Abocom HL2000 User manual

HomeNetToEthernetIPSharing
IP Share device is designed for IP address simplification and conservation, as it enables private IP
Internet works that use non-registered IP addresses to connect to the Internet. It usually connects two
networks together, and translates the private (not globally unique) addresses in the internal network into
single legal address before packets are forwarded onto another network. Therefore, only one IP address
is needed for the entire network to the outside world. This provides additional security, effectively hiding
the entire internal network from the world behind that address.
FEATURES
nAllow 32 users to access
Internet concurrently
nInternet applications such as
Web browser, ICQ, AoE,
NetMeeting, FTP, Telnet, E-
Mail, News, Ping, VDOLive
Player, and many Internet
Games are supported Natural
firewall keeps hackers out
nNatural firewall keeps hackers
out
nDHCP server allocates up to
128 client IP addresses
nDHCP client to request a global
IP address from ISP
nWAN: 1Mbps HomePNA for
home networking
nLAN: 10Mbps Ethernet.
nVirtual server
nEasy setup using terminal
program through serial cable,
or Telnet through network
nEasy Graphic User Interface
setup program for Windows
95/98/NT and 2000 through
network
nFlash memory for firmware
upgrade
nSupport most operating
systems such as Windows
95/98/NT, Unix, and Mac
MDF/IDF
Line3B
Line3A
Line4B
Line4A
Voice
MDI-1X
MDI-2X
MDI-3X
MDI-4X
MDI-5X
MDI-6X
MDI-7X
MDI-8X
MDI-II
HomeNet
Switch Hub
Data
H
o
m
e
N
e
t
t
o
E
t
h
e
r
n
e
t
I
P
S
h
a
r
i
n
g
HomeNet
HomeNet
Cable Modem/
ADSL Modem
Ethernet
Ethernet

SPECIFICATION
Protocol IP, NAT, ARP, ICMP, DHCP client/server
Management Direct serial cable connection through Console port
Telnet and GUI program for Windows 95/98/NT through network.
WAN 1M Home-PNA interface for home networking
LAN
10 Base-T Ethernet to local network.
Console DB-9 female connector for configuration and firmware upgrade
LED Indicators Power, Local Link/Activity, Global Link/Activity, Error
Electronic Specifications Input Power 5V DC @2.4A
Agency and Regulatory FCC part 15 Class B, VCCI, CE, FCC Part68
Physical Dimension 160 x 105.4 x 27 mm3(LxWxH)
Weight 218 g
Operating Temperature 0℃to 50℃
Operating Humidity 0-90% non-condensing
