ACU-RITE 200S READOUTS User manual

200S R EADOUTS
REFERENCE MANUAL

200S i
200S Key Layout
200S Soft keys
There are multiple pages of soft key functions to select from the
operating modes. Use the LEFT/RIGHT arrow keys -4- to cursor
through each page. The page indicator in the Status Bar will show the
page orientation. The darkened page indicates the page you are
currently on.
1Display Area
2Soft keys
3Power Indicator light
4Arrow Keys: Use the UP/DOWN keys to adjust the
screen contrast.
5Axis Keys
6Numeric Keypad
7ENTER key
8CLEAR key
1Page Indicator
2Set Zero Indicator
Soft Key function (Page 1) Soft key
Opens on-screen help instructions.
Opens the Tool Table. Page 18 for Milling, and
page 36 for Turning.
Switches display between operating modes
Actual Value (Absolute) / Distance-to-Go
(incremental). See page 10.
Toggles between Set / Zero functions. Used
with individual axis keys (page 16).
Soft Key function (Page 2) Soft key
Opens the Datum form to set the datum for
each axis (page 20).
Opens the Preset form. This form is used to set
a nominal position. This is a Distance-To-Go
(Incremental) function (page 23).
Used to divide the current position by two. This
function is for Milling applications only
(page 26).
1
1
1
2
1
4
1
5
1
6
1
7
1
8
3
1
1
1
2

ii
Press to select the Circle Pattern, Linear
Pattern, Incline Mill, or Arc Mill table. This
function is for Milling applications only
(page 28).
This soft key toggles between radius and
diameter displays. This function is for Turning
applications only (page 41).
Soft Key function (Page 3) Soft key
Opens the Job Setup menu and provides
access to the Installation Setup soft key
(page 11).
Press when ready to identify a reference mark
(page 9).
Opens the Calculator functions for standard
math, trigonometry, RPM, and Taper for
Turning functions.
Toggles between inch and millimeter units
(page 11).
Soft Key function (Page 2) Soft key

200S iii
Readout Parameter Access Code
An access code must be entered before machine-related installation
parameters can be set or changed. This prevents inadvertent
adjustments to the installation setup parameters.
Access to Machine Parameter Operations
Refer to the Setup section also.
Begin by pressing the SETUP soft key.
Press the soft key INSTALLATION SETUP.
Press the access code numbers 8891 using the numeric key pad.
Press the ENTER key
The readout is now ready for machine parameter setting operations.
IMPORTANT!
The access code is 8891.
IMPORTANT!
To prevent setup parameters from being changed, remove
this page from the Reference Manual after initially setting
up the readout system. Retain this information in a safe
place for future use.

iv

200S v
Introduction
Software Version
The software version is shown on the initial power up screen.
200S
DRO axis availability.
Symbols within Notes
Every note is marked with a symbol on the left indicating to the
operator the type, and/or potential severity of the note.
200S Fonts
The following shows how soft keys, and hard keys are represented
within the text of this manual:
Soft keys - SETUP soft key
Hard keys - ENTER hard key
This User's Manual covers the functions of the 200S for
both milling, and turning applications. Operational
information is arranged in three sections: General
Operations, Mill Specific Operations, and Turn
Specific Operations.
The 200S DRO is available in two, and three axis form.
The 3 axis 200S DRO is used through out this manual for
illustration, and description of function keys.
General Information
e.g. on the behavior of the 200S.
Warning
e.g. when a special tool is required for a function.
Caution - Risk of electric shock
e.g. when opening a housing.

vi

200S vii
Hassle-Free Warranty
ACU-RITE Companies, Inc. is proud to offer the 3-Year Hassle-Free Warranty for all digital readout systems, vision readout
systems, and precision glass scales. This warranty will cover all of the ACU-RITE repair and replacement costs for any readout
or precision glass scale returned during the three (3) year warranty period. ACU-RITE will repair or replace the damaged
components - regardless of the product’s condition absolutely free, no questions asked. This warranty covers both materials,
and factory labor. In addition, authorized ACU-RITE service representatives will provide service labor (field service) for a period
of one (1) year at no charge. Notice of the claimed defect must be received by ACU-RITE within the warranty period.
This warranty applies only to products and accessories installed and operated in accordance with this reference manual.
ACU-RITE shall have no obligation, with respect to any defect, or other condition caused in whole or part by the customer’s
incorrect use, improper maintenance modification of the equipment, or by the repair, or maintenance of the product by any
person except those deemed qualified by ACU-RITE.
Responsibility for loss of operation, or diminished performance due to conditions beyond ACU-RITE’s control cannot be
accepted by ACU-RITE.
The foregoing warranty obligations are in lieu of all expressed or implied warranties. ACU-RITE Companies, Inc. shall not be
liable under any circumstances for consequential damages.

viii

200S ix
Table of Contents
200S Key Layout........................................................................................................i
200S Soft keys...........................................................................................................i
Readout Parameter Access Code
Access to Machine Parameter Operations ..............................................................iii
Introduction
Software Version ......................................................................................................v
200S DRO axis availability...........................................................................................v
Symbols within Notes...............................................................................................v
200S Fonts................................................................................................................v
Hassle-Free Warranty
3-Year Hassle-Free Warranty.......................................................................................vii
I - 1 Fundamentals of Positioning
Datums .................................................................................................................... 2
Actual Position, Nominal Position, and Distance-To-Go........................................... 2
Absolute Workpiece Positions................................................................................. 3
Incremental workpiece positions............................................................................. 3
Zero Angle Reference Axis ...................................................................................... 4
Reading head position ............................................................................................. 4
Encoder Reference Marks ....................................................................................... 5
I - 2 General Operations for 200S
Screen Layout.......................................................................................................... 6
General Navigation................................................................................................... 7
Power Up................................................................................................................. 7
Reference Mark ....................................................................................................... 8
Working without reference mark........................................................................ 9
Enable/Disable Ref function................................................................................ 9
Operating Modes................................................................................................... 10
Setup .................................................................................................................... 11
Job Setup Parameters ........................................................................................... 11
Units.................................................................................................................. 11
Scale Factor ...................................................................................................... 12
Mirroring a part ................................................................................................. 12
Edge Finder (milling applications only).............................................................. 12
Diameter Axes .................................................................................................. 13

x
Measured Value Output.................................................................................... 13
Near Zero Warning............................................................................................ 13
Status Bar Settings ........................................................................................... 14
Job Clock .......................................................................................................... 14
Remote Switch ................................................................................................. 14
Console Adjustment ......................................................................................... 15
Language .......................................................................................................... 15
Import/Export.................................................................................................... 15
Viewing the main operating screen: ................................................................. 16
Set/Zero Soft Key.............................................................................................. 16
Distance to Go “INC” ....................................................................................... 17
Actual Value mode [abs] ................................................................................... 17
I - 3 Milling Specific Operations
Soft Key Functions................................................................................................. 18
Tool Soft Key .................................................................................................... 18
Tool Table ......................................................................................................... 18
Tool Compensation........................................................................................... 19
Sign for the length difference ΔL ...................................................................... 19
Calling the Tool from the Tool Table ................................................................. 20
Datum Soft Key ................................................................................................ 20
Probing Functions for Datum Setting ............................................................... 20
Probing with a Tool ........................................................................................... 21
Example: Probe workpiece edge and set edge as datum ................................ 22
Presets.............................................................................................................. 23
Absolute Distance Preset ................................................................................. 23
Incremental Distance Preset ............................................................................ 25
1/2 Soft Key ...................................................................................................... 26
Circle, and Linear Patterns..................................................................................... 27
Soft key Functions ............................................................................................ 27
Circle, and Linear Pattern Form ........................................................................ 28
Circle, or Linear Pattern Execution ................................................................... 29
Incline, and Arc Milling........................................................................................... 30
Soft Key Functions............................................................................................ 30
Incline, and Arc Milling...................................................................................... 31
Incline, and Arc Milling form entry.................................................................... 32
Incline Milling.................................................................................................... 32
Arc Milling......................................................................................................... 33
Incline, and Arc Mill Execution.......................................................................... 34

200S xi
I - 4 Turning Specific Operations
Tool Display Icon............................................................................................... 36
Tool Table.......................................................................................................... 36
Setting Tool Offsets.......................................................................................... 36
Datum Setting................................................................................................... 38
Taper Calculator ................................................................................................ 40
Presets.............................................................................................................. 41
Radius/Diameter ............................................................................................... 41
Vectoring........................................................................................................... 42
Z Coupling......................................................................................................... 42
Enabling / Disabling Z0, and Z Coupling........................................................... 43
II - 1 Installation Setup
Installation Setup Parameters................................................................................ 46
Encoder Setup ....................................................................................................... 46
Display Configuration............................................................................................. 48
Error Compensation............................................................................................... 48
Linear Error Compensation ............................................................................... 49
Non-Linear Error Compensation............................................................................. 49
Starting a Non-Linear Error Compensation Table ..................................................... 50
Configuring the Compensation Table................................................................ 50
Exporting the current Compensation Table ...................................................... 51
Importing the current Compensation Table ...................................................... 51
Backlash Compensation ........................................................................................ 51
Serial Port .............................................................................................................. 52
Counter Settings.................................................................................................... 52
Diagnostics ............................................................................................................ 53
Keypad Test ...................................................................................................... 53
Edge Finder Test............................................................................................... 53
Display Test ...................................................................................................... 53
II - 2 RS-232C Serial Communications
Serial port............................................................................................................... 54
II - 3 Installation and Electrical Connections
Installation.............................................................................................................. 55
Electrical requirements ..................................................................................... 55
Environmental................................................................................................... 55
Preventative maintenance ................................................................................ 55

xii
II - 4 I/O Connections
Pin layout for Electronic Edge Finder................................................................ 56
Wiring the Serial communication cable ............................................................ 57
II - 5 Remote Switch Data Output
Data output using external signals.................................................................... 58
Data output using Edge Finder ......................................................................... 60
II - 6 Dimensions
DRO Dimensions ................................................................................................... 63

1
Operating Instructions

2I
I - 1 Fundamentals of Positioning
I - 1 Fundamentals of Positioning
Datums
The workpiece drawing identifies a certain point on the workpiece
(example: “a corner”) as the absolute datum, and perhaps one, or
more other points as relative datums.
The datum setting procedure establishes these points as the origin of
the absolute, or relative coordinate systems. The workpiece, which is
aligned with the machine axes, is moved to a certain position relative
to the tool. The display is set either to zero, or to another appropriate
value (e.g., to compensate for tool radius).
Actual Position, Nominal Position, and
Distance-To-Go
The position of the tool at any given moment is called the ACTUAL
POSITION I, while the position that the tool is to move to is called the
NOMINAL POSITION S. The distance from the nominal position to
the actual position is called the DISTANCE-TO-GO R.

200S 3
I - 1 Fundamentals of Positioning
Absolute Workpiece Positions
Each position on the workpiece is uniquely identified by its
absolute coordinates.
Example: Absolute coordinates of position 1:
X = 20 mm
Y = 10 mm
Z = 15 mm
If you are drilling, or milling a workpiece according to a workpiece
drawing with absolute coordinates, the tool is moving to the value of
the coordinates.
Incremental workpiece positions
A position can also be referenced to the preceding nominal position.
In this case the relative datum is always the last nominal position.
Such coordinates are referred to as incremental coordinates
(increment = increase). They are also called incremental, or chain
dimensions, since the positions are defined as a chain of dimensions.
Incremental coordinates are designated with the prefix I.
Example: Incremental coordinates of position 3referenced
to position 2.
Absolute coordinates of position 2:
X = 10 mm
Y = 5 mm
Z = 20 mm
Incremental coordinates of position 3:
IX = 10 mm
IY = 5 mm
IZ = 20 mm
If you are drilling, or milling a workpiece according to a drawing with
incremental coordinates, you are moving the tool by the value of
the coordinates.

4I
I - 1 Fundamentals of Positioning
Zero Angle Reference Axis
The Zero Angle Reference Axis is the 0.0° position. It is defined as
one of the two axes in the plane of rotation. The following table
defines the Zero Angle where the position of the angle is zero for the
three possible planes of rotation.
For angular positions, the following reference axes are defined:
Positive direction of rotation is counterclockwise if the working plane
is viewed in the negative tool axis direction.
EXAMPLE: Angle in the working plane X / Y
Reading head position
The reading head position provides feed back to the 200S that
converts the movement of the machine axes into electrical signals.
The 200S constantly evaluates these signals, and calculates the actual
positions of the machine axes, which it displays as a numerical value
on the screen.
If there is an interruption in power, the calculated position will no
longer correspond to the actual position. When power is restored, you
can re-establish this relationship by using the reference marks on the
provided on the scale. The 200S provides the Reference Mark
Evaluation feature (REF).
Plane Zero Angle Reference Axis
XY +X
YZ +Y
ZX +Z
Plane Zero Angle Reference Axis
+ 45° ... bisecting line between +X and +Y
+/- 180° ... negative X axis
- 270° ... positive Y axis

200S 5
I - 1 Fundamentals of Positioning
Encoder Reference Marks
Encoders normally contain one or more reference marks which the
200S Reference Mark Evaluation feature uses to re-establish datum
positions after a power interruption. There are two main options
available for reference marks; fixed and distance-coded.
Distance-coded reference marks: Encoders that have marks
separated by a specific encryption pattern allows the 200S to use any
two pair of marks along the length of the encoder to re-establish the
prior datums. This configuration means that the operator only has to
travel less than two inches any where along the encoder, to re-
establish the datums when the 200S is turned back on.
Fixed reference marks: Encoders that have one or more marks on
fixed intervals, have to re-establish the datums correctly. It is
necessary to use the same exact reference mark, during the
Reference Mark Evaluation routine, that was used when the datum
was first established.
The established datums’ cannot be restored from one
power cycle to the next if the reference marks were not
crossed before the datums were set

6I
I - 2 General Operations for 200S
I - 2 General Operations for 200S
Screen Layout
ACU-RITE’s 200S readout provides application-specific features that
allows you to obtain the most productivity from your manual
machine tools.
Status Bar - This displays the current datum, tool, feed rate, job
clock time, unit of measure, operating mode status, page indicator,
and set/zero. See Job Setup for details on setting up the Status
Bar parameters.
Display Area - Indicates the current position of each axis. Also
shows forms, fields, instruction boxes, error messages and
help topics.
Axis Labels - Indicates axis for corresponding axis key.
Ref Symbols - Indicates current reference mark status.
Soft key Labels - Indicates the various milling or turning functions.
1Datum
2Tool
3Feed Rate
4Job Clock
5Unit of Measure
6Operating Modes
7Page Indicator
8Set/Zero
9Axis Labels
10 Ref Symbol
11 Soft key Labels
12 Display Area
13 Near Zero Warning (In Distance-To-Go mode only)
9
10
4
5
1
6
7
8
2
1
11
12
13
3
