ACADEMY DA-810DSP User manual

User Manual
DA-810DSP
SPECIAL DSP AMPLIFIER
Please read this manual carefully before using this product and keep it for future reference

Precautions
Warning：To prevent unit be short circuit，please do not put it in
the wet or damping places.
If unit catch water and any liquid that please turn off power
immediately and do not open cover by yourself. Please contact with
professional engineer for checking to avoid accident happen.
Packing List
For every package including below items, Please noticed retailer and
Factory if shortage:
DA-810DSP unit 1PC
User Manual 1PC
Warranty Card 1PC
Head Unit Cable 1PC (Option)
USB computer tuning cable 1PC

Contents User Manual
Mobile Application Instructions............................................................................................1-4
1. Features
1.1 Audio specification、main audio signal process diagram………........5
1.2 Input and output side panel………....…………………………………..........…...6
1.3 Software Introduction……………………………….…………................................6
1.4 Function Introduction………………………………………….................................7
2. Installation
2.1 System classic connecting reference……….......……...….......………..……...8
2.2 Unit connection..……………….………….……..…….….........................................9
2.3 Low level RCA input/output……………………………………….........................9
2.4 USB2.0 Port……………….….........………………….……….................................…10
2.5 The remote control function is introduced .............................................11
3. Software Operation
3.1 Software Installation………………………………………………..........………....…..12
3.2 Run and turn off.…………………………………………………….............………..…..12
3.3 Software interface………......……….…………………………...........……..……..…..13
3.3.1 Input signal select….…………………………….………..........…...…..13
3.3.2 Output switch……............................................................................14
3.3.3 Output voice, delay, type, mute and phase setting............14
3.3.4 Output signal equalizer and crossover operation…...........17
3.3.5 Output signal function operation.....…………………………......19
3.4 Setting introduce....………………….....................................................................21
3.4.1 Original setting change...................................................….....….21
3.4.2 Load and save the whole store a scene............................…..24
3.5 Operations Introduction..………………………….…………….............................26
3.5.1 Noise Gate.....................................…….……………….….….......…....26
3.5.2 Reset..............................................................………………..……....….26
3.5.3 Input Vol...........................................………………….….....................26
3.5.4 Information about the inquiry.………………….…......................27
3.5.5 Encrypt Setting................................................................................27
4. Common trouble shouting................………………..........……………………..........….…..........28

DA-810DSP Special DSP amplifier
1
Mobile Application Instructions
Android mobile scan Qrcode on gift box to
download the application to install DA-810DSP
app. Turn on the unit and plug in external
bluetooth, then the external bluetooth will be
power on and auto enter into a paring mode
with blue light flash alternately. Open the
bluetooth of your android mobile, searching
DSP to pairing it to finish the connected.
1.User Operation Instruction
Main Interface
Main volume adjustment
●The main volume can be adjusted by
pressing the main volume scale clockwise or
counterclockwise by hand.
Input Source
1、Click Hi.Level button to switch input
source.
E.g : Head unit input source is high level,
then the Input source on app choice
Hi.Level。
Preset
There are 1~6 presets to choose from.
MOBILE APPLICATION

DA-810DSP Special DSP amplifier
2
Connection Status
1、【 】Red means not connected；【 】 gray
means connected.
When the mobile phone is connected to
Bluetooth, open the mobile phone software and
it will be connected automatically. The Bluetooth
symbol turns green. The software can control
the host playback and data adjustment.
2、User mode click [ ] to enter the [Exit]
3、Click to enter the main interface. The main
menu is at the bottom of the interface.
4、Slide to adjust the main / subwoofer volume.
The main / subwoofer volume is 0-66.
Click【EQ】to enter EQ interface
Setting EQ Output channel
1、EQ curve(gain, Q value and frequency)
2、Output EQ gain setting: A total of 31 EQ,
left.and right sliding screen can select EQ,
you can drag the slider up and down. PEQ
mode (the equalizer frequency,Q value
and gain are restored to their initial
values).
3、Click each channel Freq in the pop-up
dialog box to adjust the adjustment range:
-20dB~+20dB.
Equalization settings
1、Click 【Reset EQ 】to restore the
parameters of the 31-band equalizer to the
original.
pass-through mode (the equalizer frequency,
Q value and gain are restored to their initial
values).

DA-810DSP Special DSP amplifier
3
Channel settings
1.Choose from 10 channels to choose from
2.Output channel volume setting,Click【 】
the speaker button to mute.
2、Click 【 】to adjust the volume by
sliding left and right.
2.Click phase for every output channel:
In Phase or Out Phase（0゜/180 ゜）
Crossover settings
1. Channel high-low-pass crossover setting
with high-low-pass independent filtering.
2. Frequency Range: 20Hz~20KHz. Slope
selection: 6 dB/Oct 、12dB/Oct 、18dB/Oct 、
24dB/Oct 、30dB/Oct 、36dB/Oct 、42dB/Oct 、
48dB/Oct 、OFF.
Output Signal Function
●Click [System] to synchronize the data,for
Group/Noise-gate/Preset Setting.

DA-810DSP Special DSP amplifier
4
Delay setting
Click[Channel] to enter the delay interface.Then
click [ ] to enter the delay setting
corresponding direction of the dot to the left
and right to set the delay. for the CH1 to CH10
speakers.
Mixer settings
Click [Mixer] to enter Mixer interface, It can
Perform 10 Output Channel adjustment.
USB-L, USB-R, digital left and digital right,
Bluetooth left and Bluetooth right mix
selection and adjustment.

DA-810DSP Special DSP amplifier
5
1. Feature User Manual
1.1 Audio specification、main audio signal process diagram
This equipment adopts the audio extraction method with high sampling rate of
48KHz. The core processor is the digital signal processor (DSP) with high resolution
64 bit double precision floating point and 170 section 31 parametric equalizer or
graphic equalizer, delay and frequency device (low shear and high cut filter, the
types of specialized division include: Ning g / Bessel / Butterworth, CH1-CH10 nine
slope 6dB and 12dB /18dB/ 24dB/30dB /36dB/ 42dB/ 48dB/off optional) etc..
Main audio signal process diagram
PC APPLICATION
low level /lossless /Bluetooth input
Bluetooth
Three groups of stereo high
level input
main voice choosing
output/input adaptor
Output
voice
80W
(main
cable
output)
CH1
CH2
CH3
CH4
CH6
CH9
CH5
CH8
CH7
CH10
Mute
limiter
Mute
limiter
Mute
limiter
Mute
limiter
Mute
limiter
Mute
limiter
Mute
limiter
Mute
limiter
Mute
limiter
Mute
limiter
1-10each output channel is independent of the 31 segment equalizer
Filter / Slope choice
RCA
Low
level
output 9
output voice
Phase
time
delay
Phase
time
delay
Phase
time
delay
Phase
time
delay
Phase
time
delay
Phase
time
delay
Phase
time
delay
Phase
time
delay
Phase
time
delay
Phase
time
delay
Output
voice
Output
voice
Output
voice
Output
voice
Output
voice
Output
voice
Output
voice
Output
voice
Output
voice
RCA
Low level
Output1
80W
(main
cable
output)
RCA
Low level
Output2
80W
(main
cable
output)
RCA
Low level
Output3
80W
(main
cable
output)
RCA
Low level
Output4
35W
(main
cable
output)
RCA
Low level
Output5
35W
(main
cable
output)
RCA
Low level
Output6
35W
(main
cable
output)
RCA
Low level
Output7
35W
(main
cable
output)
RCA
Low level
Output8
RCA
Low level
Output10

DA-810DSP Special DSP amplifier
6
1. Feature User Manual
1.2 Input and output side panel
Figure 1.2.1
1) Power Input 2) Speaker Output
3) High Input 4) ACC /High convertor
5) BT/Power LED indicator 6) Low level RCA output
7) Low level RCA input 8) Optical In
9) HIFI Player 10) PC Connection
11) Remote Control
1.3 Software Introduction
DA-810DSP PC software control: (please check 3. Software Operation detail )
1) Auotmetically detect whatever the hardware is connecting with USB cable,
if ready and will connect with head unit autometically.
2) Display resolution over than 1280*760, or else cannot show fully.
3) Only for windows system's computers.

DA-810DSP Special DSP amplifier
7
1. Feature User Manual
1.4 Function Introduction
Specification
Input signal type:
8 Channel High Level Input / 2 Channel Low Level Input
Output location:
10 Channel Low Level Output [RCA] / 8 Channel High Level Output
RMS Power Output (4 Ohm):
35W x 4 CH + 80W x 4CH
RMS Power Output (2 Ohm):
50W x 4 CH + 120W x 4CH
Peak Power Output (4 Ohm):
70W x 4 CH + 150W x 4CH
Active Range :
≥110dB
S/N Ratio
≥100dB
T.H.D.
≤0.05%
Freq. Response
20Hz～20KHz
Input Impedance
Low level input:20KΩ, High level input:240Ω
Low level output impedance
100Ω
Signal input/output range
RCA Input：6Vpp；High level：26Vpp；
RCA Output：9Vpp；Amplifier：26Vpp
Equailzation:
31 Band Independent Parametric / Graphic Equalizer
Equalizer Gain:
-20.0dB ~ +20.0dB, resolution 0.1dB
Output signal crossover type:
6db/Octave- 48db/Octave, Linkwitz Riley, Butterworth & Bessel
BesselButterworth & Bessel6db/Octave- 48db/Octave, Linkwitz
Riley, Butterworth & BesselButterworth & BesselButterworth
& Bessel
Time Delay :
0.000-20.00ms, 0.00-692.0cm, 0.00-273 inch
Phase:
0 ゜/180 ゜
Bluetooth Version:
Bluetooth 5.0
Signal Input:
Bluetooth Audio Player
Optical In/ PC Connection
Android/ Ios APP & PC Software for DSP Setup & Tuning
Lossless Audio Player (USB):
for FLAC, WAV, MP3, WMA, AAC
Sampling rate:
48KHz/24Bit
Remote control:
Optional
Turn-on REM output
+12 V starting voltage output(0.2A)
Power consumption
≤0.1W
Output signal gain range
Mute, -59.9dB to 6.0dB

DA-810DSP Special DSP amplifier
8
2. System connections User Manual
2.1 System classic connecting reference
Figure 2.1
this connecting method is for two units input, please refer below:
1. Please use Plug & Play cable to connect original car unit and DA-810DSP for
upgrade audio system effects. Please use OUT9 and OUT10 RCA output when
Install bass amplifier or subwoofer
2. with the player, using RCA low level input connection, mobile phone use
standard AUX special line.

DA-810DSP Special DSP amplifier
9
2. System connections User Manual
2.2 Unit connection
Figure 2.2
indication“2”is the plug connecting position and assort with connecting cable which
is matching unit.(figure 2.2) Connecting wire specifically defined in the following
table:
indication“3”is the plug connecting position and assort with connecting cable which
is matching unit.(figure 2.2) Connecting wire specifically defined in the following
table:
Direction:
1.only for the original Plug & Play cables, or user using others directly.
2.REM input, when the toggle switch to ACC, only ACC input; When the toggle switch
is switched to DC, the two high level input lines of FL+/FL- are defined. When there is
original car or other high level input, the machine will detect the audio signal to start
the machine.
Note: when do not use high level input (only RCA low level input), the toggle switch dial in
DC, defined in FL+/FR+/RR+/RL+ arbitrary a all can access REM or ACC input, can be
normal to start the machine.
2.3 Low level RCA input/output indication
“6”“7”position where is "low level RCA input/output" (figure1.2.1)
1. Low level RCA inputs, usually followed by an external player RCA output as the
auxiliary input, maximum input level is10VPP.
2.the low level RCA output, CH1 to CH4 signal with the original car interface is the
same, but there is without power amplifier, the default output type of CH7and CH8 is
null, while the default output type of CH9 and CH10 is ultra-low left and ultra-low
right, usually external bass amplifier, as bass strengthened. Of course,users can
configure their own initiative RCA low level output to complete more high-end
divided by two or three-way system.

DA-810DSP Special DSP amplifier
10
2. System connections User Manual
2.4 USB2.0 Port
As shown in figure 1.2.1, the "10" indicator bit is the "USB2.0" position.
Figure 2.3
Use Random accessories USB cable into this hole on a computer connected to
the PC, open tuning software to debug the sound system.

DA-810DSP Special DSP amplifier
11
2. System connections User Manual
2.5 Introduction to central control function
The central control can control the host, including playback mode, sound effect call,
delay calibration, frequency divider, channel volume, mixing, screen light, square
control setting, EQ, delay, phase, volume, song selection, fast back, fast forward and
almost all other functions.
Remote Control (optional)
Press the knob to switch between:
1, VOL : Rotate the knob to increase/decrease the main Volume.
2, SUB VOL : Press and hold knob for 3 sec, then press to enter ,Rotate the knob to
increase or decrease SUB Volume.
3, : Press the knob to switch, return to the start song. Press and hold knob for 3
sec,to go to preset mode.
4, : Press the knob to switch, Enter to mute mode.
5, : Press the knob to switch between available input sources.
6, : Press the knob to switch, select previous song.
7, : Press the knob to switch, select next song.
8, : Press the knob to switch, select pause song.
PLAYER Mode. Connect a USB device into the dedicated port. Press the knob to select
SOURCE then press the knob to select USB.

DA-810DSP Special DSP amplifier
12
3. Software Operation User Manual
3.1 Software Installation
PC tuning software is no need to install drive program, plug and play.
Operating environment: Suitable for Windows XP / Vista / WIN7 / WIN8 / WIN10
operating system.
The installation procedure describes:
After you install the software and downloading, double-click the installation file, step
down can be achieved by tuning the software is installed.
3.2 Turn on and turn off
Double-click the DA-810DSP icon to open the software, and the main interface
before online is shown in figure 3.2.1 :(the upper right corner refers to the
unconnected state)
Figure 3.2.1
DA-810DSP provides only wired USB PC software connection. Wired USB
connection:
Ensure that DA-810DSP power state, with a USB cable to connect to a computer
through the USB interface, the computer will find the new device and automatically
install the update equipment, after a few seconds the installation is complete.
Mixer software will automatically line up with the hardware. Right corner refers to
"connected" state.

DA-810DSP Special DSP amplifier
13
3. Software Operation User Manual
3.3 Software interface
Figure 3.2.2
Software interface DA-810DSP unit divided into the following functional:
1．as shown in figure 3.2.2, "1", input signal selection: high level,Bluetooth, AUX,
optical and USB.
2．as shown in figure 3.2.2 "2", shows the main menu and connection status.
3．as shown in figure 3.2.2 "3", the high-pass and low-pass Settings of the divider.
4．as shown in figure 3.2.2, "4", area is output channel EQ setting.
5．as shown in figure 3.2.2, "5", shows the setting of delay space.
6．as shown in figure 3.2.2, "6", output channel configuration and common
parameter adjustment area.
7．as shown in figure 3.2.2, "7", shows the setting of Mixer space.
3.3.1 Input signal select
In the online mode, in Figure 3.2.2 "1", click the appropriate input source, you can
switch the audio input signal.
8．Optional: high level,Bluetooth, AUX,optical and USB. The default audio source
can be selected in the option of "2" zone. The default power source is high level.
Users can choose AUX and player as the default power source.
The volume can be directly pushed left and right, or input volume value, scroll
the mouse wheel, etc. Adjustable range: 0-40

DA-810DSP Special DSP amplifier
14
3. Software Operation User Manual
3.3.2 Output channel switch and operations
"6" area, click on the corresponding channel number in Figure 3.2.2 (CH1, CH2 ......
CH10), you can switch to the corresponding channel to adjust relevant parameters
when changing the channel editing, where there are only 3.2. 2 "4" zone (crossover
and equalization parameters) will vary depending on the channel and change the
parameter values.
3.3.3 Output volume, delay, type, mute and phase setting
In Figure 3.3.1, there are six output channels commonly used parameters are
displayed, the user can quickly adjust the parameters directly here. Of course,
users can also customize the horn type of each output channel.
Specifically adjusted as follows:
Figure 3.3.1
the output volume control, volume control for each channel independently and
the master volume, pushing the volume fader below each channel label can be
in OFF (off), - adjust between 59dB to 6dB; while on the right also has a total
volume of all output is adjustable, adjustment range is OFF (off), - between
-39dB to 6dB.
mute and phase adjustment, also under the label of each channel are phase and
mute both buttons select, and click on the button you can be between "positive
phase" and "inverted" Switch, click the mute button You can switch between
"open tone" and "off the sound." Figure 3.3.2 as follows:
Figure 3.3.2
Select delay units, which are in milliseconds, centimetres, and inches. The range
of milliseconds: 0.000~20;Range of mm: 0~692;Range of inches: 0 to 273;
DA-810DSP processor output signal path can be any type of configuration
freedom to any sound field point and the speaker type. The system defaults to

DA-810DSP Special DSP amplifier
15
3. Software Operation User Manual
4.1 full-range passive mode. Figure 3.3.3 as follows ;
Figure 3.3.3
CH1: front left output CH2: front right output
CH3:rear left output CH4: rear right output
CH5: center a left-field output CH6: right after the sound field output
CH9: left subwoofer output CH10: Right subwoofer output
Users can be customize the speaker type for each output channel, the specific
methods of operation:
The first step: Click on the right side of the "Reset Output Configuration" button in
the dialog box, select the "Clear" button, return to the main interface, all channels are
reset to "empty" (no connection to any speaker , there is no output of), as shown
below 3.3.4:
Figure 3.3.4
The second step, the channel number beneath each, click on the type
drop-down menu box, select the option in the pop-up users locate the type of

DA-810DSP Special DSP amplifier
16
3. Software Operation User Manual
speaker. Figure 3.3.5 as follows:
Figure 3.3.5
The system will be based on the user has selected the type of output signal path,
the shielding portion of the signal path type option (as a shadow, the user is not
optional). Specific options are:
Front 》 left, right 》 high/ mid/ low/ mid-high/ mid-low/ and full frequency
Rear 》 left, right 》 high/ low/ and full frequency
Center 》high-frequency, low frequency and full frequency
Super low 》 left super low, right super-low and super-low
The third step, after the user has configured all of the output signal path, click on the
right side of Figure 3.3.4 "Lock Output Configuration" to lock the configured output
channel speaker sound field position. So that users and then in the bottom of each
channel label, click on the type of drop-down menu box, type options will not pop
up.
the output delay adjustment, is set in the delay space area to the left of the
illustrated adjustment, as follows (Figure 3.3.6), click on the value of the input box
next to the corresponding speaker can be entered after the delay value
corresponding units.
Figure 3.3.6

DA-810DSP Special DSP amplifier
17
3. Software Operation User Manual
3.3.4 Output signal equalizer and crossover operation
Output channel equalizer and crossover editor mainly in the following areas of
regulation, as shown in 3.3.7:
Figure 3.3.7
Gain, drag around to adjust the equalizer frequency points; when the mouse is
moved to the left and right of the small red box, press and drag left and right to
adjust the equalizer Q. All parameters are displayed simultaneously adjust the
current real-time equalizer is also updated value EQ parameters editing area.
1. the output channel EQ editing method, all 31 equalizer will work for the next
parametric equalizer. When the parametric equalizer curve, if available in the box
below the corresponding input parameter values can be (frequency, Q value, and
gain) adjusted in real time will also be revealed at the top (as shown in Figure
3.3.8 parametric equalizer case ).
Figure 3.3.8
Straight balanced: the button shown in Figure 3.3.4, the current channel as long
as there is an equalizer in the open state, this button will appear highlighted in
green state, indicating that you can click this button to make all the equalizer
