Acros AS7508F User manual
Dispensing water:
Press a container or a glass against the lever until the
desired level of water is completed.
The container to collect water retains any
drops that may fall while you are dispensing water.
Use a dry cloth to clean or dry the container to collect water.
Cleaning the tank:
Clean the tank frequently. For cleaning, never use the
dishwasher. Remove the water tank by turning it and
withdrawing it in the direction indicated in the figure.
Support the tank and remove the lid.
Disengage the tip of the valve by turning it to the
left until you feel that the piece is loose.
Remove it and clean it carefully.
Use sponge or soft cloth moistened with
detergent or neutral soap. Rinse well
and dry with a clean dry cloth.
Important:
Do not remove the body of the
valve, indicated in the figure.
Refilling the tank:
Fit and lock the valve again, as shown in the figure.
Important:
Before replacing the tank, verify that the
valve is correctly installed.
Install the tank on the side hooks
and in the hole in the door.
Verify that the tank is firmly installed.
Note the absence of spaces between the support
and the door.
Your refrigerator has a system that allows you to dispense cold water without
opening the door, thus avoiding excessive door openings, consequently,
reducing energy consumption.
Filling tank:
To fill up water in the tank, turn the lid on and
fill it with a jug. After filling, close the funnel
cover, turning it to the initial (closed) position.
Important:
Exclusive use for water.
Any other liquid may cause malfunction of the product.
Only use potable water to fill the tank.
The manufacturer is not responsible for damage caused to the system if the
tank is supplied with any other type of liquid other than water.
Adjust the refrigerator’s racks according to the way the refrigerator is used.
To remove the shelves:
1. Remove all items from the shelves.
2. Lift the top.
3. Slide the grill out.
To replace the shelves:
1. Ensure that the molding tab is positioned up,
according to the image.
2. Place the back of the shelf
on the rails located on the side walls.
3. Guide the front of the grill onto the rails.
4. Slide it in until it stops.
Procedure for cleaning doors and cabinets with significant rust stains:
Keep the refrigerator in a dry environment. As moisture builds up, the metal
rusts and rust will keep developing.
Manual cleaning method
Remove the shelf
Care of your refrigerator
To defrost, follow these instructions:
1. Press the button on the temperature control.
Defrost starts automatically.
2. Once the defrosting is complete, remove the meat tray and / or
defrost, empty the water and insert the tray again.
3. Thoroughly dry the freezer and the entire interior of the refrigerator with
a soft cloth.
4. The refrigerator, once the defrosting is finished, will automatically work
again without having to re-select the temperature.
NOTE: Do not use sharp or pointy objects to
remove frost from the freezer.
This will damage the evaporator.
1. Moisten a
sponge in
water with
detergent.
2. Use the soft
surface of the
sponge to rub
over the rust
stain. The
rubbing should
be in the
same sense of
polishing.
3. Use the hard
surface to rub
over the rust
stain.
The rubbing
should be in the
same direction
of the grain.
4. Rinse the
sponge with
tap water until
the detergent is
removed.
5. Moisten the fiber
in water.
6. Dry the
surface of the
unit well with
the sponge.
7. Use a piece of
dry cloth and
rub on the wet
surface. It is
recommended
to use a
stainless steel
cleaner for a
shiny finish.
A- Hard surface
B- Smooth
surface
Tools needed:
• Piece of dry cloth
• Soft / hard surface sponge
Water dispenser (some models)
Tank
Turn the funnel lid outwards to fill the tank
Recipient to
collect water
Lever
VERY IMPORTANT
IT IS THE RESPONSIBILITY OF THE USER TO VERIFY THE FOLLOWING
INFORMATION BEFORE CALLING THE TECHNICIAN:
If you followed the instructions in the installation, use and care manual
correctly, and have questions about the operation of the refrigerator, this guide
offers solutions to problems you can detect and correct in your home.
IF THE REFRIGERATOR DOES NOT WORK
• Connect the plug directly, DO NOT USE CORD EXTENSIONS.
• Check the ELECTRICAL CONTACT, IT COULD BE DAMAGED, connect
another device and test if it works.
• Avoid starting several devices at the same time; THE ELECTRICAL
INSTALLATION MAY OVERLOAD.
• Verify that the TEMPERATURE CONTROL IS IN THE ON-OFF POSITION.
• Make sure the refrigerator is NOT NEXT TO A HEAT SOURCE such as an
oven, stove or direct sunlight.
• THE DOORS MUST CLOSE HERMETICALLY, check the magnetic gasket of
the doors.
• LEVEL THE REFRIGERATOR, remove the wooden bases and adjust the
leveling screws (figure 1).
• DO NOT OVERLOAD THE REFRIGERATOR, the circulation of cold air will
be deficient.
• Set the TEMPERATURE control knob to MED (medium cold) and wait at least
24 hours before making a new temperature change.
THE REFRIGERATOR WORKS FOR EXTENDED PERIODS
• Check that the CONDENSER IS FREE OF DUST AND LINT (figure 1)
• AVOID OPENING THE DOOR CONTINUOUSLY or for prolonged periods.
• DO NOT STORE HOT FOODS and keep them covered.
IF YOU HEAR STRANGE SOUNDS
•
Check that there are NO OBJECTS OVER OR BEHIND THE REFRIGERTOR.
• The COMPRESSOR DOES NOT WORK PROPERLY, it may be that a low
voltage is present, verify the intensity of the light, if it is low this indicates that
it has a low voltage, speak to your company of light to correct the power supply
(figure 1).
Before calling the technician
MAGNETIC GASKET
LEVELING SCREWS
CONDENSER
COMPRESSOR
IF AFTER FOLLOWING
THESE INSTRUCTIONS,
THE REFRIGERATION IS
MALFUNCTIONING, PLEASE
CONTACT OUR TECHNICAL
SUPPORT CENTER
Figure 1
Procedimiento para limpieza de puertas y gabinetes con mancha de oxido Importante:
Mantén el refrigerador en un ambiente seco. Al haber acumulación de humedad, el metal
se oxida y se produce herrumbre.
Método de limpieza manual
1. Humedezca una
esponja en agua
con detergente.
2. Use la ƐƵƉĞƌĮĐŝĞ
suave de la esponja
para frotar sobre la
mancha de oxido.
El frote debe ser
en el mismo
Cuidado de su refrigerador
3. Use la ƐƵƉĞƌĮĐŝĞ
dura para frotar
sobre la mancha de
oxido. El frote debe
ser en el mismo
4. Enjuague la
esponja con agua
simple hasta eliminar
el detergente.
. de R.L. de C.V
..
W11347727 Rev. A STM W11202260 Rev. C
MX
AS8950G
1. Garantizar que la pestaña de la moldura este posicionada
para arriba, de acuerdo con la image.
4.
Accesorio de alambrón
ĐĐĞƐŽƌŝŽƷƟůLJƉƌĄĐƟĐŽ
para acomodar productos
ĞŶϮĂůƚƵƌĂƐĚŝƐƟŶƚĂƐ
ENGLISH - 4 ESPAÑOL - 1
MANUAL W11347727 - W11354967.indd 1-2MANUAL W11347727 - W11354967.indd 1-2 24/04/19 15:1124/04/19 15:11
Your refrigerator is equipped with an electric
cord provided with a 3-terminal grounding
plug. To reduce the possibility of electric shock
to a minimum, the cord must be connected to
an electrical grounded wall outlet for 3-prong
plugs. The installation must be grounded in
accordance with the National Electric Code
and all local codes and regulations.
e
W11354967 Rev. A
This manual contains useful information, please read it carefully.
Manufactured by:
Industrias Acros Whirlpool
Address: Carretera Panamericana km. 280, Celaya Gto. Tel: 461 618 55 00
This use and care guide is applicable for the following models:
STM W11354974 Rev. A
Use and Care
Guide MX
AS7508F
AS7608F AS7518F
AS7818A AS8518F
AS8818A
AS8950G
Nominal current
Electrical frequency
Voltage
General dimensions
Height
Wide
Depth
Models
1.6 A 1.6 A
60 Hz 60 Hz
127 V~ 127 V~
1193 mm 1343 mm
504 mm 504 mm
560 mm 560 mm
Technical features
In order to reduce the risk of fire, electric
shock or personal injury when using your
refrigerator, follow these basic precautions:
• Read all the instructions carefully before using your refrigerator.
• Leaving a refrigerator abandoned can cause that someone may get
stuck in it while playing around and suffocate.
• If you are planning on changing your refrigerator, please do it in a safe
way for everyone.
• We recommend removing the refrigerator doors of your old unit at
disposal or at least, secure the doors with a resistant rope.
• Never leave the refrigerator unattended for unexperienced children to
play with it or walk in the refrigerator.
• Never clean the refrigerator parts with flammable liquids; the fumes may
cause fire or explosions.
• This appliance is not intended for use by persons (including children
whose physical, sensory or mental abilities are different or reduced, or
lack experience or knowledge, unless such persons receive supervision
or training for the operation of the device by a person responsible for your
safety.
• Do not use extensions or adapters without an electrical ground terminal.
• Children must be supervised around the refrigerator.
Make sure the refrigerator is not used as a toy.
FOR YOUR SAFETY
• Do not store gasoline or any other flammable gases around this or any other
kitchen appliance. Fumes may cause fire or explosions.
• If the electrical cord is damaged, this must be replaced by the manufacturer,
authorized repair service technician or by someone qualified. Avoid risks.
• This device is intended for use in domestic and similar applications, such as:
a) Kitchen areas for personnel working in stores, offices and other work
environments;
b) Farms, hotels, motels and other work environments;
c) In bed and breakfast type environments;
d) For the preparation of food and similar commercial applications.
KEEP THESE INSTRUCTIONS
Risk of Electrical Shock
This appliance must be connected to an electrical ground.
Do NOT modify the electrical cord. If the electrical plug
doesn’t fit, have a qualified electrician to install a proper
electrical outlet on the wall.
Do NOT use a cord extension for this refrigerator.
Contact a qualified electrician if you have doubts about the
electrical grounding of the refrigerator.
Not following these precautions correctly may cause injury
or even death.
Important Safety Instructions
Instructions to connect to ground
Electrical grounded wall
outlet for 3-prong plugs
Electrical plug with
3 terminals
Electrical
cord
Electrical ground
terminal
• Do not operate the refrigerator in a room where the temperature may be
below 13 °C (55 °F).
• Keep the refrigerator away from outdoor weather.
• Plug the refrigerator only in an electrical grounded wall outlet. Make sure
power supply is within the accepted standards.
• Do not store food in the refrigerator before allowing some time for the
refrigerator to cool.
• Only use the refrigerator as it’s been specified in this guide.
• Schedule maintenance for your refrigerator.
• This refrigerator is intended for domestic use only.
Follow these steps before turning on your new refrigerator:
1. Remove all accessories and shelves from inside.
2. Place the refrigerator in a space leaving clearance space
around: 2 to 3 cm clearance space on the sides, 10 cm on the
back and 5 to 10 cm on top. Keep the refrigerator away from
heat sources such as stoves, ovens, heaters or sun light.
3. To level the refrigerator, turn the leveling screws that are on
the lower front part, adjust them so that the refrigerator is
slightly tilted backwards. In this way the door will close itself.
4. Let the refrigerator stand for 2 to 3 hours before connecting to
a power supply, this will allow the gas and oil to settle before
starting the cooling process.
5. Place the temperature control in the middle position.
Let the refrigerator run for at least 24 hours to reach an
adequate temperature.
The voltage required for its operation is 127 V~ at a nominal
frequency of 60 Hz. Never install any other device at the same
contact as it may cause voltage variation.
Temperature control
The cooling level of the
refrigerator is selected by
moving the temperature control,
depending on the quality of the food inside the
refrigerator. You can select from moderate temperatures (Min/1)
to extreme cold (Max/3) according to the cold conditions you want.
Meat tray (some models)
You can store foods that require temperatures close to
freezing, such as cold meats.
This tray also has the function of collecting the water that is
generated when thawing your refrigerator.
Crisper drawer
The drawer for vegetables and fruits is designed to preserve the freshness of
fruits and vegetables.
Shelf extension accessory
This is a useful and practical accessory to store products
in 2 different heights
Recommendations before use
How to install the refrigerator
How to use the refrigerator
Semi-automatic
thaw button
Temperature
control
Figure 1
1. Unplug the refrigerator or disconnect power supply.
2. Replace the light bulb using another one with of
the same size and power (15 W).
3. Plug refrigerator o reconnect power supply.
How to replace the light bulb
Temperature control
Semi-automatic thaw (some models)
The refrigerator has a semi-automatic defrosting system and
works by simply pressing the automatic defrosting button (figure
1) periodically (minimum recommended once per month), so you
will not accumulate frost, so you will not have to remove all the
food to thaw the refrigerator.
How to thaw your refrigerator
Install properly
Solo utilizar agua potable para llenar el tanque
MUY IMPORTANTE
ES RESPONSABILIDAD DEL USUARIO VERIFICAR LA SIGUIENTE INFORMACIÓN ANTES DE LLAMAR AL TÉCNICO:
Si usted siguió correctamente las instrucciones del manual de instalación, uso y cuidado, y tiene preguntas sobre el
funcionamiento del refrigerador, esta guía le ofrece soluciones a problemas que puede detectar y corregir en su hogar.
SI EL REFRIGERADOR NO FUNCIONA
•Conecte directa y correctamente la clavija, NO USE EXTENSIONES.
•Revise EL CONTACTO ELÉCTRICO, PODRÍA ESTAR DAÑADO, conecte otro aparato y pruebe si funciona.
•Evite poner a funcionar varios aparatos a la vez; LA INSTALACIÓN ELÉCTRICA SE SOBRECARGA.
•Asegúrese de que NO ESTÉ JUNTO A UNA FUENTE DE CALOR como horno, estufa o luz directa del sol.
•LAS PUERTAS DEBEN CERRAR HERMÉTICAMENTE, revise el empaque magnético de las puertas.
•NIVELE EL REFRIGERADOR, retire las bases de madera y ajuste los tornillos niveladores (FIGURA 1).
•Coloque la perilla de control de TEMPERATURA EN MED (frío medio) y espere por lo menos 24 horas antes de hacer un
nuevo cambio de temperatura.
NOTA QUE EL REFRIGERADOR TRABAJA POR PERIODOS PROLONGADOS
•EVITE ABRIR CONTINUAMENTE LA PUERTA o por periodos prolongados.
•NO INTRODUZCA ALIMENTOS CALIENTES y manténgalos tapados.
SI ESCUCHA SONIDOS EXTRAÑOS
•Revise que NO HAYA OBJETOS SOBRE O DETRÁS DEL REFRIGERADOR.
de la luz, si es baja esto nos indica que tiene un bajo voltaje, hable a su compañía de luz para que corrijan el suministro de
energía (FIGURA 1).
FIGURA 1
CONDEN
-SADOR
EMPAQUE
MAGNÉTICO
TORNILLOS
NIVELADORES
COMPRESOR
SI DESPUÉS DE SEGUIR LAS
INSTRUCCIONES
DE ESTA GUÍA, EL REFRIGERADOR
NO FUNCIONA LLAME A
LOS CENTROS DE SERVICIO
INDICADOS
Antes de llamar al técnico
5. Humedecer la
ĮďƌĂen agua pura.
ϲ^ĞĐĂƌďŝĞŶůĂ
ƐƵƉĞƌĮĐŝĞde la
ƵŶŝĚĂĚĐŽŶůĂ
ĞƐƉŽŶũĂ
7. Use unaƉŝĞnjĂĚĞ
ƚĞůĂƐĞĐĂLJĨƌŽƚĞ
ƐŽďƌĞůĂƐƵƉĞƌĮĐŝĞ
húmeda. Se
ƌĞĐŽŵŝĞŶĚa
ƵŶůŝŵƉŝĂĚŽƌĚĞ
ĂĐĞƌŽŝŶŽdžŝĚĂďůĞ
ƉĂƌĂƵŶĂĐĂďĂĚŽ
ďƌŝůůĂŶƚĞ
A. SuƉĞƌĮĐŝĞdura
B. ^ƵƉĞƌĮĐŝĞsuave
,ĞƌƌĂŵŝĞŶƚĂs ŶĞĐĞƐĂƌŝĂƐ
•WŝĞnjĂĚĞ tela seca
•ƐƉŽŶũa de ƐƵƉĞƌĮĐŝĞsuave/dura
ENGLISH - 3ESPAÑOL - 2
MANUAL W11347727 - W11354967.indd 3-4MANUAL W11347727 - W11354967.indd 3-4 24/04/19 15:1124/04/19 15:11
This manual suits for next models
6
Other Acros Refrigerator manuals
