Accu1 Direct AccuVac 23 User manual
Table of Contents
1) Warranty
2) Safety
3) Specifications
4) Starting Procedures
5) Shutdown Procedures
6) Maintenance
7) Troubleshooting
1) Warranty
Accu1Direct machines are warranted to be free from
defects in metal fabrication for a period of five (5) years
from the date of purchase.
The following restrictions apply:
1. The warranty applies to products in normal use only. The
product must be serviced and maintained as described herein.
2. If the product fails, it will be repaired or replaced at the option of
Accu1Direct.
3. All shipment/delivery charges are the responsibility of the
purchaser.
4. Warranty service claims are subject to factory inspection for
product defect(s). If during warranty evaluation it is determined
that the machine has been used in any way other than the
purpose for which it was designed, Accu1Direct reserves the
right to void the warranty.
5. All warranty claims must be made within the warranty period.
This warranty is non-transferrable.
6. Note that the warranty does not apply if the product or product
part is damaged by accident, misuse, or has been tampered
with in any way.
7. Normal wear items (seals, filters, etc.) are specifically excluded
from warranty unless found defective by Accu1Direct.
8. Blowers, gear boxes, and engines are covered under the
warranty of the manufacturers of those products.
9. This warranty is exclusive and shall be in lieu of any other
warranty, expressed or implied, which may be available to the
purchaser.
10. All returned goods must be accompanied by a Returned
Goods Authorization number (RGA). Contact our factory to
obtain the RGA number.
2) Safety
All operators must read and understand this manual.
1. Equipment is to be operated by qualified personnel only.
2. Do not start the machine until you have hose attached to the inlet port. There
should also be a bag attached to the discharge port before starting the machine.
3. Only use qualified personnel when repairing or maintaining equipment.
4. This equipment must be used in the manner it was intended, which is to pull
existing fiber from residential attics. Any other use will void the warranty and
possibly damage the equipment or cause bodily harm.
5. Do not leave the machine unattended while running.
6. Do not wear loose clothing or jewelry when operating this
equipment.
7. Never operate the machine without proper ventilation.
8. Obey all safety labels.
If you have any questions about the safe operation of this equipment, call us at
1- 800-438-2776.
3) Specifications
1. Purpose: The AccuVac 23 is intended to safely remove existing
insulation.
2. Physical Characteristics
HEIGHT: 48"
WIDTH: 33"
LENGTH: 47"
WEIGHT: 420 lbs.
Fuel: Regular, unleaded gasoline
4) Starting Procedures
Keep hands, clothing, etc. away from the inlet and discharge of
the vacuum.
1. Place the vacuum on a level surface. Position it so the removal bag will not
be blown by the wind and come in contact with the exhaust system.
2. Attach the removal bag to the discharge of the vacuum using the
strap clamp provided.
3. Attach hose to the vacuum inlet using the clamp provided.
Do not overfill the gas tank.
4. Refer to the engine manual for correct starting procedures.
5. Start the engine.
6. The vacuum is ready for use.
Do not stand by or behind the filter bag.
4
5) Shutdown Procedures
1. Move the throttle to the slow position. Run vacuum for approximately (5)
minutes.
2. Turn the engine off.
3. Remove the bag.
4. Disconnect the hoses.
Do not remove the hoses or bag until the machine has come to a
complete stop.
6) Maintenance
1. Engine: Refer to the manufacturers service manual.
2. Battery: The battery cables should be checked daily for corrosion and
tightness.
3. Fan Housing & Impeller: With normal use, no maintenance is required.
If a problem, noise, or vibration should occur, stop the equipment and contact
Accu1Direct immediately.
The impeller assembly has been balanced at the factory. Noises or vibration
coming from the impeller means it has come out of balance. Do not replace the
impeller with any impeller than an Accu1Direct approved replacement.
7) Troubleshooting
Engine: Refer to the manufacturer’s manual
No Suction:
1. Stop engine.
2. Check hoses for a blockage or if they are loose.
3. Check the inlet tube for blockage.
4. Check the discharge tube for blockage.
5. Inspect impeller housing for blockage or damage.
6. Check the removal bag. As the bag fills, suction is lost.
