ACS Ventus User manual

Ventus
INSTRUCTION
MANUAL

1:
AMBIENT&SPRESSO
Dear Customer,
We thank you for your purchase of this machine.
The espresso machine Ventus was born from our passion for coffee and for sailing and is also a
tribute to the city of Naples, where it has been designed and will be built. Neapolitans, who still loves
so much the extraction of espresso by a lever group.
So, the aim was to create a machine to prepare espresso in the most traditional way: the lever
extraction, which in the silence of its operation remember the silence of the gait of a sailing boat.
GENERAL RULES
HOW TO USE THE MACHINE
Please read carefully the instruction manual and warranty limitations. The machine must be connected
to a regular power outlet provided grounding. The machine must be kept clean by frequently washing
the grill, drip tray, filter holder with its filters, the steam wand and outlet holes and empting the boiler.
WE RECOMMEND:
1 to get the best performance, leave the filter underneath the group and keep the porter-filter
empty and clean.
2 at least once a week decalcify the boiler empting it by unscrewing the nut at the bottom of the
boiler (see pictures in last page).
IMPORTANT SAFETY PRECAUTIONS
Using electrical appliances should always be down as follows security measures.
USING YOUR MACHINE:
- This appliance must be used only for professional and/or domestic use preparing espresso coffee
and related drinks. Any other use is considered improper and therefore dangerous.
- Disconnect the power cord from the power when not in use.
- Pay attention to the hot surfaces.
- This machine is designed to "make espresso coffee": Be careful not burn yourself with water or
steam or improper use of the machine.
- The device should not be used by children.
- The appliance must be used only by adults with mental and physical capacities.
- Use the device only in a closed areas and protected from weather elements.
- To protect against fire, electric shock or injury do not immerse the power cord, plug and the
appliance in water or other liquid.
- Do not use the appliance for purposes other than those provided.
- Do not place the appliance on a gas or electric stove or inside of a hot oven.
- Before unplugging make sure the power button is turned off, otherwise the power light is off.
- Using accessories not recommended by the manufacturer may cause fire, electric shock, or injury to
persons.
- Do not let cord hang over edge of table or counter.
INSTALLING THE APPLIANCE
- Read these instructions carefully.
- Never install the machine in an environment that can reach a temperature of less than or equal to 0
°C (if the water freezes, the device may be damaged).
- Check that the main voltage is the same as indicated on the label of the machine. Only connect the
machine to an outlet with a minimum of 9 Amp when powered at 230 Vac and 17 Amp at 120 Vac

2:
AMBIENT&SPRESSO
when powered and equipped with efficient earthing.- In case of incompatibility between the plug and
the appliance, replace the socket with another suitable type by a qualified person.
- Place the appliance on a stable work surface.
CLEANING
- Disconnect the power cord when you clean.
- Before unplugging make sure the power button is turned off, or not illuminated.
- Do not expose the device to heavy jets of water or diving partial or total.
- Let the appliance cool before cleaning.
- Clean the body and accessories with a damp cloth and then dry it by a non-abrasive product.
Detergents are not recommended.
MALFUNCTION OF THE MACHINE
- Do not use an appliance if the power cord or plug is damaged or if the unit shows signs of
malfunctioning or if it has been some damage. Return the appliance to the nearest authorized dealer
for checks or repairs.
If the power cord is damaged it must be replaced by the manufacturer or an authorized service center.
- In case of failure or malfunctioning, turn it off and do not tamper with it. For any repairs, contact a
Service Centre authorized by the manufacturer and request the use of original spare parts. The non-
respect of the content may compromise the safety of the device and void the warranty.
IMPROPER USE OF THE MACHINE
- This device must be used only for professional and/or domestic use. Any other use is considered
improper and therefore dangerous.
- The manufacturer cannot be held responsible for any accidents caused by lack of or non-compliance
with the laws of the plant grounding.
- The manufacturer cannot be held responsible for any damage caused by improper, incorrect or
unreasonable use.
INSTALLATION AND SWITCHING THE APPLIANCE
Before connecting the machine to the power supply, carefully read the safety instructions in the
previous chapter.
Make sure that the machine is disconnected from the main power.
Connect the machine electrically.
We recommend keeping always the original packaging to send the machine to the service center for
repair
WARNING
When the machine is in operation, the contact with the coffee group, the steam, water tap and the
metal part of the filter holder can cause burns.
TURN ON AND OFF
To turn on the machine, press the green button underneath the central control panel of the machine
(see pictures in last page). The green light indicates that the machine is powered. The red light is on
when element is heating and vice versa.
Turning off the red light next to the manometers also indicates that the machine’s boiler has reached
its set operating temperature and pressure.
The manometer shows the boiler’s pressure level.
The machine is equipped by an electronic water level probe, which will provide to keep the boiler’s
water level constant while operating.

3:
AMBIENT&SPRESSO
PROBLEMS AND SOLUTIONS
To turn off the machine, press the button and make sure the green light on the front panel is off, you
should not unplug the cord from the power outlet when the machine is on.

4:
AMBIENT&SPRESSO
COFFEE PREPARATION
VENTUS BASIC OPERATIONAL STEP
HOW TO BREW COFFEE BY A VENTUS
1. Fill up the filter basket with coffee and press it properly.
2. Put the basket underneath the group and pull firmly to the right, making sure that it is in the
right position at about 6 hour.
3. Pull the lever down, holding it firmly always in your hand. Wait 6-9 sec. or until the spouts starts
to drop.
4. Release the lever slowly up and leave it until the cups has been filled according to you need.
HOW TO RELEASE THE LEVER BEFORE THE EXTRACTION IS ENDED (LEVER REACH THE
UPPER POSITION)
1. Hold with one hand the filter holder.
2. With the other hand pull down the lever so that the spout stops to drop
3. Slowly release the filter holder until the remaining pressure will drop down.
DECALCIFICATION
For a proper maintenance, the machine must be descaled periodically. This is according to use and
the quality of the water. For a basis descale we recommend to empty once a week the boiler by
removing the nut under the boiler.
CLEANING AND MAINTENANCE
For the correct operation and a high standard of quality of the drink is recommended that you regularly
and carefully clean the machine.
Operations to be performed with the machine cold and disconnected:
Clean the water tank.
Clean the filter holder and the filter with hot water and detergent (at the end check that the holes in the
filter are free).
Cleaning the brew group of any residual powder coffee by brushing gently its bottom.
ADVICES
To enjoy a high quality espresso, remember to:
- Use water with a low calcium content to reduce deposits inside the machine.
- Use pre-warmed cups.
WARNING
- Do not clean the machine with aggressive cleaning agents (methanol, methyl chloride, acetone,
aromatic hydrocarbons) they may damage the surfaces
- The cleaning and maintenance of the machine must always be carried out with the plug
disconnected from the mains wall socket.

5:
AMBIENT&SPRESSO
TECHNICAL FEATURES
Frame material : 304 Stainless steel
Boiler material: 316 Stainless steel
Tank : 5 liters
Drain solenoid
Net Weight : 40 kg
Voltage : 230 V, 50 Hz (EU), 120 V, 60 Hz (USA)
Power : 9 Amp (EU); 17 Amp (USA)
The manufacturer reserves the right to make changes or improvements without notice.
WARRANTY LIMITATIONS
The warranty does not cover damage caused by:
- Failures caused by lime or a non-periodic decalcification
- Any failure caused by operation with voltages other than those indicated on the label
- Damage caused by improper use or contrary to the instructions
- Damage caused by changes internally are also not covered by warranty, labor and parts cost on
machines previously manipulated by unauthorized service centers that will be totally chargeable to the
customer.
Finally:
- Failure to observe these instructions may cause damage to the body not covered by warranty.
Warning:
- We recommend that you keep the original packaging to ship the machine to the service center for
repair
- Any damage caused by transport without adequate packaging will not be covered by warranty

6:
AMBIENT&SPRESSO
DICHIARAZIONE DI CONFORMITÀ CE - DECLARATION OF CE CONFORMITY
DÉCLARATION DE CONFORMITÉ CE - CE KONFORMITÄTSERKLÄRUNG - DECLARAÇÃO DE
CONFORMIDADE CE
EG CONFORMITEITSVERKLARING - CE-OVERENSSTEMMELSESERKLÆRING
M & V S.r.l.
Dichiara sotto la propria responsabilità che la macchina in seguito denominata, in base alla sua
progettazione, costruzione e per l'utilizzo, è conforme alle disposizioni
delle direttive CE in materia di sicurezza e salute.
Declares under its sole responsibility that the following appliance conforms to the CE directive health
and safety provisions as regards design, construction and use thereof.
Déclare sous sa propre responsabilité que la machine ci-après spécifiée, sur la base de sa
conception, construction et pour l'utilisation prévue est conforme aux dispositions des directives CE en
matière de sécurité et de santé.
Erklärt unter eigener Verantwortung, dass die folgend genannte Maschine, in Hinsicht auf die
Planung, den Bau und die Verwendung, mit den CE Vorschriften für Sicherheit und Gesundheit
übereinstimmt.
Declara bajo su propia responsabilidad que la máquina que se indica más abajo, teniendo en cuenta
cómo se ha proyectado, cómo se ha construido y para qué se usará, respeta las disposiciones de las
directivas CE en materia de seguridad y salud.
Declara, sob a própria responsabilidade, que a máquina indicada a seguir, em base ao próprio
projecto, fabricação e utilização, está em conformidade com as disposições das directivas da CE
sobre a segurança e a saúde.
Verklaart onder eigen verantwoordelijkheid dat het volgende toestel, voor wat het ontwerp, de bouw
en het gebruik betreft, conform de EG richtlijnen is voor veiligheid
en gezondheid.
Erklærer at maskinen, som nævnt herunder, er tilpasset EU-direktiverne for sikkerhed og sundhed på
design-, konstruktions- og anvendelsesområdet.

7:
AMBIENT&SPRESSO
Tipo di macchina - Machine type - Type de machine - Maschinenart - Tipo de máquina - Tipo de
máquina - Type toestel - Maskintype
VENTUS
Direttive specifiche - Specific directives - Directives spécifiques - Besondere Vorschriften - Directivas
específicas - Directivas específicas - Specifieke richtlijnen - Specifikke direktiver
2002/95/CE (RoHS) 89/336/CEE - 2006/95/CE - 2002/96/CE (Raee)
Norme applicate - Applicable standards - Normes appliquées - Angewandte Vorschriften - Normas
aplicadas - Normas aplicadas - Toegepaste normen - Anvendte standarder
EN 61000-3-2 - EN 61000-3-3 - EN 55014-1+A1+A2 - EN 55014-2 + A1 - EN 50366 - EN 60335 -2-15
- EC 1935/2004
EN 61000-4-2+A1+A2 - EN 61000-4-4+A1+A2 - EN 61000-4-5+A1 - EN 61000-4-6+A1 - EN 61000-4-
11+A1
………………………………………………………………….
Direzione Tecnica - Technical Management - Direction Tecnique - Technische Leitung
Dirección Técnica - Direcção Técnica - Technische directie - Teknisk ledelse
La presente dichiarazione perde la sua validità se l'apparecchio viene modificato senza la nostra
espressa autorizzazione
This declaration shall cease to be valid if the appliance is modified without out explicit authorisation
La présente déclaration perd sa validité si l'appareil est modifié sans notre autorisation expresse
Die folgende Erklärung ist nicht gültig, wenn die Maschine ohne ausdrückliche Genehmigung von
illycaffè verändert wird
La presente declaración no tendrá validez si se modifica el aparato sin que nosotros lo hayamos
autorizado expresamente
A presente declaração perde a sua validade se o aparelho for modificado sem uma nossa autorização
expressa
Deze verklaring is niet meer geldig wanneer er wijzigingen worden uitgevoerd op de machine die niet
geautoriseerd werden door
Denne erklæring ophører med at gælde, hvis maskinen ændres uden vores udtrykkelige accept
M & V S.r.l.- Via Malatesta ,39 B
• 80049 Somma Vesuviuana (NA) Italy

8:
AMBIENT&SPRESSO
Red light :boiler’s element on/off
Green light: machine on/off
Monometer: boiler’s pressure
Front Control Pannel
Button: on/off machine
Bottom Control Pannel
Plug: connection to power
Water: in let water connection
Back Control Pannel
