Usage and Maintenance Instructions
www.careco.co.uk CareCo, Hubert Road, Brentwood, Essex, CM14 4JE
Titan Mobility Scooter - MS03039
Standard Packing List:
• 1 Owner’s Manual
• 1 Battery Pack
• 1 Seat with Armrests
• 2 Keys
• Battery Charger
• Seat Post Nut and Bolt or Detent Pin
Thank you for purchasing your Titan Scooter. We are delighted you have chosen
CareCo (UK) Ltd for your mobility needs.
Product Code: MS03039

www.careco.co.uk CareCo, Hubert Road, Brentwood, Essex, CM14 4JE
Titan Mobility Scooter - MS03039
2
Disclaimer
We ask that you read this manual completely before operating your new TITAN scooter.
CareCo (UK) Ltd is not, and cannot be held responsible for, any damage or injury incurred due to improper or unsafe use of the
CareCo TITAN scooter.
CareCo (UK) Ltd specifically disclaims responsibility for any bodily injury or property damage that may occur during any use
that does not comply with applicable laws.
Congratulations on the purchase of your new TITAN scooter. The TITAN combines cutting edge technology with attractive de-
sign which is highly functional in today’s world. We at CareCo (UK) Ltd know that you have chosen a scooter that will give you
years of dependable operation and will also enhance the quality of your life by providing you with the mobility to experience
an active daily lifestyle.
Even though your new TITAN is both user-friendly and designed for maximum manoeuvrability in the tightest spaces, we ask
that you please read, understand and follow all of the instructions and suggestions in this manual before you operate your
scooter for the first time. The safe use of your new scooter is very important to us.
If you feel that you do not understand the instructions and suggestions presented in this Owner’s Manual, or if, for any reason,
you do not feel capable of performing the activities necessary to assemble, disassemble, operate, or maintain your TITAN,
please contact CareCo Customer Services on 0845 611 8022 or email: [email protected].
CareCo (UK) Ltd cannot be held responsible for personal injury or property damage resulting from the unsafe or the improper
use of any of our broad range of health and personal mobility products. Also, CareCo (UK) Ltd cannot be held responsible for
personal injury or property damage resulting from attempts to follow instructions, suggestions, and guidelines presented in
this Owner’s Manual.
Our Research and Development Department, our Quality Control Department, and our Engineering Department have used the
latest product specifications and the latest product design information to manufacture your TITAN scooter. CareCo (UK) Ltd
reserves the right to implement changes into our product lines when those changes become desirable or necessary. If changes
are implemented into our product line, there may be minor differences between the product you purchased and the illustra-
tions and instructions in this Owner’s Manual.
We at CareCo (UK) Ltd would appreciate hearing about the dependability of your TITAN and about the convenience of mobility
it has provided for you. We would also appreciate hearing about the service you received from our Company.
CareCo (UK) Ltd. Customer Services Phone: [phone]
Hubert Road Fax: [phone]
Brentwood
Essex
CM14 4JE
www.careco.co.uk
For more information about our products and services, or to send us your comments, please visit our website at
www.careco.co.uk or email: [email protected]

www.careco.co.uk CareCo, Hubert Road, Brentwood, Essex, CM14 4JE
Titan Mobility Scooter - MS03039
3
Contents
1. Preface and introduction 4
2. Safety notice
2.1 Before driving 5
2.2 While driving 5
2.3 Labelling 7
3. Parts introduction
3.1 Parts description 9
4. Operation
4.1 Control panel 10
4.2 How to operate your scooter 10
5. Battery charging and care
5.1 Charging the battery 13
5.2 Batteries 14
6. Inspection and maintenance
6.1 Inspection 16
6.2 Regular checking record 16
6.3 Battery, fuse and tyres 17
6.4 Storage 17
6.5 Manually moving the scooter 18
7. Trouble shooting and specification 19
8. Warranty 22

www.careco.co.uk CareCo, Hubert Road, Brentwood, Essex, CM14 4JE
Titan Mobility Scooter - MS03039
4
Please carefully read this owner’s manual before using the vehicle. Improper use of the vehicle could result in harm, injury
and/or traffic accidents.
• This owner’s manual includes operation instructions for every aspect of the vehicle.
• The symbols used in this manual are explained below:-
• This manual includes a copy of repair and maintenance record chart and warranty information.
Please keep it in a safe place or in the scooter.
• If someone else uses the scooter, please make sure that you provide them with the instruction manual for their
consideration.
• As designs change some illustrations and pictures in the manual may not correspond to the vehicle that you
purchased. We reserve the right to make design modifications.
Our scooters have been designed and manufactured to provide a comfortable and secure yet affordable solution for some
mobility requirements.
Warning Improper usage could result in serious injury or death
Attention Improper usage could lead to injury and/or damage to your scooter.
Suggestion Follow these instructions to keep your vehicle in a good operating order.
1. Preface and introduction
Suggestion
To maximise the efficiency and service life of your batteries, please fully charge before their first use.

www.careco.co.uk CareCo, Hubert Road, Brentwood, Essex, CM14 4JE
Titan Mobility Scooter - MS03039
5
2.1 Before driving
The user should become familiar with the usage and operation of this vehicle before driving. Please follow the
recommendations in this safety notice.
The same traffic rules apply to the use of this vehicle as apply to pedestrians
For your safety, please therefore follow the rules that apply to pedestrians.
• Ride on the pavement, single carriage roads, or pedestrian areas only. Never ride on motorways or dual
carriageways.
• Please do not drive your scooter after consuming alcohol or when you are tired.
• Please be careful when driving your scooter in low light; it has not been designed for use at night.
• Be extremely cautious when driving your scooter on busy streets or in shopping malls.
Practice operating your vehicle
Before using the scooter familiarise yourself with its operation. Practice in a wide and open area such as a park.
In order to avoid accidents whilst driving, please take care when accelerating, stopping, turning, reversing and
travelling up and down ramps.
• Please turn the speed dial to value 3 for your initial practice.
• Be sure someone accompanies you for safety when driving for the first time.
• Only use higher speed setting when you are confident that you can easily operate and control your scooter.
The scooter is only to be used by one person at a time
Do not carry passengers on your scooter (including children)
Do not use this vehicle to carry or haul goods
• As the maximum weight can be carried please refer to ‘MAX USER WEIGHT’ in ‘7. SPECIFICATION’
• Maximum loading weight for the basket is 3 kg (7lbs).
2.2 While driving
Do not alight from the vehicle while moving
• Such action may cause you to lose balance and risk injury from falling.
• Ensure that your clothes do not tangle in the wheels.
Do not use your vehicle under the following conditions:-
• On surfaces that are muddy, gravelly, bumpy, narrow, snowed over, icy, or canal towpaths not guarded by
a fence or hedge. Keep away from places where the wheels may get stuck.
• Do not drive at night or in rain, snow, fog or strong winds.
• Do not drive your vehicle in an ‘S’ pattern or make erratic turns.
• Do not take the scooter onto escalators.
Under no circumstances should the scooter be used as a seat in a motor vehicle (e.g. Cars, buses, trains, etc).
2. Safety notice

www.careco.co.uk CareCo, Hubert Road, Brentwood, Essex, CM14 4JE
Titan Mobility Scooter - MS03039
6
Mobile phones and other electrical equipment
• Do not use a mobile phone or other wireless communication devices while driving.
• Always switch off the scooter and remove the ignition key before using a mobile phone.
• Do not charge the mobile phone or any other electrical devices from your scooter’s battery.
Automatic Power Shut Down
In order to avoid accidentally draining the batteries, your scooter is equipped with an automatic power
shut down facility. If the scooter is left switched on, but remains undisturbed for a period of 30 minutes,
it will automatically turn off. When this happens, simply switch your scooter off and back on and it will
be ready to use once again.
Ramps, inclines and descents
• Do not drive onto ramps greater than the specified gradient. Refer to the section entitled ‘CLIMBING ANGLE’ in
‘7. SPECIFICATION’.
• Always use a low speed setting when ascending or descending a gradient.
• Do not drive on roads with uneven surfaces or potholes.
• Slow down when driving uphill.
• Do not make sudden turns when driving on gravel roads or ramps.
• Always lean forward when climbing a steep hill.
Starting and Driving
1. Make sure the seat is installed properly.
2. Make sure the tiller has been secured properly.
3. Fold down the armrests so you can rest your arms on them.
4. Turn the power switch to ‘ON’. If necessary, turn on the headlights.
5. Check battery indicator to see whether there is enough power for your journey. If you have any doubt
about the remaining power, please recharge the batteries before departure.
6. Set the speed dial to a position you feel safe and comfortable with.
7. Check the forward/reverse speed lever works correctly.
8. Make sure the electromagnetic brake works correctly.
9. Before driving, check your way is clear. Engage the 4 mph switch if you are driving on the pavement.
Warning !
• Do not set in the freewheel mode when driving on a gradient.
• Always re-engage the anti-freewheel device before use. Failure to do so may result in injury.
• To protect your safety, the power will automatically cut off and the electromagnetic brake system will activate
while you are driving down a steep slope. This will limit the speed to a safe level. Turn the power on again to
re-start your scooter.
• Maximum User Weight Limit
Refer to section entitled ‘MAX. USER WEIGHT’ in ‘7. SPECIFICATION ‘. Overloading past the weight limit may
lead to damage of your scooter or cause it to malfunction which could endanger your safety. The warranty does
not cover this type of damage.

www.careco.co.uk CareCo, Hubert Road, Brentwood, Essex, CM14 4JE
Titan Mobility Scooter - MS03039
7
Attention
1. Do not push both RH & LH sides of the speed control lever simultaneously – control of your scooter will be
affected.
2. Do not turn the power switch to OFF while driving as this will lead to an emergency stop and possible risk of
accident and injury.
3. Do not set to the highest speeds while driving indoors.
4. Do not adjust the speed dial while driving - a sudden change in speed may cause danger to you and others;
and may cause damage to your scooter.
5. Do not place magnetic devices near the area of the operation handle as this could affect the safe operation of
your scooter.
6. Do be careful whilst driving in heavy traffic or crowded areas.
7. When reversing the vehicle, beware of people or objects behind you.
Stopping
1. Release the speed control lever completely. The vehicle will naturally brake and stop.
2. Turn the power switch to OFF. Then pull out the key.
Driving on the pavement
• Ensure the 4 mph limit switch is set to the slowest setting when using the scooter on the pavement.
• This will limit the scooter to a maximum speed of 4 mph. It is an offence to travel at more than
4 mph on the pavement.
• The limit switch can be set to the fastest setting for use on the road or on private ground.
2.3 Labelling
Please carefully read all labels on the scooter before driving it. For your future reference, do not remove them.
 Warning
Do not operate the scooter unless the handle bar is in a locked position.
Do not lean against or pull forward on the handle bar while mounting or
dismounting from the scooter. Serious harm or injury can occur.
The manufacturer disclaims all responsibility for any personal injury or
property damage which may occur as a result of improper use of its
products.
Never lift the scooter up by the
front or rear shroud

www.careco.co.uk CareCo, Hubert Road, Brentwood, Essex, CM14 4JE
Titan Mobility Scooter - MS03039
8
Warning:
Radio waves may affect scooter control.
Radio wave sources, such as radio stations, amateur radio (HAM) transmitters, two-way radios, and cellular
phones,can affect powered motorised scooters. Following the warning listed below should reduce the chance of
unintended brake release or powered scooter movement which could result in serious injury.
1. Do not turn ON hand-held personal communication devices, such as citizens band (CB) radios and mobile phones,
while the powered scooter is turned ON.
2. Be aware of near by transmitters, such as radio or TV stations, and try to avoid coming close to them.
3. If unintended movement or brake release occurs, turn the powered scooter OFF as soon as it is safe.
4. Be aware that adding accessories or components, or modifying the powered scooter, may make it more
susceptible to interference from radio wave sources. (Note: There is no easy way to evaluate their effect on a
powered scooter.)
5. Report all incidents of unintended movement or brake release to CareCo, and note whether there is a radio wave
source nearby.

www.careco.co.uk CareCo, Hubert Road, Brentwood, Essex, CM14 4JE
Titan Mobility Scooter - MS03039
9
3. Parts information
3.1 Parts description
1. Indicator Lamp
2. Charger Socket Cover
3. Basket
4. Tiller Adjust Lever
5. Head Lamp
6. Seat
7. Side Reflector
8. Rear Lamp
9. Anti-tip Wheel
10. Rear Reflector
11. Fold up and Width adjustable armrests
12. Rear Pocket
1
2
11
9
6
7
3
4
5
12
10
8

www.careco.co.uk CareCo, Hubert Road, Brentwood, Essex, CM14 4JE
Titan Mobility Scooter - MS03039
10
4.1 Control panel
1. Speed Dial
2. Horn Button
3. Indicator lamp switch
4. Head light / Rear Light Button
5. Battery Indicator
6. Emergency lamp switch
7. Indoor/Outdoor switch
4.2 How to operate your scooter
Power switch
Turn the key to power ON or OFF
On: Power is turned on
Off: Power is turned off
Speed dial
Turn this dial to determine to the speed range of the scooter. Turn the dial anti-clockwise to go slower and
clockwise to go faster.
Forward, Reverse, and Braking
• Push the speed control lever forwards with your right thumb and the vehicle will move forward.
• Push the speed control lever forwards with your left thumb and the vehicle will move backward.
• The horn will beep when the vehicle is in reverse.
• Release the speed control lever freely while either going forward or reverse, and the electromagnetic brake in
the motor will be activated, and the vehicle will stop.
Indicator Lamp Switch
• The light will flash and buzzer will make a beeping sound when turning the switch to the left or right.
• Return the switch back to the middle, and the indicator will be cancelled.
Horn Button
Press the horn button to sound the horn. Release the button to stop the horn.
Light Button
Push the light button to switch the front and rear lights on.
Push the button again to turn the lights off.
Battery Indicator
• When the power switch is turned on the battery indicator will show red, yellow, and green squares indicating
the remaining battery power.
• The remaining power indicated by the battery indicator will vary by the actual driving time incurred and how
you drive. Repeated starting, stopping, climbing will consume the power more quickly.
4. Operation
12
6
7
3
4
5

www.careco.co.uk CareCo, Hubert Road, Brentwood, Essex, CM14 4JE
Titan Mobility Scooter - MS03039
11
Suggestion
1. You should recharge the batteries after each time the vehicle is used to ensure maximum range. The batteries
should be charged at least twice a week even if the scooter is not used.
2. After charging or replacing the batteries, drive the vehicle for 2-3 minutes to make sure the battery capacity is
sufficient.
3. In winter, the batteries may respond slower and the battery range may be reduced.
4. When driving on a slope or hill, the battery indicator light might move up and down.
This is normal and there is no need for concern.
5. Even if the batteries are used properly, it is natural for their capacity will reduce in time and this will result in
reduced range compared to brand new batteries. When the batteries’ range is approximately 50% of that
when new, it is time for replacements. Please contact CareCo regarding replacement batteries.
If you continue to use the old batteries, the performance of your scooter may be affected.
6. The battery range will be reduced when frequently driving uphill or on rough ground, as this leads to greater
consumption of power.
7. The batteries have a six-month warranty covering manufacturing defects. This warranty does not cover faults
due to incorrect battery recharging.
Braking
Electro-magnetic brake: Release the speed control lever completely, and the electromagnetic brake will be
activated automatically, and the scooter will stop.
Seat
• The seat can be turned to 45 degrees or 90 degrees.
• Pull the seat adjustment lever forward and swivel the seat.
• Release the lever, then continue swiveling the seat until it locks in position.
Warning
When on a gradient NEVER switch the vehicle to the freewheel mode. The electromagnetic brakes will NOT be
applied and this may result in injury.
Attention
• Return the seat to the forward position before driving.
• Ensure the limit switch is set to the slowest setting when using the scooter on the pavement. It is an offence
to exceed 4mph on the pavement.

www.careco.co.uk CareCo, Hubert Road, Brentwood, Essex, CM14 4JE
Titan Mobility Scooter - MS03039
12
How to adjust the armrest width
Loosen the knobs at the back of the seat frame first, then adjust the arm-
rest width by sliding the armrest. Once satisfied with the width, tighten
the knob.
How to re-position the seat
Slide the seat backwards and forwards for a comfortable driving position.
To slide the seat, pull the lever at the front the seat and reposition as
required.
Tiller Adjustment
The tiller can be adjusted to several positions to ensure your comfort.
1. Push (or pull) the lever to adjust the tiller to the position that
suits.
2. Release the lever to secure the tiller.
Manual Brake
If your scooter is equipped with a manual brake, squeeze the brake lever
to apply and then release the lever to release the brake. The manual brake
tightness can be adjusted by the brake cable adjuster near the left-hand
side wheel.
Main Circuit Breaker (Reset Button)
When the voltage in your scooter’s batteries becomes low, or the scooter
is under strain due to excessive loads or steep inclines, the main circuit
breaker may trip to protect the motor and electronics from damage.

www.careco.co.uk CareCo, Hubert Road, Brentwood, Essex, CM14 4JE
Titan Mobility Scooter - MS03039
13
5. Battery charging and care
5.1 Charging the battery
Follow the procedure below step by step:
1. Turn the power switch to OFF.
2. Connect the charger’s power cord into the power outlet.
3. Open the charging socket cap on the scooter’s tiller; then connect
the charger’s round plug to the charging socket.
4. Turn on the switch on the charger.
5. Both the charger’s red and orange LEDs will be illuminated when
beginning to charge. The charging duration is 6 to 8 hours.
To ensure optimum performance a 10 to 12-hour charge is
recommended. We do not recommend a charge of more than 24
consecutive hours.
6. Both the charger’s LEDs will be illuminated during the charging
process. The orange LED will turn green when charging is complete.
7. Turn off the charger; disconnect the power cord and the round plug
from charger socket on the scooter.
Warning
• The fan inside the charger will be activated accordingly when you turn on the charger. If the fan does not work
when connected to the charger or the green light is not showing, DO NOT use this charger. The charger may
overheat and cause a fire as a result.
• There is a red LED present on the charger to illustrate operation. If this LED does not illuminate the charger is
defective - please contact CareCo Customer Service on 0845 611 8022 or email: [email protected]
Attention
• When returning the battery pack to the battery pack cavity of the shroud, again, beware of trapping fingers or
hands.
• A flap at the end of battery pack can be opened to place your bag (not over 3 kg).
Warning
1. Keep away from flammable objects while charging due to danger of fire or explosion of batteries.
2. Do not smoke while charging as the batteries may release hydrogen gas. Always charge your batteries in a
well-ventilated area.
3. Never connect or disconnect the plug or cord with wet hands while charging. Do not connect or disconnect the
plug or cord when they are wet as this may cause an electric shock.
NOTE: The immovable function will be activated when your scooter is in charging status; your scooter will not move.

www.careco.co.uk CareCo, Hubert Road, Brentwood, Essex, CM14 4JE
Titan Mobility Scooter - MS03039
14
5.2 Batteries
• Do not expose the batteries to temperatures below 10°C or above 50°C when charging or storing the vehicle.
Under or above temperature range can cause the battery either to freeze or over heat. This will damage the
batteries and shorten their life.
• These batteries are maintenance free and there is no need to refill with water.
• You are required to recharge the batteries on a regular basis. Even if the scooter stands idle, you should charge
the batteries at least once a week.
• The batteries carry a six-month manufacturer's warranty. This warranty only covers issues relating to
manufacturing faults, and not faults relating to failure to recharge as instructed above.
Attention- Please follow the rules below to avoid accidents while charging.
1. Please use the CareCo charger only, and recharge the battery to its full capacity every time.
You may damage the battery and scooter if you use a charger, which is not to the correct specification.
2. Please charge in a well-ventilated space where it is not directly exposed to the sunlight. Do not charge in
humid, damp or wet surroundings.
3. Do not charge in temperatures less than -10°C or higher than +50°C as the charger may operate correctly and
the batteries may become damaged.
Suggestion – How to maximise your batteries efficiency and service life
1. Fully recharge your new batteries before their first time use.
2. Be sure to charge the batteries fully every time. The battery life will be seriously shortened or decayed if the
battery is repeatedly used without being fully charged.
3. Always complete the charging – the orange LED light may turn green after 1-4 hours but continue charging for
the specified time. NEVER stop charging before it is complete.
4. Keep your batteries fully charged whenever possible.
5. If you do not use your scooter for a long time, the batteries should be charged at least once a week to keep
them in a fully usable condition.
6. The ambient temperature will affect charging time. Charging time will be longer in the winter.
7. After charging, do not leave the charger socket plugged in to the scooter - this will cause a power drain on
the scooter and temporarily reduce its range.

www.careco.co.uk CareCo, Hubert Road, Brentwood, Essex, CM14 4JE
Titan Mobility Scooter - MS03039
15
Warning
1. The wiring system and charger are placed correctly in the battery pack during assembly by the manufacturer.
Do not attempt to re-locate the wiring system by yourself. The improper layout of wiring system may result
in the wires pinched by battery box, which could result in an electronic system failure.
2. Be sure the battery wires are connected to their correct battery terminal.
Suggestion
If necessary, ask for help from CareCo for advice about maintaining and replacing the battery. Contact Customer
Services on 0845 611 8022 or email: [email protected]
Suggestion
A larger 50Ah battery can be fitted.
Suggestion
1. Make sure the terminals are installed properly and replace the cover.
2. Do not use the battery to charge telecom equipment or other items.
3. Battery efficiency will vary with outside conditions; the driving distances will be shorter in the winter.
If the vehicle is not used for a long time, please charge the batteries at least once a week.
4. Replace both batteries together.

www.careco.co.uk CareCo, Hubert Road, Brentwood, Essex, CM14 4JE
Titan Mobility Scooter - MS03039
16
6.1 Inspection
• Clean the scooter with a damp cloth and dust down approximately once a week to preserve the appearance of
the scooter.
• Adjust the tiller height and return to the original position and swivel the seat once a week to ensure the parts
adjust and remove smoothly and easily when required.
• Check for signs of wear and tear on the tyres and the upholstery on a regular basis.
• For optimum performance and to increase the lifespan of your scooter, it is recommended that you have your
scooter serviced once a year.
6.2 Regular checking record
To make sure your scooter is correctly serviced, contact CareCo regarding regular maintenance checks.
This should be at intervals of six months following an initial inspection after one month. These checks may be
chargeable.
6. Inspection and maintenance
YEAR 1 2 3 4 YEAR 1 2 3 4
Service Dates Service Dates
Controller Upholstery
On/ Off Switch Seat
Control Lever Back
Braking Armrests
Recharge Point Electrics
Batteries Connections Condition
Levels Lights
Connections Test Run
Discharge Test Forwards
Wheels and Tyres Reverse
Wear Emergency Stop
Pressure Left Turn
Bearings Right Turn
Wheel Nuts Slope Test
Motors Over Obstacles
Wirring List Items repaired
Noise
Connections
Brake
Chasis
Condition
Steering

www.careco.co.uk CareCo, Hubert Road, Brentwood, Essex, CM14 4JE
Titan Mobility Scooter - MS03039
17
6.3 Battery, fuse and tyres
Battery
Refer to the section entitled ‘5.2 Battery’ in ‘5. Battery charging and care’.
Fuse
If the battery charger is turned on and no LEDs are lit, check the fuse.
Tyres
The condition of the tyres depends on how you drive and use your scooter.
• Inspecting tyre tread
• Please check the tread groove regularly. Replace the tyres when the tread groove is less than 0.5 mm.
Suggestions
Ask for help from CareCo to inspect or replace the fuse, as the tiller shroud has to be removed before the fuse
can be replaced. Contact Customer Services on 0845 611 8022 or email: [email protected]
Suggestions
• Do not splash water directly onto your scooter when washing as this could lead to malfunction of the system
electrics.
• Do not use petrol or solvents as these may damage the shrouds.
• Do not use wax.
Attention
1. When tread depth is below 0.5mm the scooter may not grip well making braking distances longer.
Therefore replace the tyres as soon as they are found to have insufficient tread depth.
2. The tyre pressure should be kept at about 26 PSI (approx. 1.8KG/cm) for the best ride and handling.
Attention
When carrying out maintenance of your vehicle, please turn the power switch to OFF and remove the
charger leads.
6.4 Storage
Make sure the vehicle is stored as follows:-
- The seat is set in the ‘Forward’ position
- The Power switch is turned to ‘OFF’

www.careco.co.uk CareCo, Hubert Road, Brentwood, Essex, CM14 4JE
Titan Mobility Scooter - MS03039
18
Suggestions
Store your Titan scooter out of direct sunlight, rain, and damp conditions. When storing for a length of time, please
charge the batteries to full power and then disconnect the battery terminal. For details contact CareCo Customer
Services on 0845 611 8022 or email: [email protected]
6.5 Manually moving the scooter
• Turn the power switch to off before moving.
• Lift the scooter by the chassis, and not by the bumpers. Lifting the scooters by the bumpers could cause
damage or injury.
• For your safety, always ask for help. 2 or 3 persons will be needed when moving or lifting the vehicle.

www.careco.co.uk CareCo, Hubert Road, Brentwood, Essex, CM14 4JE
Titan Mobility Scooter - MS03039
19
7. Trouble shooting and Specification
Symptom Remedy
The scooter will not switch on: • Try recharging the batteries.
• Check the fuse and circuit breaker in the scooter.
The scooter switches on, but the scooter will not move: • Ensure there is enough power in the batteries;
if not, recharge.
• Ensure the freewheel lever is engaged in the
‘DRIVE’ position.
The scooter appears slow: • Check the battery power level and recharge.
• Check the speed dial is not set to slow.
The seat turns when in operation: • Slowly rotate the seat until it drops into place
and is secure.
The handlebar appears loose: • Tighten the height adjustment handle to secure
the handlebar.
Horn sounds involuntarily: • Ensure that the wigwag paddle is released.
• Switch the scooter off and on.
• Recharge the batteries.
• If problem persists contact CareCo.
The LED lights will ‘blink’ if there is a problem with your Titan scooter. The list below will assist you in identifying any
possible malfunction.

www.careco.co.uk CareCo, Hubert Road, Brentwood, Essex, CM14 4JE
Titan Mobility Scooter - MS03039
20
Fault Codes Description Meaning
1 Low battery warning only
(no fault generated)
The battery needs to be charged.
2 Battery voltage is too low The battery needs to be charged.
3 Battery voltage is too high The battery is over charged or the speed is too high
when driving down a slope.
4 Time out for maximum current The motor is stalled or the controller outputs the
maximum current for more than 15sec.
5 Park brake fault Check park brake connection.
6 Speed pot neutral fault Calibrate speed pot neutral.
7 Speed pot error Check speed pot connection.
8 Motor error Check motor connection.
9 Other errors Internal error.
