ACU-RITE 01120M User manual

Instruction Manual
SAVE THIS MANUAL FOR FUTURE REFERENCE.
Questions? Contact Customer Support at
877-221-1252 or visit www.AcuRite.com.
CONTENTS
Unpacking Instructions ........... 2
Package Contents .................. 2
Product Registration ............... 2
Features & Benets: Sensor...... 2
Features & Benets: Display ..... 3
Setup .................................... 6
Sensor Setup ......................... 6
Display Setup ........................ 7
Set the Time, Date & Units ...... 8
Backlight Settings................... 8
Placement Guidelines ............. 9
Using the Weather Station.....10
Programmable Alarms........... 11
Troubleshooting ....................12
Care & Maintenance.............13
Calibration ...........................13
Specications........................14
FCC Information ...................14
Customer Support .................15
Warranty..............................15
Weather Station
model 01120

2
Congratulations on your new AcuRite product. To ensure the best
possible product performance, please read this manual in its entirety
and retain it for future reference.
Unpacking Instructions
Remove the protective lm that is applied to the LCD screen prior to using this
product. Locate the tab and peel off to remove.
Package Contents
1. Display with Tabletop Stand
2. Outdoor Sensor
3. Instruction Manual
4. Power Adapter
Features & Benets
4
3
2
1
5
OUTDOOR SENSOR
1. Integrated Hanger
For easy placement.
2. Wireless Signal Indicator
Flashes when data is being sent
to the display.
3. Battery Compartment
4. A-B-C Switch
ID code that must match display’s
A-B-C switch to ensure units synchronize.
5. Battery Compartment Cover
PRODUCT REGISTRATION
Register online to receive 1 year of warranty protection
www.AcuRite.com
IMPORTANT PRODUCT MUST BE REGISTERED
TO RECEIVE WARRANTY SERVICE

3
Features & Benets
BACK OF DISPLAY
1. Integrated Hang Hole
For easy wall mounting.
2. Plug-in for Power Adapter
3. Backup Battery Compartment
4. Fold-out Tabletop Stand
5. RESET Button
For full reset to factory defaults.
6. A-B-C Switch
ID code that must match sensor’s
A-B-C switch to ensure units
synchronize.
7. Power Adapter
8. Battery Compartment Cover
(not shown)
7
1
2
3
4 5 6

4
Features & Benets
Display
121
20
19
18
17
16
2
4
5
6
7
8
9
10
11 12 1413 13 15
3

5
Features & Benets
FRONT OF DISPLAY
1. Outdoor Sensor Signal Strength
2. Sensor Low Battery Indicator
3. Current Outdoor Temperature
Arrow icon indicates the direction
temperature is trending.
4. Alarm ON Indicator
Indicates alarm is activated to emit an
audible alert when conditions exceed
your presets (see page 11).
5. Outdoor Low Temperature Record
Lowest temperature recorded since
midnight.
6. Outdoor High Temperature Record
Highest temperature recorded since
midnight.
7. Current Outdoor Humidity
Arrow icon indicates the direction
humidity is trending.
8. Current Indoor Temperature
Arrow icon indicates direction
temperature is trending.
9. Current Indoor Humidity
Arrow icon indicates direction
humidity is trending.
10. Date
11. Button
For alarm setup.
12. Display Low Battery Indicator
13. and Buttons
For setup preferences and viewing
indoor high & low records.
14. SET Button
For setup preferences.
15. Button
For momentary backlight and
dimmer settings.
16. AUTO Icon
Indicates display is in auto-dimming
brightness mode (see page 8).
17. Moon Phase
18. Clock
19. Current Barometric Pressure
Arrow icon indicates the direction
pressure is trending.
20. 12 to 24 Hour Weather Forecast
Self-calibrating forecasting pulls data
from the outdoor sensor to generate
your personal forecast.
21. Learning Mode Icon
Disappears after weather forecast
self-calibration is complete.

6
SETUP
Sensor Setup
Set the A-B-C Switch
The A-B-C switch is located inside
the battery compartment. It can
be set to A, B or C. However,
you must select the same letter
choices for both the sensor and
the display in order for the units
to synchronize.
Install or Replace Batteries
AcuRite recommends high quality
alkaline or lithium batteries for
the best product performance.
Heavy-duty or rechargeable
batteries are not recommended.
The sensor requires lithium
batteries in low-temperature
conditions. Cold temperatures
can cause alkaline batteries
to function improperly. Use
lithium batteries in the sensor for
temperatures below -4ºF / -20ºC .
1. Slide off the battery
compartment cover. Take
note of the A-B-C switch
setting inside the battery
compartment.
2. Insert 2 x AA batteries into
the battery compartment, as
shown. Follow the polarity
(+/-) diagram in the battery
compartment.
3. Replace the battery cover.
2
1
1A-B-C Switch
Set to match
display
2Install Batteries
2 AA batteries
A B C

7
PLEASE DISPOSE OF OLD OR DEFECTIVE BATTERIES IN AN ENVIRONMENTALLY SAFE
WAY AND IN ACCORDANCE WITH YOUR LOCAL LAWS AND REGULATIONS.
BATTERY SAFETY: Clean the battery contacts and also those of the device prior to battery installation. Remove batteries from equipment that will not be
used for an extended period of time. Follow the polarity (+/-) diagram in the battery compartment. Promptly remove dead batteries from the device. Dispose of used
batteries properly. Only batteries of the same or equivalent type as recommended are to be used. DO NOT incinerate used batteries. DO NOT dispose of batteries in fire,
as batteries may explode or leak. DO NOT mix old and new batteries or types of batteries (alkaline/standard). DO NOT use rechargeable batteries. DO NOT recharge
non-rechargeable batteries. DO NOT short-circuit the supply terminals.
IMPORTANT: Batteries are
a backup power source to
preserve records in the event of
a power outage. Power adapter
is recommended as the primary
power source to enjoy the full
functionality of this product.
Display Setup
1Set the A-B-C Switch
Locate the A-B-C switch inside
the battery compartment. Set
the A-B-C switch to A, B or C.
You must select the same letter
choices for both the display and
the sensor in order for the units to
synchronize.
Install or Replace Backup
Batteries (optional)
1. Remove the battery
compartment cover.
2. Insert 3 x AAA alkaline
batteries into the battery
compartment, as shown. Follow
the polarity (+/–) diagram in
the battery compartment.
3. Replace the battery cover.
Plug in Power Adapter
For the best performance, plug
in the power adapter as the main
power source for this product.
3Plug in
Power
Adapter
1A-B-C Switch
Set to match
sensor
2
3
Install Backup
Batteries
3 AAA Batteries
(optional)
2
A B C

8
Set the Time, Date & Units
Press and release the “SET” button, located on the front of the display, to enter
SET MODE. Once in set mode, the preference you are currently setting will
blink on the display.
To adjust the currently selected (ashing) item, press and release the “ ” or
“ ” buttons (press and HOLD to fast adjust).
To save your adjustments, press and release the “SET” button again to adjust
the next preference. The preference set order is as follows:
AUTO CHANGE for DST? (Daylight Saving Time Y or N)*
CLOCK HOUR
CLOCK MINUTE
CALENDAR MONTH
CALENDAR DATE
CALENDAR YEAR
TEMPERATURE UNITS (ºF or ºC)
BAROMETRIC PRESSURE UNITS (hPa or inHg)
*If you live in an area that observes Daylight Saving Time, DST should be set
to Y, even if it is not currently Daylight Saving Time.
You will automatically exit SETUP MODE if no buttons are pressed for 10
seconds. Enter setup mode at any time by pressing the “SET” button.
Display Backlight Settings
This weather station’s color display features three different lighting settings:
High (100%) brightness, Medium (60%) brightness and Low (30%) brightness.
When display is powered with the power adapter, backlight remains on at
100% brightness. Press the button once to dim to 60% brightness; press
again to dim to 30%, press a third time to enter AUTO-DIM mode. “ ” will
appear next to the clock.
AUTO DIM MODE: Automatically adjusts display brightness based on time of day.
6:00 a.m. - 9:00 p.m. = 100% brightness
9:01 p.m. - 5:59 a.m.= 30% brightness

9
Placement for Maximum Accuracy
AcuRite sensors are sensitive to surrounding environmental conditions. Proper
placement of both the display and the outdoor sensor are critical to the
accuracy and performance of this product.
Display Placement
Place the display in a dry area free of dirt and dust. Display
stands upright for tabletop use or is wall-mountable.
Outdoor Sensor Placement
Sensor must be placed outside to observe outdoor conditions.
Sensor is water-resistant and is designed for general outdoor
use, however, to extend its life place the sensor in an area
protected from direct weather elements.
Hang the sensor using the integrated hang holes or hanger, or
by using string (not included) to hang it from a suitable location,
like a well covered tree branch. The best location is 4 to 8 feet
(1 to 2 meters) above the ground with permanent shade and
plenty of fresh air to circulate around the sensor.
Important Placement Guidelines
• To ensure accurate temperature measurement, place units out of direct
sunlight and away from any heat sources or vents.
• Display and outdoor sensor must be within 330 ft (100 m) of each other.
• To maximize wireless range, place units away from large metallic items, thick
walls, metal surfaces, or other objects that may limit wireless communication.
• To prevent wireless interference, place both units at least 3 ft (90 cm) away
from electronic devices (TV, computer, microwave, radio, etc.).
Setup is Complete
The sensor will now synchronize with the display. It may take a few minutes for
synchronization to complete. Please refer to the troubleshooting section of this
manual if anything appears to be functioning improperly.
TV
(330 feet maximum)
(100 meters)
3feet
(.9m)
AT
LEAST
APART

10
Using the Weather Station
Learning Mode
Self-calibrating forecasting uses a unique algorithm to analyze changes in
pressure over a time period (called Learning Mode) to determine your altitude.
After 14 days, the learning mode icon disappears from the display screen. At
this point, the self-calibrated pressure is tuned in to your location and the unit is
ready for superior weather prediction.
Weather Forecast
AcuRite’s patented self-calibrating forecasting provides your personal forecast
of weather conditions for the next 12 to 24 hours by collecting data from the
sensor in your backyard. It generates a forecast with pinpoint accuracy -
personalized for your exact location.
OPERATION
View the complete list of icons at www.AcuRite.com/acurite-icons
Barometric Pressure
Subtle variations in barometric pressure greatly affect the weather. This
weather station displays the current pressure with an arrow icon to indicate
the direction the pressure is trending (FALLING, STEADY, or RISING).
Moon Phase
Track the phases of the moon, conveyed through simple lunar phase icons:
FULL
NEW WAXING
CRESCENT
WANING
CRESCENT
1ST
QUARTER
3RD
QUARTER
High & Low Records
Today’s high and low records are displayed for indoor and outdoor temperature
and humidity. Today’s records automatically clear at 12:00am midnight every
day. View today’s indoor high or low records by pressing and releasing the
“ ” or “ ” buttons.
To manually clear all of today’s LOW recorded values, press and release
the “ ” button to view low records, then press and hold the “ ” button for
2 seconds. Dashes display to conrm you have cleared the LOW records.
To manually clear all of today’s HIGH recorded values, press and release
the “ ” button to view high records, then press and hold the “ ” button for
2 seconds. Dashes display to conrm you have cleared the HIGH records.
STORM
DEVELOPING
(Flashing)
SNOW
LIKELY LIGHT RAIN LIKELY PARTLY CLOUDY SUNNYCLOUDY
