
3. Set Speed Control switch to desired setting.
Note: Refer to the chart in this instruction manual entitled “AIRFLOW RATINGS” that lists the
airflows for the PAS1200.
Note: In the event of a power failure while the unit is running, or loss of power due to any
other cause, this unit’s motorized impeller will re-start when power is restored, after a brief
delay.
FILTER CHANGE INDICATORS
“Primary” light “ON” indicates one or more of the following:
1. Loaded pre-filter(s). Refer to filter change procedures.
2. Restrictions on air intake. Refer to Troubleshooting Guide.
“HEPA” light “ON” indicates the following:
1. Loaded HEPA filter. Refer to filter change procedures.
FILTER REPLACEMENT
Note: Personnel responsible for changing filters, servicing units or relocating units within
the facility are urged to wear the proper personal protective equipment and follow safe work
practices in accordance with federal, state, provincial, and employer regulations.
Note: Filters being replaced must be disposed of in accordance with federal, state, provincial,
local and facility regulations.
System airflow reduction is generally the result of filter loading, blockage of the unit’s inlet or use of
excessive lengths of flex duct that is connected to the inlet.
Thesize andconcentrationof airbornecontaminants,temperature andhumidityconditions,andduration
of use determine how often filters need replacement. If the Filter Change Indicator(s) on the control
panel illuminate, this indicates one or more of the following: (1) pre-filter(s) are loaded, (2) the inlet or
exhaust is obstructed, (3) the flex duct, if attached to inlet or exhaust, is too long or has too many
bends, and (4) the HEPA filter is loaded.
Themethodof determiningwhen toreplace theoptionalactivated carbonfilter issomewhat subjective.
As the odor, vapor, and/or gas filtration capacity decreases, the user will begin to sense a slight odor
or taste of the contaminant, indicating that the filter should be replaced.
Note: The filters are not reusable, therefore, do not attempt to clean and reuse them.
Caution:Abatement Technologies PAS1200 Portable Air Scrubber units are designed to meet
or exceed standards for high efficiency air filtration equipment. Use only Abatement
Technologies parts, including replacement filters. Use of non-Abatement Technologies parts
and filters voids the product warranty and all performance claims.
Warning: To reduce the risk of fire, electrical shock or personal injury, always turn the PAS1200
“OFF” and disconnect the power cord from supply receptacle before replacing the HEPA
filter and before cleaning or servicing the unit.
8

FILTER CHANGE PROCEDURE
To Change the First Stage Filter:
1. With the unit operating, pull up on the door latch and open the pre-filter access door.
2. Remove the first stage filter and replace it with a new one.
3. Close the door and lock it in position by pushing down on the latch. Make sure the door is flush
against the PAS1200 cabinet before closing latch.
4. Ifthefilter change indicatorremains “ON” afterchanging the firststagefilter, thesecondstage filter
should be replaced.
To Change the Second Stage Filter:
1. Open the pre-filter access door.
2. Remove the second stage filter and replace it with a new one.
3. Close the door and lock it in position.
4. If the filter change indicator remains “ON” after changing the second stage filter, the optional third
stage filter should be replaced. The light would remain “ON” only if the optional third filter is in use
and has become loaded.
To Change the Optional Third Stage Filter:
1. Open the pre-filter access door.
2. Remove the third stage filter and replace it with a new one.
3 Close the door and lock it in position.
Note: If an optional Vapor-Lockfilter is being used, be sure to remove it from its poly bag before
installing it in the unit. Vapor-Lockfilters are packaged in poly bags to preserve the integrity of the
carbon granules.
To Change the HEPA Filter:
1. Turn the unit “OFF” and disconnect the power cord from the electrical outlet.
2. Remove the HEPA filter access panel.
3. Using a 1/2" wrench, loosen the 2 HEPA filter retaining bolts by turning them in a
counterclockwise direction and remove the HEPAfilter.
4. Replace the HEPA filter making sure that the new filter’s foam seal is facing upward so that it
seats against the upper HEPA filter mounting surface. The HEPA filter is delicate and should be
handled with care.
5. Push the HEPA filter into the cabinet, making sure it is positioned in the middle if its V-shaped
bracket.
6. Tighten the filter retaining bolts and reattach the HEPA filter access panel.
Warning: Use only Abatement Technologies pre-filters, HEPA filters, and replacement parts.
Substitute parts void the warranty, jeopardize worker and environmental safety, and adversely
effect engineered performance levels.
9

PAS1200 SPECIFICATIONS
Note: Specifications subject to change without notice.
AIRFLOW RATINGS (PAS1200 ISA VARIABLE SPEED UNIT)
Note: Airflow ratings estimates are based on factory and independent testing @ 120 VAC with an air
straightener and a traverse of readings taken with a computing vane-anemometer. Actual results may
vary for various reasons, including motor and blower and HEPAfilter tolerances. Factors such as
filter loading, reduced voltage to the motor, and inlet and outlet ducting will reduce airflow. Use
these ratings as a general guideline only.
10
ERUTAEF0021SAP
:sretlif/wthgiewteN.sbl58
:thgiewgnippihS.sbl701
:)HxWxL(snoisnemiDH"93xW"22xL"4/191
:stnemeri
uqerylppusrewoP.tiucricpma51,zH06,CAstlov021
:spmagnitarepolamroNsselrospma5.3
:rellepmIdezirotoM ,noitcet
orpdaolrevolamrehthtiwrellepmidezirotomttaw004 .esahpelgnis,zH06,tes-erotua
:etarwolfgnitarepO )sretlifn
aelchtiw( MFC009-051elbairaV
:rekaerBtiucriCpma01
:leveldnuoslanoitarepOteef5tanekatgnidaer,ABd76-26
:tenib
aC smaeS.stevirdiloshtiwdelbmessa,leetssselniatseguag02 .deteksagera
:ytilibatropsnarT leviws°063.ae2dnar
aernisleehwrebbur"8hcae2 .tnorfnisretsac
:sseccaretliferP -llewsytudyvaehaybderucessirooddegnihgnitarepo
-ysaE .ssap-ybretliftsniagatcetorpothctal
:retlif-erpegatstsriF)126F(retlif-erpetalucitrapesraoc"1
:retli
f-erpegatsdnoceS)205H(retlif-erpetalucitrapdetaelp"2
:retlif-erpegatsdrihtlanoitpO)2001LV(retlifnobracyt
icapachgih"2
:retlifAPEH rehgihro%79.99foycneiciffenaotdeifitrecdnadetseT )99-C016H(.selcitrapezisnorcim
3.0tsniaga
deepStsewoLdeepStsehgiH
0021SAPMFC051MFC009

TROUBLESHOOTING GUIDE
11
MELBORPESUACELBISSOPNOITULOS
EHTNEHWESNOPSERON
."NO"DENRUTSIREWOP
.DEGGULPNUDROCREWOP-
.DROCREWOPEVITCEFED-
.REKAERBTIUCRICDEPPIRT-
TIUCRICTLUAFDNUORGDEPPIRT-
.RETPURRETNI
EHTNODAOLREVOLAMREHT-
.DEPPIRTSAHRELLEPMI
DEZIROTOM
OTNIYLMRIFDROCREWOPGULP-
.LLAWNITELTUOLACIRTCELE
DNASNOITCENNOCLLAKCEHC-
TONOD.SDROCLLAFONOITID
NOC
REWOPDEGAMADHTIWETAREPO
.)S(DROC
TESER.GNIDLIUBROFREKAERBTESER-
.LENAPLORTNOCNOREKAERBPMA01
RO/DNALENA
PLORTNOCNOICFGTESER-
.ECRUOSREWOPTA
SETUNIM03TIAW,"FFO"TINUNRUT-
.TINUTRATSERDNA
NOREKAERBTIUCRIC
ROLENAPL
ORTNOC
."SPIRT"GNIDLIUB
.TIUCRICDEDAOLREVO- TNEMPIUQELANOITIDDAYNAGULPNU-
.ELCATPECERICFGEHTOTDETCENNOC
TR
ATSER.REKAERBTIUCRICTESER
TINU
.DEEPS"HGIH"NO
EGNAHCRETLIF
."NO")S(ROTACIDNI
.SRETLIFDEDAOL-
EKATNINOSNOITC
IRTSEREVISSECXE-
.TSUAHXERO
NEEBTONSAHRETLIFNOBRAC-
.GABYLOPMORFDEVOMER
HTIWECNADROCCANIEGNAHC-
.SNOITCURT
SNIGNITAREPO
TCUDXELFFOHTGNEL,SDNEBECUDER-
.SNOITCIRTSERETANIMILERO
MORFRETLIFNOBRACEVOMER-
.GABYLOP
Note: If the unit does not start or malfunctions after carefully following the Troubleshooting Guide, call
AbatementTechnologiesservicedepartment at 800-634-9091 (U.S.) or905-871-4720 (Canada) for assistance.
COMPONENT REPLACEMENT AND CARE OF THE UNIT
Warning: To reduce the risk of fire, electrical shock or personal injury, always turn the unit
“OFF” and disconnect power cord from supply receptacle before removing the control panel,
replacing the HEPA filter and before cleaning or servicing the unit. The PAS1200 is equipped
with an automatic restart motorized impeller that will restart without warning after a temporary
power interruption or recovery from a thermal overload (over-heating) condition. Keep clear
of the motorized impeller at all times to reduce the risk of injury.
Occasionallya defectivecomponentwill causethe unitto operateimproperly ornotatall.Any electrical
component can fail. Refer to the Wiring Diagrams and Wiring Schematics to diagnose the failure of
any component. Diagnostics should only be performed by a technician qualified to service electrical
equipment.
The unit should be cleaned with a damp cloth or a water-based cleaner/sanitizer. Do not use harsh
chemicals, solvents or detergents to clean the unit.

12
Warning: Keep electrical components dry as their exposure to liquids poses a safety hazard
and can damage components.
CERTIFICATION OF ROOM AIR FILTRATION UNITS
The Abatement Technologies room air filtration units have been tested by Intertek Testing Services
(ITS) and are ETL and ETLC (Canada) listed for electrical safety.
ITS is accredited by the U.S. Occupational Safety and HealthAdministration (OSHA) as a Nationally
Recognized Testing Laboratory (NRTL).
LIMITED WARRANTY
Abatement Technologies, Inc (ATI) warrants that goods sold to the original user shall be free
fromdefectsin materialandworkmanship foraperiod of1 year,except suchas are commercially
acceptable. This warranty does not include useful filter life.ATI does not warrant that the goods
sold are merchantable or fit for any particular purpose. ATI makes no warranties other than as stated
inthis paragraph. Allotherwarranties, guaranties,or representations,express or implied,by operation
of law orotherwise, are expressly disclaimed. Goods found byATI to be defective or not to conform
to specification shall upon return be replaced or repaired by ATI without any additional charges,
or, at ATI’s option, ATI may refund the purchase price of such goods. ATI will pay return
transportation charges on returned goods not exceeding the transportation charges applicable
to shipment from original destination unless the returned goods are free from defect and
conform to specifications. Returned goods which are found by ATI to be free from defect and
to conform to specifications shall be held for Purchaser’s shipping instructions, which
instructions Purchaser shall furnish promptly upon request. ATI’sliabilityshall inno eventextend
beyond replacement, repair or refund of the purchase price and ATI shall not be liable under any
circumstances for special, contingent or consequential damages, nor for loss, damages, or expenses
directly or indirectly arising from the use of the goods, including without limitation, warehousing, labor,
handling and service charges, die, equipment, or machine breakage, nor for costs, lost profits or loss
of good will. The use of substitute, non-ATI parts and/or filters, in any ATI product, voids all warranties
and performance claims. The remedies set forth herein are exclusive.
For warranty information and assistance contact Abatement Technologies’ Customer Service
Department at 800-634-9091 (U.S.) or 905-871-4720 (Canada.)
Abatement Technologies' PAS1200 high-efficiency air filtration units are originally equipped with true
HEPA(High Efficiency Particulate Air) filters designed to maximize the performance of the equipment,
and to meet the following industry standards:
Institute of Environment Sciences and Technology
IEST-RP-CC001.3 (TypeAHEPAand ULPAFilters)
IEST-RP-CC021.1 (Testing HEPAand ULPA Filter Media)
Underwriters Laboratories
UL900, Class II (Flammability Specifications)
100% Efficiency Tested
AbatementTechnologiesHEPAfilters areindividuallytested andcertified to ensurethat thecompleted
filterprovidesan overallminimumefficiency of99.97% when challengedby a thermallygenerated test
aerosol, 0.3-microns in size, in accordance with IEST-RP-CC001.3.

13

14

15
