Absolute Acoustics NDS-UM Series User manual

NDS-UM
NDS-UM44
NDS-UM88
INSTA LL GUIDE
NDS ULTRA HD MATRIX SW ITCHERS

INTRODUCTION .............................................................0 2
KEY FEATURES.................................................0 2
DESCRIPTION UM 4 4 .................................................0 3
DESCRIPTION UM 88 .................................................0 4
INSTA LLATION INSTRUCTIONS ..........................0 5
QUICK SETUP GUIDE......................................0 5
FEATURES CONFIGURATION ..............................0 6
HDMI AUDIO DE-EMBEDDING....................0 6
CEC BRIDGE.......................................................0 6
EDID DATA TA BLE..........................................0 8
CONTROL PORTS CONFIGURATION ...............0 8
IR.............................................................................0 9
RS232....................................................................0 9
DEVICE OPERATION ...................................................10
MA NUAL OPERATION.....................................10
IR, RS232 A N D TELNET OPERATION.........11
W EB INTERFACE OPERATION.....................11
W EB INTERFACE ...........................................................12
DEFAULT SETTINGS .....................................................12
PACKAGE CONTENTS ................................................12
SPECIFICATIONS ............................................................13
NOTES ...................................................................................14
THA NK YOU FOR PURCHA SING THIS
PRODUCT.
For optimum performance and safety, please read these instruc-
tions carefully before connecting, operating or adjusting this
product. Please keep this manual for future reference.
SURGE PROTECTION DEVICE RECOMMENDED
This product contains sensitive electrical components that may
be damaged by electrical spikes, surges, electric shock, lightning
strikes, etc. Use of surge protection systems is highly recommen-
ded in order to protect and extend the life of your equipment.
SA FETY A ND PERFORMA NCE NOTICE
Do not substitute or use any other power supply other than the
enclosed unit, or a Absolute Acoustics®approved replacement.
WA RRA NTY NOTICE
This product is covered by a two year limited warranty. Absolute
Acoustics®warrants to the original purchaser that this product is
functional and free from defects in materials and workmanship
for the period of two year from date of purchase.
To obtain warranty service please contact Absolute Acoustics®
one of itso cial distributorsfor further instruction.
Proof of purchase including date, and an explanation of
complaint is required for warranty service.
CONTENTS
NDS-UM

KEY FEATURES
Int rod uct ion
Absolute Acoustics®NDS UM is a family of HDMI/HDMI matrix switchers capable of transmitting audio, video, and control signals
from any source to any display. As an exclusive feature, UM models extracts the digital audio from each HDMI input to a pair of analog
RCA connectors, enabling the direct connection with any audio distribution system.
With a range of exclusive technologies, UM matrix switchers o ers advanced features for distributing HDMI signals, such as native
support for UHD/4K resolutions and high defnition audio formats, and compliance with the new HDCP 2.2 copy protection standard,
making it perfect for deployment of multimedia distribution systems in residential or corporate environments. Additionally, all inputs
and some output zones of UM mat rix switchers have HDMI audio de-embedding, extracting the digital audio contained in the HDMI
signal into a pair of RCA connectors.
UMs can be controlled manually via front panel buttons or remotely, by sending IRor RS232 codes. When connected to an Ethernet
network, it can also be controlled over Telnet protocol, or through its web interface - which also works as an easy way to perform all
settings. And further expanding the range of features, UM44 can act as an automation hub, forwarding commands received on its
control ports via HDMI-CEC to devices connected on each of its outputs.
Compatible with the new ultra-high de nition sources
and displays, sending signals with resolutions up to
2160@30 with YCbCr 4:4:4, or 2160@60 with 4:2:0 color
format;
Fully licensed and compatible with HDCP 2.2, t he
latest content protection speci cation, enabling the
transmission of ultra-high de nition signals directly
from the source;
Digital audio extraction from the all input and some
output zones, enabling direct connections to
multi-room or professional audio distribution systems;
Control of connected displays through the
HDMI-CEC protocol, saving control ports of the
home automation controller;
Capable of control connected display through the
sending of commands in the HDMI-CEC protocol;
Web interface for con guration and control of the
device, with separated user pro les and optimized
for use on mobile devices.
NDS-UM

UM44 Descript ion
1. Power statusindicator
2. Switching statusdisplay
3. Operational controls
4. Openingsfor optional cover panel
5. HDMI input ports
6. Analog audio outputs
7. HDMI output ports
8. S ervice port
9. Unit RS232 control port
10 . Unit IRcontrol port
11. Unit Ethernet port
12. DCpower cable inlet
13. Chassisground pin
41 2
3
6
CONTROL
5 7
7
6 9
10
81312
11
NDS-UM

5 5 8 9 10 11
41 2
1. Power statusindicator
2. Switching status display
3. Operational controls
4. Openings for optional cover panel
5. Analog audio outputs
6. HDMI input ports
7. HDMI output ports
8. Unit Ethernet port
9. Unit IRcontrol port
10 . Unit RS232 control port
11. Service port
12. DCpower cable inlet
13. Chassisground pin
6 7 1312
3
NDS-UM
UM88 Descrip t ion

NDS-UM
1. Begin with the UM unit and all external devices turned o and
with power cablesremoved.
2. Place the UM unit at the installation site, allowing proper
space for ventilation.
3. Connect the source devicesto the input ports of the UM unit.
4. Connect the HDMI displaysto the HDMI output ports of the
UM unit.
5. [Optional] Connect the control system to the IRor RS232
port of the UM unit.
6. Connect the UM unit to an Ethernet network.
7. Connect the power cable to the UM unit.
8. Connect external devicesto the power supply and turn on.
9. Accessthe device’sWeb Interface and make the appropriate
con gurations(it may be necessary to restart the sources so the
new settings can take e ect).
10 . Perform tests and validate the installation.
QUICK SETUP GUIDE
Inst allat ion Inst ruct ions
Warning
All devices should be unplugged from
electrical supply prior to begin the
installation. Damages caused due to misuse
are not covered by the product warranty.
Tip
Before permanently securing the unit for
nal installation, test for proper operation
of the unit and cables in your system.
Feat ures Confi gurat ion
CEC BRIDGE
HDMI A UDIO DE-EMBEDDING
UM matrix switchers can control connected displays by sending commands in the HDMI-CEC standard. Commands to turn on and o
the display are precon gured in the device’s control functions, and accessible via RS232 and Telnet control protocols. Additionally,
custom HDMI-CECcommands can be sent through a speci c function of the device’s RS232 and Telnet control protocols.
UM matrix switchers extract the digital audio embedded in its output ports to analog stereo audio connectors. To make it possible,
the input audio signal must be in 2 Ch PCM 32-192kHz @16-24 bits. Ensure that the HDMI audio will be sent from the source in a
supported format using the appropriate EDID setting, or making an equivalent con guration directly in the signal source.
Note: If the input signal is in multichannel PCM format, the analog audio outputs will only reproduce audio from left and right
channels.

NDS-UM
CEC BRIDGE
Note: The operation of CEC Bridge is subject to the
availability of HDMI-CEC functions on the controlled
display. Depending on the brand/model, some functions
may not work.
Co nt ro l Syst em NDS-UM
CEC
IP / RS232
CEC
Display 1
Display 8
(...)

NDS-UM
Preset #
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
Descrip t ion
10 8 0 p Vid eo | St ereo A ud io
10 8 0 p Vid eo | Mult ic hannel A ud io
10 80 p Video | High Defi nition Aud io
10 80 p 3D Vid eo | Stereo Aud io
10 8 0 p 3D V id eo | Mult ichannel A udio
10 80 p 3D Vid eo | High Definit ion A udio
4 K/ UHD 30 Hz Vid eo | Stereo A ud io
4 K/ UHD 30 Hz Vid eo | Mult ichannel A udio
4K/ UHD 30 Hz Video | Hig h Defi nit ion A udio
4K/ UHD 60 Hz Video | Stereo Audio
4 K/ UHD 60 Hz Vid eo | Mult ic hannel A ud io
4 K/ UHD 60 Hz Vid eo | High Defi nit ion A ud io
10 80 i Video | St ereo A ud io
10 80 i Vid eo | Mult ic hannel A udio
10 80 i Video | Hig h Defi nition Audio
1920 x10 80 DVI Vid eo | (No A udio)
At times, HDMI sources and display may not synchronize properly. UM matriz switchers feature an internal library of EDID settings to
ensure HDMI source’s output compatibility with the display devices. The con guration can be performed by device’sWeb Interface, or
by sending RS232 commands. Please reset the unit by either unplugging and plugging the HDMI connections, or power cycle so that
the new settings take e ect.
EDID DATA TA BLE

NDS-UM
Device Operat ion
MA NUA L OPERATION
UM matrix switchers can be controlled in several ways, either manually or integrated to a control system. This section describes the
functions available for each form of control, as well as a brief description of how to perform them.
To sw it ch an Inp ut t o a sing le O ut p ut :
1. Press the desirable output button, cycling trough the inputs (presented in the display) until the desirable input.
2. If there is no signal in the selected Input, the display change the text for “N” in the matching zone.
To check t he d ev ice st at us:
1. Press and hold the ENTERbutton for 3 seconds, until the display enters in Status Check mode;
2. Use the top layer and buttons to navigate between the status screens;
3. Use the top layer and buttons to navigate between inputs and output numbers.
Signal
Ground
12V
IRCTRL port of UM matrix switcherscan be used for device control. A list of available
features, and their respective codes are available on the Absolute Acousticswebsite.
The connection cable between the unit and the IR emitter equipment must be
assembled with the following con guration:
The RS232 control port can be used for device control and con guration . A list of
available features, and their respective codesare available in the Absolute Acoustics
website. The connection cable between the unit and the controller must be
assembled with the following con guration:
Cont rol Port s Confi gurat ion
GND RXTX
IR
RS232

User Level
Usernam e:
Passw ord:
Usernam e:
Password:
Ad m inist rat or Level
user
user
ad m in
ad m in
IR, RS232 A ND TELNET OPERATION
W EB INTERFACE OPERATION
UM matrix switchers can also be controlled via IR, RS232 or Telnet. Please refer to the speci c documentation, available at
www.absoluteacoustics.com for a complete description of the control functions and codes available for each protocol.
Control via integrated Web Interface is a friendly option for most users. To access it, follow the instructions in the next section of this
document.
Web Interface
UM matrix switchersprovide aWeb Interface for device control and con guration.To access theWeb Interface, rst connect the device
in an Ethernet network. Then, enter the current IP address in a web browser.
When you start the Web Interface access, you'll be prompted to insert the credentials. Two access levels are available: at User level,
only device's operational controls are available; at Administrator level, operational controls and device con guration options are
available. The default credentials are listed below:
Note: The device's default IP settings de ne the addressing mode as DHCP. To nd the address associated with the device, use a
network scanner software. The unit will show up in the scanner as ”Absolute”.
Note: The Web Interface access passwords can be changed by the system administrator. If you cannot login, you must restore the
device's factory settings.
In case a network scanner is not available, the current IPaddress can be found on the matrix switcher’s display.
Press and hold the rightmost button and navigate between the status screens with the and keys until the current IP address
shows up.
NDS-UM
