Introduction
Important Precautions
Safety Warnings & Instruction Labels
,GHQWL¿FDWLRQRI3DUWV
Charging the Batteries
Troubleshooting
Disassembling your Scooter
Functions
Kondor Cabin Variation
Safety Information and
Electromagnetic Interference (EMI)
6SHFL¿FDWLRQV
Warranty
Table of Contents
03
04
05
06
09
10
12
14
20
22
24
25
2

Thank you and congratulations on purchasing your new Abilize Mobility Scooter.
It is designed to provide you with transportation ability indoors and outdoors.
We pride ourselves on providing safe and comfortable products. Our goal is to ensure your
complete satisfaction. We sincerely hope you enjoy your Abilize Mobility Scooter.
Please read and observe all warnings and instructions provided in owner’s manual before
you operate the various functions of this scooter. Also, please retain this booklet for future
reference.
IF YOU HAVE ANY QUESTIONS, YOU CAN CONTACT:
UK Authorised Dealer
Information of European Representation
MedNet EC-REP GmbH
Borkstrasse 10,
48163 Muenster,
Germany
3
UK Authorised Dealer
UK Authorised Dealer
0333 015 5000
www.CareCo.co.uk
CareCo (UK) Limited,
1 Turing Court, Great Notley,
Braintree, CM77 7AT
CareCo (UK) Limited,
1 Turing Court,
Great Notley,
Braintree,
CM77 7AT
UKRP
MediMap Ltd, 2 The Drift,
Thurston, Suffolk, IP31 3RT

4
Important Precautions:
• Only one person at a time can ride the Scooter.
• Maximum load is 181KG / 400 lbs (Ranger), 200KG / 440lbs (Kondor).
•7XUQNH\RႇEHIRUHJHWWLQJRQRURႇ
• Always drive carefully and be aware of others using the same area.
• Always use pedestrian crossings wherever possible. Take extreme care when crossing roads.
• Do not drive on slope exceeding 9 degrees, and take extreme care when turning on a slope.
• Do not use full power when turning on a sharp corner.
• Take great care and drive in a low speed when reversing, riding downhill or on an uneven
surface, and climbing curbs.
•Please use the lowest speed when driving through a descending road or uneven terrain. If
VSHHGLVWRRIDVWOHDYH\RXUKDQGVRႇWKHKDQGOHEDUDQGOHWWKHVFRRWHUVWRS0DNHVXUH\RX
are safe and start again.
•7KHZHLJKWFDSDFLW\OLPLWFDQEHGLႇHUHQWGHSHQGLQJRQUDPSGHJUHH
•Aslow speed must always be used when ascending, descending or traversing a slope or
incline and also on uneven terrain, ramps and soft or loose surfaces, such as gravel or grass.
•To prevent any danger, do not turn around at high speed while ascending or descending
a ramp.
•Scooter may not operate well in high humidity.
• Do not leave the powered scooter in a rain storm of any kind.
•Direct exposure to rain or dampness will cause the scooter to malfunction electrically and
mechanically; may cause the powered scooter to prematurely rust.
•Never put scooter in neutral when driving on slopes.
•)ROORZWUDႈFODZVZKHQULGLQJRXWVLGH
• Do not sit on the scooter if taking on moving transport vehicles such as trains.

The following labels are positioned on your scooter, they communicate important warnings or
instructions regarding the safe operation of your scooter. Please carefully read all labels before driving.
Please read the instruction booklet carefully before using your scooter. Do not
drive the scooter on slippery surfaces or on slopes over 8 degrees. Do not drive on
highways, crowded roads, or unfamiliar areas. Do not turn at high speeds. Do not
wash with water or leave scooter in a humid environment as water can damage the
electronic parts.
Do not hang baggage or other objects on the tiller / tiller adjustment lever.
Information Sticker states the date of manufacture and serial number of the scooter.
Tiller angle adjustment.
N-D Lever Adjustment label which instructs freewheel mode operation.
Wiring diagram Label.
Ensure your hands are away from any moving parts before activating the door.
The DC 24/2A port is for LED reading light use ONLY.
Do not use the port to charge scooter or any other devices.
Tie-down points of the scooter. Do not sit on the scooter if taking on moving transport
vehicles. Tie-down points of the scooter. Do not sit on the scooter if taking on moving
transport vehicles.
Safety Warnings & Instruction Labels
WARNING! Do not operate longer than 20 minutes at one time, to cool completley after use.
Air Heater (6) (Optional)
With fresh air / heating air (for defrost or demist). Push the switch to position (6) for fresh air,
*Please do not put your hands near the vent after extended periods of time for heating air.
5

6
Before attempting to drive this scooter on your own, it is important that you familiarise
yourself with the controls and how to operate them. (Please refer to page 20 for Kondor
Cabin Scooter’s parts)
Figure 1 - Front View
Figure 2 - Top Control Panel Figure 3 - Back View
Hand Brake Angle Armrest
Adjustment
Rear Mirror
Left Turn
Indicator
Right Turn
Indicator
Power
Indicator
Headlight
Indicator
High Speed
Indicator
Wig Wag Captain Seat
Tiller Angle Adjustment Seat Back Angle
Adjustment
Rear Bag
Seat Adjustment Lever Rear Bumper
N-D Lever
Rear Indicator
5HDU5HÀHFWRU
Anti-Tip Wheels
Please turn to the next page for more information.
Swivel Lever
Headlight
Indicators
Front Bumper
Tiller Storage Compartment
6LGH5HÀHFWRUV

- Clock
- Temperature
- Speedometer
- ODO
- Trip Meter
Function of parts:
Main key switch (A)
• Turn the key to the right to turn the scooter on.
•7XUQWKHNH\WRWKHOHIWWRWXUQWKHVFRRWHURႇ
CAUTION: Always ensure that the scooter is
VZLWFKHGRႇEHIRUHJHWWLQJRQRURႇWKHVFRRWHU
and before removing any items from the scooter.
CAUTION: Turning the scooter OFF whilst driving
will bring the scooter to an abrupt stop.
Top Control Panel Symbols and meanings:
-Hazard light (B):6ZLWFKRQE\SUHVVLQJRQFHDQGRႇE\SUHVVLQJDVHFRQGWLPH:KHQ
\RXSUHVVRQFHWKHULJKWDQGOHIWOLJKWVDQGSDUNLQJLQGLFDWRUZLOOVWDUWWRÀDVKDQGZDUQLQJ
WRQHVZLOOVRXQG7KHKD]DUGOLJKWVZLOOFRQWLQXHWRÀDVKHYHQRIWKHNH\LVVZLWFKHGRႇ7KH
only way to stop the lights and sound is to press the hazard button a second time.
- Change mode by pressing once (C):
- Press the horn button (D): Once to sound warning tone when necessary.
- ‘Left Turn Signal (E): Press the Left Indicator button once to activate the front and rear
LQGLFDWRUVDQGZDUQLQJVRXQGV3UHVVWKHEXWWRQDVHFRQGWLPHWRVZLWFKWKHLQGLFDWRUVRႇ¶
- ‘Right Turn Signal (G): Press the Right Indicator button once to activate the front and rear
LQGLFDWRUVDQGZDUQLQJVRXQGV3UHVVWKHEXWWRQDVHFRQGWLPHWRVZLWFKWKHLQGLFDWRUVRႇ¶
- ‘Headlight (F):3UHVVKHDGOLJKWEXWWRQRQFHWRVZLWFKRQDQGDVHFRQGWLPHWRVZLWFKRႇ¶
- ‘Acceleration (H): Press acceleration button once to increase speed - option of 5 speeds
DYDLODEOH¶
- ‘Deceleration (J): Press deceleration button once to decrease speed - option of 5 speeds
DYDLODEOH¶
- ‘Hi/Lo Button (I): Press H/L Speed button once and the high/low speed indicator light
will come on which means you are driving in high speed mode. Press a second time and
the light will go out which means you are driving in low speed mode. (Hi/Lo speed will vary
GHSHQGLQJRQ\RXUFXUUHQWVSHHGVHWWLQJV¶
7
A
BH
CI
D
EFG
J

Tiller Storage Compartment (K):
Provides you spacious room for storage.
Hand Brake (L). Hold brake (L), when immediate stop is required.
CAUTION: If you have to brake in an emergency, simply release
the Throttle and hold the hand brake which will bring you to a halt!
Wigwag Lever Operation:
Pull the right-hand drive lever (N) carefully to travel forwards.
Pull the left-hand drive lever (M) carefully to travel in reverse.
(This can be reversed if required by local dealer.) Releasing both, engages automatic brake.
These are also your accelerators - The further you depress them, the faster you go. (Subject to the
position of the Rabbit / Turtle control).
CAUTION: Keep LCD display panel and Wigwag Lever dry. If panel and Wigwag Lever get
wet, allow to dry out before using.
Steering Adjustment:
Press angle adjustment (N)
down to achieve a comfortable
steering angle.
CAUTION: Do not make
adjustments whilst driving.
Ensure steering is at optimum
angle before and after use.
Seat Adjustment (P):
Pull the Seat Adjustment Lever (Q) to disengage the seat (P). Slide the seat forwards or
backwards into the required position. Let go of the lever (Q) again to lock the seat into its required
position.
CAUTION: Seat position should be set as far forward as is comfortable to prevent the
scooter tipping over.
&$87,212QFHRQWKHVFRRWHUVLW¿UPO\RQWKHVHDWGRQRWVWDQGRQWKHIRRWUHVWDVWKLV
could cause the scooter to tip over causing damage.
Angle Armrest Adjustment (R):
Pull the lever (S) and adjust the armrest to the required angle.
CAUTION: Pull the armrest up
ZKHQJHWWLQJRQRURႇWKHVFRRWHU
Do not hang heavy items on the
armrests as this could cause the
scooter to tip over. Basket
assembling and disassembling:
8
K
L
M
N
O
Q
R
S
P

Seat Swivel Adjustment:
Pull the lever (T) upwards to disengage and rotate seat (P) to required angle, Let go of the lever
(T) to lock the seat into its required position.
Seat Back Angle Adjustment:
Pull the lever (U) upwards to adjust
Pull the lever (U) upwards to adjust
EDFNUHVW¶VDQJOHWKHQUHOHDVHWKH
lever when adjusted to required
position, then release the lever when
adjusted to required position.
CAUTION: For safety reasons the backrest’s position must remain vertical before driving.
Seat Height Adjustment:
1. Remove seat (P) and rear shroud (Z).
2. Remove screw, nut and washer from seat post (V).
3. Adjust seat post (V) to desired height, and attached tightly with screw, nut and washers.
4. Then assemble the rear shroud (Z), seat (P) back to its original position.
(Height cannot be adjusted for the Kondor model)
Seat Electrical Lifter (Optional):
1. Press seat lifter button lightly (W) to raise the seat. Press lightly, to lower the seat.
CAUTION:
• Do not operate this function on a slope, or in motion or under unstable condition.
• The main purpose of this function is to assist you to reach certain height.
• Seat’s position must remain at the lowest before driving.
• Do not set N-D lever at N, before setting the seat at lowest position.
• Please keep the center of gravity of the scooter in the middle, to prevent the scooter
tipping over.
N-D Lever Adjustment:
When scooter has stopped or is
experiencing problems, press the
unlocking knob on the N-D lever (X).
Push the N-D lever forwards this
will allow you to push the scooter
by hand.
&$87,21)UHHZKHHORSHUDWLRQLVRQO\UHFRPPHQGHGRQÀDWVXUIDFHVQHYHURQVORSHV
1HYHUOHDYH\RXUVFRRWHURQDVORSHZLWKLWVHQJLQHVZLWFKHGRႇ$OZD\VVZLWFKWKHHQJLQH
on immediately after pushing the scooter.
CAUTION: The scooter won’t operate if it is
set at (N) position, to restore to it’s normal status,
\RXPXVWVZLWFKWKHSRZHURႇDQGDGMXVWWR'
position, then switch the power on.
s
9
U
T
P
V
W
P
DN
X
V

Proportion Speed Reduction:
1. The scooter is equipped with proportional speed reduction. It will automatically reduce speed
when encountering a corner, reducing speed corresponding to the angle of turn.
2. For safety reasons, when pushing the scooter by hand, if the pre-determined speed is
exceeded, the controller automatically switches on and brakes the scooter.
CAUTION: Avoid shifting your center of gravity as well as abrupt changes of direction when
the scooter is in motion.
CAUTION: Reduce speed before negotiating corners! Only accelerate when you have
¿QLVKHGWXUQLQJWKHFRUQHU
Tie-Down Hook:
To enable you to transport your scooter safely and
securely there are 2 additional tie down hooks located
on the underside of the scooter.
&$87,21:KHQ¿[HGRQDWUDQVSRUWDWLRQV\VWHP1'OHYHU;PXVWORFDWHGDW'SRVLWLRQ
The scooter must not be occupied or used as a seat on a moving vehicle whilst being
transported.
Charging the Batteries:
%DWWHULHVPXVWEHFKDUJHGEHIRUHXVLQJWKHVFRRWHUIRUWKH¿UVWWLPHDQGVKRXOGEHUHFKDUJHGDIWHU
each days use.
&$87,21(DFKFRXQWU\PD\VXSSO\GLႇHUHQWFKDUJHU7KHFKDUJLQJSURFHGXUHPD\EH
GLႇHUHQWIURPEHORZ,I\RXUHTXLUHPRUHGHWDLOVSOHDVHFRQWDFW\RXUDXWKRUL]HGGHDOHU
Be sure the scooter key is in the OFF position before charging.
Operating Instruction:
1. Always ensure the battery charger output voltage is the same as the connecting battery.
2. Plug in the power cord.
3. Connect the battery charger to the battery.
4. Start charging refer to charge levels indicated below.
y
y
y
y
y
y
y
y
Plug In:
Unplug:
Indicator:
1. Green Flash : Power On
2. Orange Flash : Pre-Charge
3. Orange : Charging
4. Green & Orange Flash : Charged 80%
5. Green : Full Charge
6. Red Flash : Defect
10
Y
E
A
C
B
D

11
l
Further issues:
If the above troubleshooting does not help to resolve
the issue please contact the authorised dealer (page 2).
Please have your serial no. to hand to provide to the
authorised dealer, which can be found on the battery pack.
Battery voltage is too high. This may occur if
overcharged &/or travelling down a long slope.
• If travelling down a slope, reduce your speed to
minimise the amount of regenerative charging.
• Check the battery and associated connections and
wiring.
7KHPRWRUKDVEHHQH[FHHGLQJLWVPD[LPXP
current rating for too long. This may be due to a
faulty motor.
• Check the motor and associated connections and
wiring.
•7XUQWKHFRQWUROOHURႇOHDYHIRUDIHZPLQXWHVDQG
turn back on again.
Either a park brake release switch is active or
the park brake is faulty.
• Check the park brake and associated connections
and wiring.
• Ensure any associated switches are in their correct
positions.
The throttle is out of neutral when turning the
controller on.
• Ensure the throttle is in neutral when turning the
controller on.
• The throttle may require re-calibration.
The throttle, speed limit pot or their associated
wiring may be faulty.
• Check the throttle and speed pot and associated
connections and wiring.
The motor or its associated wiring is faulty.
• Check the motor and associated connections and
wiring.
Battery low or
low battery fault
High battery
fault
Current limit
time-out
Park brake
ÀXLG
Throttle
OONAPU
Speed pot
fault
Motor voltage
fault
7
8
6
5
4
3
2
1
Other error
MeaningDescriptionFlash
The controller may have an internal fault.
• Check all connections & wiring.
The batteries are running low.
• Recharge the batteries for a minimum of 12 hours.

12
Troubleshooting:
1. ,IJUHHQLQGLFDWRULVRႇ
• Check AC input. If it works normally, the battery charger may be defective.
2. ,IJUHHQLQGLFDWRUNHHSVÀDVKLQJDQGZRQ¶WJLYHFKDUJLQJLQGLFDWLRQ
• Check if the battery is connected correctly.
• Check if the output connection is short or open.
• If the battery connection is correct, the battery charger may be defective.
3. ,IUHGLQGLFDWRUNHHSVÀDVKLQJ
• Check if the battery connection is reversed.
• Check if the output connection is short or open.
• Check if the environment temperature is too low (0ºC).
,IWKHUHGLQGLFDWRUVWLOONHHSVÀDVKLQJWKHEDWWHU\FKDUJHUPD\EHGHIHFWLYH
4. Charging indicator (orange) can’t turn to green:
• The battery may be defective please stop charging and have the battery replaced.
5. If the charging indicator (orange) turns green (fully charged) immediately:
• The battery may be in fully charged condition.
• If the battery is not fully charged, the battery may be defective.
&$87,217KHWLPHUHTXLUHGWRUHFKDUJHZLOOYDU\GHSHQGLQJRQWKHGHSOHWLRQRIWKH
EDWWHULHVDK%DWWHU\$SSUR[KRXUV'RQRWFKDUJHWKHEDWWHULHVIRUPRUHWKDQ
KRXUVDVWKLVFDQFDXVHGDPDJHWRWKHEDWWHULHV
CAUTION:
1. Before using the battery charger, read all instructions and cautionary markings.
2. Use the battery charger in a well-ventilated area.
3. To avoid the risk of injury, charge only lead-acid or gel cell type rechargeable batteries.
4. 3OHDVHWXUQRႇWKHSRZHUDIWHUFKDUJLQJ
Disassembling your Scooter
Seat (P) Disassembling:
Pull the lever (T) upwards to disengage the seat (P), hold the
VHDW3¿UPO\E\WKHEDFNUHVWDQGIURQWHGJHDQGUHPRYHLW
upwards from the scooter.
&$87,21,IWKHVHDWLVGLႈFXOWWRUHPRYHKROGVHDWVZLYHOOHYHU5DQGWKHQURWDWHWKH
seat to reduce resistance then pull up. Proceed with caution, if you need assistance, please
have someone to help you.
Rear Shroud (Z) and Batteries (C1) Disassembling:
1. Remove rear shroud (Z) upwards.
2. Unplug one battery connector (A1).
3. Release Velcro (B1).
4. Remove two batteries (C1).
P
T
A1
Z

CAUTION: Take into account the heavy
weight of the batteries (C1) please
consider your physical condition before
disassembling. DO NOT short-circuit
battery connector (C1). The red wire on
the battery connects to the red positive
location, and the black wire to the black
negative location. For safety, please wash
your hands after disassembly.
Resetting the Circuit Breaker:
You may need to reset the circuit breaker if the scooter does not turn on. The circuit breaker will
WULSLIWKHVFRRWHU¶VFLUFXLWLVRYHUORDGHG
1. To reset, press the circuit breaker button (D1) upwards.
2. Reassemble the rear shroud (Z).
3. Reassemble the seat.
CAUTION: If the circuit breaker trips repeatedly, IMMEDIATELY
XQSOXJFKDUJHUDQGFRQWDFWGHDOHURUDTXDOL¿HGWHFKQLFLDQ
CAUTION: NEVER defeat or bypass the circuit breaker. ONLY
replace with a circuit breaker of the same rating.
Obstacle climbing:
• Your scooter can climb obstacles and curbs of up to 60mm (Ranger) and 100mm (Kondor) in
height. Never attempt to overcome an obstacle when on an uphill or downhill gradient.
• Always approach obstacles straight on! Ensure that the front wheels and rear wheels move
over the obstacle in one stroke, do not stop halfway.
• The maximum gap the scooter can drive over is 220mm / 8.6”.
• When driving scooter on a ramp, adjust body centre of gravity accordingly.
Other information:
• In the unlikely event of panel display error, you will need to re-set the display system by turning
WKHRQRႇPDLQVZLWFK7KHGLVSOD\FLUFXLWLVVHSDUDWHIURPWKHPRWRUFRQWUROV\VWHP$GLVSOD\
FRQVROHHUURUGRHVQRWHႇHFWWKHVFRRWHUVSHHGFRQWURO
• Charge the batteries after each trip. If the scooter is not used for some time, batteries may lose
their charge. Batteries should be charged at least once a month.
• Check the battery gauge before driving to prevent power depletion.
• Do not disassemble the battery or open sealed parts by yourself to prevent electric shock and
burns from acid leakage.
•$GMXVWVSHHGWRDVORZVHWWLQJZKHQVWDUWLQJRႇWRSUHYHQWVXGGHQDFFHOHUDWLRQ
• Never attempt to drive downhill backwards.
• Try not to drive scooter at night or in rain or bad weather.
• If storing your scooter for a long time (1 month or more), make sure that batteries are fully
charged, then disconnect the plugs, and store the scooter in a dry location.
13
B1
C1
D1
C1

14
Function Buttons and Indicators:
1. Control Buttons - Hazard Light, Horn, Right Indicator, Headlight, Left Indicator,
Turtle(decelerate), H/L Speed, Rabbit(accelerate).
2. LED Indicators - Status Indicator (Green), Headlight Indicator (Green), Left / Right Indicators
(Green), High/Low Speed Indicator (Green).
3. Connector - 20PIN.
4. LCD Back Light - Blue LEDs illuminate while key on.
Function Descriptions:
5. Full Lighting Control - Headlight , Tail light, Left/Right Indicator, Hazard Light, Brake Light.
6. Speedometer - 7 Segment display (2 1/2 digits + 1 decimal) “km/h” and “mph” symbol.
7. Digital High / Low Speed Control - Low (L) Speed: 1 - 5 Rate, High (H) Speed: 1 - 5 Rate.
8. Power Indicator - Battery charging indicator (6 segments).
9. Malfunction Messages - Error code: 1-7 (1 digit) + LED Indicator.
10.Key On Display - LCD full segments display.
11. Warning Tone Setup - Volume adjustment for tones of Left/Right Indicator, Parking light,
Low voltage warning and horn.
Clock:
1. Timekeeping error per day - + 2 seconds.
2. Initial Display - Hour, Minute, Mode: AM 12:00.
3. Time Format (12 hours - AM/PM) 3UHVVµ0RGH¶EXWWRQDQGVZLWFKWRFORFNPRGH
Display range: AM12:00 - PM11:59.
++GLVSOD\7KH³RIWHQ¶VGLJLWLVLQYLVLEOHIURP¶FORFNWRR¶FORFN
4. Setup Mode (Time Adjustment) - Press + together for 3 seconds to enter setup mode.
:KLOHµ++¶LVÀDVKLQJSUHVVWRLQFUHDVHGLJLWVDQGWRGHFUHDVHGLJLWV3UHVVµ0RGH¶WR
HQWHUµ00¶VHWXSPRGHZKHQ¿QLVKHG7KHVDPHUXOHDSSOLHVLIµ00¶LVÀDVKLQJ
Press ( ) once to increase (decrease) one digit. The digits can increase (decrease)
accumulating when you press the buttons for more than 2 seconds. The display is cycling. It
takes 2 seconds to increase from 0 to 9 for each position.
(
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)

5. Quit Setup Mode - The user could quit the setup mode with the following conditions.
(1) Leave or buttons alone for 15 seconds.
3UHVVDQ\EXWWRQRI3DUNLQJOLJKW+RUQ,QGLFDWRURU+HDGOLJKWWKHGH¿QLWLYHVHWWLQJVZLOOEH
stored and return to normal clock mode.
Thermometer:
1. Operation Feature - Use thermistor (NTC) to detect the signal and transfers to related
temperature.
2. Display Errors - + 2ºC
3. Operational Mode of Thermometer -
3UHVVµ0RGH¶EXWWRQDQGVZLWFKWR
thermometer mode. Display range:
Centigrade -20 - 50ºC or Fahrenheit -4 - 122ºF.
4. Setup Mode (Unit Change) - Press + together for 3 seconds to enter setup mode. While
µ&¶µº)¶LVÀDVKLQJSUHVVRUWRVZLWFKWRµº)¶µ&¶
5. Quit Setup Mode - The user could quit the setup mode with the following conditions.
(1) Leave or buttons alone for 15 seconds.
3UHVVDQ\EXWWRQRI3DUNLQJOLJKW+RUQ,QGLFDWRURU+HDGOLJKWWKHGH¿QLWLYHVHWWLQJVZLOOEH
stored and return to normal thermometer mode.
Speedometer:
1. Operation Feature - Use optical coupler to detect the signal and transfer to related speed.
6SHHGGLVSOD\VNPKZKLOHLW¶VRQUSP
2. Display Errors - +15~20%.
3. Display Range / Operational Mode of Speedometer -
0.0 ~ 30.0, display resolution: 0.5
3UHVVµ0RGH¶EXWWRQDQGVZLWFKWRVSHHGRPHWHU
When “km/h” is displayed, speed will be indicated in km per hour. When “MPH” is displayed,
speed will be indicated in miles per hour. When “/h” is displayed, the function of speedometer
will be disable. (This display will be applied to the model that is not equipped with optical
coupler) And the display will be replaced to WIP (accelerator) operation indicator as follows:
Standby Indication Backward IndicationForward Indication
15

16
4. Setup Mode (Unit Change) - Press + together for 3 seconds to enter setup mode. While
µNPK¶µ03+¶LVÀDVKLQJSUHVVRUWRVZLWFKWRµ03+¶µNPK¶
The user could quit the setup mode with the following conditions.
(1) Leave or buttons alone for 15 seconds.
3UHVVDQ\EXWWRQRI3DUNLQJOLJKW+RUQ,QGLFDWRURU+HDGOLJKWWKHGH¿QLWLYHVHWWLQJVZLOOEH
stored and return to normal speedometer mode.
Odometer:
1. Operation Feature - Use optical coupler to detect the signal and transfer to related distances.
2. Unit Switch -:KHQVSHHGRPHWHUZDVVHWDVµNPK¶WKHRGRPHWHUGLVSOD\VDVNLORPHWHU
µPSK¶WKHRGRPHWHUGLVSOD\VDVPLOHµK¶PHDQVWKHRGRPHWHULVGLVSOD\LQJDVWUDYHOKRXUV
3. ODO Mode -
3UHVVµ0RGH¶EXWWRQDQGVZLWFKWR2'2PRGH
Display range : 0~99999
When the total distance goes
to 99999km or 62149mile
(99999÷1.609mile), the digits
will be reset to zero “0”.
TRIP Mode:
1. Operation Feature 3UHVVµ0RGH¶EXWWRQ
DQGVZLWFKWRµ75,3¶PRGH'LVSOD\UDQJH
0.0~999.9 When the distance goes to
999.9, the counter will stop.
2. Reset Mode (Rest TRIP to Zero) - Press + together for 3 seconds to enter setup mode.
:KLOHµ75,3¶LVÀDVKLQJSUHVVµ0RGH¶IRUVHFRQGVWRUHVHWWR]HURµ¶
3. Quit Setup Mode - The user could quit the setup mode with the following conditions.
(1) Leave or buttons alone for 15 seconds.
3UHVVDQ\EXWWRQRI3DUNLQJOLJKW+RUQ,QGLFDWRURU+HDGOLJKWWKHGH¿QLWLYHVHWWLQJVZLOOEH
stored and return to normal TRIP mode.
Notice to Routine Maintenance for certain mileage
1. Display I for Routine Maintenance - The initial mileage of routine maintenance is 5000km
'LVSOD\:KHQLWUHDFKHVWKHPLOHDJHIRUURXWLQHPDLQWHQDQFH2'2V\PEROZLOOVWDUWWRÀDVK
for 1 minute.
Time to display :
'XULQJÀDVKLQJWKHPRELOLW\YHKLFOH
could be driven normally and the control
panel could be operated without any delay.

2. Display II for Routine Maintenance - $IWHUWKHURXWLQHPDLQWHQDQFHLV¿QLVKHGWKHXVHUFRXOG
setup the mileage for next maintenance. (Count down setting) Setup steps:
3UHVVµ0RGH¶EXWWRQDQGVZLWFKWR2'2PRGH
.H\RႇWRVKXWGRZQWKHFRQWUROOHU
3UHVVµ0RGH¶DQGµ+/¶EXWWRQVWRJHWKHU
4. Key on to start the controller.
7KHGLVSOD\ZLOOHQWHUVHWXSPRGHLQVHFRQGVWKHPLOHDJHZLOOEHÀDVKLQJ1RWH
6. Press or button to adjust to the mileage for next maintenance. (Note 2)
$IWHUVHWXSLV¿QLVKHGSUHVVDQ\EXWWRQRIWKH3DUNLQJOLJKW+RUQ,QGLFDWRURU+HDGOLJKW
WKHGH¿QLWLYHVHWWLQJVZLOOEHVWRUHGDQGUHWXUQWRQRUPDOZRUNLQJPRGH
8. The display will quit to normal working mode if the user does not press the button within
10 seconds.
Note 1: Setup mode.
The mileage counts down to 0km. The mileage does not count down to 0km.
Note 2:
Press or button to adjust to the mileage for next maintenance.
Press to increase the mileage:
1000 - 2000 - 3000 - 4000 - 5000 - OFF - 1000. (Displays in cycling).
Press to decrease the mileage:
OFF - 5000 - 4000 - 3000 - 2000 - 1000 - OFF. (Displays in cycling).
Digital High/Low Speed Control
1. Operation Failure - 3UHVVµ+/6SHHG¶EXWWRQWRVZLWFK+LJK/RZVSHHG3UHVVRUWR¿QH
tune in 5 speeds.
2. Control Mode - 3UHVVµ+/6SHHG¶EXWWRQRQFH
the High/Low Speed Indicator (labelled H)
will light on. Press again, the indicator
OLJKWZLOOWXUQRႇ
Press button to increase the speed.
Press button to decrease the speed.
3. Usage Condition - While (1) controller
shut down (2) in charging-mode, the
function will be disabled.
17

18
Power Indicator
1. Discharge Capacity:
2. Operation Characters - The segments will not increase, only decrease.
3. Low Voltage Warning Tone - When the battery capacity is lower than 30%, the warning tone
will sound with 3 short double beeps.
4. )OLFNHU)UHTXHQF\ Once per two seconds.
5. Usage Condition - While (1) controller shut down (2) is in charging-mode, the function will
be disabled.
Charge Status
1. Charge Status - The charging status displays
with cycling segments.
2. Charging Indicating:
3. Increasing Ratio - 0.5 sound.
4. Operation Feature -
(1) The segments will only increase, not decrease.
(2) Take PIN3 (CH3) of charger as determinant signal. Whether the key is switched on or not,
the charging mode will be activated once CH3 is connected to Ground (L).
7KH/&'EDFNOLJKWZLOOEH21ZKLOHDQ\EXWWRQLVSUHVVHG,WZLOOOLJKWRႇDXWRPDWLFDOO\LQ
seconds if no button has been pressed.
5. Remarks - Displayed segments are for reference only. Please refer to indicator of charger for
more accurate charging status.

Malfunction Messages
1. Operation Feature - Take the connector pin (KEY) of controller as determinant signal, then
converts it into digital codes.
2. Usage Condition - :KHQWKHFRQWUROOHUVHQGVRXWDQHUURUPHVVDJH/('VWDUWVÀDVKLQJ
DQGZLOOGLVSOD\WKHµ(UURUPHVVDJHFRGH¶DVIROORZV
Key On Display
1. Initial Status - When scooter power is on, the back light and all LCD segments will be tuned
on for 3 seconds, then switch to the default working mode automatically.
19
/
/
/
/
/
/
/
/
/
/
//
/
/
/
/
/
/
/
/
/
Battery needs charging soon.
Low voltage, needs charging now
Over voltage
Over current
Park Brake is lost or faulty
Accelerator Others
Accelerator is broken or faulty
Motor is broken or faulty
Others

Kondor Cabin Variation
%HIRUH\RXWDNH\RXU¿UVWWULS\RXVKRXOGIDPLOLDUL]H\RXUVHOIZHOOZLWKWKHRSHUDWLRQRIWKHVFRRWHU
and with all operating elements. Take your time to test all functions and driving modes.
Cabin Door
Cabin Side Window
1. Turn the handle upwards (clockwise) to lock the door.
2. Turn the handle downwards (anticlockwise) to unlock the door.
3. Watch your head when getting into the scooter.
*Ensure your hands are away from any moving parts before activating or closing the door.
Lock
Open
1. Slide the window forwards to close it, backwards to open it.
2. Do not leave the windows open when the scooter is not in use.
5XEEHUVWULSVPD\EHORRVHRURႇVLGHDIWHUDSHULRGRIXVDJH
\RXPD\QHHGWRDGMXVWRUUHSODFHWKHSDUWVLIWKHVWULSLVQRW¿UPO\
sealed. Please contact the dealer for assistance.
20
Interior Rearview Mirror
22” Captain Seat
Door Handle
6LGH5HÀHFWRU
Rear Bumper
Rear Mirror
Windshield Wiper
Hand Brake
Headlight
Turn Signal
Front Bumper
Other manuals for ranger
1
This manual suits for next models
3
Table of contents
Other Abilize Scooter manuals
