ABK AXT8900 User manual

AXT8900 IP PA Intercom-based Server
www.abk-pa.com
User Manual
2U
7U

Warning！ Please follow the requirements below in order to lower the risk
of electric shock and damage to the equipment:
● Must use a separate three-pin power outlet with a grounding wire.
● Avoid squeezing, knotting or damaging the power cord. If the power cord
is damaged, please contact the dealer immediately. After the power cord is
replaced, the system can be powered on. Otherwise, it may cause electric
shock or even fire.
● Unplug the power when repairing or cleaning the surface.
● Do not directly pull the power cord when unplugging the power plug, in
case of breaking or even electric shock; It is forbidden to place inflammable
and explosive materials near the host to prevent explosion and fire.
● The host is required to be placed horizontally on the plane, not tilted,
inverted or upright.
● The host should be placed in a dry and ventilated environment, more than
5cm around, to facilitate heat dissipation. Do not cover the host. Do not
put heavy weight on the host.
● Non-professionals are strictly forbidden to open the host.
● Please turn off and unplug the power if not in use for a long time or during
thunderstorm.
Safety Precautions
The lightning triangle is used to alert the user to the danger of an
electric shock.
The exclamation triangle is used to alert the user to important
operations or maintenance instructions
Please pay attention to the following symbols:

Contents
Introduction
System Overview
Features
Product Information (2U)
Product Information (7U)
Connection and Installation
System Diagram
Connection Example (2U)
Installation (2U)
Connection Example (7U)
Installation (7U)
Quick System Configuration
Server IP Settings
System VOIP Settings
Terminal Network and SIP Settings
System Operations
System Login
Main Interface
Zones
Groups
Settings
System Information
Broadcast Set
File Sync
Timing Management
Fire Management
Device Management
Device Bind
Advanced Set
1
1
1
3
4
5
5
6
6
7
7
8
8
12
15
19
19
19
20
33
36
36
37
37
38
39
40
45
46

46
46
46
47
47
47
48
49
49
50
51
51
51
52
52
53
54
54
54
55
55
55
56
56
56
57
57
57
58
Intercom Set
Status Display
Extension
VIOP External Line
Basic Settings
User Extension
Outbound Call Router
FXO Trunk Line
Dial Rules
VOIP Trunks
Advanced Set
Extension Set
Meeting Room
Intercom Paging
Ringing Group
SIP Set
System Management
Network Set
Network Detection
System Maintenance
Reset and Restart
System Upgrade
System Set
Time Set
Language Set
System Backup
Account Management
Administrator Set
Operator Set

58
59
59
59
61
61
62
Log Management
Monitor Set
Monitor Set
Event Bind
FAQ
Specification
Packing List

11
The IP PA Intercom-based System is an integrated audio and video communication system
that incorporates computer network, PSTN telecommunication network and mobile
communication network. The equipment in the system can be interconnected with the
equipment in the PSTN network and mobile communication network in the LAN and WAN.
Leveraging on the network convergence, it can realize convenient voice, video intercom
and broadcast functions at a lower cost. The system server adopts industrial-grade host,
stable and reliable, with built-in SSD and aluminum alloy panel. Working 24 hours a day, it
can run stably for a long time under low temperature and high temperature environment.
With the help of mature Ethernet hardware, the entire system does not require additional
line maintenance. Through this server, all terminal devices in the same network can be
configured, managed and maintained. The server has two forms of 7U and 2U, which can
meet your different requirements.
Introduction
Features
System Overview
Thanks for using our product. All our products are tested strictly before leaving the factory,
with guaranteed quality. Our product are widely used in such places as schools, gymnasiums,
square halls, parks, parking lots, railway stations, airports, villa communities and mall
supermarkets, etc., and they will be your ideal choice for public address system.
For better installation, commissioning and use of the product, please read this manual in
detail before installation.
● With mature IP convergence technology, it can support Internet and telecommunications
network integration, and HD voice conversation between fixed-line/mobile numbers and
IP network terminals; provide low-latency broadcast, intercom, conference, recording,
monitoring and other functions in WAN environment.
● With the powerful VOIP relay server, it can support seamless bridge with Cisco, Avaya,
HUAWEI, 3CX and other well-known VOIP servers at home and abroad to realize the
interaction of voice, video and text information between multiple systems.
● Support linkage with mainstream cameras such as Hikvision and Dahua to achieve AI
broadcast functions such as event triggering and event broadcasting, and integrate iFlytek
TTS module with clear and natural voice.

2
● Based on the Linux system and B/S architecture, you can log in the system through any PC
or mobile platform browser.
● With background broadcast, emergency broadcast, voice intercom, video intercom,
monitoring and video monitoring functions.
● Support custom grouping operations on all zones, for broadcast and volume adjustment.
● Can display group information, zone status (switch/volume/real-time program name),
program list, and timing point information.
● Support broadcast program operations for one or more groups/zones.
● Can create multiple timing schemes with multiple timing points, and support timing
schemes backup storage and direct import/export, as well as add/modify/delete timing
points and send them to a designated zone.
● Support EQ and Bass enhancement.
● Can manage all network terminal equipment, upgrade and maintain the program sources
and timing schemes of the terminal equipment and the equipment.
● Support USB encryption device control function.
● Quick upgrade and maintenance (support cloud upgrade, remote upgrade, and local
upgrade).
● 10/100M/1000M self-adapting, support DHCP/IP settings, LAN and WAN.
● Support PSTN.
● Support audio acquisition card.
● Equipped with several USB and VGA interfaces for extension.
● Adopt 17.3-inch touch screen (Only for 7U), built-in large capacity SSD with sensitive
touch, fast reading and writing speed and low power consumption.
● Hidden push-pull keyboard and TouchPad for 7U, no need for external keyboard or mouse.
● Adopt professional rack case design and aluminium alloy structure, with high
anti-magnetic, anti-dust, anti-impact ability.
● 3C certificate, stable and reliable.

3
Product Information (2U)
Front Panel
Rear Panel
1
89 10 11 13 14 15
16 17 18
12
2
3
5
4
67
1. Chassis Holder 2. Mounting Hole
3. OWER 4. POWER LED P
5. USB 6. RESET
7. HDD LED
8. Power Interface 9. PS/2 Interface
10. . Print Interface COM Interface 11
12. VGA Interface 13. HDMI Interface
14. USB2.0 Interface 15. Audio Interface
16. USB3.0 Interface 17. Network Interface
18. Micro SD Slot (Support PSTN & audio card)

4
Product Information (7U)
PSTN (Purchased by yourself)
Front Panel
1
78 9 10 11
17
12
2
3
4
5
6
Rear Panel
13 14 15 16
Audio card (Purchased by yourself)
1. Mounting Hole 2. Chassis Holder
3.Display Touch Screen 4.POWER
5. Keyboard Handle 6. Front USB2.0 Interface
7. Power Interface 8. Trigger Input Interface (Not available)
9. PS/2 . Interface Interface 10 COM1
11. Print Interface 12. VGA Interface
13. USB3.0 Interface 14. Network Interface, USB2.0 Interface
15. Audio Interface 16. Micro SD Slot (Support PSTN & audio card)
17. COM2 Interafce
Hardware Configuration

5
Connection and Installation
System Diagram
IP Decoder Player
(Wall-mounted)
IP PA Intercom-based Server
2U or 7U
Wireless Router
IP Calibrator
GPS+Beidou Wireless Control
1 2 3 4
IP Audio Collector
IP Waterproof
Column Speaker
IP Indoor
Column Speaker
IP Fire Collector
IP Broadcast Digital Amplifier
(Multiple)
Outdoor
Intercom Terminal
Broadcast Intercom
Paging Station
Indoor
Intercom Terminal
1 2 3 4
Constant Voltage Amplifier
1 2 3 4
IP DecoderPower Partitioner
Constant Voltage Amplifier
×8
IP Decoder Player
(Multiple)
Teaching Amplifier

6
Hardware Configuration
Install two holders on the left and right sides of the front end of the server and
push the device parallel to the cabinet, so that four holes on both sides of the
device are aligned to the installation holes on both sides of the cabinet. Fix it
with screws. (As shown below)
Installation (2U)
Connection Example (2U)
Cabinet
In order to ensure the normal operation of the whole system, a router
must be set up in the network connected by devices.
* External devices, PSTN and audio card in the server need to be purchased by yourself.
Holder
IP Switch
External Display
External Mouse
& Keyboard
PSTN
DVD

7
IP Switch
PSTN
Push the device parallel to the cabinet, so that four holes on both sides of the
device are aligned to the installation holes on both sides of the cabinet. Fix it
with screws. (As shown below)
Installation (7U)
Connection Example (7U)
Cabinet
External Display
(Extended display,
not necessary)
External Mouse
& Keyboard
(Extended device,
not necessary)
In order to ensure the normal operation of the whole system, a router
must be set up in the network connected by devices.
* External devices, PSTN and audio card in the server need to be purchased by yourself.
DVD

8
Enter the main interface.
Server IP Settings
Log In
After booting up, the server will automatically enter the Login interface.
Enter the default account and password and then click Login to enter the
main interface of theserver. The user can double click the “IP PA
Intercom-based System”icon on the system desktop to open the browser
again if it has been closed accidently. Click the “Help” button to view the
help file. (The default account: admin, password: admin)
Quick System Configuration
Quick System Configuration

9
Click Settings.
Enter the Settings interface to view the System Information.
(The default IP: 192.168.10.100)

Click “System management - Network Set -WAN port settings” to set the
system network, and then click “Save”.
Click “Yes” in the pop-up tip of Restart to become effective and wait for
the restart.
Configure the system network
according to the network environment
①
②
③
④
⑤
Quick System Configuration
10

11
After restart, please check whether the network information has been
changed successfully. If not, please follow the Step 5 to modify again.
Check whether the network info
has been changed successfully

12
System VOIP Settings (Only for intercom projects or intercom paging stations
across network segments)
In the Settings, click “Intercom Set - Status Display - Extension” to view the
exsiting SIP accounts. If the default account can not meet the site requirements,
it is required to do the following steps.
(The user should follow the steps below if no extension number when leaving
the factory)
Click “Intercom Set - Advanced configuration - Extension Set” to set the
User extension number. The default limit for the user extension number
section is 600.
①
②
③
①
②
③
④
Quick System Configuration

13
If more user extension numbers are required, please click “Intercom Set -
Basic settings - User Extension” to click “Batch create users”. (A maximum
of 50 users for Batch create once)
Set the number and password in the pop-up window of “Batch create
users” and click “Save”.
①
②
③
④

14
Click “Edit” to view the password and related settings of the user
extension. (The default passwords of all SIP accounts:1234)
①
②
Quick System Configuration

15
Terminal Network and SIP Settings
1 Terminal Network Settings
In the "Broadcast Set" interface, select the device that requires network settings,
and then click the "IP settings" in the lower right corner.
Set the IP based on the network environment (The default IP: 192.168.10.128) in
the pop-up window of "IP settings" and click "OK". (It requires a restart to become
effective due to a certain network delay.)
⑤
④
①
②③
