Acer Veriton 7600GT User manual

Veriton 7600GT/GTR/V
User’s guide

Changes may be made periodically to the information in this publication without obligation
to notify any person of such revision or changes. Such changes will be incorporated in new
editions of this manual or supplementary documents and publications. This company makes
no representations or warranties, either expressed or implied, with respect to the contents
hereof and specifically disclaims the implied warranties of merchantability or fitness for a
particular purpose.
Record the model number, serial number, purchase date, and place of purchase information in
the space provided below. The serial number and model number are recorded on the label
affixed to your computer. All correspondence concerning your unit should include the serial
number, model number, and purchase information.
No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in
any form or by any means, electronic, mechanical, photocopy, recording, or otherwise,
without the prior written permission of Acer Incorporated.
Model Number : _________________________________
Serial Number: ___________________________________
Purchase Date: ___________________________________
Place of Purchase: ________________________________
Copyright © 2003 Acer Incorporated
All Rights Reserved.
Veriton 7600GT/7600GTR/7600V
User’s guide
First Issue November 2003
Acer and the Acer Logo are registered trademarks of Acer Inc. Other company’s product
names or trademarks are used herein for identification purposes only and belong to their
respective companies.

iii
1 First things first 1
System specifications 3
Package contents 5
Accessing the user’s guide 5
2 System tour 7
Features 9
Performance 9
Multimedia 9
Connectivity 9
Front panel 10
Rear panel 12
Keyboard 14
Internet/E-mail/Search keys 15
Multimedia keys 16
Volume control/Mute keys 17
Lock keys 18
Cursor keys 19
Windows keys 19
Function keys 20
Palm rest 20
Optical drive 21
To take care of your CDs and DVDs 22
Hard disk 23
3 Setting up your computer 25
Arranging a comfortable work area 27
Adjusting your chair 27
Positioning your PC 27
Positioning your monitor 28
Positioning your keyboard 28
Positioning your mouse 29
Connecting peripherals 30
Connecting your mouse 30
USB mouse 30
PS/2 mouse 31
Connecting your keyboard 32
USB keyboard 32
PS/2 keyboard 33
Connecting a monitor 34
Connecting the power cable 35
Turning on your computer 36
Turning off your computer 37
Contents

Contents
iv
Connecting options 38
Connecting your printer 38
Connecting the modem (optional) 39
Connecting to the network 40
Connecting multimedia devices 41
Connecting USB devices 45
4 Upgrading your computer 47
Installation precautions 49
ESD precautions 49
Preinstallation instructions 49
Installation precautions 49
ESD precautions 49
Preinstallation instructions 49
Post-installation instructions 50
Opening your computer 51
To remove the side panel 51
To replace the side panel 52
Internal components 54
System boards 55
Mainboard layout 55
Audio board 58
Upgrading your computer 59
Installing additional memory 59
To remove a DDR DIMM 59
To install a DDR DIMM 60
To reconfigure your computer 61
Replacing the hard disk 61
Installing an expansion card 62
5 System utilities 65
Acrobat Reader 68
Acer LANScope (optional) 69
Norton AntiVirus 70
How do I check for viruses? 70
NTI CD-Maker (for models with CD or DVD Burner) 72
PowerDVD (for models with DVD) 74
How do I open and watch a DVD? 74
BIOS utility 75
Reinstalling programs 76
Recovering your system 77
Using Backup (Windows® XP only) 83
How do I back up files from my hard drive? 83

v
Disk Defragmenter (Windows® XP only) 84
How do I defragment my hard drive? 84
6 Frequently asked questions 85
Frequently asked questions 87
Appendix A: Notices 91
Energy Star Guidelines Compliance 92
FCC notice 92
Notice: Canadian users 93
Declaration of Conformity for EU countries 93
Modem notices 93
Notice for USA 93
TBR 21 94
Notice for Australia 94
Important safety instructions 94
Macrovision copyright protection notice 95
Lithium battery statement 96
Laser compliance statement 96
Declaration of Conformity for CE marking 98
Federal Communications Comission
Declaration of Conformity 99
Appendix B: Taking care of your computer 101
Important tips 102
Cleaning and servicing 102
To clean your computer and keyboard 102
To clean your pointing device 103
To clean your monitor 103
When to contact a service technician 103
Asking for technical assistance 104
Appendix C: RAID introduction
(for R series model only) 105
Intel® ICH5R Serial ATA RAID Introduction 106
Parallel ATA and Serial ATA device configurations 106
ATA Operate Mode 106
BIOS Configuration 107
Using the Intel RAID Option ROM 107
Option 1: Create RAID Volume 108
Option 2: Delete RAID Volume 111

Contents
vi
Option 3: Reset Disks to Non-RAID 113
Installation of IAA RAID Utility 114
RAID Migration Instructions 118
Index 123

1 First things
first

This chapter describes the system specifications
and the contents of your computer package.

3
System specifications
Component Specification
Processor • Intel® Pentium® 4 2.0~3.6 GHz
• Intel®Celeron® 2.0 - 2.8 GHz
System memory Four SDRAM slots support a maximum of 4 GB dual-
channel DDR memory
Chipset • Intel® 865G+ICH5(7600GT)
• Intel® 865G+ICH5 R(7600GTR)
• Intel® 865GV+ICH5(7600V)
Graphics Intel® 865G/865GV supporting:
• DVMT technology
• Dual Display
Audio AC ’97 Codec
LAN 10/100/1000 Base-T Gigabit Ethernet connectivity
IDE Two 40 pin parallel ATA IDE slots
Two Serial ATA ports
FDD 1.44 MB 3.5 inch floppy drive
PS/2 • PS/2 keyboard port
• PS/2 mouse port
USB Eight external USB 2.0 ports
Serial port One serial port on I/O bracket
(Optional 2nd serial port connecting via “COM2” on
page 56 )
Printer port One parallel printer port
Thermal Dynamic fan speed control
Security • Chassis lock pad
• Chassis intrusion alarm

1 First things first
4
Wake system Wake on LAN
Wake on modem
Mouse/keyboard
HDD • Paralle ATA (5400, 7200 RPM)
• Serial ATA (7200 RPM)
Optical Drive CD-ROM, CD-RW, DVD-ROM, DVD/CD-RW combo, or
DVD burner/Supermulti plus
Operating
system
• Windows® 2000
• Windows® XP Home
• Windows® XP Professional
• Novell®/SCO® Unix/Red Hat® Linux(driver support)
Dimensions • Mini-Tower 438.5mm(H) /186mm(W) /475mm(D)
Gross weight • Mini-Tower 8.5 kg/18.7lb
Thermal
overrides • System temp >90oC - functions suspended until
system temp is below 90oC
• CPU temp >110oC - functions suspended until CPU
temp is below 110oC
• CPU temp >120oC - system auto-shutdown
Component Specification

5
Package contents
Before you unpack your computer, make sure that you have enough
space to set up your computer.
Carefully unpack the carton and remove the contents. If any of the
following items are missing or damaged, contact your dealer
immediately:
• Veriton 7600 series
• Items contained in the accessory box
• USB or PS/2 keyboard
• USB or PS/2 mouse
• User’s guide and installation poster
• Other user documentation and third-party software
Accessing the user’s guide
This user’s guide is also available on your computer as an Adobe
Acrobat PDF file.
To access the user’s guide (for Windows®XP)
1 On the Windows®XP taskbar, click on the start button then select
Help and Support.
2 On the Help and Support Center home page, double-click the
Veriton 7600 series Online icon.
To access the user’s guide (for Windows®2000)
Double-click on the Veriton 7600 series Online icon on your Windows
desktop.

1 First things first
6

2 System tour

This chapter discusses the features and
components of your computer.

9
Features
Here are just a few of your computer’s many features:
Performance
•Intel®Pentium® 4/Celeron®supporting FSB(Front Side Bus) up to
800 /400MHz and HyperThreading Technology™
•Intel
®865G+ICH5 (for 7600GT) , 865G+ICH5 R(for 7600 GTR) or
865GV+ICH5(for 7600V) chipset
• DDR-SDRAM 400/333/266, 4 DIMM slots, Expandable to 4GB dual-
channel memory
• Power management function
• CD-ROM, CD-RW, DVD-ROM, DVD/CD-RW combo, DVD+/-RW, or
DVD-RAM(Supermulti plus) drive
• High-capacity, Enhanced-IDE hard disk
Multimedia
• 3-D quality audio system via onboard audio controller
• Audio-in/Line-in, Audio-out/Line-out, Headphone-out, and
Microphone-in interfaces
Note: The system has two microphone-in jacks (front and rear).
However, you can not use both of them at the same time.
Connectivity
• Two PS/2 interfaces for mouse and keyboard
• One serial port(Option 2nd serial port via “COM2” on page 56)
• One parallel port
• One VGA port
• Eight Universal Serial Bus (USB) 2.0 ports (four on the front and
four on the rear panel)
• High-speed V.92, 56K Fax/modem (optional)
• Gigabit Ethernet LAN support with remote wake-up function

2 System tour
10
Front panel
Your computer’s front panel consists of the following:
1
4
5
6~8
14
12
2
13
9
3
8 7 6
11
10

11
Note: The system has two microphone-in jacks (front and rear).
However, you can not use both of them at the same time. By
default, your system enables the microphone-in jack in front and
disables the one at the back.
Label Icon Component
1 Eject button for Optical Drive
2 5.25-inch drive bays
3 One button recovery slot
4 Floppy drive eject button
5 Power button
6 Hard disk activity LED
7 LAN activity LED
8PowerLED
9 Speaker-out/Line-out port
10 Microphone-in jack (front) see note
11 USB ports
12 Optical Drive
13 3.5-inch floppy drive
14 Floppy drive LED

2 System tour
12
Rear panel
Your computer’s rear panel consists of the following:
1
2
3
5
6
7
8
9
10
11
12
13
14
15
4
16

13
For information on how to connect the peripherals, see page 30 and
“Connecting options” on page 38.
Label Icon Color Component
1 Power supply
2 Power cord socket
3 Voltage selector switch
4 Green PS/2 mouse port
5 Purple PS/2 keyboard port
6/11 Black USB ports
7 Teal or
Turquoise
Serial port
8 Burgundy Parallel/Printer port
9 Blue CRT/LCD monitor port
10 White Network port
12 Pink Microphone-in jack (rear)
13 Lime Audio-out/Line-out jack
14 Light blue Audio-in/Line-in jack
15 Expansion slots
16 Chassis lock pad

2 System tour
14
Keyboard
The keyboard has full-sized keys that include separate cursor keys, two
Windows keys, four multimedia keys, and twelve function keys.
For information on how to connect your keyboard, see “Connecting
your keyboard” on page 32.
No. Description No. Description
1 Sleep button 2 Internet/E-mail/Search keys
3 Multimedia keys 4 Volume control/Mute keys
5 Scroll lock key 6 Num lock key
7 Cursor keys 8 Application key
9 Windows logo key 10 Caps lock key
11 Function keys
