ABD Lighting ABD-LW7M User manual

ABD Lighting Equipment Co.,LTD Website : www.abdlighting.com
1
Channel
Value
Control
1 Channel
0
Stop
1-255
Adjustment for Motor X moving
2 Channel
0
Stop
1-255
Located adjustment for Motor X
3 Channel
0
Stop
1-255
Adjustment for Motor Y moving
4 Channel
0
Stop
1-255
Located adjustment for Motor Y
5 Channel
0
Close
1-255
General dimmer control,brightness is from dark to bright.
6 Channel
0
Close
1-255
Red color control,brightness is from dark to bright.
7 Channel
0
Close
1-255
Green color control,brightness is from dark to bright.
8 Channel
0
Close
1-255
Blue color control,brightness is from dark to bright.
9 Channel
0
Close
1-255
Amber color control,brightness is from dark to bright.
10 Channel
0
Close
10-255
White color control,brightness is from dark to bright
11 Channel
0-9
Close
10-255
Adjustment for 32 kinds of mixed color
12 Channel
0-9
Close
10-255
Strobe control,strobe is from slow to fast.
13 Channel
0-127
Close
128-255
Sound control of DMX controller is open.
User Manual
7*15w RGBAW 5in1
Led MINI MOVING HEAD
Professional Entertainment Equipment

ABD Lighting Equipment Co.,LTD Website : www.abdlighting.com
2
Features
Voltage: AC110-240V 50/60Hz
Power: 110W
Light source: 7*15W RGBAW LED(5 IN 1)
DMX Channel: 8/13 CH
4 operation modes: Automatic running, DMX, Sound Active, Master/Slave
Weight: 3.9 kgs
Control
DMX Control Instruction
Display
Function
ADDR
A001-A512
CHND
8CH/13CH
SLND
NAST(Master)
SL 1 (Slave 1)
SL 2 (Slave 2)
SOUN
0-100(set up the sensitivity of sound control)
AUTO
NO/YES(Set up the Auto mode)
STBY
NO/YES(Set up the pause mode for the beginning)
PAN
NO/YES (Set up positive and negative moving for Motor X)
TILT
NO/YES (Set up positive and negative moving for Motor Y)
LED
ON/OFF(background light )
DISP
Set up positive and negative direction
TEST
Self-checking function
HOUR
Work time
RSET
Self-checking reset
Notice:
1. When power in,the display is rolling with “LED-RGBW”.
2. Mixed color adjustment:
First,press “Menu” Button to enter in menu choose mode,then press “Eneter”button for about
5 seconds, display “BALA” will bring you into mixed color menu.And the led display will keep
flicking.Press “Enter” button again,you can enter in mixed color adjustment directly.
RED(0-255)GREE(0-255)BLUK(0-255)WHIT(0-255)
DMX channel display:
8 Channel:
Channel
Value
Control
1 Channel
0
Stop
1-255
Adjustment for Motor X moving
2 Channel
0
Stop
1-255
Adjustment for Motor Y moving
3 Channel
0-10
Close
11-255
General dimmer control,brightness is from dark to bright.
4 Channel
0
Close
1-255
Red color control,brightness is from dark to bright.
5 Channel
0
Close
1-255
Green color control,brightness is from dark to bright.
6 Channel
0
Close
1-255
Blue color control,brightness is from dark to bright.
7 Channel
0
Close
1-255
Amber color control,brightness is from dark to bright.
8Channel
0
Close
1-255
White color control,brightness is from dark to bright.
13 Channel:
