Chapter 1: Introduction
The PCI Express Multiport Serial cards were designed for RS232, RS422 and RS485
asynchronous communications for use in a variety of applications. These boards were
designed to offer compatibility with the PCI Express bus and to be used by system integrators
and manufacturers in the design of industrial and commercial communication systems. The
card is available in 4-port and 2-port versions and is compatible with all popular operating
systems. Each COM port is capable of supporting data rates up to 3Mbps (460.8kbps in
RS232 mode is standard) and implements full RS-232 modem control signals to ensure
compatibility with a wide range of serial peripherals. Existing serial peripherals can connect
directly to the industry standard DB9M connectors or via RJ45 connectors. The board features
a x1 lane PCI Express connector which can be used in any length PCI Express slot.
Features
•Four- and two-port PCI Express serial communication cards with on board DB9M or
RJ45 connectivity
•Serial protocol (RS-232/422/485) SOFTWARE CONFIGURED per port, stored in
EEPROM for auto-configure at next boot
•High performance 16C950 class UARTs with 128-byte FIFO for each transmit and
receive buffer
•Supports data communication speeds up to 3Mbps (standard model RS-232 is
460.8kbps)
•ESD protection +/-15kV on all signal pins
•Supports 9-bit data mode
•Full modem control signals in RS-232 mode
•Software compatible with all operating systems
•Jumper selectable termination for RS-485 applications
Applications
•POS (Point-of-sale) Systems
•Gaming Machines
•Telecommunications
•Industrial Automation
•ATM (Automated Teller Machine) Systems
•Multiple terminal control
•Office Automation
•Kiosks

PCIe-COM-4SMDB and RJ Family Manual
6
Functional Description
These cards feature high performance 16C950 class UARTs which support the complete
register set of the standard 16C550-type devices. The UARTs support operations in 16C450,
16C550 and 16C950 modes. Each port is capable of data communication speeds up to
3Mbps (standard model up to 460.8kbps in RS-232 mode) in asynchronous mode and has
128-byte deep transmit and receive FIFOs to protect against lost data in multitasking
operating systems, to help reduce CPU utilization and to improve data throughput.
Serial protocol (RS-232/422/485) is software configured per port via a Port Configuration
Utility provided on the CD which ships with each card. When RS-485 is selected, jumper
selectable termination is provided per port.
Four-port “DB” models (PCIe-COM-4SMDB, PCIe-COM-4SDB, PCIe-COM232-4DB) ship with
a additional mounting bracket and cable. This plugs directly into the dual 10-pin IDC headers
on board and mounts to the next adjacent bracket slot.
A crystal oscillator is located on the card. This oscillator permits precise selection of a
multitude of different baud rates.
Figure 1-1: Block Diagram

PCIe-COM-4SMDB and RJ Family Manual
7
Ordering Guide
•PCIe-COM-4SMDB* PCI Express four-port RS-232/422/485
•PCIe-COM-4SMRJ PCI Express four-port RS-232/422/485
•PCIe-COM-4SDB* PCI Express four-port RS-422/485
•PCIe-COM-4SRJ PCI Express four-port RS-422/485
•PCIe-COM232-4DB* PCI Express four-port RS-232
•PCIe-COM232-4RJ PCI Express four-port RS-232
•PCIe-COM-2SMDB PCI Express two-port RS-232/422/485
•PCIe-COM-2SMRJ PCI Express two-port RS-232/422/485
•PCIe-COM-2SDB PCI Express two-port RS-422/485
•PCIe-COM-2SRJ PCI Express two-port RS-422/485
•PCIe-COM232-2DB PCI Express two-port RS-232
•PCIe-COM232-2RJ PCI Express two-port RS-232
DB = DB9M connectivity
RJ = RJ45 connectivity
*Four-port DB models require the use of a provided additional mounting bracket.
Model Options
•-T Extended temp. operation (-40° to +85°C)
•-F Fast version (RS-232 up to 921.6kbps)
•-RoHS RoHS compliant version
•-W Remote wake-up enable (see Chapter 3: Hardware Details)
Optional Accessories
ADAP9 Screw terminal adaptor DB9F to 9 screw terminals
ADAP9-2 Screw terminal adaptor with two DB9F connectors and 18
screw terminals

PCIe-COM-4SMDB and RJ Family Manual
8
Special Order
Virtually any custom baud rate can be achieved with the standard card (see Table 5-2: Higher
Baud Rate Register Settings) and still be within the standard tolerance range for serial
communications. If that method doesn’t produce an exact enough baud rate a custom crystal
oscillator may be specified, contact factory with your precise requirement. Examples of special
orders would be conformal coating, custom software, etc., we will work with you to provide
exactly what is required.
Included with your board
The following components are included with your shipment, depending on options ordered.
Please take the time now to ensure that no items are damaged or missing.
•Four- or two-port card
•2 x Header to 2 x DB9M cable/bracket for Four-port “DB” model cards
•Software Master CD
•Quick-Start Guide

PCIe-COM-4SMDB and RJ Family Manual
9
Chapter 2: Installation
A printed Quick-Start Guide (QSG) is packed with the card for your convenience. If you’ve
already performed the steps from the QSG, you may find this chapter to be redundant and
may skip forward to begin developing your application.
The software is provided with this card on the CD and must be installed onto your hard disk
prior to use. Perform the following steps as appropriate for your operating system.
A complete driver support package is provided including an easy-to-use Windows terminal
program for testing out your COM ports. This simplifies the verification of proper COM port
operating. The card installs as standard COM ports in all operating systems.
A software reference manual is installed as part of the software and support package for this
product. Please refer to this document for extensive information and guidance on software
tools and programming support at your disposal.
CD Software Installation
The following instructions assume the CD-ROM drive is drive “D”. Please substitute the
appropriate drive letter for your system as necessary.
DOS
1. Place the CD into your CD-ROM drive.
2. Type B- to change the active drive to the CD-ROM drive.
3. Type GLQR?JJ- to run the install program.
4. Follow the on-screen prompts to install the software for this board.
Windows
1. Place the CD into your CD-ROM drive.
2. The system should automatically run the install program. If the install program does not
run promptly, click START | RUN and type BGLQR?JJ, click OK or press -.
3. Follow the on-screen prompts to install the software for this board.
Linux
1. Please refer to linux.htm on the CD-ROM for information on installing under linux.
Note: COM boards can be installed in virtually any operating system. We do support
installation in earlier versions of Windows, and are also likely to support future versions.

PCIe-COM-4SMDB and RJ Family Manual
10
Hardware Installation
Caution! * ESD A single static discharge can damage your card and cause
premature failure! Please follow all reasonable precautions to
prevent a static discharge such as grounding yourself by touching
any grounded surface prior to touching the card.
1. Do not install the card into the computer until the software has been fully installed.
2. Turn OFF computer power AND unplug AC power from the system.
3. Remove the computer cover.
4. Carefully install the card in an available PCIe expansion slot (you may need to remove a
backplate first).
5. Inspect for proper fit of the card and install and tighten the mounting bracket screw. Make
sure that the card mounting bracket is properly screwed into place and that there is a
positive chassis ground.
6. Four-port “DB” model cards use a header to DB9M cable accessory that installs in an
adjacent mounting bracket / slot location. Install this and tighten screw.
Figure 2-1: Port Configuration Utility Screenshot
.
7. Replace the computer cover and turn ON the computer.
8. Most computers should auto-detect the card (depending on the operating system) and
automatically finish installing the drivers.
9. Run the Port Configuration Utility program (setup.exe) to configure the protocol (RS-
232/422/485) for each COM port.
10. Run one of the provided sample programs that was copied to the newly created card
directory (from the CD) to test and validate your installation.

PCIe-COM-4SMDB and RJ Family Manual
11
Chapter 3: Hardware Details
There only user-selectable options for this card are for applying a termination load to the RS-
485 lines. Channel protocols are selected via software.
Figure 3-1: Option Selection Map –DB Models
DB9M connector
“DB” models use an industry standard 9-pin Male D-Subminiature connector with screw locks

PCIe-COM-4SMDB and RJ Family Manual
12
Figure 3-2: Option Selection Map –RJ Models
RJ45 connector
“RJ” models use an industry standard 8P8C modular jack.

PCIe-COM-4SMDB and RJ Family Manual
13
Factory Option Descriptions
Fast RS-232 transceivers (-F)
The standard RS-232 transceivers used are capable of speeds up to 460.8kbps which is
adequate in many applications. For this factory option, the board is populated with high-speed
RS-232 transceivers enabling error-free communications at up to 921.6kbps.
Remote Wake-Up (-W)
The “Remote Wake-Up” factory option is for use in RS232 mode when your PC enters the L2
low-power state. When the Ring Indicator is received on serial port COM A in the L2 power
state, Wake-Up is asserted.
Extended temperature (-T)
This factory option is for use in harsh environments and is populated with all-industrial rated
components, specified at a minimum temperature range of -40°C to +85°C.
RoHS compliance (-RoHS)
For international customers and other special requirements, this factory option is available in
RoHS compliant versions.

PCIe-COM-4SMDB and RJ Family Manual
14
Chapter 4: Address Selection
The card uses one I/O address space PCI BAR[0]. COM A, COM B, COM C, COM D, COM E,
COM F, COM G and COM H each occupy eight consecutive register locations.
The Vendor ID for all cards is 494F.
The Device ID for the PCIe-COM-4SMDB card is 10DAh.
The Device ID for the PCIe-COM-4SMRJ card is 10DAh.
The Device ID for the PCIe-COM-4SDB card is 105Ch.
The Device ID for the PCIe-COM-4SRJ card is 105Ch.
The Device ID for the PCIe-COM232-4DB card is 1099h.
The Device ID for the PCIe-COM232-4RJ card is 1099h.
The Device ID for the PCIe-COM-2SMDB card is 10D1h.
The Device ID for the PCIe-COM-2SMRJ card is 10D1h.
The Device ID for the PCIe-COM-2SDB card is 1050h.
The Device ID for the PCIe-COM-2SRJ card is 1050h.
The Device ID for the PCIe-COM232-2DB card is 1091h.
The Device ID for the PCIe-COM232-2RJ card is 1091h.

PCIe-COM-4SMDB and RJ Family Manual
15
Chapter 5: Programming
Sample Programs
There are sample programs with source-code provided with the card in a variety of common
languages. DOS samples are located in the DOS directory and Windows samples are located
in the WIN32 directory.
Windows COM Utility Program
WinRisc is a COM utility program provided on CD with the installation package for this card
that is very useful when working with any serial ports and serial devices. If you haven’t used
this program yet, do yourself a favor and run this program to test your COM ports.
Windows Programming
The card installs into Windows as COM ports so standard API functions can be used.
See the documentation for your chosen language for details.
In DOS the process is identical to programming 16550- compatible UARTs.
Baud Rate Generation
The built-in Baud Rate Generator (BRG) allows a wide range of input frequency and flexible
Baud Rate generation. To obtain the desired Baud Rate, the user can set the Sample Clock
Register (SCR), Divisor Latch Low Register (DLL), Divisor Latch High Register (DLH) and
Clock Prescale Registers (CPRM and CPRN). The Baud Rate is generated according to the
following equation:
The parameters in the equation above can be programmed by setting the “SCR”, “DLL”,
“DLH”, “CPRM” and “CPRN” registers according to the table below.
Setting Description
Divisor DLL + (256 * DLH)
Prescaler 2M-1*(SampleClock + N)
SampleClock 16 - SCR , (SCR = ‘0h’ to ‘Ch’)
M CPRM, (CPRM = ‘01h’ to ‘02h’)
N CPRN, (CPRN = ‘0h’ to ‘7h’)
Table 5-1: Baud Rate Generator Setting

PCIe-COM-4SMDB and RJ Family Manual
16
To ensure the proper operation of the Baud Rate Generator, users should avoid setting the
value ‘0’ to Sample Clock, Divisor and Prescaler.
The following table lists some of the commonly used Baud Rates and the register settings that
generate a specific Baud Rate. The examples assume an Input Clock frequency of 14.7456
Mhz. The SCR register is set to ‘0h’, and the CPRM and CPRN registers are set to ‘1h’ and
‘0h’ respectively. In these examples, the Baud Rates can be generated by different
combination of the DLH and DLL register values.
Baud Rate DLH DLL
1,200 3h 00h
2,400 1h 80h
4,800 0h C0h
9,600 0h 60h
19,200 0h 30h
28,800 0h 20h
38,400 0h 18h
57,600 0h 10h
115,200 0h 08h
921,600 0h 01h
Table 5-2: Sample Baud Rate Setting

PCIe-COM-4SMDB and RJ Family Manual
17
Chapter 6: Connector Pin Assignments
Input/Output Connections
The serial communications ports are interfaced at the card mounting bracket either via 4x
DB9M connectors or 4x RJ45 connectors.
PIN RS-232 RS-422 and
4-Wire RS-485 2-Wire RS-485
1 DCD TX- -
2 RX TX+ -
3 TX RX+ TX+/RX+
4 DTR RX- TX-/RX-
5 GND GND GND
6 DSR - -
7 RTS - -
8 CTS - -
9 RI - -
Table 6-1: DB9 Male Connector Pin Assignments
Figure 6-1: DB9 Male Connector Pin Locations
PIN RS-232 RS-422 and
4-Wire RS-485 2-Wire RS-485
1 DSR - -
2 DCD TX- -
3 DTR RX- TX-/RX-
4 GND GND GND
5 RX TX+ -
6 TX RX+ TX+/RX+
7 CTS - -
8 RTS - -
Table 6-2: RJ45 Connector Pin Assignments
Figure 6-2: RJ45 Connector Pin Locations

PCIe-COM-4SMDB and RJ Family Manual
18
RS-232
Signals
RS-232 Signal
Descriptions
RS-422
Signals
(4-w 485)
RS-422 Signal
Descriptions
RS-485
Signals
(2-wire)
RS-485 Signal
Descriptions
DCD Data Carrier Detected TX+ Transmit Data + TX/RX + Transmit / Receive +
RX Receive Data TX- Transmit Data - TX/RX - Transmit / Receive -
TX Transmit Data RX+ Receive Data + GND Signal Ground
DTR Data Terminal Ready RX- Receive Data -
GND Signal Ground GND Signal Ground
DSR Data Set Ready
RTS Request To Send
CTS Clear to Send
RI Ring Indicator
Table 6-3: COM signal names to corresponding signal descriptions
To ensure that there is minimum susceptibility to EMI and minimum radiation, it is important
that the card mounting bracket be properly screwed into place and that there be a positive
chassis ground. Also, proper EMI cabling techniques (cable connect to chassis ground at the
aperture, shielded twisted-pair wiring, etc.) should be used for the input/output wiring.

PCIe-COM-4SMDB and RJ Family Manual
19
Chapter 7: Specifications
Communications Interface
•I/O connection: DB9M or RJ45
•Serial ports: 4 (or 2) RS-232/422/485
•Serial data rates: RS-232 460.8k (921.6k avail)
RS-422/485 3Mbps
•UART: Quad type 16C950 with 128-byte transmit & receive FIFO,
16C550 compliant
•Character length: 5, 6, 7, 8, or 9 bits
•Parity: Even, Odd, None, Space, Mark
•Stop interval: 1, 1.5, or 2 bits
•Flow Control: RTS/CTS and/or DSR/DTR, Xon/Xoff
•ESD Protection: ±15kV on all signal pins
Environmental
•Operating temp.: Commercial: 0°C to +70°C
Industrial: -40°C to +85°C
•Storage temp.: -65°C to +150°C
•Humidity: 5% to 95%, non-condensing
•Power required: +3.3VDC @ 0.8W (typical)
•Size: 4.722“ long x 3.375” high
(120 mm long x 85.725 mm high)

PCIe-COM-4SMDB and RJ Family Manual
20
Customer Comments
If you experience any problems with this manual or just want to give us some feedback, please email
us at: [email protected]. Please detail any errors you find and include your mailing address so
that we can send you any manual updates.
10623 Roselle Street, San Diego CA 92121
Tel. [phone] FAX [phone]
www.accesio.com
