Abocom BM200 User manual

Bandwidth Management
The BM200 is the newest Bandwidth Management
system from AboCom Systems, Inc. specifically designed
for business networks. It guarantees Internet quality and
assists network managers to attain maximum bandwidth.
Additionally, QoS is added to further guarantee
bandwidth and quality speed.
The Accounting Report function of the BM200 helps to quickly discover network traffic jam
problems. This is a needed tool for properly managing an enterprise’s networking system.
Added to that is the Policy Management function of BM200 which helps network managers to
strategically allocate bandwidth. This function allows companies to effectively and efficiently
reach and manage bandwidth goals, thus saving network resources and the Internet down
time.
FEATURES










QoS (Quality of Service) guarantees best
bandwidth and quality of the Internet
connection.
Supports NAT Mode and Transparent Mode
Supports two-ways (Incoming & Outgoing)
bandwidth control and asymmetrical
management policy
Supports NAT Modeand Transparent Mode
Professional Network Log and Accounting
Report
Policy Management by
User/Group/Server/Port
Time-Schedule Management
Supports MRTG Traffic Statistics, easy to
trace and analyze
Provides Multi-Servers Load Balancing
Supports Content Filte
 Supports Virtual Server and IP
mapping (Multi-DMZ Host)
 Embedded Linux OS and Watch Dog
enhances high performance,
reliability and compatibility.
 4x LAN Port; 1x WAN Port
 Supports Multi-language UI, easy to
manage
 Firmware upgradeable Via Web UI
Benefits:
Guaranteed bandwidth
QoS (Quality of Service) function of the BM200 guarantees best bandwidth and quality of the
Internet connection.
Simple Setup
The BM200 supports NAT Mode and Transparent Mode, therefore allowing for the original
network structure and setup to remain in place without making changes to the system or
adding an extra database. Its plug and play trait makes it convenient and smart in all
networking environments.
Professional Network Log and Accounting Report
With AboCom Systems’s Accounting Report and MRTG Statistics, the BM200 can dynamically
detect network resources to assist in the configuring policy of bandwidth management. This
advantage helps the network manager quickly discover problems that cause network traffic
jams; thus managing the bandwidth effectively and efficiently.

Prevents Hackers
The BM200 provides strategic firewall protection; more than ten anti-hacker modes are inner-
built to intercept hackers. Users can setup a Rule Base themselves. With 24 hours, 7 days a
week (24x7) elastic time management and Hacker Alert, E-mail can be sent simultaneously to
inform the network manager to intensify the safety of the internal network.
Highly-Integration and Expansion
Whether you place BM200 in front of the firewall or before/after NAT, you can instantly
connect to the Bandwidth Management to integrate and expand the efficiency of the network
system.
Easy Operation and Convenient Management
The BM200 provides multi-language web interface management, making it even easier to
manage and control. The Bandwidth Management produces graphs and reports under a variety
of different network management demands. The network manager is always kept informed
with automatic alerts when abnormalities occur.
SPECIFICATIONS
SOFTWARE SPECIFICATIONS:
Multi-language UI Web management
- System Log
- Incoming Log
- Outgoing Log
Log
- Intruder Log
- Packet statistic (MRTG)
Statistics
- Accounting Report
- Support xDSL
- PPPoE
- Cable
ISP Service
- Leased Line Services
- QoS (Quality of Service)
- Guaranty
- Max
- Bandwidth
Bandwidth Management
- Priority
- Transparent Mode-Multiple NAT
- Packet Filter (Policy base access control)
- URL & General Blocking (Content Filter)
- Access Control by Group
- Time-Schedule Management
- Stateful Packet Inspecition (SPI)
- Attack (DoS) detected item select
Firewall Security
- Attack (DoS) Alert (Email & Log)

- DHCP Client / Server
- DNS Proxy
- PPPoE
Protocols Support
- NTP (Network Time Protocol)
- DDNS
- Virtual Server
- Special Internet Application
- Multi-Servers Load Balancing
- Multi-DMZ host (Mapped IP)
- Idle renew DHCP
- Dial-on-Demand, Auto-Disconnect & Reconnect
Application
- Authentication with PAP & CHAP for PPPoE
HARDWARE SPECIFICATIONS:
CPU Waveplus MIPS 100MHz
Memory 8MB Flash Memory32MB SDRAM
4 x 10/100Mbps LAN Ethernet Ports (Auto MDI-X)Interface
1 x 10/100Mbps WAN Ethernet Ports (Auto MDI-X)
LED 1 x Power / 1 x Status / 1 x WAN /4 x LAN Port LED
Power Supply External, DC 5V / 2.4A
Physical: Dimension 22(W) x 15(D) x 4(H) cm, Weight: 940g
Regulatory EMI / CE
