NAUTICAST Installation Manual
Index Page Number

Installation Manual III Y1-03-0212 Rev. B
History of Changes
Date Version Rev. Status Comments Responsible
2005-11-01 1.0.0 A Released A. Lesch
2006-07-14 1.0.1 B Released Editorial work M. D’Arcangelo

Installation Manual 1Y1-03-0212 Rev.B
1 General Introduction
1.1 Description of AIS
What does the abbreviation AIS stand for?
AIS stands for: “Automatic Identification System”
What is AIS?
According to IALA regulations, AIS is defined as follows:
Very simply, the AIS is a broadcast Transponder system, operating in the VHF maritime
mobile Band. It is capable of sending ship information such as identification, position
course, speed and more, to other ships and to shore. It can handle multiple reports at
rapid update rates and uses Self-Organizing Time Division Multiple Access (SOTDMA)
technology to meet these high broadcast rates and ensure reliable and robust ship to ship
operation.
What are the performance standards of AIS?
The IMO defines the performance standards as follows:
- Ship to Ship working
- Ship to Shore working, including Long Range Application
- Automatic and continuous operation
- Provision of information messaging
- Utilization of maritime VHF channels
Which modules make up an AIS-Transponder?
The Modules:
- DGPS / GPS receiver
- VHF Radio
- Antenna
- Computer (CPU)
- Power Supply
Appropriate application software connects the individual modules.
In which modes does AIS function?
AIS are required to function flawlessly in a variety of modes. The relevant regulations require:
The system shall be capable of
- An "autonomous and continuous" mode for operation in all areas. This mode
shall be capable of being switched to/from one of the following alternate modes by
a competent authority;
- An "assigned" mode for operation in an area subject to a competent authority
responsible for traffic monitoring such that the data transmission interval and/or
time slots may be set remotely by that authority;
- A "polling or controlled" mode, where the data transfer occurs in response to
interrogation from a ship or competent authority.

Installation Manual 2Y1-03-0212 Rev.B
1.2 AIS in an Operational Environment
This illustration depicts a typical AIS System, where two or more AIS
equipped vessels (and shore based systems) are automatically
communicating with each other.
On the bottom, a typical NAUTICAST installation in a common environment is shown.
The NAUTICAST is connected to the vessels emergency power supply, and in
connection with the VHF, and GPS-Antennas, the minimal requirements for Transponder
operation are fulfilled.
Both vessels in the above illustration are equipped with a NAUTICAST (or any other
certified AIS-Transponder). Due to “Time – Synchronization” they use the same
organization of free and allocated windows (Slots) in the shared VHF Data Link (this
method is called “Self Organized Time Division Multiple Access”) to send and receive
messages.
Without the necessity of any active interaction, both vessels know exactly who or what is
cruising nearby and where the individual object is heading.

Installation Manual 3Y1-03-0212 Rev.B
1.3 AIS Networks
The scenario below shows a full AIS coverage area (including all applications and complete
shore infrastructure).
The Carriage Requirement currently applies to SOLAS Vessels and will be extended on
Inland Waterways.

Installation Manual 4Y1-03-0212 Rev.B
2 NAUTICAST
2.1 System Overview
Unlike other AIS devices, the NAUTICAST combines all required functions into one cabinet.
Additionally, the NAUTICAST gives the operator a number of additional features (easy
mounting & installation, environmental protection and smallest dimensions).

Installation Manual 5Y1-03-0212 Rev.B
3 Installation
IMPORTANT: AUTHORITIES MANDATES that after the physical installation has
been successfully completed, all ships data and settings be entered into the AIS
transponder. See Section 4 for further instructions.
3.1 Installation Requirements
General Requirements
Please note that international conventions, regulations, instructions and guidelines have to be
adhered to when installing the NAUTICAST.
The following points must be observed before installation can commence:
- Permission by the local authority to install such a device must be granted.
- Trained service personnel must undertake the installation.
- The NAUTICAST must be fitted in a suitable place on the bridge.
- The VHF and GPS Antennas must be installed in a suitable position, where excellent
reception conditions apply (refer to Chapter 3.10 Installation of VHF antenna)
- All available interfaces must be installed.
- The vessels power supply must suffice, and the GMDSS power supply has to be
used.
- Installation of the pilot plug in conning position (close to the pilot working place).
3.2 Installation Overview
Survey
AIS is considered part of the ship’s radio station and is surveyed together with radio
installation. Surveys on SOLAS Convention ships should be carried out in accordance with
the rules laid down in IMO Res. A 746(18) "Survey Guidelines under the harmonized system
of survey and certification" (R) 8, and "Protocol of 1988 relating to the International
Convention for the Safety of Life at Sea, 1974."
The NAUTICAST consists of one unit, which integrates all necessary modules.

Installation Manual 6Y1-03-0212 Rev.B
Step-by-Step Installation Procedure:
•Mount the NAUTICAST close to ships operation workstation for traffic surveillance and
maneuvering.
•Use the VHF adapter cable (P/N 2612) together with the VHF plug and TNC plug to
connect the VHF and GPS antenna cables and antennas.
•The sensors, ECDIS, PC, pilot case, long range devices and auxiliary displays can be
connected to the NAUTICAST cabinet by the AIS cable by means of the connection
box. The device is driven by a 24V DC 7A supply, which is connected to the power
terminal at the connection box. The AIS should be connected to an emergency power
source. A battery capacity calculation together with GMDSS-equipment is needed!
Please refer to Appendix 9.1 for examples of battery capacity calculations.
•After performing these steps, the NAUTICAST automatically starts operation.
•The NAUTICAST has a ground terminal which has to be connected to ship ground.
•Now configure the required initial system parameters according to Chapter 4 “Starting
the NAUTICAST.”
NAUTICAST Connection Diagram
Note: The optional ACR connection box includes a fuse of 6,3A. If it is not used, then the unit
has to be protected against high current by an external slow blow fuse of 6,3A.

Installation Manual 7Y1-03-0212 Rev.B
Components and Interfaces
The diagram below illustrates which devices can be connected to the NAUTICAST. For a
detailed description of sensor connecting e.g. an existing Gyro to the NAUTICAST refer to
Chapter 3.5 “Sensor Interface Definitions.”.
3.3 General Interface Description
Interface Designation Speed Direction
Sensor 1 CH 1 4800bps or 38400bps Input
Sensor 2 CH 2 4800bps or 38400bps Input
Sensor 3 CH 3 4800bps or 38400bps Input
ECDIS CH 4 38400bps Input/Output
PILOT CH 5 / CH 15 38400bps Input/Output
LONG RANGE CH 8 38400bps Input/Output
DGPS (RTCM SC104) CH 9 9600bps Input/Output
ALARM CIRCUIT CH 10 Dry relay contact (power off and alarm state closed)

Installation Manual 8Y1-03-0212 Rev.B
3.4 Interface NMEA Description:
3.4.1 Sensor - Interface CH1, CH2, CH3
Refer to Chapter 3.8 for detailed information on Sensor - Interface and Configuration.
3.4.2 ECDIS – Presentation Interface CH 4
Sentence Formatters Direction Used Fields
ABK UAIS Addressed and binary broadcast acknowledgement out
ACA AIS Channel assignment message in / out
ACK Acknowledge Alarm in
AIR UAIS Interrogation Request in
ALR Set Alarm State out
ABM UAIS Addressed binary and safety related message in
BBM UAIS Broadcast Binary Message in
DSC Digital Selective Calling Information out
DSE Expanded Digital Selective Calling out
DSI DSC Transponder Initialize out
DSR DSC Transponder Response out
LRI UAIS Long-Range Interrogation out
LRF UAIS Long-Range Function out
SSD Station Static Data in
TXT Text Transmission out
VSD Voyage Static Data in
VDM UAIS VHF Data-link Message out
VDO UAIS VHF Data-link Own-vessel report out
All fields are provided
for Input and Output.
For further information
please refer to
IEC 61993-2 / NMEA
0183 HS V3.0 for
detailed field
information.

Installation Manual 9Y1-03-0212 Rev.B
3.4.3 Pilot Port CH 5
The used sentence formatters for the pilot plug are the same as those listed for the ECDIS
port.
Note:
A pilot input/output port is part of an AIS Class A installation. A plug connected to this port
should be installed on the bridge near the pilot’s operating position, so that a pilot can
connect a Personal Pilot Unit (PPU) if required. Also, a power connector for the pilot unit
should be available nearby.
The pilot plug should be configured as follows: (Refer to SUB-COMMITTEE ON SAFETY OF
NAVIGATION NAV48/18 2.4.2002)
AMP/Receptacle (Square Flanged (-1) or Free-Hanging (-2)), Shell size 11, 9-pin,
Std. Sex 206486-1/2 or equivalent with the following connections:
- Tx A (out-) is connected to Pin 1
- Tx B (out+) is connected to Pin 4
- Rx A (in-) is connected to Pin 5
- Rx B (in+) is connected to Pin 6
- Shield is connected to Pin 9
3.4.4 Long Range CH 8
The AIS long range function requires a compatible long range communication system (e.g.
Inmarsat-C or MF/HF radio as part of GMDSS). This connection is required in order to
activate the long range function of the AIS. Its input/output port must meet the IEC 61162-2
requirements.
Sentence Formatters Direction
LRI UAIS Long Range Interrogation Input
LRF UAIS Long-Range Function Input / Output
LR1 UAIS Long-Range Reply Sentence l Output
LR2 UAIS Long-Range Reply Sentence 2 Output
LR3 UAIS Long-Range Reply Sentence 3 Output
Field Information:
All fields are provided for input and output.
For further information please refer to
IEC 61993-2 / NMEA 0183 HS V3.0 for detailed field
information.

Installation Manual 10 Y1-03-0212 Rev.B
3.4.5 DGPS – DGNSS Channel 9
Field / Protocol information:
All fields are provided with further information; please refer to ITU-R M.823-2 / RTCM SC 104
for detailed field information.
3.4.6 Alarm Circuit – BIIT Channel 10
The AIS requires that an alarm output (relay) must be connected to an audible alarm device
or the ships alarm system, if available.
Alternatively, the BIIT (built-in integrity test) alarm system may use the alarm messages
output on the presentation port (ECDIS Port Channel 5), provided the ECDIS alarm system is
connected and AIS compatible.
3.4.7 Proprietary Sentences
The proprietary ACR NMEA sentences have the NMEA registered manufacture talker ID
“NAU”. The $PNAU sentences are an addition to the standard sentences and offer other
manufactures full remote control to the Transponder. The additional “Extended NMEA
command set” – manual, which could be requested on demand, includes the full description
of how to use the proprietary NAUTICAST sentences.
Proprietary NMEA-Sentences $PNAU
MID - Mobile (MMS) Id
ASD - Advanced Ship Data
RCS - Read Configuration Settings
STO - Set Transponder Options
TSI - Transponder State Information
SCR - Sensor Configuration Request
SCA - Sensor Configuration Acknowledge
SCD - Sensor Configuration Data
SCM - Sensor Configuration Mode
AIQ - Request status information from the Transponder

Installation Manual 11 Y1-03-0212 Rev.B
3.5 Sensor Interface Definitions
All interface ports of the NAUTICAST comply with IEC-61162-1 / -2 and NMEA-0183 HS 3.0
specifications (aligned to RS422 parameters).
3.5.1 Talker drive circuits
The maximum output current is Imax = 50mA on each port. The drive circuit meets the
requirements of ITU-T V.11.
3.5.2 Listener Receiver Circuits
Multiple listeners may be connected to a single talker. Optional termination resistors
(120Ohm) for the input lines are provided in the connection box. The input terminals A, B and
C are electrically isolated from the remaining electronics of the listening device.
The input impedance is 30kOhm between A and B lines, disregarding the connection of
termination resistors. The minimum input voltage is ±0,3V.
The listener's receiver circuit complies with ITU-T V.11.
3.5.3 Electrical isolation
There are no direct electrical connections between the signal lines A and B.
The signal ground C must not be connected to the ship main ground or power line!
This isolation is in accordance with IEC 60945.
3.5.4 Maximum voltage on the bus
The maximum applied voltage between signal lines A and B and between either line and
ground C is in accordance with ITU-T V.11. For protection against incorrect wiring and for
unintended connection to older TALKER models, all receiver circuit devices are capable of
withstanding 15 V between both lines and signal ground for an indefinite period.
3.5.5 Data transmission
Data is transmitted in serial asynchronous form in accordance with IEC 61162-1. The first bit
is a start bit, and is followed by data bits, whereby the least significant bit is first.
The following parameters are used:
– Baud rate 38 400 (bits/s) 9600 (bits/s) 4 800 (bits/s)
– Data bits 8 (D7 = 0), parity none
– Stop bits 1.

Installation Manual 12 Y1-03-0212 Rev.B
3.6 Sensor notes
External Sensor
The AIS has interfaces (configurable as IEC 61162-1 or 61162-2) for position, bottom track
(BT) speed, heading and rate of turn (ROT) sensors. In general, sensors installed in
compliance with other carriage requirements of SOLAS Chapter V should be connected to the
AIS System.*1. The sensor information transmitted by AIS should be the same information
being used for navigation of the ship. Interfacing problems might occur if the existing on board
sensors do not have serial (IEC 61162) outputs. A converter is needed to translate the non
conform data to IEC 61162 – sensor data. For Example ACR Converter type P/N 2641.
*1) The fact that AIS is fitted on board a vessel does NOT entail the need to install additional sensors
other than those stated in the carriage requirements.
External GPS
GNSS position sensors normally have IEC 61162 outputs suitable for direct AIS interfacing.
However, it is important to note that:
• The Geodetic Datum of the position data is transmitted by the sensor in WGS84 so that an
IEC 61162 DTM sentence is configured.
• AIS is able to process two reference points for its antenna position, one for external, and
one for an internal sensor. If more than one external reference point is used, the appropriate
information needs to be input to the AIS, so that the reference point information is suitably
adjusted.
External Heading
A gyrocompass providing heading information is a mandatory sensor input to the AIS. A
converter unit (synchro or step-signal converter to NMEA 0183 v.3.0 for example ACR
Converter type P/N 2641 will be needed for AIS connection in the case that the ship’s
gyrocompass does not provide IEC 61162 output.
External Speed and Course
If a bottom track (BT)log for speed over ground (SOG) is available, it may be connected. A
converter (for example ACR Converter type P/N 2641) is needed if the BT-log does not
provide IEC 61162 outputs
External Rate of Turn
Not all ships will carry a Rate-Of-Turn (ROT) indicator according to IMO A.526. However, if a
rate-of-turn indicator is available and it includes an IEC 61162 interface, it should be
connected to the AIS.
If ROT information is not available from a ROT indicator, it may (optionally) be derived from
heading information through:
• The gyrocompass itself,
• An external converter unit (see Heading),
• The AIS itself (calculated ROT).

Installation Manual 13 Y1-03-0212 Rev.B
3.7 Sensor Hardware Installation:
3.7.1 Installation of an RS422 serial interface:
In most cases, the output from a GPS is already being used by existing navigation equipment.
It is possible to split an RS 422 output for two devices. If the signal becomes too low, then an
NMEA splitter has to be used.
Example for single talk multi-listener connection:
Each interface on the Transponder is a RS422 serial interface
The shield or ship main ground should not be connected with the signal ground (GND).
AIS Conncetion Box
Listener (other
equipment)
A
B
C (GND)
- IN
+ IN
G1 (or 2,3)
Shields
A
B
C (GND)
Talker (e.g.: GPS)

Installation Manual 14 Y1-03-0212 Rev.B
3.8 Sensor Software Configuration
3.8.1 Introduction
The NAUTICAST AIS requires a connection to various sensor devices. Sensor Configuration
should enable compatibility with existing navigation devises aboard any vessel.
This chapter deals with several ways to configure the NAUTICAST and to comply with the
requirements of the specific sensor interfaces.
Configuration and display is visible on two screens of the Sensor Configuration Menu. The
NAUTICAST offers the following configuration options:
•Set up data speed 4800/9600/38400 baud.
•Monitor the connected sensor inputs for each sensor channel.
•Verify and edit the Sensor Configuration on the display screen.
•Analyze the information received from the connected sensor devices.
•Produce an electronic installation report.
•Configuration of various NMEA protocols.
The individual options may be repeated until the required configuration for the connected
sensor devices is achieved.
During the configuration process, the NAUTICAST is not operational.
3.8.2 Set up Sensor Speed, Checksum (CRC) and NMEA Talker and Sentence ID
Sensor configuration is available in the AIS software versions higher than 2.0.1.0. It is
accessible via the new submenu ‘5. Sensor Settings’ in the Service Password protected
menu: ‘5. Transponder Configuration’.
N 1^19' E 0^13' |1> N/A|2>0.00|3>0.10nm
|----------------------------------
| 5. Transponder Configuration
-----| |
| +- 1. Change User Password
View | +- 2. Region Settings
| +- 3. Alarm Settings
-----| +- 4. Interrogation Settings
| +- 5. Sensor Settings
Msg. |
|
-----|
|
Displ|
----------------------------------------
NUM|Select->| | |<-Back

Installation Manual 15 Y1-03-0212 Rev.B
After accessing the Sensor Configuration menu this main configuration screen is active:
A variety of possible settings can be made on this screen. It is possible to navigate from one
configuration item to another by pressing the up and down arrow keys.
Value will be changed by pressing the left and right arrow key.
The fastest way to jump from one sensor to another is by pressing numbers 1 – 3 on the
keyboard. (Refer also to chapter 3.8.4 for specific information on a particular sensor)
The following changes can be undertaken for each of the sensor interfaces (by left and right
arrow key):
oChanging the baud rate (4800, 9600 and 38400) to the required speed of the sensor
device by pressing the right or left arrow keys.
oEnabling or disabling CRC-Checking by pressing the right or left arrow keys.
<auto> Sentence will be accepted with or without Checksum
<on> Checksum must be available
oConfiguring NMEA sentences, which the system filters and ignores
There are 5 entry fields where characters can be input. Two positions of each entry
field are for Talker-Id, and three for Sentence-Id, which represents the NMEA-
sentence which should be ignored by the system.
(i.e. the default setting: “HC“ means ignore all NMEA records starting with HC on this
particular sensor interface)
Note: HC stands for magnetic north and should be ignored.
For Example:
--VTG means all VTG sentence IDs will be ignored like GPVTG, GNVTG…
VW--- means all VW Talkers ID from speed log will be ignored like VWVHW, VWVBW
Changes on this screen can be saved by pressing the “Save” – Button [M5].
The factory settings can be recalled be pressing the “Default” – Button [M6].
Returning back to the previous screen is possible by pressing the “BACK” – Button [M8].
The next step is the analysis of the current sensor interface settings, which can be
undertaken with the “Analyze” – Button [M7]. After pressing this button, the real-time analysis
of the sensor data stream begins. This process takes around 30 seconds and is visible on a
temporary screen.
N 1^19' E 0^12' |1> N/A|2>0.00|3>0.10nm
*********** Sensor Settings ************
BaudRate Sensor1:< 4800> CRC: auto
Ignored:$HC---$-----$-----$-----
$-----$-----$-----$-----
1>Start Monitor>
BaudRate Sensor2: 4800 CRC: auto
Ignored:$HC---$-----$-----$-----
$-----$-----$-----$-----
2>Start Monitor>
BaudRate Sensor3: 38400 CRC: auto
Ignored:$HC---$-----$-----$-----
$-----$-----$-----$-----
3>Start Monitor>
----------------------------------------
| Save | Default | Analyze | Back

Installation Manual 16 Y1-03-0212 Rev.B
It is possible to interrupt this process by pressing the “Back” - Button [M8].
After the analysis is complete, the Transponder will list the data used for the AIS operation.
*********** Sensor Settings ************
**************************************
* *
* Please stay... *
* analyze Sensor 1..3 *
* this takes max. 30sec. *
* *
**************************************
----------------------------------------
| | | | Back
N 1^18' E 0^12' |1> N/A|2>0.00|3>0.10nm
************ Sensor Analyze ************
Analyze:
Date Src Used CHx Update
Position: Ext >$GPGLL 1,2 820ms
: Int $GPGGA i,1 273ms
: Int $GPRMC i,1,3 656ms
UTC : Ext $GPGLL 1,2 820ms
: Int $GPGGA i,1 273ms
: Int $GPRMC i,1,3 656ms
Date : Int $GPRMC i,1,3 656ms
COG : Ext $GPVTG 1,2 792ms
: Int $GPRMC i,1,3 656ms
SOG : Ext $VDVBW 1,2 820ms>
----------------------------------------
| Select | | | Back
