AR-R5800 System
System Installation Guide
5

Revision: 1.0
1 Introduction to AR-R5800
AR-R5800 series is a 1U height, rack-mounted platform for networking appliance, e.g. VPN,
SSL, UTM or firewall. With Intel advanced Core 2 Quad / Duo / Pentium / Celeron CPU,
AR-R5800 is a powerful platform to satisfy different applications. By eight
10/100/1000Mbps LANs, the AR-R5800 is sufficient for the small to middle size business
security solution.
AR-R5800 series can be equipped with 2 x HDD for RAID 0/1 redundancy. Customers
don’t need to worry about data lost due to HDD defected problem. With LCM module,
users can easily understand system status. BIOS, GPIO and Jumper can control LAN
bypass feature. It provides flexibility to access Internet by user setting. It also has
standard PCIe x 8 slot. Customers can purchase suitable add-on card to meet their
appliance.
Key features:
1. Support Intel Core 2 Quad or Core 2 Duo or Pentium or Celeron CPU
2. Intel G41 + ICH7R Chipset to support RAID 0/1 redundancy
3. DDRIII DIMM x 2, up to 4GB memory
4. Intel 82574L 10/100/1000Mbps x 6 + 82541PI 10/100/1000Mbps x 2
5. Two pairs LAN ports support bypass feature (LAN 1/2 + LAN 3/4)
6. LAN bypass can be controlled by BIOS, GPIO and Jumper
7. CF socket, 2.5” HDD x 2, SATA II interface x 2
8. Console, VGA (pinhead), USB 2.0 x 4 (2 x connectors, 2 x pin head)
9. Support boot from LAN, console redirection
10. Support standard PCIe x 8 slot for feature expansion
11. LCM module to provide user-friendly interface
12. Standard 1U rack mount size
1.1 Specifications
Item Description
System AR-R5800
CPU Board AR-B5800
System Dimensions 442.4x371.5x44(mm)
6

Revision: 1.0
1.2 Packing List
Description Quantity
AR-R5800 system 1
Console Cable(RJ45) 1
Quick user manual 1
CD with Driver and Manual 1
SATA cable 2
USA or Europe or Japan or UK power
cord
1
Rack bracket 2
Screw for bracket (for Rack + HDD
bracket)
14
Power cord hook 1
1.3 System Dissection
(1)Dimensions
7

Revision: 1.0
(2)Front Panel
LCM Module Console
USB*2
LEDs
Lan*8Keypad
Reset
(3)Back Panel
PCIe x 8 slot Power Inlet
8

Revision: 1.0
(4)System Configuration
9

Revision: 1.0
Item Description Quantity
1 TOP COVER 1
2 POWER SUPPLY 1
3 POWER BRACKET 1
4 HDD BRACKET 1
5 BOTTOM BASE 1
6 1U EAR BRACKET 2
7 MEMBRANE 1
8 AR-B5800 1
9 SHEET FLOW 1
10 FAN 2
11 CPU SINK 1
12 CPU SINK BKT 2
13 INTERFACE BKT 1
14 FAN 2
15 RISER CAR & BKT 1
10

Revision: 1.0
2 Procedures of Assembly/Disassembly
2.1 2.5” HDD Installation
The following instructions will guide you to install 2.5” HDD step-by-step.
1. Unfasten 2 screws of chassis top cover and take off it.
2. Release HDD bracket by unfastening 4 screws.
11

Revision: 1.0
3. Take out HDD screws from packing bag.
4. Fix HDD with HDD bracket by 4 screws.
12

Revision: 1.0
5. Fix HDD with HDD bracket by 4 screws.
13

Revision: 1.0
6. Plug SATA power cable into motherboard.
7. The SATA power cable MUST go through below M/B power cable, please follow
below photo.
14

Revision: 1.0
8. Connect SATA cable and SATA power cable with HDD module.
9. Assemble top cover back by fastening the 2 screws.
15

Revision: 1.0
2.2 CF Card Installation
1. Open the top cover (the same as above steps).
2. Push CF card into CF socket.
3. Finish the CF card installation.
16

Revision: 1.0
2.3 Power Cord Hook Installation
1. Take out the hook from packing bag.
2. Install the hook from right side firstly.
3. Then install the hook by left side.
17

Revision: 1.0
2.4 PCIe Card Installation
1. Unfasten two screws of PCIe bracket and then take out the PCIe card bracket.
2. Release the PCIe dummy bracket.
18

Revision: 1.0
3. Fix the PCIe card with PCIe bracket.
4. Plug the PCIe module into PCIe slot following below direction.
19

Revision: 1.0
5. Fasten the 2 screws in order to firm the PCIe module.
