Siemens SPCK420 User manual

SPCK420/421/422 LCD-Keypad - User Manual
© Siemens Industry - 11-24-2009
SPCK420/421/422 LCD-Keypad - User Manual
© Siemens Industry - 11-24-2009

SPCK420/421/422 LCD-Keypad - User Manual
Security
Security
Further information
Target group
General safety instructions
Meaning of written warning notices
Meaning of hazard symbols
© Siemens Industry - 11-24-2009

SPCK420/421/422 LCD-Keypad - User Manual
Security > Target group
Target group
The instructions in this documentation are directed at the following target group:
End user
Instruction by technical specialists is necessary.
Performs only the procedures for proper operation of the product.
The product is installed and configured.
Target readers
Qualification
Activity
Condition of the product
© Siemens Industry - 11-24-2009

SPCK420/421/422 LCD-Keypad - User Manual
Security > General safety instructions
General safety instructions
Further information
Generalinformation
Operation
Service and maintenance
© Siemens Industry - 11-24-2009

SPCK420/421/422 LCD-Keypad - User Manual
Security > General safety instructions > General information
General information
Read the general safety precautions before operating the unit.
Keep this document for later reference.
Always pass this document on together with the product.
Please also take into account any additional country-specific, local safety standards or regulations concerning
project planning, operation and disposal of the product.
Liability claim
Do not make any changes or modifications to the device unless they are expressly mentioned in this manual and
have been approved by the manufacturer.
© Siemens Industry - 11-24-2009

SPCK420/421/422 LCD-Keypad - User Manual
Security > General safety instructions > Operation
Operation
Dangerous situation due to false alarm
Make sure to notify all relevant parties and authorities providing assistance before testing the system.
To avoid panic, always inform all those present before testing any alarm devices.
© Siemens Industry - 11-24-2009

SPCK420/421/422 LCD-Keypad - User Manual
Security > General safety instructions > Service and maintenance
Service and maintenance
Danger of electrical shock during maintenance
Maintenance work must only be carried out by trained specialists.
Danger of electrical shock while cleaning the device
Do not use liquid cleaners or sprays that contain alcohol, spirit or ammonia.
© Siemens Industry - 11-24-2009

SPCK420/421/422 LCD-Keypad - User Manual
Security > Meaning of written warning notices
Meaning of written warning notices
DANGER
Danger of death or severe bodily harm.
WARNING
Possible danger of death or severe bodily harm.
CAUTION
Danger of minor bodily injury or property damage
IMPORTANT
Danger of malfunctions
Signal Word
Type of Risk
© Siemens Industry - 11-24-2009

SPCK420/421/422 LCD-Keypad - User Manual
Security > Meaning of hazard symbols
Meaning of hazard symbols
WARNING
Warning of hazard area
WARNING
Warning of dangerous electrical voltage
© Siemens Industry - 11-24-2009

SPCK420/421/422 LCD-Keypad - User Manual
Directives and standards
Directives and standards
Further information
EU directives
© Siemens Industry - 11-24-2009

SPCK420/421/422 LCD-Keypad - User Manual
Directives and standards > EU directives
EU directives
This product complies with the requirements of the European Directives 2004/108/EC “Directive of Electromagnetic
Compatibility” and 2006/95/EC “Low Voltage Directive”. The EU declaration of conformity is available to the
responsible agencies at:
Siemens Building Technologies
Fire & Security Products GmbH & Co. oHG
Siemensallee 84
76181 Karlsruhe
European Directive 2004/108/EC „Electromagnetic Compatibility”
Compliance with the European Directive 2004/108/EC has been proven by testing according to the following standards:
emc emission
EN 55022 Class B
emc immunity
EN 50130-4
European Directive 2006/95/EC „Low-Voltage Directive”
Compliance with the European Directive 2006/95/EC has been proven by testing according to the following standard:
Safety
EN 60950-1
© Siemens Industry - 11-24-2009

SPCK420/421/422 LCD-Keypad - User Manual
Introduction
Introduction
The keypad is a wall-mounted interface that allows:
Engineers to program the system through the Engineer Programming menus (password protected) and to set/unset
the system; a user can control the system on a day-to-day basis.
Users to enter User Programming menus (password protected), and to perform operational procedures (set/unset)
on the system.
The keypad unit includes an integral front tamper switch and has a 2 line x 16 character display. It features an easy-to-
use navigation key to assist in locating required programming options, and has 2 context sensitive soft keys (left and
right) for selecting the required menu or program setting. 3 LEDs on the keypad provide an indication of AC power,
system alerts, and communications status.
The standard keypad may be factory fitted with a Portable ACE (PACE) proximity device reader (see page ).

LCDkeypad
LCD keypad
1
LCDdisplay
The keypad display (2 lines x 16 characters) shows all alert and warning messages and provides a visual interface for
programming the system (engineer programming only). The display can be adjusted fro contrast and under which
conditions the backlight comes on.
2
Alphanumeric keys
Alphanumeric keypad allow for both text and numeric data entry during programming. Alphabetic characters are
selected by applying the appropriate number of key presses. To switch between upper and lower case characters, press
the hash (#) key. To enter a numeric digit, hold down the appropriate key for 2 seconds.
3
Leverage access tabs
The leverage access tabs provide access to the keypad back assembly clips. Users can unhinge these clips from the front
assembly by inserting a 5mm screwdriver into the recesses and pushing gently.
4
Back assembly securing screw
This screw secures the front and back assemblies on the keypad. This screw must be removed to open the keypad.
5
LED status indicators
The LED status indicators provide information on the current status of the system as detailed in the table below.
6
Soft function keys

The left and right soft function keys are context sensitive keys to navigate through menus/programming.
7
Proximity device receiver area
If the keypad has been fitted with a proximity device receiver (see page ), users should present the Portable ACE Fob to
within 1 cm of this area to SET/UNSET the system.
8
Multi-functional navigation Key
The multi-functional navigation key in combination with the keypad display provides an interface for programming the
system.
LED
Status
AC mains
(Green)
Indicates the presence or failure of the mains supply
FLASHING: AC mains fault detected
STEADY: AC mains OK
Systemalert
(Yellow)
Indicates a system alert
FLASHING: System alert detected; display indicates the location and nature of alert. If the system is SET, then NO
indication is given of system alerts
OFF: No alert detected; If a keypad is assigned to more than one area, LED does not indicate an alert condition if any of
those areas is SET
X-BUS Status
(Red)
Indicates the status of the X-BUS communications when in FULL ENGINEER programming
Flashes regularly: (once every 1.5 seconds approx) indicates communications status is OK
Flashes quickly: (once every 0.25 seconds approx) indicates the keypad is the last expander on the X-BUS
If the keypad is being installed for the first time and power is supplied to it before a connection to the controller X-BUS
interface is made, the LED remains in the ON state
© Siemens Industry - 11-24-2009

SPCK420/421/422 LCD-Keypad - User Manual
Overview of keypad types
Overview of keypad types
Keypadtype
Model no. Basic Functionality
Proximity Detection
Wireless Sensor Support
Voice
Standard Keypad
SPCK420 -
-
-
Keypad with PACE
SPCK421
-
-
Keypad with 868 MHz wireless module
SPCK422 -
-
Comfort Keypad
SPCK620
-
Comfort Keypad with Audio/CR
SPCK623

Keypad Label SPCK420/421/422
Keypad Label SPCK420/421/422 1
Label on inside of Keypad 2
Pull-down label for providing installer details. Fill in all relevant details when installation is complete.
© Siemens Industry - 11-24-2009

SPCK420/421/422 LCD-Keypad - User Manual
Using the keypad interface
Using the keypad interface
Keypaddisplay
Keypad display 1
RIGHT SOFT KEY
This key is used to select the option presented on the right side of the bottom line display.
Possible values are:
SELECT to select the option displayed on the top line
ENTER to enter the data displayed on the top line
SAVE to save a setting 2
OK
The OK button acts as a SELECT key for the menu option displayed on the top line and also as an ENTER/SAVE key
for data displayed on the top line. 3
In Programming mode, the right arrow key advances the user through the menus in the same way as pressing the
SELECT option (right soft key).
In data entry mode, press this key to move the cursor one position to the right. 4
In Programming mode, the down arrow key moves the user to the next programming option in the same menu level.
Continually press this key to scroll through all programming options available on the current menu level.
In alphanumeric mode, press this key over an upper case character to change the character to lower case. 5
In Programming mode, the left arrow key returns the user to the previous menu level. Pressing this key when in the top

menu level exits the user from programming.
In data entry mode, press this key to move the cursor one position to the left. 6
In Programming mode, the up arrow key moves the user to a previous programming option in the same menu level.
Continually press this key to scroll through all programming options available on the current menu level.
In Alphanumeric mode, press this key over a lower case character to change the character to upper case. 7
LEFT SOFT KEY
This key is used to select the option presented on the left side of the bottom line display.
Possible values are:
EXIT to exit programming
BACK to return to previous menu 8
BOTTOMLINE
OFDISPLAY
In the IDLE state, this line is blank.
In Programming mode, this line displays options available to the user. These options align over the left and right soft
keys for selection as required. 9
TOP LINE
OFDISPLAY
In the IDLE state, displays the current date and time. In Programming mode, this line displays one of the following:
The programming feature to be selected
The current setting of the selected feature
During an alert condition, this line displays the nature of the current alert.
© Siemens Industry - 11-24-2009

SPCK420/421/422 LCD-Keypad - User Manual
User programming via the keypad
User programming via the keypad
This section provides User programming options using the LCD keypad.
For each menu option, the keypad must be in User programming:
Enter a valid User code (default 2222).1.
Using the up/down arrow keys, scroll to the desired programming option.2.
To select a programming option using the keypad digits, enter the User programming code plus the digit as shown in the
graphic below.
3.
A quick select function is implemented. Press # to select a parameter (e.g. an user right). The selected parameter is
displayed with a * (e.g. *Inhibit).
4.
Upon completion of the programming options, the keypad displays UPDATED momentarily.

SPC_mnu_overview_user_menu
A user’s ability to see menus and options available on the intrusion control panel is programmed by the installation
