1. Introduction
ZN030-ABPROG and ZN031-M35XXX/SPI/I2C Adapter together with ABPROG Programmer software
allows you to erase and write SPI, I2C, Micro Wire EEPROM memory (35xxx, 95xxx, 24xxx, 93xx) with and
without incremental registers, read the SSID of the NEC KEY, erase the NEC chip and then program it
again. ZN030-ABPROG and ZN031-M35XXX/SPI/I2C Adapter together should be used with ABRITES
software produced by Abrites Ltd.
ABRITES is a trade mark of Abrites Ltd.

www.abrites.com 7 www.abrites.com 7
2021 ABPROG Programmer for AVDI User Manual
1.1 Scope of the manual
This document describes software and hardware installation of kit for EEPROM and MCU memory
programming.
The basic package of kit for EEPROM and MCU memory programming:
ZN030-ABPROG
ZN031- M35XXX/SPI/I2C Adapter

www.abrites.com 8 www.abrites.com 8
2021 ABPROG Programmer for AVDI User Manual
SO8 –DIP8 Adapter
ZN032 - Adapter with socket for NEC
MCU (optional)
ZN034 - ABPROG flat cable

www.abrites.com 9 www.abrites.com 9
2021 ABPROG Programmer for AVDI User Manual
ZN055 - ABPROG EWS3 adapter
The Abrites ABPROG EWS3 Reader (ZN055 - ABPROG EWS3 adapter) is an assistance tool
designed to allow you to read the EWS3 Dump from the EWS3 cars in order to make a key for
them, this tool will be very useful when working on the BMW E46/ E53 model cars. The tool
attaches to the ABPROG programmer which attaches to the AVDI interface in order to read the EWS3
dump.
Once you have read the EWS3’s dump you will be able to save it on your computer. After you
do that you will be able to load this dump in the PROTAG software and program a key using it.
With the help of the EWS3 Adapter you will no longer need to use third party EWS3
Programmers to read the EWS dump.
1. ZN055 - ABPROG EWS3 adapter
2. Connection diagram and Boot Pin on
EWS

www.abrites.com 10
2021 ABPROG Programmer for AVDI User Manual

www.abrites.com 11
2021 ABPROG Programmer for AVDI User Manual
ZN057 EEPROM Adapter
The ZN057 Adapter is designed to make EEPROM reading/writing easier, where the need to desolder/
solder eeprom is skipped while the adapter cables can be directly soldered to any connection point on
the PCB or the EEPROM.

www.abrites.com 12 www.abrites.com 12
2021 ABPROG Programmer for AVDI User Manual
The photo below shows how to connect to a BMW BDC and a FEM unit to read the EEPROM:
The photo below shows how to connect to a BMW BDC and a FEM unit to read the EEPROM:

www.abrites.com 13
2021 ABPROG Programmer for AVDI User Manual
Minimum system requirements – Windows 7, Pentium 4 with 512 MB RAM
USB port with supply 100 mA / 5V +/- 5%
- M35080VP M95080
- M35080V6 M95160
- D080D0WQ M95320
- D160D0WQ M95640
- M95010 M95128
- M95020 M95256
- M95040 24C01
- M95080
- M95160
- M95320
- M95640
- M95128
- M95256
- 24C01
- 24C02
- 93C76
- 24C04
- 93C86
- 24C08
- 24C16
- 24C32
- 24C64
- 24C128
- 24C256
- 24C512
- 24C1024
- 93C46
- 93C56
- 93C66
- RENAULT BCM (X95)
- W164 ,W166, W203, W204, W210, W211, W212, W216, W220, W221
MB EZS Reading hash without password
2. System Requirements
3. Supported Devices

www.abrites.com 14 www.abrites.com 14
2021 ABPROG Programmer for AVDI User Manual
We suppose that already your AVDI interface is configured and fully working.
You can receive optional separate installation file for your kit EEPROM and MCU memory programming.
Software is a windows executable file named ‘SetupInterface_ABPROG_VVxxxx.exe’ where VVxxxx is
your interface identification number.
4.1 Software installation steps
Please start the executable file above to
initiate installation procedure and follow
the onscreen instructions.
Depending of your operation system
and settings you can be asked to
confirm starting of installation
procedure.
4. Getting Started

www.abrites.com 15 www.abrites.com 15
2021 ABPROG Programmer for AVDI User Manual
Press “Next” button to proceed with the installation.
Read carefully license agreement and select “I accept the agreement” if you accepting all. Then press
“Next” button.
If you not agree press cancel to interrupt installation procedure.
Press “Next” button to proceed with the
installation.
Press “Next” button to proceed with the
installation.

www.abrites.com 16 www.abrites.com 16
2021 ABPROG Programmer for AVDI User Manual
Press “Next” button to proceed.
If you don’t want desktop icons
uncheck the checkbox about
creation of icons.
Press “Next” button to proceed.
Press “Install” and wait until
installation complete.

www.abrites.com 17 www.abrites.com 17
2021 ABPROG Programmer for AVDI User Manual
Be sure that checkbox about
installation of interface’s USB
drivers is set especially if you
installing for first time Abrites
Diagnostic Software.
Press “Finish”.
Depending setting of your operation
system you can be asked to confirm
installation of USB drivers.
Press “Yes”.
Wait until installation of USB
driver finish.

www.abrites.com 18
2021 ABPROG Programmer for AVDI User Manual
4.2 Connection of the programmer to the interface
4.3 Starting of the software
When programmer is ready and connected to the interface you can start the software.

www.abrites.com 19
2021 ABPROG Programmer for AVDI User Manual
Verify EEPROM
Erase EEPROM
Load dump
Save dump
Exit
Read EEPROM
Drop down list for device type:
SPI, I2C, MW, NEC_KEY, MCU
Drop down list for
EEPROMmodels:
Write EEPROM

www.abrites.com 20
2021 ABPROG Programmer for AVDI User Manual
5. Erasing Incremental EEPROM
Keep in mind that the time to erase “M35080VP/M35080V6” could reach 90 seconds!
After erase finish you can write the new data using the button “Load” and “Prog Incr.”.
Once you select the “EEPROM” use button “Erase Incr.”.
