Quick Reference Guide

Intimidator™ Beam LED 350 QRG EN
2
About This
Guide
The Intimidator™ Beam LED 350 Quick Reference Guide (QRG) has
basic product information such as mounting, menu options, and DMX
values. Download the User Manual from www.chauvetlighting.com
for
more details.
Disclaimer
The information and specifications contained in this QRG are subject to
change without notice.
Safety Notes
These Safety Notes include important information about installation, use,
and maintenance.
•This product is not intended for permanent installation.
•ONLY connect this product to a grounded and protected circuit.
•Always disconnect from power before cleaning or replacing the fuse.
•DO NOT look at the light source when the product is on.
•Make sure the power cord is not crimped or damaged.
•Never disconnect this product from power cord by pulling on the cord.
•When mounting this product overhead, use a safety cable.
•DO NOT allow flammable materials close to the unit while operating.
•DO NOT touch this product when it is operating because it may be hot.
•The voltage of the outlet to which you are connecting this product must
be within the range stated on the decal or rear panel of the product.
•This product is for indoor use only! (IP20) To prevent risk of fire or
shock, do not expose this product to rain or moisture.
•Always mount this product in a location with adequate ventilation, at
least 20 in (50 cm) from adjacent surfaces.
•Be sure that no ventilation slots on the unit’s housing are blocked.
•Never connect this product to a dimmer or rheostat.
•Replace the fuse with the same type and rating.
•ONLY use the hanging/mounting bracket or the handles to carry this
product.
•The maximum ambient temperature
is 104° F (40° C). Do not operate this
product at higher temperatures.
•In the event of a serious operating problem, stop using immediately.
•
DO NOT open this product. It contains no user-serviceable parts.
Contact
Outside the U.S., United Kingdom, or Ireland, contact your distributor to
request support or return a product. Visit www.chauvetlighting.com
for
contact information.

EN Intimidator™ Beam LED 350 QRG
3
What Is
Included
•Intimidator™ Beam LED 350
•Hanging Bracket with Mounting
Hardware
•Power Cord
•Warranty Card
•Quick Reference Guide
To Begin Unpack your Intimidator™ Beam LED 350 and make sure you have
received all parts in good condition. If the box or contents appear damaged,
notify the carrier immediately, not CHAUVET®.
Product
Description
The Intimidator™ Beam LED 350 is a compact, feature-packed 75W
moving head with a frost effect that can shift the beam to a wash. A fixed
gobo wheel with animation effects and a 3-sided prism that splits the beam
provide complex looks over a large coverage area. Power linking saves time
running cords, and built-in sound-activated programs dance to the beat of
the music.
Product Overview
AC Power This product has an auto-ranging power supply that can work with an input
voltage range of 100~240 VAC, 50/60 Hz.
Power Linking You can link up to 3 Intimidator™ Beam LED 350 products at 120 VAC
and 7 units at 230 VAC.
Fuse Replacement 1.Disconnect the product from power.
2.Using a flat-head screwdriver, loosen the fuse holder and pull straight
out.
3.Remove the blown fuse from the holder and replace with a fuse of the
exact same type and rating.
4.Re-insert the fuse holder and reconnect power.
Fuse Holder
DMX In/Out
Power In
LED Display
Safety Loop
Power Out

Intimidator™ Beam LED 350 QRG EN
4
Mounting
Before mounting this product, read the Safety Notes.
Product
Mounting
Diagram
Control Panel
Description Button Function
<MODE/ESC>
Exits from the current menu or function
<UP>
Navigates upwards through the menu list and increases the
numeric value when in a function
<DOWN>
Navigates downwards through the menu list and decreases the
numeric value when in a function
<ENTER>
Enables the currently displayed menu or sets the currently
selected value into the selected function
Bracket Attachment (x2)
Rubber Feet (x4)
Safety Loop Attachment Point

EN Intimidator™ Beam LED 350 QRG
5
Menu Options
Main Level Programming Levels Description
DMX Address
d001~d512
Sets the DMX starting address
Operation Modes
SLAv (Son)
Slave operating mode
NASL (SLoU)
Automatic Mode, Slow Program
NAFA (FASt)
Automatic Mode, Fast Program
NStS (SrUn)
Sound Active Mode
Pan
Normal Pan
PAn
Normal Pan operation
Inverse Pan operation
Inverse Pan
r PAn
Tilt
Normal Tilt
tiL
Normal Tilt operation
Inverse Tilt operation
Inverse Tilt
r tiL
Display
Normal Display
diS
Change the LCD display text position
Inverse Display
r diS
Channel Mode
14-Channel
Mode
14CH Selects the DMX personality
8-Channel Mode
8CH
Manual Pan Restrict
Pan 540°
PA54
Select Pan angle restrictions
Pan 360°
PA36
Pan 180°
PA18
Manual Tilt Restrict
Tilt 270°
Ti27
Select Tilt angle restrictions
Tilt 180°
Ti18
Tilt 90°
Ti 9
Reset
rESt
Resets fixture
Load
LoAd
Load factory defaults
Movement Speed nous
ins
Increasing speed
dES
Decreasing speed
DMX Linking
The Intimidator™ Beam LED 350 can work with a DMX controller when
linked by DMX serial connections. Instructions for connecting and
configuring this product for DMX operation are in the User Manual. If you
are not familiar with DMX, download the DMX Primer
from
www.chauvetlighting.com.
Starting Address
To ensure full access to all channels in each DMX mode, the highest
recommended DMX address is 501.
Master/Slave
Connection
The Intimidator™ Beam LED 350 uses the DMX data connection for its
Master/Slave mode. Instructions for connecting and configuring this product
for Master/Slave operation are in the User Manual.
Note: The Intimidator™ Beam LED 350 can be connected in
Master/Slave with the Intimidator™
Spot LED 350, but the
Intimidator™ Beam LED 350 must be put in Slow Mode for the
products to sync correctly.
Do not change the Movement Speed on the Intimidator™ Beam LED
350 while the product is in motion. Stop the product before changing
speeds.

Intimidator™ Beam LED 350 QRG EN
6
DMX Values
8-CH
Channel
Function Value
Percent/Setting
1
Pan
000 255
0~540°
2
Tilt
000 255
0~270°
3 Color Wheel
000 006
White
007 013
Yellow
014 020
Pink
021 027
Green
028 034
Red
035 041
Light Blue
042 048
Kelly Green
049 055
Orange
056 063
Dark Blue
064 070
White + Yellow
071 077
Yellow + Pink
078 084
Pink + Green
085 091
Green + Red
092 098
Red + Light Blue
099 105
Light Blue + Kelly Green
106 112
Kelly Green + Orange
113 119
Orange + Dark Blue
120 127
Dark Blue + White
128 191
Color cycling rainbow with increasing speed
192 255
Reverse color cycling rainbow with
increasing speed
4 Gobo Wheel
000 047
Gobos 1-6
048 063
Animation Effect
064 079
Gobo 6 shake, from slow to fast
080 087
Gobo 5 shake, from slow to fast
088 095
Gobo 4 shake, from slow to fast
096 103
Gobo 3 shake, from slow to fast
104 111
Gobo 2 shake, from slow to fast
112 119
Gobo 1 shake, from slow to fast
120 127
Open
128 191
Cycle effect with increasing speed
192 255
Reverse cycling effect with increasing speed

EN Intimidator™ Beam LED 350 QRG
7
DMX Values (cont.)
14-CH
Channel
Function
Value
Percent/Setting
1
Pan
000 255
0~540°
2
Fine Pan
000 255
Fine control of panning
3
Tilt
000 255
0~270°
4
Fine Tilt
000 255
Fine control of tilting
5
Speed
000 255
Pan/Tilt speed (fast to slow)
6 Color Wheel
000 006
White
007 013
Yellow
014 020
Pink
021 027
Green
028 034
Red
035 041
Light Blue
042 048
Kelly Green
049 055
Orange
056 063
Dark Blue
064 070
White + Yellow
071 077
Yellow + Pink
078 084
Pink + Green
085 091
Green + Red
092 098
Red + Light Blue
099 105
Light Blue + Kelly Green
106 112
Kelly Green + Orange
113 119
Orange + Dark Blue
120 127
Dark Blue + White
128 191
Color cycling rainbow with increasing speed
192 255
Reverse color cycling rainbow with
increasing speed
8-CH (cont.)
Channel
Function
Value
Percent/Setting
5
No Function
000 255
No function
6 Prism/Frost
000 007
Open
008 012
Prism on
013 130
Prism rotation with increasing speed
131 247
Reverse prism rotation with increasing speed
248 255
Frost effect
7
No Function
000 255
No function
8 Shutter
000 003
Closed
004 007
Open
008 076
Strobe effect with increasing speed
077 145
Pulse strobe
146 215
Random Shutter
216 255
Open

Intimidator™ Beam LED 350 QRG EN
8
DMX Values (cont.)
14-CH
(cont.)
Channel
Function Value
Percent/Setting
7 Gobo Wheel
000 047
Gobos 1-6
048 063
Animation Effect
064 079
Gobo 6 shake, from slow to fast
080 087
Gobo 5 shake, from slow to fast
088 095
Gobo 4 shake, from slow to fast
096 103
Gobo 3 shake, from slow to fast
104 111
Gobo 2 shake, from slow to fast
112 119
Gobo 1 shake, from slow to fast
120 127
Open
128 191
Cycle effect with increasing speed
192 255
Reverse cycle effect with increasing speed
8
No Function
000 255
No function
9 Prism/Frost
000 007
Open
008 012
Prism on
013 130
Prism rotation with increasing speed
131 247
Reverse prism rotation with increasing speed
248 255
Frost effect
10
No Function
000 255
No function
11
Dimmer
000 255
0~100%

EN Intimidator™ Beam LED 350 QRG
9
DMX Values (cont.)
14-CH
(cont.)
Channel
Function Value
Percent/Setting
12 Shutter
000 003
Closed
004 007
Open
008 076
Strobe effect with increasing speed
077 145
Pulse strobe
146 215
Random Shutter
216 255
Open
13 Control Functions
000 007
No function
008 015
Blackout while pan/tilt moving
016 023
Blackout while moving color wheel
024 031
Blackout while moving gobo wheel
032 039
Disable blackout while pan/tilt/moving color
wheel
040 047
Disable blackout while pan/tilt/moving gobo
wheel
048 055
Disable blackout while moving all options
056 095
No function
096 103
Reset pan
104 111
Reset tilt
112 119
Reset color wheel
120 127
Reset gobo wheel
128 135
Reset gobo rotation
136 143
Reset prism
144 151
Reset focus
152 159
Reset all channels
160 255
No function
14 Auto Programs
000 007
No function
008 023
Auto program 1
024 039
Auto program 2
040 055
Auto program 3
056 071
Auto program 4
072 087
Auto program 5
088 103
Auto program 6
104 119
Auto program 7
120 135
Auto program 8
136 151
Sound-controlled program 1
152 167
Sound-controlled program 2
168 183
Sound-controlled program 3
184 199
Sound-controlled program 4
200 215
Sound-controlled program 5
216 231
Sound-controlled program 6
232 247
Sound-controlled program 7
248 255
Sound-controlled program 8

Intimidator™ Beam LED 350 GRR ES
10
Acerca de Esta
Guía
La Guía de Referencia Rápida (GRR) del Intimidator™ Beam LED 350
contiene información básica sobre el producto, como montaje, opciones de
menú y valores DMX.
Descargue el manual de usuario de
www.chauvetlighting.com para una información más detallada.
Exención de
Responsabilidad
La información y especificaciones contenidas en esta GRR están sujetas a
cambio sin previo aviso.
Notas de
Seguridad
Estas notas de seguridad incluyen información de seguridad importante sobre
el montaje, uso y mantenimiento.
•Este producto no está concebido para una instalación permanente.
•Conecte este producto SOLO a un circuito con toma de tierra y protegido.
•
Desconecte siempre de la alimentación antes de la limpieza o sustitución
del fusible.
•NO mire a la fuente de luz cuando el producto esté encendido.
•
Asegúrese de que el cable de alimentación no está retorcido ni estropeado.
•Nunca desconecte este producto del cable de alimentación agarrando o
tirando del cable.
•Cuando monte este producto en alto, use un cable de seguridad.
•NO permita la presencia de materiales inflamables cerca de la unidad
cuando esté en funcionamiento.
•NO toque este producto cuando esté en funcionamiento, pues podría estar
caliente.
•La tensión del enchufe al que conecte este producto ha de estar en el rango
establecido en el grabado o en el panel posterior de producto.
•¡Este producto es para uso en interiores solamente! (IP20) Para evitar
riesgos de incendio o descarga, no exponga este producto a la lluvia o la
humedad.
•
Monte siempre este producto en una ubicación con ventilación adecuada, al
menos a 50 cm de superficies adyacentes.
•Asegúrese de que ninguna ranura de ventilación en la carcasa de la unidad
queda bloqueada.
•Nunca conecte este producto a un atenuador o reostato.
•Sustituya el fusible con uno del mismo tipo y categoría.
•Use SOLAMENTE los soportes de colgar/montar o las asas para mover
este producto. NO lo transporte sujetando por la cabeza móvil.
•La máxima temperatura ambiente es de 104º F (40º C). No haga funcionar
este producto a temperaturas más altas.
•En caso de un problema grave de funcionamiento, deje de usarlo
inmediatamente.
•NO abra este producto. No contiene piezas reparables por el usuario.
Contacto
Fuera de EE.UU, Reino Unido o Irlanda, póngase en contacto con su
distribuidor para solicitar asistencia o devolver el producto. Visite
www.chauvetlighting.com para información de contacto.
