ActionTec ECB6000 User manual

Coaxial-to-Ethernet
Conversion Kit
User Guide
MoCA Network Adapter
Model # ECB6000
0535-0002-000 Rev1

Table of Contents
Table of Contents 1
Getting Started 3
Introduction 3
Package Contents 4
Requirements 4
Features 4
Connecting the Adapters 5
Connecting the First Adapter 5
Connecting Additional Adapters 7
Specications 9
Notices 11
Warranty 11
Important Safety Instructions 12
1

Network Adapter
FCC Class B Equipment 13
Contact Information 14
EU CE Declaration of Conformity 15
Technical Support 15
2

Getting Started
Introduction
Congratulations on the purchase of a MoCA Network Adapter. e
Adapter is a exible solution for extending a home network. By
leveraging the ubiquity of coaxial cabling within the modern home, the
Adapter allows the set up of an Ethernet Internet port anywhere a coaxial
connection is available.
is user manual explains the procedures needed to connect the Adapter.!
3

MoCA Network Adapter
Package Contents
• MoCA Network Adapter
• Coaxial cable
• Power adapter
• Quick Start Guide
• Wall-mount template
• Ethernet cable
Requirements
• Available coaxial port in installation areas
• Available electrical wall socket in installation areas
Features
• Gigabit Ethernet port
• Power, Coax, and Ethernet LEDs:
- Power LED: glows solid green when Adapter is powered up.
- Coax LED: glows solid green with connection on Coax port.
- Ethernet LEDs (2): located on upper right and lecorners of
Ethernet port; leLED glows green on connection; right LED
blinks amber when data is transferred across port.
!
!
4

Connecting the Adapters
Connecting the MoCA Adapters is a relatively simple process. First,
connect one Adapter to the broadband modem/router via Ethernet, and
then to the coaxial network. en, additional Adapters can be installed
throughout the home or oce at any location Ethernet Internet access is
needed, and an available coaxial port is available.
Connecting the First Adapter
e rst Adapter must be connected to the broadband modem/router,
and then to the coaxial network. is Adapter takes the Internet signal
from the modem or router and delivers it to the coaxial network.
To connect the rst Adapter:
1. Connect a coaxial cable into a coaxial wall port near the modem/
router.
2. Connect the other end of the coaxial cable installed in step 1 to the
Coax port on the side of the Adapter.
3. Connect one end of an Ethernet cable into the Ethernet port of the
modem/router.
4. Connect the other end of the Ethernet cable into the Ethernet port on
the side of the Adapter.
5. Plug the provided power adapter into the Power port on the side of
the Adapter.
!
5

MoCA Network Adapter
6. Plug the other end of the power adapter (external, 5V DC, 2A, made
by APD, model #WA-10P05FU) into an electrical outlet.
When complete, the setup should look similar to the gure below:
e Internet signal is now being delivered across the coaxial network.!
6

MoCA Network Adapter
Connecting Additional Adapters
If necessary, additional Adapters can be placed in locations around the
home or oce that need an Ethernet Internet connection, but at present
only have a coaxial port.
To connect additional Adapters:
1. Connect a coaxial cable into a coaxial wall port near the location an
Ethernet port is needed.
2. Connect the other end of the coaxial cable installed in step 1 to the
Coax port on the side of the Adapter.
3. Connect one end of an Ethernet cable into the Ethernet port of the
device to connect to the Internet.
4. Connect the other end of the Ethernet cable into the Ethernet port on
the side of the Adapter.
5. Plug the provided power adapter into the Power port on the side of
the Adapter.
!
7

MoCA Network Adapter
6. Plug the other end of the power adapter (external, 5V DC, 2A, made
by APD, model #WA-10P05FU) into an electrical outlet.
When complete, the setup should look similar to the gure below:
e device is now connected to the Internet.!
8

MoCA Network Adapter
Specications
Model Number
ECB6000
IP
LAN MoCA
LAN Ethernet Port 10/100/1000 (1)
LAN Connections
LAN MoCA frequency: 1125 MHz - 1425 MHz (6 channel)
LED Indicators
Power, Coax
Power
External, 5V DC, 2A"
Made by APD, model #WA-10P05FU
Regulatory
FCC part 15, UL-60959-1
!
9

MoCA Network Adapter
Environmental
Operating temperature - 0º C to 40º C (32ºF to 104ºF)
Storage temperature - 0ºC to 70ºC (32ºF to 158ºF)
Operating humidity - 10% to 85% non-condensing
Storage humidity - 5% to 90% non-condensing
Note: Specications are subject to change without notice.
!
10

Notices
Warranty
is product has a one-year Limited Hardware Warranty and 90-day free
soware updates from date of purchase.
Local Law
is Limited Warranty Statement gives the customer specic legal rights.
e customer may also have other rights which vary from state to state in
the United States, from province to province in Canada, and from
country to country elsewhere in the world.
To the extent that this Limited Warranty Statement is inconsistent with
local law, this Statement shall be deemed modied to be consistent with
such local law. Under such local law, certain disclaimers and limitations
of this Warranty Statement may not apply to the customer.
Go to http://www.actiontec.com/products/warranty.php for more
information.
!
11

MoCA Network Adapter
Important Safety Instructions
Basic safety precautions should always be followed to reduce the risk of
re, electrical shock, and personal injury, including the following:
• Do not use this product near water – for example, near a bathtub,
kitchen sink, laundry tub, or swimming pool, or in a wet basement;
only clean with dry cloth.
• Do not block any ventilation openings. Install in accordance with the
manufacturer's instructions. Do not install near any heat sources such
as radiators, heat registers, stoves, or other apparatus including
ampliers that produce heat.
• Do not use the telephone to report a gas leak in the vicinity of the
leak;
• Use only the power cord and batteries indicated in this manual if
applicable. Note: you may need to reword for batteries or adapters.
• Do not dispose of batteries in re, as they may explode – check with
local codes for possible special disposal instructions if applicable.
Coaxial Cable
If applicable, the coaxial cable screen shield needs to be connected to the
Earth at the building entrance per ANSI/NFPA 70, the National Electrical
Code (NEC), in particular Section 820.93, “Grounding of Outer
Conductive Shield of a Coaxial Cable,” or in accordance with local
regulation.
!
12

MoCA Network Adapter
FCC Class B Equipment
is equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. ese limits
are designed to provide reasonable protection against harmful
interference in a residential installation. is equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment oand on, the user is encouraged
to try and correct the interference by implementing one or more of the
following measures:
• Reorient or relocate the device;
• Increase the separation between the equipment and receiver;
• Connect the equipment to an outlet on a circuit dierent from that to
which the receiver is connected; (applicable only to powerline
products)
• Consult the dealer or an experience radio or television technician for
help.
Modications
e FCC requires the user to be notied that any changes or
modications made to this device that are not expressly approved by
Actiontec Electronics, Inc, may void the user’s authority to operate the
equipment.
13

MoCA Network Adapter
Declaration of Conformity for Products Marked With
the FCC logo or Industry Canada (IC)– North
America Only
is device complies with Part 15 of the FCC Rules and with Industry
Canada license-exempt RSS standard(s). Operation is subject to the
following two conditions:
1. is device may not cause harmful interference;
2. is device must accept any interference received, including
interference that may cause undesired operation of the device.
Contact Information
For questions regarding your product or the FCC/Industry Canada
declaration, contact:
Actiontec Electronics, Inc
760 North Mary Avenue, Sunnyvale, CA 94085, United States
Tel: [phone] Fax: [phone]!
14

MoCA Network Adapter
EU CE Declaration of Conformity
To obtain the complete Declaration of Conformity form in socopy, go to
the Actiontec Electronics Declarations of Conformity EU/EEA website at
http://international.actiontec.com/support/doc
e symbol below is placed in accordance with the European Union
Directive 2002/96 on the Waste Electrical and Electronic Equipment (the
WEEE Directive). If disposed of within the European Union, this product
should be treated and recycled in accordance with the laws of your
jurisdiction implementing the WEEE Directive.
Technical Support
Go to www.actiontec.com/support for product support, updates, and
more information including:
• Firmware updates
• Troubleshooting
• Registration
• FAQs
Technical Support Phone Number
United States: 1-888-436-0657
15
