Acer CB292CU User manual

Acer LCD Monitor
User Guide

CB292CU User Guide English
Copyright © 2020. Acer
Incorporated. All Rights
Reserved.
Acer LCD Monitor User Guide
Original Issue: 09/2020
Changes may be made periodically to the information in this publication without
obligation to notify any person of such revisions or changes. Such changes will
be incorporated in new editions of this manual or supplementary documents and
publications. This company makes no representations or warranties, either
expressed or implied, with respect to the contents hereof and specifically
disclaims the implied warranties of merchantability or fitness for a particular
purpose.
Record the model number, serial number, purchase date and place of purchase
information in the space provided below. The serial number and model number
are recorded on the label affixed to your computer. All correspondence
concerning your unit should include the serial number, model number and
purchase information.
No part of this publication may be reproduced, stored in a retrieval system, or
transmitted, in any form or by any means, electronically, mechanically, by
photocopy, recording or otherwise, without the prior written permission of Acer
Incorporated.
Acer LCD Monitor User Guide
Model number: __________________________________
Serial number: ___________________________________
Date of purchase: ________________________________
Place of purchase: ________________________________
Acer and the Acer logo are registered trademarks of Acer Incorporated. Other
companies’ product names or trademarks are used herein for identification purposes
only and belong to their respective companies.

CB292CU User Guide English
Information for your safety and comfort
Safety instructions
Read these instructions carefully. Keep this document for future reference. Follow all
warnings and instructions marked on the product.
Special notes on LCD monitors
The following are normal with the LCD monitor and do not indicate a problem.
•Due to the nature of the fluorescent light, the screen may flicker during initial
use. Turn off the power switch and then turn it on again to make sure the flicker
disappears.
•You may find slightly uneven brightness on the screen depending on the desktop
pattern you use.
•The LCD screen has 99.99% or more effective pixels. It may include blemishes
of 0.01% or less such as a missing pixel or pixel lit all the time.
•Due to the nature of the LCD screen, an afterimage of the previous screen may
remain after switching the image, when the same image is displayed for hours.
In this case, the screen is recovered slowly by changing the image or turning off
the power switch for a few hours.
Cleaning your monitor
Please carefully follow these guidelines when cleaning the
monitor:
•Always unplug the monitor before cleaning.
•Use a soft cloth to wipe the screen and cabinet front and sides.
Accessibility
Be sure that the power outlet you plug the power cord into is easily accessible and
located as close to the equipment operator as possible. When you need to
disconnect power from the equipment, be sure to unplug the power cord from the
electrical outlet.
Safe listening
To protect your hearing, follow these instructions.

CB292CU User Guide English
•Gradually increase the volume until you can hear it clearly and comfortably and
without distortion.
•After setting the volume level, do not increase it after your ears have adjusted.
•Limit the amount of time listening to music at high volume.
•Avoid turning up the volume to block out noisy surroundings.
•Turn the volume down if you can’t hear people speaking near you.
Warnings
•Do not use this product near water.
•Do not place this product on an unstable cart, stand or table. If the product falls, it
could be seriously damaged.
•Slots and openings are provided for ventilation to ensure reliable operation of the
product and to protect it from overheating. These openings must not be blocked or
covered. The openings should never be blocked by placing the product on a bed,
sofa, rug or other similar surface. This product should never be placed near or
over a radiator or heat register, or in a built-in installation unless proper ventilation
is provided.
•Never push objects of any kind into this product through cabinet slots as they may
touch dangerous voltage points or short-out parts that could result in a fire or
electric shock. Never spill liquid of any kind onto or into the product.
•To avoid damage of internal components and to prevent battery leakage, do not
place the product on a vibrating surface.
•Never use it under sporting, exercising, or any vibrating environment which will
probably cause unexpected short current or damage internal devices.
•The adapter is only used for this monitor, do not be used for other purposes.
Using electrical power
•This product should be operated from the type of power indicated on the marking
label. If you are not sure of the type of power available, consult your dealer or
local power company.
•Do not allow anything to rest on the power cord. Do not locate this product where
people will walk on the cord.
•If an extension cord is used with this product, make sure that the total ampere
rating of the equipment plugged into the extension cord does not exceed the
extension cord ampere rating. Also, make sure that the total rating of all products
plugged into the wall outlet does not exceed the fuse rating.
•Do not overload a power outlet, strip or receptacle by plugging in too many
devices. The overall system load must not exceed 80% of the branch circuit

CB292CU User Guide English
rating. If power strips are used, the load should not exceed 80% of the power
strip’s input rating.
•This product’s power cord is equipped with a three-wire grounded plug. The plug
only fits in a grounded power outlet. Make sure the power outlet is properly
grounded before inserting the power cord plug. Do not insert the plug into a non-
grounded power outlet. Contact your electrician for details.
Warning!
The grounding pin is a safety feature. Using a power outlet that is not properly
grounded may result in electric shock and/or injury.
Note: The grounding pin also provides good protection from unexpected
noise produced by other nearby electrical devices that may interfere with the
performance of this product.
• Use the product only with the supplied power supply cord set. If you need to
replace the power cord set, make sure that the new power cord meets the
following requirements: detachable type, UL listed/CSA certified, type SPT-2,
rated 7 A 125 V minimum, VDE approved or its equivalent, 4.6 meters (15 feet)
maximum length.
Product servicing
Do not attempt to service this product yourself, as opening or removing covers may
expose you to dangerous voltage points or other risks. Refer all servicing to qualified
service personnel.
Unplug this product from the wall outlet and refer servicing to qualified service
personnel when:
•the power cord or plug is damaged, cut or frayed
•liquid was spilled into the product
•the product was exposed to rain or water
•the product has been dropped or the case has been damaged
•the product exhibits a distinct change in performance, indicating a need for
service
• the product does not operate normally after following the operating instructions
Note: Adjust only those controls that are covered by the operating instructions,
since improper adjustment of other controls may result in damage and will often
require extensive work by a qualified technician to restore the product to normal
condition.

CB292CU User Guide English
Potentially explosive environments
Switch off your device in any area with a potentially explosive atmosphere and
obey all signs and instructions. Potentially explosive atmospheres include areas
where you would normally be advised to turn off your vehicle engine. Sparks in
such areas could cause an explosion or fire resulting in bodily injury or even death.
Switch off the device near depots, storage and distribution areas; chemical plants;
or where blasting operations are in progress. Areas with a potentially explosive
atmosphere are often, but not always, marked. They include below deck on boats,
chemical transfer or storage facilities, vehicles using liquefied petroleum gas (such
as propane or butane), and areas where the air contains chemicals or particles
such as grain, dust or metal powders.
Additional safety information
Your device and its enhancements may contain small parts. Keep them out of the
reach of small children.
IT Equipment Recycling Information
Acer is strongly committed to environmental protection and views recycling, in
the form of salvaging and disposal of used equipment, as one of the company’s
top priorities in minimizing the burden placed on the environment.
We at Acer are very conscious of the environmental effects of our business and strive
to identify and provide the best working procedures to reduce the environmental
impact of our products.
For more information and help when recycling, please go to this website:
https://www.acer-group.com/sustainability/en/our-products-environment.html
Visit www.acer-group.com for further information on the features and benefits of our
other products.
Disposal instructions
Do not throw this electronic device into the trash when discarding. To
minimize pollution and ensure utmost protection of the global
environment, please recycle.
For more information on the Waste from Electrical and Electronics Equipment
(WEEE) regulations, visit https://www.acer-group.com/sustainability/en /our-
products-environment.html

CB292CU User Guide English
LCD pixel statement
The LCD unit is produced with high-precision manufacturing techniques.
Nevertheless, some pixels may occasionally misfire or appear as black or red dots.
This has no effect on the recorded image and does not constitute a malfunction.
This product has been shipped enabled for power management:
•Activate display’s Sleep mode within 5 minutes of user inactivity.
•Wake the monitor when it is in Active Off mode,move the mouse or press any
keyboard key.
Tips and information for comfortable use
Computer users may complain of eyestrain and headaches after prolonged use.
Users are also at risk of physical injury after long hours of working in front of a
computer. Long work periods, bad posture, poor work habits, stress, inadequate
working conditions, personal health and other factors greatly increase the risk of
physical injury.
Incorrect computer usage may lead to carpal tunnel syndrome, tendonitis,
tenosynovitis or other musculoskeletal disorders. The following symptoms may
appear in the hands, wrists, arms, shoulders, neck or back:
•numbness, or a burning or tingling sensation
•aching, soreness or tenderness
•pain, swelling or throbbing
•stiffness or tightness
•coldness or weakness
If you have these symptoms, or any other recurring or persistent discomfort and/or
pain related to computer use, consult a physician immediately and inform your
company’s health and safety department.
The following section provides tips for more comfortable computer use.
Finding your comfort zone
Find your comfort zone by adjusting the viewing angle of the monitor, using a
footrest, or raising your sitting height to achieve maximum comfort. Observe the
following tips:
•refrain from staying too long in one fixed posture
•avoid slouching forward and/or leaning backward
•stand up and walk around regularly to remove the strain on your leg muscles

CB292CU User Guide English
Taking care of your vision
Long viewing hours, wearing incorrect glasses or contact lenses, glare, excessive
room lighting, poorly focused screens, very small typefaces and low-contrast
displays could stress your eyes. The following sections provide suggestions on
how to reduce eyestrain.
Eyes
•Rest your eyes frequently.
•Give your eyes regular breaks by looking away from the monitor and focusing on
a distant point.
•Blink frequently to keep your eyes from drying out.
Display
•Keep your display clean.
•Keep your head at a higher level than the top edge of the display so your eyes
point downward when looking at the middle of the display.
•Adjust the display brightness and/or contrast to a comfortable level for enhanced
text readability and graphics clarity.
•Eliminate glare and reflections by:
•placing your display in such a way that the side faces the window or any light
source
•minimizing room light by using drapes, shades or blinds
•using a task light
•changing the display’s viewing angle
•using a glare-reduction filter
•using a display visor, such as a piece of cardboard extended from the
display’s top front edge
•Avoid adjusting your display to an awkward viewing angle.
•Avoid looking at bright light sources, such as open windows, for extended periods
of time.
Developing good work habits
Develop the following work habits to make your computer use more relaxing and
productive:
•Take short breaks regularly and often.
•Perform some stretching exercises.
•Breathe fresh air as often as possible.
•Exercise regularly and maintain a healthy body.

CB292CU User Guide English
Acer Incorporated
8F, 88, Sec. 1, Xintai 5th Rd., Xizhi
New Taipei City 221, Taiwan
Declaration of Conformity
We,
Acer Incorporated
8F, 88, Sec. 1, Xintai 5th Rd., Xizhi, New Taipei City 221, Taiwan
And,
Acer Italy s.r.l
Tel: [phone] ,Fax: [phone]
www.acer.it
Product: LCD Monitor
Trade Name: Acer
Model Number:
SKU Number:(“x” = 0~9, a ~ z, A ~ Z, or blank)
We, Acer Incorporated, hereby declare under our sole responsibility that the product described above is in
conformity with the relevant Union harmonization legislations as below Directive and following harmonized
standards and/or other relevant standards have been applied:
C B29 2C U XXXXXX
Year to begin affixing CE marking:2020.
_______________________________
RU Jan / Sr. Manager
Acer Incorporated (Taipei, Taiwan)
Viale delle Industrie 1/A, 20020 Arese (MI), Italy
.
C B29 2C U
EMC Directive: 2014/30/EU
EN55032:2015+AC: 2016 Class B
EN61000-3-2:2014 Class D EN 55024:2010+A1: 2015 EN61000-3-3:2013
LVD Directive: 2014/35/EU
EN 62368-1: 2014+ A11: 2017
RoHS Directive: 2011/65/EU
EN 50581:2012
ErP Directive: 2009/125/EC
(EU) 2019/ 2021; EN 50564:2011
Date

C B29 2C U
C B29 2C U

A third-party certification according to ISO 14024
Say hello
to a more sustainable product
IT products are associated with a wide range of sustainability risks
throughout their life cycle. Human rights violations are common in the
factories. Harmful substances are used both in products and their
manufacture. Products can often have a short lifespan because of poor
ergonomics, low quality and when they are not able to be repaired or
upgraded.
This product is a better choice. It meets all the criteria in TCO Certified,
the world’s most comprehensive sustainability certification for IT
products. Thank you for making a responsible product choice, that help
drive progress towards a more sustainable future!
Criteria in TCO Certified have a life-cycle perspective and balance
environmental and social responsibility. Conformity is verified by
independent and approved verifiers that specialize in IT products, social
responsibility or other sustainability issues. Verification is done both
before and after the certificate is issued, covering the entire validity
period. The process also includes ensuring that corrective actions are
implemented in all cases of factory non-conformities. And last but not
least, to make sure that the certification and independent verification is
accurate, both TCO Certified and the verifiers are reviewed regularly.
Want to know more?
Read information about TCO Certified, full criteria documents, news and
updates at tcocertified.com. On the website you’ll also find our Product
Finder, which presents a complete, searchable listing of certified
products.
Toward sustainable IT products

English
Table of Contents
Information for your safety and comrt ...........................................................................ii
Safety instructions.......................................................................................................ii
Special notes on LCD monitors ..................................................................................ii
Cleaning your monitor ........................................................................................ii
Accessibility........................................................................................................ii
Safe listening......................................................................................................ii
Warnings ............................................................................................................ii
Using electrical power ....................................................................................... iii
Product servicing............................................................................................... iii
Potentially explosive environments ...................................................................iv
Additional safety information......................................................................................iv
IT Equipment Recycling Information ..........................................................................iv
Disposal instructions ..................................................................................................iv
LCD pixel statement....................................................................................................v
Tips and information for comfortable use....................................................................v
Finding your comfort zone..................................................................................v
Taking care of your vision...................................................................................v
Developing good work habits ............................................................................vi
Unpacking .........................................................................................................................1
Adjusting the monitor ......................................................................................................2
Height Adjustment...................................................................................................... 2
Tilt .............................................................................................................................. 3
Swivel......................................................................................................................... 3
Wall Mounting ...................................................................................................................5
Monitor introduction ........................................................................................................
Connecting the cables ...............................................................................................
Connecting Power cord .............................................................. 7
Power saving ............................................................................................................. 7
Display Data Channel (DDC) ..................................................................................... 8
Standard timing table ............................................................................................... 10
Using the Shortcut Menu.................................................................................................11
Main page .................................................................................................................11
Hot key1 (default: Modes) ................................................................................11
Hot key2 (default: Brightness) ..........................................................................11
Hot key3 (Selecting the input) ......................................................................... 12
Main Menu....................................................................................................... 13
Troubleshooting ...............................................................................................................21
6
6

CB292CU User Guide English
Unpacking
Please check that the following items are present when you unpack the box, and save
the packing materials in case you need to ship or transport the monitor in the future.
USER GUIDE
LCD Monitor
Quick Start Guide DP Cable
(Optional)
HDMI Cable
(Optional) AC Power Cord
1

CB292CU User Guide English
Adjusting the Monitor
For optimal viewing, we recommend that you look at the full face of the monitor,
then adjust the monitor to the angle that is most comfortable for you.
Hold the stand to prevent the monitor from falling when you change its angle.
You can adjust the monitor’s angle from +35˚ to -5˚, and it allows 360˚ swivel
adjustment from either left or right. You can also adjust the monitor’s height within
+/- 180 mm.
Height Adjustment
After pressing the top of the monitor then you can adjust the height of the monitor.
Note:
Please adjust the height of the monitor after pressing the top of the
monitor.
2

CB292CU User Guide English
Tilt
Swivel
With the built-in pedestal, you can swivel the monitor for the most comfortable viewing
3

CB292CU User Guide English
Monitor Pivot
Before rotating the display, lift it to the top position and then push it back to the utmost
degree. Rotate clockwise or counter-clockwise until the monitor stops at ±90°.
4

CB292CU User Guide English
Preparing to install an optional wall mount arm.
This monitor can be attached to a wall mounting arm you purchase separately.
Disconnect power before this procedure. Follow these steps:
1. Remove the base.
2. Follow the manufacturer’s instructions to assemble the wall mounting arm.
3. Place the wall mounting arm onto the back of the monitor. Line up the holes of the
arm with the holes in the back of the monitor.
4. Insert the 4 screws into the holes and tighten.
5. Reconnect the cables. Refer to the user’s manual that came with the optional wall
mounting arm for instructions on attaching it to the wall.
Note:
• VESA mounting screw holes are not available for all models, please check with
the dealer.
•
The screw length should be selected according to the wall mounting arm
type, please check with the dealer.
•
Wall Mounting
5
If installing with a wall mounting kit, it is recommended to use VESA mounting kit
(100mmX100mm) with M4x16(L)mm screws to fix your monitor on the wall.

CB292CU User Guide English
Monitor Introduction
User Controls
External controls
1 Power button Turns the monitor on/off.Blue indicates power on. Amber indicates
standby/ power saving mode.
2 Function key
/
a. Press to view Main page. Press again to enter hotkey1 function.
b. When the Function Menu is active, press this key to view the basic
information for your monitor and current input or reset the custom
color settings to the factory defaults.
3 Function key
/
a. Press to view Main page.Press again to enter hotkey2 function.
b. When the Function Menu is active, press this button to select
select scenario mode or game mode .
4 Function key
/
X
a. Press to view Main page.Press again to enter Input select
function.
b. When the Function Menu is active, this button will quit the OSD.
5Function key
/
a. Press to view Main page.Press again to enter next function in
the Function Menu.
b. The single toggle button on the backside of the Display bezel
operates like a joystick. To move the cursor, simply toggle the
button in four directions. Press the button to select desired option.
Bright gray indicates operable. Dark gray indicates inoperable.
6

CB292CU User Guide English
Connect the cables
Audio output is only for audio output model. Please check user manual for more instruction.
*POWER CORD specications refer to page15
*For the installation of replaceable parts, please refer to the above installation instructions.
*Users may go to the local service network to replace /purchase the qualied replaceable parts.
For local service centers and service contacts, please refer to https://www.acer.com/ac/en/US/content/support
To install the monitor on your host system, please follow the steps below:
1. Turn off your computer and unplug your computer's power cord.
2. Connect the signal cable to the DP (optional) and/or HDMI (optional) input
socket of the monitor, and the DP (optional) and/or HDMI (optional)output
socket of the graphics card on the computer.
3.
DP
POWER
Note:
7
Insert the monitor power cable into the power port at the back of the monitor, then
connect to a properly grounded AC outlet.

CB292CU User Guide English
Connecting the Power cord
•Check first to make sure that the power cord you use is the correct type required
for your area.
•The monitor has a universal power supply that allows operation in either 100/120
V AC or 220/240 V AC voltage area. No user-adjustment is required.
•Plug one end of the power cord to the AC inlet, and plug the other end into an AC
outlet.
•For units using 120 V AC:
Use a UL-listed cord set, type SVT wire and plug rated 10 A/125 V.
•For units using 220/240 V AC:
Use a cord set consisting of H05VV-F cord and plug rated 10 A/250 V. The cord
set should have the appropriate safety approvals for the country in which the
equipment will be installed.
Power saving
The monitor will be driven into "Power Saving" mode by the control signal from the
display controller, as indicated by the amber-color power LED.
State LED Light
ON Blue
Power Saving Mode Amber
The power saving states will be kept until a control signal has been detected or the
keyboard or mouse is activated. The recovery time from Active OFF state back to ON
state is around 3 seconds.
Display Data Channel (DDC)
To make installation easier, so long as your system supports the DDC protocol, the
monitor is able to plug-and-play. The DDC is a communication protocol through
which the monitor automatically informs the host system about its capabilities; for
example, supported resolutions and corresponding timing. The monitor supports the
DDC2B standard.
8
