Product Information Packet
7309D
.5HP,3000/3600RPM,3PH,50/60HZ,3420M,GRND
Copyright © All product information within this document is subject to Baldor Electric Company copyright © protection, unless otherwise noted.

ForBaldorSalesandSupport,PleaseContact:WalkerEMD•http://www.walkeremd.com•Toll-Free:[phone]•Phone:[phone]•Fax:[phone]
Page 2 of 8
Product Information Packet: 7309D - .5HP,3000/3600RPM,3PH,50/60HZ,3420M,GRND
Part Detail
Revision: AG Status: PRD/A Change #: Proprietary: No
Type: AC Prod. Type: 3420M Elec. Spec: G7WG0044 CD Diagram:
Enclosure: GRND Mfg Plant: Mech. Spec: G7-0312 Layout:
Frame: Mounting: F1 Poles: 02 Created Date:
Base: RG Rotation: RInsulation: BEff. Date: 06-21-2012
Leads: 9#18 Literature: Elec. Diagram: Replaced By:
Nameplate NP0113
CAT.NO. 7309D
HP .5 VOLTS 208-230/460
PHASE 3AMPS .85-.8/.4
HZ 50//60 RPM 3000//3600
SER.NO
SPEC. G7-312-44

ForBaldorSalesandSupport,PleaseContact:WalkerEMD•http://www.walkeremd.com•Toll-Free:[phone]•Phone:[phone]•Fax:[phone]
Page 3 of 8
Product Information Packet: 7309D - .5HP,3000/3600RPM,3PH,50/60HZ,3420M,GRND
Parts List
Part Number Description Quantity
SA004991 SA G7-312-44 1.000 EA
RA002341 RA G7-312-44 1.000 EA
G7BA3000A01 BASE, MACH 1.000 EA
SP9004 SWITCH HKA270-73 CARLING 1.000 EA
G7CB4500 BASE COVER PLATE 7" GRINDER 1.000 EA
RM1005A01A BASE FOOT & SCREW ASSLY 4.000 EA
WD4502A01A02 CONDUIT BOX W/KNOCKOUTS, FOR 7,8 & 10 GR 1.000 EA
51XW1032A06 10-32 X .38, TAPTITE II, HEX WSHR SLTD S 2.000 EA
51XW1032A06 10-32 X .38, TAPTITE II, HEX WSHR SLTD S 2.000 EA
HW5100A03SP WAVY WASHER (W1543-017) 1.000 EA
G7EP3900A01 ENDPLATE, MACH 1.000 EA
HW5100A03SP WAVY WASHER (W1543-017) 1.000 EA
G7EP3900A01 ENDPLATE, MACH 1.000 EA
HA3100A29 THRUBOLT 10-32 X 7.00 4.000 EA
XY1032A02 10-32 HEX NUT DIRECTIONAL SERRATION 4.000 EA
G7FH1800A01SP GRINDER GUARD, MACH 1.000 EA
10XF2520A16 SCREW, HEX HD, ZN X 3.000 EA
G7FH1801A01SP GRINDER GUARD COVER, MACH 1.000 EA
10XN2520A16 1/4-20 X 1 HEX HEAD CAP SCR, ZINC PLATED 4.000 EA
G7FH1802A01SP GRINDER GUARD, MACH 1.000 EA
10XF2520A16 SCREW, HEX HD, ZN X 3.000 EA
G7FH1803A01SP GRINDER GUARD COVER, MACH 1.000 EA
10XN2520A16 1/4-20 X 1 HEX HEAD CAP SCR, ZINC PLATED 4.000 EA
HA2040A01SP SPACER,CRST(WELKER#824500 2.000 EA

ForBaldorSalesandSupport,PleaseContact:WalkerEMD•http://www.walkeremd.com•Toll-Free:[phone]•Phone:[phone]•Fax:[phone]
Page 4 of 8
Product Information Packet: 7309D - .5HP,3000/3600RPM,3PH,50/60HZ,3420M,GRND
Parts List (continued)
Part Number Description Quantity
HA6096A01SP WHEEL FLANGE, MACH 4.000 EA
HW3021C04 SPRG PIN 3/32 DIA .375LGH DRIV-LOK 2.000 EA
G7AP3000A01 WHEEL, 7 X 1 X 36 GRIT B73 X 1.000 EA
G7AP3000A02 WHEEL, 7 X 1 X 60 GRIT B74 X 1.000 EA
XY6311A62 5/8-11 NUT L.H. HEX (NC)X (F/S) 1.000 EA
XY6311A12SP HEX NUT 5/8-11 1.000 EA
G6AP1008A01P TOOLREST, MACH/PRIMED 1.000 EA
HA6064A01P PAINT/PRIME HA6064A01 1.000 EA
10XN2520A14 1/4 20X7/8 HX HD CAP 2.000 EA
HW1001A25 LOCKWASHER 1/4, ZINC PLT .493 OD, .255 I 2.000 EA
HW1000A25 1/4 SAE FLAT WASHER (FS) 2.000 EA
G6AP1008A01P TOOLREST, MACH/PRIMED 1.000 EA
HA6064A01P PAINT/PRIME HA6064A01 1.000 EA
10XN2520A14 1/4 20X7/8 HX HD CAP 2.000 EA
HW1001A25 LOCKWASHER 1/4, ZINC PLT .493 OD, .255 I 2.000 EA
HW1000A25 1/4 SAE FLAT WASHER (FS) 2.000 EA
G6AP1002A01SP SPARK BREAKER-6",7" & 8" GRINDERS 1.000 EA
10XN3118A10 5/16-18 X 5/8 HEX HEAD CAP 1.000 EA
HW1001A31 LOCKWASHER 5/16, ZINC PLT.591 OD, .319 I 1.000 EA
HW1000A31 5/16 SAE FL WSHR NARROW, ID=.344, OD=.62 1.000 EA
G6AP1002A01SP SPARK BREAKER-6",7" & 8" GRINDERS 1.000 EA
10XN3118A10 5/16-18 X 5/8 HEX HEAD CAP 1.000 EA
HW1001A31 LOCKWASHER 5/16, ZINC PLT.591 OD, .319 I 1.000 EA
HW1000A31 5/16 SAE FL WSHR NARROW, ID=.344, OD=.62 1.000 EA

ForBaldorSalesandSupport,PleaseContact:WalkerEMD•http://www.walkeremd.com•Toll-Free:[phone]•Phone:[phone]•Fax:[phone]
Page 5 of 8
Product Information Packet: 7309D - .5HP,3000/3600RPM,3PH,50/60HZ,3420M,GRND
Parts List (continued)
Part Number Description Quantity
WD4503A01 LID R860 HANDY BOX LID, USED WITH BOX WD 1.000 EA
GA9 EYESHIELD ASSY 1.000 EA
GA24 WATER POT ASSY 1.000 EA
GA25 TOOL TRAY ASSY 1.000 EA
MG1000G01 400-0116 BATTLESHIP GRAY LACQUER (55G) 0.014 GA
10XF0440S02 04-40 X 1/8 TYPE F HEX HD STAINLESS STIC 2.000 EA
LB1008 LABEL, UL 1.000 EA
LB1009 LABEL,ROTATION DIRECTION (ON ROLLS) 1.000 EA
LB1030 LABEL, OSHA (ON ROLLS) 1.000 EA
LB1307 LABEL, WARNING 1.000 EA
LB1119 WARNING LABEL 1.000 EA
LB1125C01 STD (STOCK) CARTON LABEL BALDOR WITH FLA 1.000 EA
MN903 INSTR MANUAL FOR GRINDERS 9/03 1.000 EA
LC0005B01 CONN LABEL GRINDER/BUFFER X 1.000 EA
NP0113 N.P.- DELUXE GRINDERS - BUFFERS 1.000 EA
07PA1005 PKG GRP., BALDOR 1.000 EA

ForBaldorSalesandSupport,PleaseContact:WalkerEMD•http://www.walkeremd.com•Toll-Free:[phone]•Phone:[phone]•Fax:[phone]
Page 6 of 8
Product Information Packet: 7309D - .5HP,3000/3600RPM,3PH,50/60HZ,3420M,GRND
Accessories
Part Number Description Multiplier
GA16E PEDESTAL LIGHT INDUSTRIAL,STEEL A8
GA16 PEDESTAL INDUSTRIAL, CAST IRON 6" - 10" A8
GA14 PEDESTAL FABRICATED STEEL W/SHELVES A8
B73 7" 36 GRIT GRINDING WHEEL A8
B74 7" 60 GRIT GRINDING WHEEL A8
GA9 PAIR LIGHTED EYESHIELDS A8
GA9-1 SINGLE LIGHTED EYESHIELD A8
GA9S PAIR EYESHIELDS W/ ON-OFF SWITCH A8
GA11 PAIR EYESHIELDS A8
DC7 DUST CONTROL UNIT A8
