GlobalWatchTM UAIS Quick User Manual I
Version 1.0
Please read this first!
Warning:
Although ACR strives for accuracy in all its publications; this material may contain errors or
omissions, and is subject to change without prior notice. ACR shall not be made liable for any
specific, indirect, incidental or consequential damages as a result of its use. ACR components may
only be used in safety of life devices or systems, with the express written approval of ACR, as the
failure of such components could cause the failure of the ACR device or system. If these fail, it is
reasonable to assume that the safety of the user or other persons may be endangered.
Y1-03-0176A

GlobalWatchTM UAIS Quick User Manual II
Version 1.0
1GLOBALWATCHTM UAIS Components and Interfaces........................................................................ 1
2GLOBALWATCHTM UAIS User Interface ............................................................................................... 2
3Navigation Screen................................................................................................................................... 3
4Inputing Voyage Related Data – (User Password Protected)............................................................. 4
5Setting Ship Related Data – (User Password Protected).................................................................... 6
6Configuring the GlobalWatchTM UAIS – (User Password Protected)................................................. 8
7Changing the Service Password – (Service Password Protected) .................................................. 11
8Changing the MMSI / IMO Numbers .................................................................................................... 13
9Writing an Addressed Safety Related Message to an individual Vessel ....................................... 15
10 Writing a Broadcast Safety Related Message to all Vessels........................................................... 17
11 Safety Functions – MOB and SRM Buttons ....................................................................................... 19
12 Display Settings .................................................................................................................................... 22
13 Contact and Support Information........................................................................................................ 23
GlobalWatchTM UAIS Short Operation Manual
Index Page Number
Y1-03-0176A

GlobalWatchTM UAIS Quick User Manual III
Version 1.0
History of Changes
Date Version Status Comments Responsible
2002-12-04 1.0 Released Latest release amendments A. Lesch
2003-06-30 1.0.1 Released Corrections B. Werner
2004-04-14 1.0.1 Changes upon Customer Requests S. Reinisch
Y1-03-0176A

GlobalWatchTM Quick User Manual 1
Version 1.0
1 GLOBALWATCH
TM
UAIS Components and Interfaces
Y1-03-0176A

GlobalWatchTM Quick User Manual 2
Version 1.0
2 GLOBALWATCH
TM
UAIS User Interface
Display
Soft Keys [M1] – [M8] Safety Keys
Curso
r
Cross
Keyboard
Enter Key
Navigation Screen
Header (max. 3 lines)
_
____________________________
_
Navigation Screen or
MENU Structure
(Content 13 lines)
Y1-03-0176A

GlobalWatchTM Quick User Manual 3
Version 1.0
3 Navigation Screen
Latitude &
Longitude
Own speed over Ground
Own course over Ground
UTC Time
GPS Solution
Received Vessels
(
Vessel Listin
g)
>Indicates further Vessels in Listing
LAT:N 1^27.845'ExtSOG:34.6kn 11/26/2002
LON:E 0^21.289'IntCOG:173.0^ 10:52:26
IntGPS: 3D ExtHDT:222^ Reg6 A/
001/021..ShipName....RNG.BRG..SOG..COG..
1>DOREEN-----------> N/A 120 22.2 301.5
2>FINE EAGLE------->0.00 N/A 13.1 359.9
3>SYLVAEPSILON----->0.10 23 32.1 203.2
4>ESSOTOKYO-------->0.43 99 10.0 120.3
5>OLYMPIAHIGHWAY FE>0.59 342 21.2 50.0
6>SANEI------------>0.80 272 32.1 270.1
7>KATOO------------>1.00 321 21.2 200.8
8>OLYMPIA PALACE--->1.34 277 [BASESTAT]
9>MINILOG---------->1.96 201 21.7 102.2
10>ALIBRAHIMYA----->2.66 340 22.1 30.3
11>TITANIC--------->2.75 121 N/A N/A
12>BWRTZ123-------->3.36 66 24.1 2.9>
Y1-03-0176A

GlobalWatchTM Quick User Manual 4
Version 1.0
Note:
The User Password is set to “NAUT” – please reconfigure it immediately after Transponder initial operation
Select “Voyage Settings” from the Main Menu with the cursor button [Up] & [Down] or press Nr. 3 on the
keyboard
The Password Query Field appears. Input User Password and press [Enter].
4 Inputing Voyage Related Data – (User Password
Protected)
N 1^20' E 0^13' |1> N/A|2>0.00|3>0.10nm
|----------------------------------
| Menu
-----| |
| +- 1. Messages
View | +- 2. AIS Status
| +- 3. Voyage Settings
-----| +- 4. Ship Settings
| +- 5. Transponder Configuration
Msg. | +- 6. Service Configuration
| +- 7. Display Settings
-----|
|
Displ|
----------------------------------------
NUM|Select->| | |<-Back
N 1^31' E 0^24' |1>0.01|2>1.30|3>1.80nm
----------------------------------------
++++++++++++++++++++++++++++++++++++++++
User password protected!
Please enter user password:
++++++++++++++++++++++++++++++++++++++++
----------------------------------------
| Enter | | | Exit
Y1-03-0176A

GlobalWatchTM Quick User Manual 5
Version 1.0
Scroll the Voyage Data Fields with [Enter] and input own vessel data. Select a default Cargo Type and
NavStat Setting with the cursor buttons [Left] & [Right].
Save the new settings by pressing [Save], and return to the Main Menu Screen by pressing [Exit]. Press
[Back] to return to the Main Menu without saving any changes.
N 1^18' E 0^12' |1>0.01|2>1.30|3>1.80nm
*********** Voyage Settings ************
Cargo :<N/A or harmless>
Draught :24.8m
PoB :1
Dest. :CASABLANCA
ETA :10/13 12:31
NavStat.:Engaged in fishing
----------------------------------------
| Save | | | Back
Y1-03-0176A

GlobalWatchTM Quick User Manual 6
Version 1.0
Select “Ship Settings” with cursor button [Up] & [Down] or press Nr. 4 on the keyboard.
Note: The User Password is set to “NAUT” – please reconfigure it immediately after Transponder initial
operation
Input User Password and press [Enter].
5 Setting Ship Related Data – (User Password Protected)
N 1^23' E 0^16' |1>0.01|2>1.30|3>1.80nm
|----------------------------------
| Menu
-----| |
| +- 1. Messages
View | +- 2. AIS Status
| +- 3. Voyage Settings
-----| +- 4. Ship Settings
| +- 5. Transponder Configuration
Msg. | +- 6. Service Configuration
| +- 7. Display Settings
-----|
|
Displ|
----------------------------------------
NUM| Select->| | |<-Back
N 1^23' E 0^16' |1>0.01|2>1.30|3>1.80nm
----------------------------------------
++++++++++++++++++++++++++++++++++++++++
User password protected!
Please enter user password:
++++++++++++++++++++++++++++++++++++++++
----------------------------------------
| Enter | | | Exit
Y1-03-0176A

GlobalWatchTM Quick User Manual 7
Version 1.0
Scroll the Ship Settings Fields with [Enter] and input own vessel data. Select a default Ship Type with the
cursor button [Left] &[Right].
Save the new settings by pressing [Save]. By pressing [Back] you return to the Main Menu Screen without
saving any changes.
N 1^19' E 0^12' |1>0.01|2>1.30|3>1.80nm
************ Ship Settings *************
/\ +
CallSign:D11233 / \|
ShipName:ANDREA DORIA | |
Length :220m | A
Beam :43m | x--+
RefPtExt:A200 B20 C10 D33m | | B
RefPtInt:A190 B30 C20 D23m +-C-+D-+
ShipType: Pilot vessel
----------------------------------------
| Save | | | Back
Y1-03-0176A

GlobalWatchTM Quick User Manual 8
Version 1.0
Select “Transponder Configuration” with the cursor button [Up] & [Down] or press Nr. 5 on the keyboard.
Note:
The User Password is set to “NAUT” – please reconfigure it immediately after Transponder initial operation
Input default User Password and press [Enter].
6 Configuring the GlobalWatch
TM
UAIS – (User Password
Protected)
N 1^19' E 0^13' |1>0.01|2>1.30|3>1.80nm
|----------------------------------
| Menu
-----| |
| +- 1. Messages
View | +- 2. AIS Status
| +- 3. Voyage Settings
-----| +- 4. Ship Settings
| +- 5. Transponder Configuration
Msg. | +- 6. Service Configuration
| +- 7. Display Settings
-----|
|
Displ|
----------------------------------------
NUM| Select->| | |<-Back
N 1^19' E 0^13' |1>0.01|2>1.30|3>1.80nm
----------------------------------------
++++++++++++++++++++++++++++++++++++++++
User password protected!
Please enter user password:
++++++++++++++++++++++++++++++++++++++++
----------------------------------------
| Enter | | | Exit
Y1-03-0176A

GlobalWatchTM Quick User Manual 9
Version 1.0
Select desired Submenu with the cursor buttons [Up] &[Down] or by pressing the appropriate number on
the keyboard.
Change User Password: Select Submenu 1
Input new User Password (4 – 8 characters) and press [Enter] to save.
Press [Back] to return to the Submenu without saving.
N 1^20' E 0^13' |1>0.01|2>1.30|3>1.80nm
|----------------------------------
| 5. Transponder Configuration
-----| |
| +- 1. Change User Password
View | +- 2. Region Settings
| +- 3. Alarm Settings
-----| +- 4. Interrogation Settings
| +- 5. Sensor Settings
Msg. |
|
-----|
|
Displ|
----------------------------------------
NUM| Select->| | |<-Back
N 1^21' E 0^14' |1>0.01|2>1.30|3>1.80nm
********* Change User Password *********
Enter new password : *****
Repeat new password: *****
{Length: 4..8 characters}
----------------------------------------
| Enter | | | Back
Y1-03-0176A

GlobalWatchTM Quick User Manual 10
Version 1.0
Alarm Settings: Select Submenu 3
Press [Change] to enable or disable the Alarms Function. [Back] takes you to the Submenu without saving,
by pressing [Save] the changes are stored and by pressing [Exit] you return to the Submenu.
Note:
It is highly recommended to enable the Alarm Function.
Long Range Interrogation: Select Submenu 4
Navigate the Input Fields with [Up] & [Down] and press [Change] to enable or disable interrogation
requests on individual data fields. [AllOn] sets all data fields free for interrogation. Press [Back] to return to
the Submenu without saving, and [Save] to save settings and return to the Submenu.
N 1^21' E 0^15' |1>0.01|2>1.30|3>1.80nm
************ Alarm Settings ************
on/off
Alarm generation: [*]/[ ]
Note: This setting also affects output
on ECDIS port.
----------------------------------------
| Save | Change | | Back
N 1^21' E 0^14' |1
>
0.01|2>1.30|3>1.80nm
******** Interrogation Settings ********
on/off auto/manu
LR-Interrogation: [*]/[ ] [*]/[ ]
Data for Interrogation:
Name,Call,IMO [*] Cargo [*]
Length,Beam,Type [*] Draught [*]
POS [*] PoB [*]
SOG [*] Dest,ETA [*]
COG [*] Date,Time [*]
----------------------------------------
| Save | Change | All On | Back
Y1-03-0176A

GlobalWatchTM Quick User Manual 11
Version 1.0
Note:
The User Password is set to “NAUT” – please reconfigure it immediately after Transponder initial operation
Select “Service Configuration” from the Main Menu with the cursor button [Up] & [Down] or press Nr. 6 on
the keyboard.
Enter default Service Password
7 Changing the Service Password – (Service Password
Protected)
N 1^19' E 0^13' |1>0.01|2>1.30|3>1.80nm
|----------------------------------
| Menu
-----| |
| +- 1. Messages
View | +- 2. AIS Status
| +- 3. Voyage Settings
-----| +- 4. Ship Settings
| +- 5. Transponder Configuration
Msg. | +- 6. Service Configuration
| +- 7. Display Settings
-----|
|
Displ|
----------------------------------------
NUM| Select->| | |<-Back
N 1^24' E 0^17' |1>0.01|2>1.30|3>1.80nm
----------------------------------------
++++++++++++++++++++++++++++++++++++++++
Service password protected!
Please enter service password:
++++++++++++++++++++++++++++++++++++++++
----------------------------------------
| Enter | | | Exit
Y1-03-0176A

GlobalWatchTM Quick User Manual 12
Version 1.0
Select Submenu 1: Change Service Password.
Input new Service Password (4 – 8 characters) and press [Enter] to save.
Press [Back] to return to the Submenu without saving.
N 1^23' E 0^17' |1>0.01|2>1.30|3>1.80nm
|----------------------------------
| 6. Service Configuration
-----| |
| +- 1. Change Service Password
View | +- 2. User Password Settings
| +- 3. Change MMSI / IMO
-----| +- 4. Restore Factory Settings
|
Msg. |
|
-----|
|
Displ|
----------------------------------------
NUM| Select->| | |<-Back
N 1^19' E 0^13' |1> N/A|2>0.00|3>0.10nm
******* Change Service Password ********
Enter new password :
Repeat new password:
{Length: 4..8 characters}
----------------------------------------
| Enter | | | Back
Y1-03-0176A

GlobalWatchTM Quick User Manual 13
Version 1.0
Select “Service Configuration”
from the Main Menu with the
cursor button [Up] & [Down] or press Nr. 6 on the keyboard.
Select Submenu 3 “Change MMSI/IMO” with cursor button [Up] &[Down] by pressing Nr. 3 on the
keyboard.
8 Changing the MMSI / IMO Numbers
N 1^19' E 0^13' |1>0.01|2>1.30|3>1.80nm
|----------------------------------
| Menu
-----| |
| +- 1. Messages
View | +- 2. AIS Status
| +- 3. Voyage Settings
-----| +- 4. Ship Settings
| +- 5. Transponder Configuration
Msg. | +- 6. Service Configuration
| +- 7. Display Settings
-----|
|
Displ|
----------------------------------------
NUM| Select->| | |<-Back
N 1^21' E 0^14' |1>0.01|2>1.30|3>1.80nm
|----------------------------------
| 6. Service Configuration
-----| |
| +- 1. Change Service Password
View | +- 2. User Password Settings
| +- 3. Change MMSI / IMO
-----| +- 4. Restore Factory Settings
|
Msg. |
|
-----|
|
Displ|
----------------------------------------
NUM| Select->| | |<-Back
Y1-03-0176A

GlobalWatchTM Quick User Manual 14
Version 1.0
Input new MMSI / IMO Numbers and press [Save] to store input data.
Press [Back] to return to the Submenu without saving.
Note:
Data input is limited to 9 characters.
N 1^21' E 0^14' |1> N/A|2>0.00|3>0.10nm
********** Change MMSI / IMO ***********
MMSI :1193046
IMO No.:303174162
----------------------------------------
NUM| Save | | | Back
Y1-03-0176A

GlobalWatchTM Quick User Manual 15
Version 1.0
Select the Main Menu Screen with the [Menu] Button.
Select Messages with the cursor button [Up] &[Down] or press number Nr. 1 on the keyboard. Then select
“Write Addressed SRM”.
Select Message Recipient with cursor button [Up] &[Down]. Press [Exit] to return to the
previous screen.
9 Writing an Addressed Safety Related Message
to an individual Vessel
N 1^46' E 0^39' |1>0.10|2>1.30|3>1.80nm
|----------------------------------
| Menu
-----| |
| +- 1. Messages
View | +- 2. AIS Status
| +- 3. Voyage Settings
-----| +- 4. Ship Settings
| +- 5. Transponder Configuration
Msg. | +- 6. Service Configuration
| +- 7. Display Settings
-----|
|
Displ|
----------------------------------------
NUM |Select->| | <-Back
N 1^19' E 0^12' |1>0.10|2>1.30|3>1.80nm
|----------------------------------
| 1. Messages
-----| |
| +- 1. Write Addressed SRM
View | +- 2. Write Broadcast SRM
| +- 3. Inbox History
-----| +- 4. Inbox SRM
| +- 5. Inbox ALR (valid only)
Msg. | +- 6. Inbox LRI
|
-----|
|
Displ|
----------------------------------------
NUM| Select->| | | <-Back
Y1-03-0176A

GlobalWatchTM Quick User Manual 16
Version 1.0
Input Message Text to selected vessel and press [Send]. The [Back] takes you back to the
Navigation Screen without sending a message.
After message transmission, the Transmission Status Screen is displayed.
After Messaging is completed, the GlobalWatchTM UAIS automatically returns to the Navigation Screen
N 1^26' E 0^20' |1>0.10|2>1.30|3>1.80nm
************ Write Message *************
..ShipName......Dist..SOG..COG..CallSign
1>DOREEN-------> N/A 22.2 301.5 DORET6W
2>FINE EAGLE--->0.00 13.1 359.9 OEX1538
3>SYLVAEPSILON->0.10 32.1 203.2 ND4RX
4>ESSOTOKYO---->0.43 10.0 120.3 ZA9A
5>OLYMPIAHIGHWA>0.59 21.2 50.0 3FSH4
6>SANEI-------->0.80 32.1 270.1 YJQX9
7>KATOO-------->1.00 21.2 200.8 A4F317
8>OLYMPIA PALAC>1.34 [BASESTAT] 4DSW
9>MINILOG------>1.96 21.7 102.2 FOR6
10>ALIBRAHIMYA->2.66 22.1 30.3 DEZ42
11>TITANIC----->2.75 N/A N/A FSG >
----------------------------------------
NUM| Select | | | Back
N 1^20' E 0^13' |1>0.10|2>1.30|3>1.80nm
************ Write Message *************
Addressed SRM 129
SendTo:5004 (DOREEN)
Text: TEXT INPUT IS POSSIBLE HERE
----------------------------------------
auto/ A / B /A+B
Channel: [*]/[ ]/[ ]/[ ]
----------------------------------------
| Send |<Channel |Channel> | Back
LAT:N 1^18.963'ExtSOG:34.6kn 11/21/2002
LON:E 0^12.408'IntCOG:173.0 09:11:08
Ships:21 /B IntGPS: 3D Region6
++++++++++++++++++++++++++++++++++++++++
Transmission Status
[+] AIS1:OK, acknowledgement received
[ ] AIS2:
++++++++++++++++++++++++++++++++++++++++
----------------------------------------
| | Send To | |<-Back
Y1-03-0176A
