ACO ShowerDrain Lightpoint Quick start guide

Tel. [phone]
Fax [phone]
1
Installation notes
ACO Haustechnik
Service-Line
0150.27.44
As per: 04/2010
This operating-/assembly instruction applies for the
ACO Showerdrain Lightpoint LED bath drain illumina-
tion and contains important information! It must be
handed out to the end user who must keep it in a safe
place!
ACO ShowerDrain Lightpoint
Function description
The ACO ShowerDrain Lightpoint illumination system consists of one
accumulator-operated LED module and a charging device. The LED
module is mounted in the top section of ACO bath drains (refer to
page 2).
In the case of water entering the drain, the module is activated
automatically and, with a continuous water inflow, it lights for max.
15 minutes. In the case of a renewed water inflow, the LED module
switches on again only after it air-dried before.
If the shower water inflow stops after less than 15 minutes, the
module still lights for a period of approx. two minutes, before the
module switches off automatically.
Charging process prior to initial use
Prior to initial use, the LED modules must be fully charged. This pro-
cess may take up to 18 hours. It must be made sure that the metal
contacts of the LED modules are free from dust, dirt and moisture.
Charging process during use
Depending on frequency of use, the LED modules must be rechar-
ged every three months. Before the LED module is inserted in the
charging device, it has to be cleaned with warm water and to be
completely dried thereafter. The metal contacts of the LED module
must be free from dust, dirt and soap residues.
Inserting the LED module in the charger
Each LED module leg may be inserted into the charging device. Ple-
ase pay attention that the module is correctly inserted. The correct
positioning can be taken from below illustration.
Control lamps at the charging device
Charging lamps‘ state
Normal blinking
Rapid blinking
Permanent lighting
Meaning
Charging of LED modules takes place
Accumulator voltage already intensely dropped
or accumulator damaged. The charging device
nevertheless tries to recharge this LED module.
If, during the charging process, the charging
device does not switch over to slow blinking
(normal charging) within one hour, the LED mo-
dule is defective and may no longer be used.
Charging process finished
Art. no. of top section Minimal installation height
(Upper edge of drain body to upper edge of grating)
5141.22.00 60 mm
5141.23.00 60 mm
5141.25.00 60 mm
5141.29.00 95 mm
5141.30.00 95 mm
5141.32.00 95 mm
5141.46.00 60 mm
5141.42.00 95 mm
5141.43.00 60 mm
5141.48.00 95 mm
Suitable for following ACO top sections
with minimal installation heights
Lighting kit
red Art. no. 9010.89.10
blue Art. no. 9010.89.11
green Art. no. 9010.89.12
warm-white Art. no. 9010.89.13

Tel. [phone]
Fax [phone]
2Service-Line
Installation of the LED module in the top
section of ACO shower drains
❶Lubricant must be applied to the internal socket of the top sec-
tion prior to fitting the LED module.
❷Insert module slantly
❸Pull the third leg upwards
❹Carry out height positioning.
Pull module upwards until it gets caught automatically. It must
be observed that approx. 10 mm clearance remain between
upper edge of grating and the upmost place of the Lightpoint.
This guarantees safe draining of water.

Tel. [phone]
Fax [phone]
3
Installation notes
ACO Haustechnik
Service-Line
0150.27.44
As per: 04/2010
Servicing and maintenance
The LED module has to be cleaned depending on frequency of show-
ering. To do this, clean the contacts with warm water and a cloth
and free them from soap residues. To do this, the LED module must
be removed from the top section (refer to dismantling shown on fig.
1 + 2).
Charging device and LED module are both maintenance-free and may
therefore not be disassembled. Repair works must always be carried
out by an authorised service center or a specialist as otherwise you
risk destruction of the product. Moreover, the approval (CE) as well
as warranty claims expire.
Prior to cleaning, unplug the mains plug.
Technical data
Wall power supply:
Input: 230 V
Output: 9 V DC, 800 mA
Charging device:
Input: 9 V DC, 300 mA
Charging current: 250 mA (typ.)
Charging time: max. 18 hours
Automatic switching-off of charging
Maximum voltage at contacts: 9 V DC
Dimensions of charging device (in mm):
L x W x H = 60 x 115 x 70
Dismantling of the LED module from the
top section of ACO shower drains
❶Slightly press one leg downwards
❷Remove module in slanting position

The ACO Group. A strong family you can build on.
ACO Passavant GmbH
Im Gewerbepark 11c
36457 Stadtlengsfeld
Tel. [phone]
Fax [phone]
www.aco-haustechnik.de
Installation notes
As per: 04/2010
Origin: German manual
Subject no. 0150.27.44
HT 874/04/2010 ●As per: 04/2010 LTC ●Subject no. 0150.27.44 Origin: German manual ●Subject to technical alterations!
Safety notes
The mentioned safety notes, the pertinent national accident preven-
tion regulations as well as possible internal working, operating and
safety regulations of the user have to be observed. The safety notes
whose non-observance could lead to danger to human beings as well
as warnings of electric voltage are marked with the pertinent safety
symbols (as per DIN 4844 . W8/9).
General danger symbol
Beware of voltage
For safety reasons and in order not to lose the approval (CE), the
arbitrary conversion and/or alteration of the product is not per-
mitted.
The product (charging station and power supply) is approved on-
ly for operation in dry, closed interior rooms. The product may
not become damp or wet.
Proper use
The LED illumination module is intended for installation in ACO
shower drains only. It serves as effective illumination when using the
shower appliance.
The associated charging station is intended exclusively for char-
ging of one illumination module (type 9010.89.05 / 9010.89.06 /
9010.89.07). Never use this device to charge other batteries. Never
bypass the charging contacts.
When using the charger, following notes have to be observed:
As power supply, only the supplied wall power supply may be used.
Operate and store in dry rooms only. Prior to charging, the illuminati-
on modules have to be thoroughly cleaned and dried.
When operating the device, pay attention to sufficient aeration. Ne-
ver cover the air vents. During operation, the device must be placed
on a hard, flame resistant support.
During charging, an ambient temperature of approx. 20°C is recom-
mended. Do not expose to direct sunlight.
Never operate the charger unattendedly.
A different use as the one described before leads to damage of this
product. Moreover, risks as short-circuit, combustion, electric shock
and alike persist.
The product as a whole may not be changed or altered. The charger
may only be operated in dry interior rooms.
Don’t leave the packing material carelessly as it could become a
dangerous toy for your children!!
The design of the wall power supply corresponds to protection
class II. Voltage-/power may only be supplied by the public mains
supply (230V~/50-60Hz).
Load the product only up to the indicated capacity. An
overload may lead to destruction of the product, to a
combustion or an electric accident.
The product may be damaged by crushes, beats or by falling
down, even from low height.
Never operate the product (or other conventional elec-
tric appliances) next to or in the vicinity of flammable
liquids or gases, air-/gas mixtures (petrol vapours) or
easily flammable solid matters.
When operating the product or other electrical applian-
ces, sparks may arise which could lead to ignition of
the gases or the air-/gas mixtures!
Danger of explosion exists!
If you are in doubt about the working principle, safety or the con-
nection of the appliance, please contact a specialist!!
Avoid the following adverse environmental conditions at the ins-
tallation location, during operation or transport:
Wetness or too high air humidity (charger)
Extreme coldness (<0°C) or heat (>40°C), direct solar
radiation
Dust or flammable gases, vapours or solvents
Strong vibrations, crushes, beats
Strong magnetic fields, as prevailing in the vicinity of
machines or loudspeakers
Pay attention that isolation of the complete product neither beco-
mes damaged nor destroyed, never disassemble it. Prior to each
use, check the product for damages!!
If you ascertain damages, the product may not be put
into operation. There is danger to life!
In this case, take the appliance to an authorised service center
or dispose of it ecologically sound; refer to “disposal”.
Disposal
At the end of its service life, dispose of the product in
accordance with the pertinent legal regulations.
