Accedian Skylight Flex 100 Manual

Specications
Power
Input Power Rating AC Input: 100-240Vrms, 2.5-1.0A, 80 Plus Platinum
DC Input: Vdc=36-72VDC, 6.5-3.25A, Efciency 80%
(Min)@48V
Power Consumption 150WNom, 230WMax
Optical Port Power Rating QSFP: 5.0W(Max) Per Port
SFP+: 2.0W(Max) Per Port
Physical
Dimensions (W x H x D) 426.6 x 44.2 x 351.3 mm (16.8 x 1.74 x 13.83 in)
Weight 6.5kg (14.3lbs)
Environmental
Operating Temperature 0C to 50C
Storage Temperature -40C to 70C
Operating Humidity 5% to 85% RH, Non Condensing
Storage Humidity 5% to 95% RH, Non Condensing
Maximum Altitude 2000 m, Above Sea Level
Regulation & Standard Compliance (Unique ID: NG100 )
Safety IEC 62368-1, EN 62368-1, UL 62368-1, CSA C22.2 No.
62368-1, AS/NZS 62368.1, J62368-1, CEI EN 62368-1,
DS/EN 62368-1, SASO-IEC-62368-1
EMC - Emission (Class A) CISPR 32, IEC 61000-3-2, IEC 61000-3-3, EN 55032,
EN 61000-3-2, EN 61000-3-3, 47 CFR Part 15 Sub-
part B, ICES-003, AS/NZS CISPR 32, VCCI-CISPR 32,
KS C 9832
EMC - Immunity CISPR 35, EN 55035, KS C 9835
Telco NEBS Level-3: GR-63, GR-1089
Radio ETSI EN 301 489-19, ETSI EN 303 413
Enviro RoHS: IEC 63000:2016,EN IEC 63000:2018
Compliance Statements
423-047-00, Revision 8
Published: 2022-12-16
FCC Class A
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio com-
munications. Operation of this equipment in a residential area is likely to cause harmful interfer-
ence in which case the user will be required to correct the interference at his own expense.
VCCI–A
Note: Package can contain other ordering options. See ordering guide for more details.
KCC-A
Attention: This product, like all electronic products, uses semiconductors that
can be damaged by electrostatic discharge (ESD). Always observe appropriate
precautions when handling.
Warning: Potential for damage to equipment or personal injury.
Conventions
Attention: This symbol indicates that the surface is hot and to use caution to avoid
touching it.
Protective grounding point
この装置は、クラスA情報技術装置です。この装置を家庭環境で使用すると電
波妨害を引き起こすことがあります。この場合には使用者が適切な対策を講ずる
よう要求されることがあります。
사용자 안내문
이 기기는 업무용 환경에서 사용할 목적으로 적합성평가를 받은 기기로서 가
정용 환경에서 사용하는 경우 전파간섭의 우려가 있습니다.
Do not place hands, ngers or foreign objects in any holes, insertion slots or gaps.
To avoid damage to the equipment, keep objects clear of system ventilation inlets,
outlets and system fans, if any, ensuring the air ow through the units is not
obstructed, and that the fans rotate freely.
Do not disassemble or alter the unit.
Package Contents
Basic Contents
–Skylight Flex 100 (1)
–This Hardware Installation Guide (1)
–19" Bracket kit
Power Supply Airow Outtake Air is exhausted through the back of the power supply
Ground Lug Unit Protective Ground Point
System Fans Fans 1, 2, 3 & 4 locations
Back Panel
Unit Description
Skylight Flex 100™
HARDWARE INSTALLATION GUIDE
The intra-building ports of the equipment or subassembly is suitable for
connection to intra-building or unexposed wiring or cabling only. The intra-
building ports of the equipment MUST NOT be metallically connected to
interfaces that connect to the OSP or its wiring.

Management 1x RJ45 Port (10/100/1000 BASE-T)
Network 4x QSFP28 Port (100GBASE-R)
Auxiliary 1xSFP+ (10GBASE-R)
Synchronization
Module
(Optional)
1x SMA, GNSS Antenna Input; 1x SMA, Sync IN; 1x SMA, Sync OUT
PSU 1 LED OFF: No AC power to all PSU
0.5Hz Flashing Red: No AC power to this PSU only
1Hz Flashing Green: AC present/only standby output on
Green: Power supply AC output ON and OK
Red: Power supply failure
0.5Hz Flashing Red/Green: Power supply warning
PSU 2 LED OFF: No DC power to all PSU
0.5Hz Flashing Red: No DC power to this PSU only
1Hz Flashing Blue: DC present/only standby output on
Blue: Power supply DC output ON and OK
Red: Power supply failure
0.5Hz Flashing Red/Blue: Power supply warning
MIN MAJ CRIT
LED
Minor (Yellow), Major (Red) or Critical (Red) alarm condition
Status LED ON: Normal operation
Flashing: The unit is booting
Console / Dry
Contacts
1x RJ45 Port (RS-232 / 2 Dry Contacts)
Note: Cannot be used at the same time.
PIN # Signal
1Dry Contact#1
2 Not Connected
3 RS323 TX Data
4 Ground
5 Ground
6 RS232 RX Data
7 Not Connected
8Dry Contact#2
Console 1x USB Mini-B Port (USB 2.0)
Reset System Reset Button
Note: Press the RST button for > 5 seconds to reset the unit to factory
defaults (warning: service affecting).
Link LED ON: Link is active / OFF: Link is inactive
Activity LED OFF: No Tx/Rx Activity
BLINKING: Port is receiving/transmitting data
Synchronization
Module LED
Pwr; Ant; Sync-In; Sync-Out; Alarm
Power Modules Hot-Swappable Input Power Modules (AC or DC)
Connecting
Powering
For safety reasons, connect the protective ground lug to a suitable grounding point before
applying power, as shown in the gure below.
Note: Applicable wire range: 2.5–16mm2 (14–6AWG). Lug Type: 2 Stud #10 Hole, 16mm Spacing.
• Establish the proper connections between the wires and the power sources.
• Connect wires to the terminal block connector of the power supply.
Note: Applicable wire range: 0.75-2.5mm2 (18–14 AWG).
Establish the Ethernet connections to the unit by plugging the appropriate media types to the
proper ports of the unit (see the numbered diagram of the front panel).
Mounting
19-Inch Rack
• For ush mount, position the L-bracket as
shown in the gure below.
• Align the bracket with the appropriate holes,
attach the bracket with six at head screws
and secure to the rack using pan head
screws.
To conform to the NEBS Seismic Zone 4 requirements, the bracket must be
secured, using screws specied by the rack manufacturer, to a NEBS Seismic
Zone 4 compliant rack. Such screws are not provided with the bracket kit.
Note: For more information, refer to the Skylight Flex 100 User Material.
• Attach the included rubber feet to the bottom of the unit for added stability when placing it
on a desktop or other at surface.
• Ensure the fan airow is not blocked.
Front Panel
When mounting unit on a wall:
• The support surface and the fasteners you use must support at least 26kg
(57lbs.)
• Cable pull—accidental or otherwise—should not exceed the 2.0kg (4.4lbs.) limit.
Wall
Note: Mounting Kits are ordered separately, see the Accedian Ordering Guide for more details.
Desktop
Grounding
An approved external power supply switch or circuit breaker must be installed in the
supply lines and be readily accessible to act as a disconnect device. The switch or circuit
breaker must disconnect all poles simultaneously and be rated 20 A max.
DC Power Connecon
Connect the protective earthing terminal(s) on the power supplie(s) to the same pro-
tective earthing point as used to ground the unit.
DC PSU must be connected to ES2 power source only (maximum voltage of 72 VDC).
The DC Battery Return (BR) input terminal(s) of the unit are not connected to the
equipement frame or grounding means of the equipement and must be congured as
isolated DC Return (DC-I) in compliance with GR-1089-CORE requirements.
This unit is designed for Common Bonding Network (CBN) installations only.
This unit is suitable for installation in network telecommunication facilities and where
the National Electrical Code (NEC) applies.
Ensure the unit's power source(s) have been turned OFF before servicing.
The Dry Contacts Interface is strictly Safety Extra Low
Voltage (SELV).
Ensure the unit's power source(s) have been turned o before servicing.
Instalaons where a unit with the GNSS may be exposed to voltage in excess of
10kV, addional measures such as external surge suppressor may be necessary.
23-Inch Rack
• For recessed mount, position the L-bracket
as shown in the gure below.
• Align the bracket with the appropriate holes,
attach the bracket with six at head screws
and secure to the rack using pan head screws.
• For ush mount, position the L-bracket
as shown in the gure below and follow as
above.
• For recessed mount, position the L-bracket
as shown in the gure below and follow as
above.
AC Power Connecon
• Connect the AC plug to the AC appliance coupler.
• Plug the power cord into a suitable power outlet.
• Secure the power cord through the retainer clip.
The AC plug must be connected to a properly grounded AC outlet.
Denmark: Apparatets stikprop skal tilsluttes en stikkontakt med jord, som giver
forbindelse til stikproppens jord.
Finland: Laite on liitettävä suojakoskettimilla varustettuun pistorasiaan.
Norway: Apparatet må tilkoples jordet stikkontakt.
Sweden: Apparaten skall anslutas till jordat uttag.
Note: Power Cord must be ordered separately, see the Accedian Ordering Guide for more details.
