Accorroni AS COND User manual

1
AS COND - AS COND EX
Floor standing hot air generators
indoor/outdoor gas condensing
AS COND - AS COND EX
INSTALLATION MANUAL

2
INDEX
PURPOSE ...................................................................................................................................................................................... 3
GENERAL INFORMATION AND PRECAUTIONS ....................................................................................................................... 5
PLATE OF THE CHARACTERISTICS OF THE WARM AIR HEATER ....................................................................................... 9
DATA SHEET WARM AIR HEATER series: “AS COND” "AS COND EX" .............................................................................. 19
ECODESIGN ............................................................................................................................................................................... 21
FUNCTION DESCRIPTION ....................................................................................................................................................... 22
INSTALLATION .......................................................................................................................................................................... 26
ELECTRICAL DIAGRAMS ................................................................................................................................ 39
TABLE OF MINIMUM MAINTENANCE INTERVALS .............................................................................................. 45
TROUBLESHOTING ....................................................................................................................................... 46
ANNEXES ..................................................................................................................................................... 47
MANUAL “Clima” CAREL for the modulation of burner ......................................................................................47
IMPORTANT WARNINGS .............................................................................................................................. 50
TABLE OF A2B ACCORRONI PIPES AND ELEMENTS FOR FLUE............................................................................................. 29
TABLE OF PIPES AND ELEMENTS FOR FUME EXHAUST APPROVED (POCED) ...................................................... 31
TRI THERMOSTAT ....................................................................................................................................... 36

3
PURPOSE
Machine we mean the warm air heater complete with its accessories
This manual is intended for operators and specialized personnel and provides important information and warnings on safety in
the installation, commissioning, use and maintenance of the machine, to allow it to be used correctly.
Inside you will find the following descriptions and information:
-a functional description of the machine and of each of its parts
-machine safety information
-information for correct installation of the machine
-information for correct use of the machine
-information for correct routine and scheduled maintenance of the machine
Symbols used in the manual
In some parts of the manual there are triangular DANGER signs.
Pay great attention to these, as they indicate a situation of potential danger.
DANGER
Maximum danger level!
This symbol indicates operations which, if not carried out correctly, cause serious injury, death or
long-term health risks.
WARNING
This symbol indicates operations which, if not carried out correctly, may cause serious injury, death or long-
term health risks.
CAUTION
This symbol indicates operations which, if not carried out correctly, may cause damage to the ma- chine and/or
injury to people.
DANGER LIVE COMPONENTS
This symbol indicates operations which, if not carried out correctly, lead to electric shocks with lethal
consequences.
DANGER FLAMMABLE MATERIAL
This symbol indicates the presence of flammable materials.
DANGER BURNING
This symbol indicates the risks of burns due to high temperatures.
DANGER CRUSHING OF LIMBS
This symbol indicates the presence of moving parts: danger of crushing of limbs.
WARNING MOVING PARTS
This symbol indicates that you must keep limbs away from moving mechanical parts; danger of crushing.
DANGER EXPLOSION
This symbol signals places where an explosive atmosphere may be present. An explosive atmosphere is defined
as a mixture - under atmospheric conditions - of air and flammable substances in the form of gases, vapours,
mist or dust in which, after ignition has occurred, combustion spreads to the entire unburned mixture.
PERSONAL PROTECTION EQUIPMENT
These symbols indicate the equipment that must be worn and kept by the operator for protection against
threats against safety and/or health while at work
ENVIRONMENTAL PROTECTION
This symbol gives indications for the use of the machine with respect for the environment.
IMPORTANT INFORMATION
This symbol indicates important information that you must bear in mind.
DANGER
WARNING
CAUTION

4
This manual is an essential and integral part of the machine, therefore it must be followed, even in the case of
transfer of ownership or to another facility, and must be stored with care.
In case of damage or loss, another copy must be requested from the manufacturer.
The operator and specialized personnel are required to read and understand the contents of this manual.
The manufacturer declines all responsibility for damage to people, animals and things caused by:
oincorrect use of the machine;
oimproper intended use of the machine;
ouse of the machine that does not comply with the instructions in this manual;
ouse that does not comply with laws, regulations, decrees, prescriptions, European, national, regional and
district ordinances.
The manufacturer also declines all responsibility if the machine is not installed or checked
periodically or repaired by service centres authorized by the manufacturer or by personnel specialized.
By specialized personnel we mean “maintenance technicians with specific knowledge of
heating in rooms where people are present".
This machine cannot be used by people (including children) with reduced physical, sensory,
mental or with little experience and knowledge of the machine in question unless the person is
been instructed on its use by the person responsible for its safety or operates under supervision
of the person responsible for safety.
IT IS STRICTLY FORBIDDEN TO USE THIS MACHINE IN THE PRESENCE OF AN
EXPLOSIVE ATMOSPHERE.
The system design, installation, commissioning, periodic checks and repairs of this machine must only be
carried out by qualified personnel.
In particular, attention is drawn to the obligations imposed by laws, decrees, rules, ordinances,
Prescriptions European, national, regional and local in matters of design, authorizations, installation,
controls periodicals, maintenance, combustion checks and atmospheric emissions, which the operator and
In the event of problems or malfunctioning of the machine, the operator must disconnect the power supply
machine and avoid any attempt to repair in order to avoid damage to the machine and / or to third parties.
See description in the TROUBLESHOOTING chapter of this manual.
Before any maintenance or repair work, remove the power supply to the
machine by selecting - O - on the electric control board
.
At the end of each heating season, the operator must request the intervention of specialized personnel to clean the combustion
chamber and the heat exchanger.
At the beginning of each heating season and, according to the deadlines set by law and regulations, the operator must have
the efficiency of all functional and safety parts of the machine checked by specialized personnel and have the combustion
checked.
The results of these interventions will be recorded in the "central log book".
The air filter, if provided, must be kept clean frequently to keep it clean.
It must be removed from its frame, blown with compressed air (see MAINTENANCE chapter) and put back in its frame.
When the air intake grille is dirty, it must be cleaned with a brush or vacuum cleaner without however removing it.
Explanation of graphic symbols on controls and alarm devices
Voltage
Heating Intervention of the thermal
switch of the remote
Intervention of the safety limit
with manual reset
Burner off
Only ventilation
WARNING

5
GENERAL INFORMATION AND PRECAUTIONS
This machine is suitable for the following uses:
a) Direct heating of the blown air through its own fan unit.
The heat exchange occurs by contact between the external walls of the combustion chamber / heat exchanger and the air
that passes through it.
b) Ventilation only.
In mode (a), the machine must be equipped with a burner, connected to the electric power supply line, to the gas pipe and to
a suitable system for discharging the products of combustion and condensate.
In mode (b) it is sufficient to connect the machine to the power supply line.
This machine must be used for heating the room air.
Attention is drawn to the fact that the machine is not suitable for use for other purposes; and in particular it is
not suitable for use in normal operation at average air outlet temperatures above 80 ° C.
The manufacturer is solely responsible for the functional characteristics of the machine
if it is used in the manner and within the limits described in this manual.
Liability and Warranty
The manufacturer guarantees its new products from the date of installation in accordance with current regulations and / or in
accordance with the sales contract.
Verify, upon initial start-up, that the machine is intact and complete.
Failure to comply with what is described in this manual, operational negligence, incorrect installation and the execution of
unauthorized modifications, cause the manufacturer to void the machine warranty.
In particular, the warranty and liability rights expire in the event of damage to persons and / or things, if the damage itself is
attributable to one or more of the following causes:
-incorrect installation, commissioning, use and maintenance of the machine;
-improper, erroneous and unreasonable use of the machine;
-intervention of unskilled personnel;
-execution of unauthorized modifications to the machine;
-use of the machine with defective safety devices, incorrectly applied and / or not working;
-installation of additional components not tested together with the machine;
-supplying the burner with unsuitable fuels;
-defects in the fuel supply system;
-use of the machine even following the occurrence of an error and / or an anomaly;
-repairs and / or overhauls performed incorrectly;
-modification of the combustion chamber by introducing inserts that prevent the regular development of the
constructively established flame;
-insufficient and inappropriate supervision and care of the machine components most subject to wear;
-use of non-original components, whether they are spare parts, kits, accessories and optionals;
-causes of force majeure.
Furthermore, the manufacturer furthermore declines any and every responsibility for the failure to observe
the contents of this manual.
WARNING

6
Information on safety and prevention
The machine has been designed and built in compliance with the standards and directives in force, applying the known
technical safety rules and providing for all potential dangerous situations.
However, it is necessary to take into account that careless and clumsy use of the machine can cause situations of danger
of death for the user or third parties, as well as damage to the machine itself or to other assets.
Distraction, lightness and too much confidence are often the cause of injuries; as can fatigue and drowsiness.
The following should be taken into consideration:
-the machine must only be used for the use for which it was expressly intended.
-Any other use is to be considered improper and therefore dangerous.
In particular:
The type and pressure of the fuel, the voltage and frequency of the supply voltage, the minimum and maximum flow rates
at which the machine can be adjusted, the ambient temperature, must be within the values indicated in this manual.
-It is not allowed to modify the machine to alter its performance and intended use.
-The machine must be used in flawless technical safety conditions.
Any disturbances that could compromise safety must be eliminated promptly.
-It is not allowed to open or tamper with the machine components, except only the parts required for maintenance.
-Only the parts specified by the manufacturer can be replaced.
The manufacturer guarantees safety and proper functioning only if all machine components are intact and positioned
correctly.

7
CONSTRUCTION EXAMINATION AND SAFETY REQUIREMENTS
The warm air heater consists of an aluminium frame and an external panelling in pre-painted sheet metal: the panels are
internally insulated with a glass wool mat.
In the heating section we find a combustion chamber and a heat exchanger.
In this area, the insulating mat is protected against the danger of overheating by a galvanized sheet cover.
In the fan section, located in the lower part of the warm air heater, there are one or more double inlet centrifugal fans,
individually driven by a three-phase electric motor / s with belt drive / s.
The fan unit is protected by an anti-finger grid that prevents accidental contact with parts of the body and the entry of leaves
or external objects.
It is designed to prevent the entry of a ball with a diameter of 16 mm, with a force of 5N.
The grid can only be removed with the aid of a tool.
The combustion chamber, built in stainless steel for high temperatures, is fixed to the frame so that its thermal expansion
does not compromise its duration over time.
The heat exchanger made with stainless steel tubes is solidly welded to the combustion chamber.
Suitable openings on both sides allow easy access for inspection and maintenance.
On the front side of the warm air heater we find:
-a plate to fit the automatic forced draught gas / fuel oil burner
-an electric control board complete with
-switch
-HEATING / VENTILATION / BURNER STOP switch
-voltage indicator
-remote switch thermal intervention light (only in 3F models)
-Safety Limit intervention light;
a combination of 3 thermostats (TRITHERMOSTAT) ensure the following control and safety functions:
-FAN (TR): thermostat normally open for the automatic start and stop of the fan unit in
"HEATING" phase;
-LIMIT (TW): burner maximum thermostat, normally closed with automatic reset.
oAutomatically turns off the burner to prevent the air temperature at the warm air heater
outlet exceeding the safety limit;
-LIMIT2 (STB): burner safety thermostat, normally closed with manual reset and a positive security.
oAutomatically turns off the burner to prevent the air temperature at the warm air heater outlet from
exceeding the safety limit set by the reference standard.
Its calibration is imposed at 100°C by the manufacturer and must not be modified to avoid overheat of the
warm air heater;
(to reset the burner, read the instructions in the Chapter: TRI-THERMOSTAT).

8
Other essential safety requirements
Electrical equipment.
After the various assembly stages, all warm air heaters are subjected to the following electrical checks to verify compliance:
-visual check of the electrical circuit and tightening of the connections;
-continuity of the earth circuit;
-insulation resistance test;
-voltage test.
Temperatures.
The temperatures of the accessible areas for normal use of the warm air heater comply with the European reference standard.
Noise.
All the necessary measures have been taken to contain noise.
The values in dB (A) are shown in the tables Chapter: TECHNICAL DATA.
Reports.
The signals on the controls and on the alarm devices are made with graphic symbols according to the ISO7000 standard.
For an explanation of the symbols used, refer to the Chapter Explanation of Graphic Symbols on page. 4.
At the beginning of each heating season and, according to the deadlines set by law and regulations, the operator must have
the efficiency of all functional and safety parts of the machine checked by specialized personnel and have the combustion
checked.
The results of these interventions will be recorded in the "central booklet".
The air filter, if provided, must be kept clean frequently to keep it clean.
It must be removed from its frame, blown with compressed air (see MAINTENANCE chapter) and put back in its frame.
When the air intake grille is dirty, it must be cleaned with a brush or vacuum cleaner without however removing it.
REFERENCE STANDARDS, DIRECTIVES AND REGULATIONS
The manufacturer declares that the machine is built in a workmanlike manner based on UNI, UNI technical
standards CIG, CEI; is according to:
-to GAR 2016/426 (EU),
-the Machinery Directive 2006/42 / EC,
-the Low Voltage Directive 2014/35 / EU,
-the Electromagnetic Compatibility Directive 2014/30 / EU,
-to ECODESIGN: Directive 2009/125 / EC,
-ErP REGULATION 2016/2281 / UE, STEP II °
SOME REFERENCE STANDARDS AND LAWS:
-UNI-CIG 7129 for natural gas installations
-UNI-CIG 7131 for LPG installations
- EN 17082: 2019
-Law 10/91 for the containment of energy consumption
-Law 46/90 for plant safety
-Ministerial Decree 08/11/2019 technical rule of fire prevention

9
PLATE OF THE CHARACTERISTICS OF THE WARM AIR HEATER
On the front of the warm air heater, the Technical Characteristics Plate is applied, made with ultra-destructible film which, if
removed, cannot be reused.
A facsimile of this plate is shown below.
Fig. 1 Facsimile of the plate on the warm air heater
MINIMUM HEAT INPUT
PLATE OF THE CHARACTERISTICS OF THE WARM AIR HEATER
On the front of the warm air heater, the Technical Characteristics Plate is applied, made with ultra-destructible film which, if
removed, cannot be reused.
A facsimile of this plate is shown below.
Fig. 1 Facsimile of the plate on the warm air heater
MINIMUM HEAT INPUT
9
Rev.5 del 04-08/2021 Pag. 9 | 78
TARGHETTA DELLE CARATTERISTICHE DEL GENERATORE d’aria calda
Sulla parte frontale del generatore d’aria calda viene applicata la Targhetta delle Caratteristiche Tecniche realizzata
con pellicola ultradistruttibile che, se rimossa, non può essere riutilizzata.
Qui di seguito viene riportato un facsimile di tale targhetta.
Figura 1 Facsimile della targhetta posta sul generatore d'aria calda.
A2B Accorroni E.G. s.r.l.
Via dʼAncona, 37 - 60027 Osimo (An)
Tel. [phone]
www.accorroni.it - [email protected]

10
CONSTRUCTION CHARACTERISTICS
COMPOSITION OF THE “AS COND” VERSION Models from 50 to 65,
with single-phase motor, and direct driven fan
1) Air outlet
2) Rear smoke box door
3) Burner
4) Burner anchor plate
5) Centrifugal fan
6) Air inlet grille
7) Condensate drain with siphon
8) Smoke exhaust connection
9) Rear smoke box
10) Heat exchanger
11) Combustion chamber
12) Fan motor
13) Tri-thermostat
14) Electrical board
16) Frame made of aluminium
sections
17) External insulated panels
Models from 80 to 200, with three-phase motor, and transmission driven fan
1) Air outlet
2) Rear smoke box door
3) Burner
4) Burner anchor plate
5) Centrifugal fan
6) Air inlet grille
7) Condensate drain with siphon
8) Smoke exhaust connection
9) Rear smoke box
10) Heat exchanger
11) Combustion chamber
12) Fan motor
13) Tri-thermostat
14) Electrical board
15) Pulleys and drive belts
16) Frame made of aluminium
sections
17) External insulated panels
18) Motor's belt tightening slide

11
Models 250 and 600, with three-phase motor and transmission driven fan
1) Air outlet
2) Rear smoke box door
3) Burner
4) Burner anchor plate
5) Centrifugal fan
6) Air inlet grille
7) Condensate drain with siphon
8) Smoke exhaust connection
9) Rear smoke box
10) Heat exchanger
11) Combustion chamber
12) 2 Fan motors
13) Tri-thermostat
14) Electrical board
15) Pulleys and drive belts
16) Frame made of aluminium
sections
17) External insulated panels
18) Motor's belt tightening slide
19) Combustion air intake for type C
Fig. 3 Left: Warm air heater 1Ph with air inlet filter and head for direct air distribution.
Right: Warm air heater 3Ph with head for direct air distribution.

12
WEIGHTS and DIMENSIONS "AS COND" SERIES
Weight in [kg] and dimensions in [mm].
HEATER
Head
height
Flue
height
Air Outlet
connection
Air Inlet
connection
Frame
profile
Flue
system
Weight (1)
Net head
weight
MOD. Lenght Width Height
net
Packed
A
B
C
D
E
F
G
H
I
L
Ø
Kg
Kg
Kg
NOTA 1: The X 600 model is made in 2 sections with the height of the fan section of 1150 mm and the heating section of
1690 mm.
AS COND 50 870 636 1750 305 860 596 830 630 830 20 100 165 175 10
AS COND 65 870 636 1750 305 860 596 830 630 830 20 100 170 180 12
AS COND 80 1020 750 1950 405 935 670 940 690 940 40 130 270 282 37
AS COND 100 1020 750 1950 405 935 670 940 690 940 40 130 275 287 37
AS COND 150 1440 1020 2340 405 1070 940 1360 760 1360 40 150 435 450 40
AS COND 175 1440 1020 2340 405 1070 940 1360 760 1360 40 150 440 455 40
AS COND 200 1440 1020 2340 405 1070 940 1360 760 1360 40 150 445 460 40
AS COND 250 1790 1020 2340 405 1130 940 1710 760 1710 40 200 570 590 46
AS COND 300 1790 1020 2340 405 1130 940 1710 760 1710 40 200 580 600 46
AS COND 425 2300 1340 2660 405 1220 1260 2220 930 2220 40 250 885 905 67
AS COND 500 2300 1340 2660 405 1220 1260 2220 930 2220 40 250 905 925 67
AS COND 600 (1) 2300 1500 2840 445 1400 1420 2220 1070 2220 40 250 1015 1035 70
*complete with burner and gas ramp
connection
Connection
of the air
outlet duct
Connection
of the air
inlet duct
The air inlet grille is on the LEFT up to model X200 and on
the RIGHT
from model X250 up to model X600.
RIGHT and LEFT are in relation to
the burner side.
In the drawing the grille is RIGHT
The
grille position can be reversed.

13
UNION OF THE FAN SECTION WITH THE HEATING SECTION OF WARM AIR HEATERS
"AS COND 600" and variants
The warm air heaters X 600 and variants are produced and delivered in 2 sections (fan and heating).
Proceed as follows:
-remove the packaging of the 2 sections;
-remove the pallet by lifting the ventilating section (A) by means of the 4 lifting eyebolts located on the
upper profile of the section itself;
-place the ventilating section (A) on a level floor;
-remove the 4 lifting eyebolts
-position the self-adhesive gasket (2) supplied along the side of the aluminum profile so that it adheres to the
aluminum profile of the heating section (B);
-place the heating section (B) on the ventilating section (A) using the 4 lifting eyebolts located in the upper profile of
the section itself;
-remove the 4 lifting eyebolts
-for mod. XO and XEO join the 2 sections horizontally;
-fix the 2 sections with the supplied screws through the brackets (1) located in the fan section (A);
-connect the tri-thermostat to the electrical panel with the supplied cable.
The warm air heater is supplied with screws, plates, brackets and self-adhesive gaskets for the versions XO e XEO.
ASSEMBLY OF THE BURNER PROTECTION CABIN FOR "AS COND EX 600" WARM AIR
HEATERS
Proceed as follows:
-place the edge (4) of the cabin on the upper profile of the warm air heater, on the burner side;
-drill the side profiles in correspondence with the brackets (3) of the cabin (holes Ø 5 mm);
-screw the brackets with the supplied screws.
FIXING THE HEAD FOR DIRECT AIR DISTRIBUTION ON THE WARM AIR
HEATERS AS COND 300-425-500- 600 series
-Place the head for direct air distribution on the warm air heater
-Position the 4 brackets supplied (as shown in the photo).
-Screw the 16 self-drilling screws 6.3x16 supplied both on the profile of the
warm air heater and on the profile of the head.

14
COMPOSITION OFWARM AIR HEATER “AS COND EX” VERSION
Models “50” and “65” with single-phase motor and direct driven fan
1) Air outlet
2) Rear smoke box door
3) Burner
4) Burner anchor plate
5) Centrifugal fan
6) Air inlet grille
7) Condensate drain with siphon
8) Smoke exhaust connection
9) Rear smoke box
10) Heat exchanger
11) Combustion chamber
12) Fan motor
13) Tri-thermostat
14) Electrical board
16) Frame made of aluminium
sections
17) External insulated panels
18) Burner cabin for protecting burner
and electric components
Models from “AS COND EX 80” to “AS COND EX 200” with three-phase motor and transmission
driven fan
1)
Air outlet
2) Rear smoke box door
3) Burner
4) Burner anchor plate
5) Centrifugal fan
6) Air inlet grille
7) Condensate drain with siphon
8) Smoke exhaust connection
9) Rear smoke box
10) Heat exchanger
11) Combustion chamber
12) Fan motor
13) Tri-thermostat
14) Electrical board
15) Pulleys and drive belts
16) Frame made of aluminium
sections
17) External insulated panels
18) Motor's belt tightening slide
20) Burner cabin protecting burner
and electric components

15
Models “AS COND EX 250”, “AS COND EX 300” with three-phase- motor and transmission
driven fan
1) Air outlet
2) Rear smoke box door
3) Burner
4) Burner anchor plate
5) Centrifugal fan
6) Air inlet grille
7) Condensate drain with siphon
8) Smoke exhaust connection
9) Rear smoke box
10) Heat exchanger
11) Combustion chamber
12) Fan motor
13) Tri-thermostat
14) Electrical board
15) Pulleys and drive belts
16) Frame made of aluminium
sections
17) External insulated panels
18) Motor's belt tightening slide
20) Burner cabin protecting burner
and electric components
Warm air heater XE for outdoor
Installations in vertical version

16
WEIGHTS and DIMENSIONS "AS COND EX" SERIES
Weight on [kg] and dimensions on [mm].
The air inlet grille is on the LEFT till model XE200 and on the RIGHT from model XE250 up to model XE600.
RIGHT and LEFT are in relation to the burner side.
In the drawing the grille is RIGHT
The grille position can be reversed.
NOTE 1: The XE 600 model is made in 2 sections with the height of the fan section of 1150 mm and the heating
section of 1690 mm.
HEATER Flue
height
Air Outlet
connection
Air Inlet
connection
Burner cabin Flue
system
Weight (*)
MOD. Lenght Width Height Depth Height Net Packed
A B C E F G H I N O Ø Kg Kg
AS COND EX 50 870 636 1750 860 596 830 630 830 400 1100 100 187 197
AS COND EX 65 870 636 1750 860 596 830 630 830 400 1100 100 192 202
AS COND EX 80 1020 750 1950 935 670 940 690 940 400 1220 130 295 307
AS COND EX 100 1020 750 1950 935 670 940 690 940 400 1220 130 300 312
AS COND EX 150 1440 1020 2340 1070 940 1360 760 1360 600 1700 150 479 494
AS COND EX 175 1440 1020 2340 1070 940 1360 760 1360 600 1700 150 484 499
AS COND EX 200 1440 1020 2340 1070 940 1360 760 1360 600 1700 150 489 504
AS COND EX 250 1790 1020 2340 1130 940 1710 760 1710 800 2170 200 615 635
AS COND EX 300 1790 1020 2340 1130 940 1710 760 1710 800 2170 200 625 645
AS COND EX 425 2300 1340 2660 1220 1260 2220 930 2220 900 2500 250 970 985
AS COND EX 500 2300 1340 2660 1220 1260 2220 930 2220 900 2500 250 990 1005
AS COND EX 600(1) 2300 1500 2840 1400 1420 2220 1070 2220 900 2680 250 1120 1140
*) complete with burner and gas train
Connection of the
air
outlet duct
Connection
of the air
inlet duct

17
STANDARD HEAD FOR DIRECT AIR DISTRIBUTION WARM AIR HEATERS OF THE
"AS COND EX "
Air blown and dimensions in mm with horizontal and vertical fin vents on three sides of the nozzles.
MOD.
P Q D R T S n° of nozzles
(1)
Air blown in m.
max 2) min
50 825 591 305 300 300 200 1+1+1 16 16
65 825 591 305 300 300 200 1+1+1 16 16
80 935 665 405 550 550 300 1+1+1 34 34
100 935 665 405 550 550 300 1+1+1 38 38
150 1355 935 405 750 750 300 1+1+1 55 55
175 1355 935 405 750 750 300 1+1+1 60 60
200 1355 935 405 750 750 300 1+1+1 63 63
250 1355 935 405 750 750 300 1+2+1 74 60
300 1355 935 405 750 750 300 1+2+1 80 62
425 2215 1255 405 650 750 300 1+3+1 90 69
500 2215 1255 405 650 750 300 1+3+1 94 72
600 2215 1415 405 650 750 300 1+3+1 102 84
1) Short side (Q) + long side (P) + short side (Q).
2) The final speed of the blown air is 0.15 m/sec, and the nozzle fins’ deflection is 0°.
If deflection = 30°, multiply the blown air value by 0.65.

18
FILTER BOXES ON AIR INLET DELIVERY WARM AIR HEATERS OF THE "AS COND "
and "AS COND EX " SERIES
MOD. U
mm
V
mm
Z
mm
Y
mm
X
mm
Filters (1)
[mm]
Pressure
drop (2)
[Pa]
AS COND 50 870 640 60 820 595 1x640x810x48 70
XE50 870 640 60 820 595 2x500x400x48 70
AS COND 80 980 700 60 940 630 1x910x695x48 88
AS COND EX 80 1020 780 60 980 740 1x625x500x48
1x625x400x48 88
AS COND 100 980 700 60 940 630 1x910x695x48 110
AS COND EX 100 1020 780 60 980 740 1x625x500x48
1x625x400x48 110
AS COND 150 1440 840 200 1400 800 4x625x400x98 68
AS COND EX 150 1440 840 200 1400 800 2X625X500X98
1X625X400X98 62
AS COND 175 1440 840 200 1400 800 4x625x400x98 85
AS COND EX 175 1440 840 200 1400 800 2x625x500x98
1X625X400X98 75
AS COND 200 1440 840 200 1400 800 4x625x400x98 105
AS COND EX 200 1440 840 200 1400 800 2x625x500x98
1X625X400X98 85
AS COND 250 1790 840 200 1750 800 2x625x400x98
4x500x400x98 85
AS COND EX 250 1790 840 200 1750 800 3x625x400x98
1x625x500x98 85
AS COND 300 1790 840 200 1750 800 2x625x400x98
4x500x400x98 105
AS COND EX 300 1790 840 200 1750 800 3x625x400x98
1x625x500x98 105
AS COND 425 2300 1010 200 2260 970 8x500x500x98 90
AS COND EX 425 2300 1010 200 2260 970 4x625x400x98
4x500x400x98 100
AS COND 500 2300 1010 200 2260 970 8x500x500x98 100
AS COND EX 500 2300 1010 200 2260 970 4x625x400x98
4x500x400x98 128
AS COND 600 2300 1010 200 2260 970 8x500x500x98 123
AS COND EX 600 2300 1150 200 2260 1110 4x625x400x98
4x500x400x98 140
1) Efficiency ASHRAE52/76 DUST WEIGHT: 87%
2) Pressure drop of a new filter.
CAUTION! For plant calculations, this pressure drop for rather
dirty (but not clogged) filters must be increased by at least 50%,
and must be subtracted from the useful pressure of the heater
(see chap. DATA SHEET)

19
DATA SHEET WARM AIR HEATER series “AS COND" "AS COND EX"
THERMAL PERFORMANCE
Mod.
50 65 80 100 150 175 200 250 300
Rated heat input, Qnom
kW 61,1 76 98,5 122 179 203 238 270 313
Rated heat output, Pn kW 59,8 73,0 96,3 116,6 178,6 201,8 234,2 269 310
Thermal efficiency at rated heat input, Pn %97,9 96,1 97,8 95,6 99,8 99,4 98,4 99,3 98,7
Heat input at 50% of the rated heat input kW 30,55 38 49,25 61 89,5 101,5 119 162 187,8
Heat rating at 50% of the rated heat
input
kW 31,8 39,0 51,6 62,1 93,8 106,0 123,6 167,3 191,3
Thermal efficiency at 50% of the rated
heat input
%104,2 102,6 104,9 101,8 104,8 104,5 103,9 103,3 101,8
Minimum heat input Qmin kW 22 22 31 31 53 53 53 88 102
Heat rating at Qmin
kW 23,3 23,3 33,4 33,4 56,65 56,65 56,65 94,51 109
Thermal efficiency at minimum heat input
Qmin %106 106 107,8 107,8 106,9 106,9 106,9 107,4 106,9
Backpressure in the combustion chamber,
with G20 at Qn
mbar 4,3 7,5 3,4 5,1 3,9 5,2 6,2 44,8
Backpressure in the combustion chamber,
with G30 at Qn
mbar 47,4 3,1 4,7 3,7 55,9 3,8 4,6
Condensate produced when the room
temperature is 20°C
l/h 2,15 2,15 4,06 4,06 4,5 4,5 4,5 5,52 5,2
AERAULIC PERFORMANCE
Air flow rate at 18 °C mc/h 4700 6100 7560 9200 13000 15800 18000 20800 24000
Useful static pressure
Pa
150
150
150
150
200
200
200
200
200
DELTA T AIR at PN °C
°C 37,4 35,1 37,2 37,2 40,4 37,6 38,3 37,1 37
MAX GAS CONSUMPTION AT 15°C-1013 mbar
METHANE G20 at 20 mbar mc/h 6,47 8,04 10,42 12,91 18,94 21,48 25,19 28,57 33,12
NAT. GAS G25 at 25 mbar mc/h 7,52 9,4 12,1 15,0 22,0 25,0 29,3 33,24 38,53
PROPANE G31 at 37 mbar Kg/h 4,75 5,90 7,65 9,48 13,91 15,77 18,49 20,98 24,32
BUTANE G30 at 28 mbar Kg/h 4,82 5,99 7,77 9,62 14,12 16,01 18,77 21,29 24,68
CO2 at Qn with G20 (tolerance ± 0.2) %8,7 8,9 8,9 8,9 8,8 8,7 8,7 8,3 8,3
CO2 at Qn with G31 (tolerance ± 0.2)
%10,5 10,5 10,5 10,5 10,5 10,5 10,5 10 10
NOx (≤50 Mg/kWh)
CL
Classe 5
ELECTRICAL DATA
Fan motor capacity kW x n. 0,736 0,736 1,5 2,2 3 4 5,5 3x2 4 x 2
Fan motor supply voltage
V-Ph-Hz
230 V - 1 - 50
400 V - 3+N - 50
Fan motor absorption A7,7 7,7 3,6 5,1 79,2 12 7 x 2 9,2 x 2
Fan motor absorption/voltage 3F 230V 50Hz A6,2 9,3 12 15 20 12 x 2 15 x 2
Sound pressure (at 5 m) dB(A) 70 72 72 73 71 73 74 74 75
Protection degree of “XE” “XEO” “XR”
versions
IP X5D X5D X5D X5D X5D X5D X5D X5D X5D
ELECTRICAL DATA, WITH USEFUL PRESSURE = 300 Pa
Fan motor capacity
kW 1,1 1,5 2,2 3 4 5,5 7,5 3 x 2 5,5 x 2
Fan motor supply voltage V-Ph-Hz 400 V - 3+N - 50
Fan motor absorption/voltage 3F 400V
50Hz
A2,9 3,6 5,1 79,2 12 17,8 7 x 2 9,2 x 2
Fan motor absorption/voltage 3F 230V
50Hz A4,8 6,2 9,3 12 15 20 31 12 x 2 15 x 2
Flue connection/combustion air intake
Ǿ 100/100 130/130 150/150 200/200
GAS CATEGORY is the gas category of the burner
Type of appliance, based on exhaust
devices/combustion air intake
type B23 – C13 – C33 – C53
Warm air heaters can be used together
with RIELLO burner RIELLO RX80
S/PV
RX80
S/PV
RX100
S/PV
RX120
S/PV
RX250
S/PV
RX250
S/PV
RX250
S/PV
RX360
S/PV
RX360
S/PV
Warm air heaters can be used together
with BALTUR burner BALTUR BPM
90
BPM
90
BPM
140
BPM
140
BPM
200
BPM
200
BPM
300
BPM
350
BPM
450
Warm air heaters can be used together
with RIELLO burner for GPL - G31 RIELLO
RX250
S/PV
+
pilot
Cod.
20127
965
RX250
S/PV
+
pilot
Cod.
20127
965
RX250
S/PV
+
pilot
Cod.
20127
965
RX360
S/PV
+
pilot
Cod.
20127
965
RX360
S/PV
+
pilot
Cod.
20127
965

20
DATA SHEET WARM AIR HEATER series: “AS COND” “AS COND EX”
THERMAL PERFORMANCE Mod. X425 X500 X600
Rated heat input, Qnom
kW 425 500 600
Rated heat output, Pn
kW 428,4 495,5 592,8
Thermal efficiency at rated heat input, Pn
%
100,8
99,1
98,8
Heat input at 50% of the rated heat input
kW 128 150 180
Heat rating at 50% of the rated heat
input
kW 137,7 159,0 189,5
Thermal efficiency at 50% of the rated
heat input
% 107,6 106,0 105,3
Minimum heat input Qmin
mbar 4,9 6,1 7,9
Heat rating at Qmin
mbar
4,6
5,8
7,6
Thermal efficiency at minimum heat input
Qmin
Lt/h 14,8 13 14,4
AERAULIC PERFORMANCE
Air flow rate at 18 °C
mc/h 32.500 38.300 41.000
Useful static pressure
Pa 200 200 160
DELTA T AIR at PN °C
°C 37,2 37,5 36,8
MAX GAS CONSUMPTION AT 15°C-1013 mbar
METHANE G20 at 20 mbar
mc/h
44,97
52,9
63,5
NAT. GAS G25 at 25 mbar
mc/h
52,3
61,5
73,8
PROPANE G31 at 37 mbar Kg/h 32,8 38,6 46,3
BUTANE G30 at 28 mbar Kg/h 33,5 39,4 47,3
CO2 at Qn with G20 (tolerance ± 0.2)
% 8,8 8,8 8,7
CO2 at Qn with G31 (tolerance ± 0.2)
%
10,5
10,5
10,5
NOx (≤50 Mg/kWh)
mg/kWh GCV
43
38,2
44,5
ELECTRICAL DATA
Fan motor capacity
KW x n.
4x2
5,5x2
5,5x2
Fan motor supply voltage
V-Ph-Hz
400V-3+N-50
Fan motor absorption
A 8,3x2 11,3x2 11,3x2
Fan motor absorption/voltage 3F 230V
50Hz
A 14,4x2 19,6x2 19,6x2
Sound pressure (at 5 m)
dB(A) 74 75 75
Protection degree of “XE” “XEO” “XR”
versions
IP X5D X5D X5D
ELECTRICAL DATA, WITH USEFUL PRESSURE = 300 Pa
Fan motor capacity kW 5,5x2 7,5x2 7,5x2
Fan motor supply voltage
V-Ph-Hz 400V-3+N-50
Fan motor absorption/voltage 3F 400V
50Hz
A 11,3x2 15x2 15x2
Fan motor absorption/voltage 3F 230V
50Hz
A 19,6x2 26,3x2 26,3x2
Flue connection/combustion air intake
Ǿ
250
GAS CATEGORY
is the gas category of the burner
Type of appliance, based on exhaust
devices/combustion air intake
tipo B23
Warm air heaters can be used together
with RIELLO burner
RIELLO RX500
S/PV
RX700
S/PV
RX700S/PV;
RX850S/PV
Warm air heaters can be used together
with BALTUR burner
BALTUR
BPM
500
BPM
650
BPM
800
Warm air heaters can be used together
with RIELLO burner for GPL - G31 RIELLO
RX500S/PV
+ pilot Cod.
20127965
RX700S/PV
+ pilot Cod.
20127965
RX700S/PV +
pilot Cod.
20127965
