Section 1 General Overview
I. Foreword
About This Manual
This manual is designed for users of Eternity 4 and Eternity 5. All installation, setup, operational information, procedures,
screen captures, and other relevant materials are contained in this manual.
Safety Warnings and Cautions
When handling a printed circuit board (PCB), guard against possible static discharges by touching a grounded object
BEFORE touching the board. Static shock could cost unexpected damage of the board.
Design Change Disclaimer
Due to design changes and product improvements, information in this manual is subject to change without notice.
assumes no responsibility for any errors that may appear in this manual.
Reproduction Disclaimer
Neither this manual nor any part of it may be reproduced, photocopied, or electronically transmitted in any way without
the written permission of .
Technical Support
When you experience any difficulty installing or operating the Eternity software, please contact your local distributor or
at 1-866-241-9874.
II. Important information
Manufacture Default Code Setting:
1. Default Setting for Login User Name / Password is: dallas / ibutton
2. Operator Password: The default operator password is 00000000 (8 digit Zeros)
3. System Password: The default System password is 000000 (6 digit Zeros)
LED and Audio Indicator:
1. Program Mode: LED indicating GREEN, audio end with two beeps (Successful)
2. Program Mode: LED indicating Red, audio end with one beep (Fail)
3. Key Access Mode: LED indicating GREEN, audio end with two beeps (Valid Access)
4. Key Access Mode: LED indicating Red, audio end with one beep (Fail)
5. Unlock Mode: LED flashing GREEN, lock is in unlock mode
6. Lock Mode: LED flashing RED, lock is in lock mode
Important Keys:
1. DS1982/DS1990- User Key (Default key-fob color from : red, yellow, black, orange)
2. DS1994/DS1904- It contains an on board real time clock to reset the lock internal clock. (Default key-fob color from :
Green)
3. DS1977- Program Key. (Default key-fob color from : Purple)
4. DS1996- Firmware Upgrade Key (Default key-fob color from : Blue)

Page 5 of 36
III. General Lock Spec
This page shows the similar specifications of the Eternity 4 and Eternity 5.
Keypad: 12 all weather numeric keypad
Keypad Functions: Permanent codes, Temporary codes, one-time service codes
Power Supply: 4 standard AA batteries with a weatherized battery pack for all weather conditions
Power Supply Life Expectancy: 10,000 operations, low battery warning when system drops below 4.8 volts
Memory Retention: Flash memory never looses memory even without power
Programming / Communication Method: iButton key-fob, no annoying wires
Functions: Time zones for lock function (automatically unlock or lock), fully programmable exception dates (holidays),
temporary dates, and time zones for iButton key-fobs.
Finishes: Stainless, or Brass.
Handles: Reversible Lever
Audit Trail: 4000-event audit trail.
iButton Users: 500
Temporary Codes: No limit
Permanent Codes: 300
One Time service code: 10
Anti-tamper: Red-warming light stays on for 60 seconds after 3 consecutive invalid code entries
Key Bypass: Standard on all units
Door Preparation: Standard ANSI A115 Series Prep, optional by adding additional 5/8” through-bolt holes to add
stability to the lock and increase security.
Strike Plate: ANSI Standard 115.3. Square corner, 1-1/8 x 2-3/4 inch T strike with 1-1/4 lip-to-center dimension.
Latch: 2 3/4 inch backset standard (2 3/8 inch backset optional), solid brass with 1/2-inch throw 1-inch diameter bore is
required.
Materials: Zinc Alloy
Temperature: 0°F-120°F (-18°C-50°C)
Exposure: All weather conditions
Accessibility Standard: Meets ADA standards Americans with disabilities act.
Lock Back Time: 1 – 25 seconds (default is 5 seconds)
Working Voltage: 4.8-6.4V
Low Battery Warning: 4.8V or lower
Door Thickness: 1 3/8" to 2"
Keyway: Schlage C 6

Page 6 of 36
IV. Eternity IV Datasheet (Heavy Duty keypad Lock)
Hardware Spec
Functions
Ordering Information
PART DESCRIPTION
E4IKSC01 E-IV TM + Keypad Satin Chrome Lockset SW Version
E4IKSC02 E-IV TM + Keypad Satin Chrome Lockset No SW Version
ECYLSC6M Eternity Schlage C 6-Pin Master Key Cylinder
ACCESSORIES DESCRIPTION
D1977K DS1977 Programming Key
D1994K DS1994 Internal Clock Key
D1990K DS1990 iButton User Key
UIBPCR iButton Reader (iButton PC Receptor)
USBPCA USB PC Adapter
EternitySWCD Eternity Lock Management Software CD
PARAMETER DETAIL
Lock Weight 6 Lb
Working Current <10 mA
Idle Current 5 µA
Lock Back Time 5 (1 – 25) Seconds
Working Voltage 4.8-6.4V
Low Battery Warning 4.8V or lower
Power Source 4 AA Alkaline Batteries
Keypad Weather Proof Keypad
Handle Reversible Lever
Door Thickness 1 3/8" to 2"
Keyway Schlage C 6
Packed Weight
Packed Size
CTN Weight
CTN Size
DESCRIPTION SOFTWARE NON-SOFTWARE
Audit Trail Yes (3000 entries) N/A
iButton Key Users 800 (Combine iButton and code) 300 (Combine iButton and code)
Keycode Users See above See above
Timed Operation Yes Yes
Auto Lock/Auto Unlock 16 time schedules Fixed time schedule (7 days a week)
Passage Mode 16 time schedules Single time schedule
Time Shift User 16 time schedules Single time schedule
Remote Access Yes Yes
Storehouse/Classroom Mode Yes Yes
One Time Use Yes Yes
iButton User Yes Yes
Permanent Code User Yes Yes
Remote Code User Yes Yes
One-Touch Lock from Inside Yes Yes
Daylight Saving Yes Yes
Lock Out Function Yes Yes
User Key Assignment Method Software + Programming Key Keypad
Software Package Yes (Optional)
Pack List:
1. Front Handle
2. Back Handle
3. Front Lock
4. Back Lock
5. Accessory Box
•Latch
•Cylinder
•Screws

Page 7 of 36
Door Prep
Parts List
1 iButton Reader 9 Inside Mounting Plate
2 Keypad 10 Batteries Housing Cover
3 Outside Lock Housing 11 Inside Lock Housing
4 Outside Lever 12 Inside lever
5 Override Cylinder 13 Spindle
6 Outside Gasket 14 Strike Plate
7 Latch 15 Dust Boot
8 Inside Gasket

Page 8 of 36
Eternity IV Installation Instruction
Step 1. Install the latch
•Insert the latch into 1″hole on edge of the
door.
•Secure the latch in place with two screws.
Fig. 1
Step 2. Install outside lock housing
•Place the outside gasket (if required) on back of the
outside lock housing prior to the assembly; align the
gasket along the edge of the lock housing.
•Insert the square spindle into the center hub and turn
the spindle until it locks. Ensure that the Dot on
center hub is point to left.
•Place the outside lock
housing against the door,
feed the power plug
through the 2 1/8 inch
door hole.
Fig. 3
Step 3. Install inside mounting plate
•Place the inside gasket (if required) on the
mounting plate, and align the inside
gasket with the position hole.
•Feed the power plug through the
small hole on the mounting plate.
•Place the mounting plate against the
door, and secure the mounting plate
attach to outside lock housing with
three screws.
Fig. 4
Step 4. Install inside lock housing
•Plug the power cable into the
inside lock housing.
•Place inside lock housing on
top of the mounting plate,
•Ensure the square spindle into
inside lever hub. Secure the
inside lock housing with two
screws.
Fig. 5
Step 5. Install inside lever door handle.
Fig. 6
Step 6. Install outside lever door handle
•Ensure override shaft inside the
cylinder housing is in vertical position
(use flat screw driver to adjust the
position when needed)
Fig. 7
•Place the key cylinder into the outside
lever door handle, insert the manual
key to the cylinder and turn clockwise
90 degrees.
•Guide the cylinder into the cylinder
housing and snap the lever door
handle into the lever catch pin
•Turn the manual key counter
clockwise 90 degree and pull the key
out
Step 7. Install Strike plate
•Inset the dust boot into the
doorframe.
•Place the strike plate over
the dust boot.
•Secure the plate in place
with two screws.
Fig. 8

Page 9 of 36
V. Eternity V Datasheet (Medium Duty keypad Lock)
Hardware Spec
PARAMETER DETAIL
Weight (Lock only) 4.2 Lbs
Working Current 250 mA
Idle Current 15 µA
Motor Running Time 0.4 Second
Working Voltage 4.2-6.4V
Low Battery Warning 4.2V
Power Source 4 AA Alkaline Battery
Keypad Weather Proof Keypad
Handle Non handed
Door Thickness 1 3/8" to 2"
Keyway SC 6 Pin
Dimension (1ps) 10 x 8 x 4 ½”
Dimension (8pcs/box) 16 x 10 ½ x 19”
Package Weight (1) 5 Lbs
Weight (8pcs/Box) 40 Lbs
Software Spec
Description Software Non-software
Audit Trail Yes. 4,000 No
Users 800 299
Timed Operation Yes Yes
Remote Access Yes Yes
Storehouse/Classroom Mode Yes Yes
One Time User Yes Yes
Software Package Yes No
Lock from Inside No No
Set Up Method Software Keypad
Daylight Saving Yes Yes
Lock Out Function Yes Yes
Mortise Spec
3/4" throw heavy duty deadbolt with anti-saw hardened pins
Rustproof heavy duty 2 3/8" backset lock case
Individual spring to prevent lever sag, easily reversible
Forged brass lever handles exceed requirements of ADA
Auxiliary latch bolt
Heavy Duty 1/2" latch bolt with anti-friction latch, easily reversible
Interconnected Deadbolt Mortise:
While unlocked turn the handle up to enable (lock) the deadbolt, or
turn the handle down to disable (unlock) the deadbolt
Ordering Information:
PART DESCRIPTION PART DESCRIPTION
E5-SW E5 Software Lock D-1977 Programming Key
E5-NS E5 Non-Software Lock D-1994/1904 Clock Key
D-MC Master Cylinder D-1990 User Key
USBPCA/UIBPCR Programming Encoder IKeypad Software CD
Interconnected
Deadbolt Mortise
Turn handle up to lock
Regular Latch Deadbolt

Page 10 of 36
Major Lock Parts
1. Rear Handle
2. Rear Lock housing Screws
3. Rear Housing
4. Battery Plate Screw
5. Battery Plate
6. Rear Rubber Gasket
7. Door
8. Latch
9. Latch Screws
10. Dust Boot
11. Strike Plate
12. Front Lock Fastener Post
13. Square Shaft
14. Front Rubber Gasket
15. Front Lock Housing
16. Position Pin
17. Upper Fastener Post (optional)
18. Attachment Screw (optional)
19. iButton Reader
20. Keypad
21. Override Key Cylinder
22. Front Handle
Accessory Parts List
1. Battery Plate Screw (3)
2. Back Cover Screw (2)
3. Screws (4)
4. Square Shaft (1)
5. Position Pin (1)
6. Fastener Extension (2)
7. Upper Fastener Extension
8. Latch (1)
9. Strike Plate (1)
10. Dust Boot (1)
11. Override Key (2)
12. SC4 Cylinder (1)
13. iButton key (Optional)
Back View Installation
22
21
19
20
Front View
Installation

Page 11 of 36
Eternity-V-Installation
Step 1
Insert the latch into door
hole. Secure the latch with
two screws.
Step 2
Insert the square shaft (A) into the center hub (B) (Fig 1). Insert the position
pin into the hole on the center hub to secure the square shaft. Bend the end
of position pin around the center hub to secure the pin in place. (Fig 2)
Step 4
Place the front lock housing onto the door, with the
rubber gasket (E) between the door and lock housing.
Feed the power plug (F) through the hole (Fig 4).
Step 3
Screw in and tighten the two fastener extensions
(C) into the front lock fastener posts located on
both side of the center hub. Attach and tighten
the upper fastener extension (D) if needed (Fig
3). Note: The upper fastener extension (D) is
optional.
Fig 2
Fig 1 Enlarged
Fig 1
A
B
Fig 4
F
E
Fig 3
C
D (optional)
C

Page 12 of 36
Step 6
Install batteries, and plug in the power
cable. Secure the back lock housing onto
the battery plate. Fasten with 2 screws.
Press both catch pin in and snap the rear
handle into drive shift (Fig 6)
Step 5
Attach the battery plate onto the door, with the
rubber gasket between the door and battery
plate. Make sure the power plug go through the
hole on the plate. Secure the battery plate to
front lock fastener post with 2 screws. Fasten
upper fastener post (Optional) (Fig 5)
Step 8
Put strike box in doorframe, and
then strike plate over it. (Fig 8)
Step 7
Place the override cylinder into front handle
housing, insert override key through the hole into
cylinder. Turn the override key 90°clockwise.
Press both catch pin in and snap the front handle
into drive shift. Turn override key 90°counter
clockwise and pull the key out. (Fig 7)
Fig 8
Fig 7
Fig 5
Fig 6

Page 13 of 36
Eternity-V-Mortise-Installation
Step 2
Insert the square shaft (A) into the center hub (B). (Fig 1)
Insert the position pin into the hole on the center hub to
secure the square shaft. Bend the end of position pin
around the center hub to secure the pin in place. (Fig 2)
Fig 2
Fig 1 Enlarged
Fig 1
A
B
Step 3
Screw in and tighten the two fastener extensions (C)
into the front lock fastener posts, located on both side
of the center hub. Attach and tighten the upper
fastener extension (D) (Fig 3) Note: The upper
fastener extension (D) is optional.
Fig 3
D (optional)
C
Step 4
Place the front lock housing onto the door, with
the rubber gasket (E) between the door and
lock housing. Feed the power plug (F) through
the hole (Fig 4).
Fig 4
F
E
Step 1
Insert the lock case into mortise
pocket. Secure the lock case with
two screws.

Page 14 of 36
Fi
g
8
Step 8
Install the dust boot with
strike plate onto it. (Fig 8)
Step 6
Install batteries, and plug in the power
cable. Secure the back lock housing onto
the battery plate. Fasten with 2 screws.
Press both catch pin in and snap the rear
handle into drive shift (Fig 6)
Fi
g
6
Step 5
Attach the battery plate onto the door, with the rubber
gasket between the door and battery plate. Make sure the
power plug go through the hole on the plate. Secure the
battery plate with 3 screws; fasten to front lock fastener
extension post and upper fastener post (Fig 5) Note:
upper fastener post is optional.
Fi
g
5
Step 7
Place the override cylinder into front handle housing,
insert override key through the hole into cylinder.
Turn the override key 90°clockwise. Press both catch
pin in and snap the front handle into drive shift. Turn
override key 90°counter clockwise and pull the key
out. (Fig 7)
Fi
g
7

Page 15 of 36
Major Lock Parts
1. Rear Handle
2. Rear Lock housing Screws
3. Rear Housing
4. Battery Plate Screw
5. Battery Plate
6. Rear Rubber Gasket
7. Door
8. Lock case (Mortise)
9. Latch Screws
10. Dust Boot
11. Strike Plate
12. Front Lock Fastener Post
13. Square Shaft
14. Front Rubber Gasket
15. Front Lock Housing
16. Position Pin
17. Upper Fastener Post (optional)
18. Attachment Screw (optional)
19. iButton Reader
20. Keypad
21. Override Key Cylinder
22. Front Handle
Accessory Parts List
1. Battery Plate Screw (3)
2. Back Cover Screw (2)
3. Screws (4)
4. Square Shaft (1)
5. Position Pin (1)
6. Fastener Extension (2)
7. Upper Fastener
Extension
8. Mortise (1)
9. Strike Plate (1)
10. Dust Boot (1)
11. Override Key (2)
12. SC4 Cylinder (1)
13. Allan Wrench (1) (Optional)
14. Allan Screws (2) (Optional)
15. iButton key (Optional)
Back View
Installation
22
21
19
20
Front View
Installation

Page 16 of 36
Section 2 Eternity Software Guide
1. Software Setup
The Eternity Software works the same for both Eternity 4 and Eternity 5.
Operating System
Eternity software is compatible with Microsoft Windows 98/2000/XP/Vista. All software must be installed using
Windows administrator account, but all level Windows users can use the program. Failure to install the applications may
result in error messages and an incomplete installation. For Vista users, you may need to run the application each time as
an administrator.
Installing 1-Wire USB Driver First
1. Insert installation CD. Note: On most computers, the Autorun program should launch automatically. If it does not,
select Start/Run, browse to CD-ROM drive, select the Autorun file.
2. Select 1-Wire USB Driver Installation, the Setup Wizard will guide you through the steps.
3. The License Agreement screen displays.
4. Select I Agree, and then Install to start installation.
5. Select Finish. The 1-Wire USB Driver Installation is complete.
6. Plug the 1-Wire USB device into the usb port on your computer
Installing the iKeypad Software
1. Select Eternity Software Installation. The Auto installer will guide you through the steps and create the shortcut –
“Eternity4-ikpad.exe” on your desktop.
2. Select Next until the installation finishes.
Login

Page 17 of 36
License Name: Input the name of your company
User Name: dallas
Password: ibutton
Default User Name and Password can be modified but can’t be deleted.
Change System Password
The default system password is 000000(6 Zeros). It is mandatory to change and remember the facility system password
when the user is ready to use this software. It is highly recommended that the system password need to be changed from
the default setting for security purpose.
2. Access Control Management I
I. Lock Setup
New Lock Set Up
Click New Lock Setup Mission button from Mission Management Tab.
This mission will accomplish:
9Initialize the lock back to the manufacture default setting.
9Sets the system password, and real time to the lock.
9Set Daylight Saving enable or disable
9Set Lock Mode to normal open or normal close
9Set LED Blinking or idle

Page 18 of 36
Steps to set up a new lock mission
9Snap the program key (DS1977) onto the USB blue dot receptor, login to the software and click on the New Lock
Setup icon, and click issue key. Click ok to clear the pop up warning message box.
9Now take the program key to the lock, hold the reset button on the lock until there are two beeps and a solid green
light; while the led is solid green, touch the program key to the iButton reader on the lock, and there will be two beeps
to show that it worked. The lock information will now be on the program key.
9Snap the program key back onto the USB blue dot receptor, and click the “Read Key” icon. New lock id number will
appear in the retrieve window. Now click the Add Lock icon. (If the lock already exists in the system, the “exist in
database” will show “True”, and you can't add the same lock to the system).
9Type in a lock name, location, status, and lock type, then click the save button.
¾Lock Setting is an alternative way to add existing locks to the system. We recommend users keep the lock ID
in file after the new lock setup so that you can manually input lock profile into the system when needed.
Edit An Existing Lock
Select Lock from lock list, click “Modify” button.
In this screen the upper window shows the lock
list and the bottom window shows the valid key
list for the selected lock.
•Serial ID: The Serial ID can be found
from the manufacture package. Serial
ID can be also obtained by using the
New Lock Setup mission.
Lock status: By manufacture default, the
lock status is “No Limit Storeroom Mode.”
To change the lock status, Click “Modify”,
and then click on underlined “Lock Status”,
Time Operation Setting screen will pop up.
Highlight the group number, click “Select”
button.

Page 19 of 36
II. User Setup
Onsite User Setting
¾Add/Edit user information
To add/edit iButton / key code user, click “Add” button in the key setting menu, and following screen will pop up:
To add iButton user, click ok and snap a user iButton key into the encoder. Click on the empty field of “Serial ID”,
the iButton key ID will be detected by the system and automatically entered. If the user key already exists in the system,
the software will pop up a warning. No duplicate keys are allowed in one system.
To add key code user, check the “Key Code User” and click ok. Type in user code under Key Code field. Enter the
User profile as follows:
•First name: Input the first name of the key owner.
•Last name: Input the last name of the key owner.
•Status: Active or Inactive (reserve for future use) User. We suggest not deleting any existing user for security reason.
User can change the key status from Active to Inactive for a lost key or employee that left.
•Department: User can either select the pre-input Department name from the pull down list, or input a new name in
the field. The new name will be saved to the Department list once the data saved.
•Title, address: Can be entered as the key owner profile; photo of the owner can be uploaded to the program.
(These are optional information fields)
After input all the users, click “Save” button and all user keys/codes will be stored.

Page 20 of 36
¾Assign Onsite user to lock
¾Single-lock key Assignment Mission:
This mission is to assign iButton keys and user codes to one lock.
oSelect lock from lock list
oChange the time shift if needed
oClick to change the ‘Selected’ Column for the assigned users to the lock
oSnap in programming key
oClick “Issue Key”
oComplete the mission by touching the programming key to the lock reader, wait till you hear a double beep.
9Multiple Lock Assignment
This mission is to assign key list to multiple locks. Up to 25 locks can be assigned to each programming key.
Copy Lock Setting
This is a very useful tool when multiple locks have identical setting such as key list and/or timetable. After enroll all the
locks and users into the system, Set timetable and assign keys/codes to one lock, then use this lock as model lock.
Double click on the field of “Select Model Lock”, and select the lock from the pop up screen. Check the
“Selected” boxes and issue the program key. Complete the mission by touching the programming key to each
selected lock reader, wait till hear a double beep.
Step1: Select Model
Lock from lock list Step2: Select “Same Key
List” or/and “Same Time
Table
”
to be copied
Step3: Select the lock
from the list
