ABSTRACTA My Hive User manual

ABSTRACTA
My Hive Workstation fixed tabletop
Monteringsanvisning/ Assembly Instructions ver 1.0
Notes!
1. For electrical installation use only
authorized electricians.
2. When using the adjustable table for the first time:
Hold down the two buttons on the remote controll
until a signal sounds.
3. Maximum weight on table 100 kg
1
2
3
4
5
6
11
10
9
Alu profile middle (1x)
Alu profile
Left (1x)
Alu profile
right (1x)
12
Table Top (1x)
15 16 17
Left Screen (1x) Right Screen (1x) Middle Screen (1x)
Felt Hood (1x)
Sheet 1 of 1
Screw (13x)
White head
Screw (4x)
Screw (10x)
Plastic foldable corner (2x)
Shaft (6x)
Screw (4x)
14
Including components:
Screw (4x)
Washer (4x)
7
8
13
Bracket (2x)

ABSTRACTA
My Hive Workstation fixed tabletop
Monteringsanvisning/ Assembly Instructions ver 1.0
Sheet 2 of 4
Floor
Placement alu profiles
120°
Fold Pos. 3 to approx. 120°
before assemblying the Alu profiles
Step 1
Place pos. 3 on pos. 9, 10
and pos. 11 before
step 3
Step 2
Before step 3 make sure that
frame are placed flat horizontally on floor
See Screen connectors guide when
assembling multiple units
Push direction
Step 3
Make sure you have placed electrical cables
in aluminum profiles before mounting the Screens.
33
9
10
11
12
2
1
17
2
Use the pre-assemblied feets
to set fram horizontally

C
C
ABSTRACTA
My Hive Workstation fixed tabletop
Monteringsanvisning/ Assembly Instructions ver 1.0
Sheet 3 of 4
Step 4
Step 5:1
Note! - to fix the screens use rubber mallet
or use shims
Push direction
Push direction
Step 6
Choose table height
Height table top 720mm
Height table top 740mm
Height table top 760mm
Step 5:2
9
GapTabletoScreenapprox.
6Gap Table to Screen approx.
15 16
13 13
44 12
12
78 7 8

ABSTRACTA
My Hive Workstation fixed tabletop
Monteringsanvisning/ Assembly Instructions ver 1.0
Sheet 4 of 4
14
To facilitate assembly fold these
perforated edges before
mounting the hood
14
Push buttons
Assembly the hood on these holes first
146
14
16 Push buttons (3x)
Folded felt hood
Unfolded felt hood
Step 7
Use pre-drilled holes to
assembly felt hood
