ACU-RITE 02007/06035RM User manual

Instruction Manual
SAVE THIS MANUAL FOR FUTURE REFERENCE.
Questions? Contact Customer Support at
[phone] or visit www.AcuRite.com.
CONTENTS
Unpacking Instructions ........... 2
Package Contents .................. 2
Product Registration ............... 2
Features & Benets: Sensor..... 2
Features & Benets: Display.... 3
Setup .................................... 6
Sensor Setup ......................... 6
Display Setup ........................ 7
Setup Preferences .................. 8
Intelli-Time Clock.................... 8
Backlight Settings................... 9
Placement Guidelines ............10
Using the Weather Station.....11
Troubleshooting ....................12
Care & Maintenance.............13
Replace Intelli-Time® Battery ....14
Calibration ...........................14
Specications........................15
FCC Information ...................15
Customer Support .................16
Warranty..............................16
Weather Station
model 02007 / 06035RM

2
Congratulations on your new AcuRite product. To ensure the best
possible product performance, please read this manual in its entirety
and retain it for future reference.
Unpacking Instructions
Remove the protective lm that is applied to the LCD screen prior to using this
product. Locate the tab and peel off to remove.
Package Contents
1. Display unit
2. Outdoor sensor
3. Power adapter
4. Instruction Manual
PRODUCT REGISTRATION
Register online
to receive 1 year
warranty protection
www.AcuRite.com
IMPORTANT PRODUCT MUST BE REGISTERED
TO RECEIVE WARRANTY SERVICE
►
Register a Product
Features & Benets
4
3
2
1
5
OUTDOOR SENSOR
1. Integrated Hanger
For easy placement.
2. Wireless Signal Indicator
Flashes when data is being
sent to the display unit.
3. Battery Compartment
4. A-B-C Switch
ID code that must match display’s
A-B-C switch to ensure units
synchronize.
5. Battery Compartment Cover

3
Features & Benets
BACK OF DISPLAY UNIT
6. A-B-C Switch
ID code that must match sensor’s
A-B-C switch to ensure
units synchronize.
7. Battery Compartment
8. RESET Button
Full reset to factory defaults.
9. Integrated Hang Hole
for easy mounting.
10. GEO Button
Set geographic region preference.
11. ZONE Button
Set time zone preference.
12. Plug-in for Power Adapter
13. Battery Compartment Cover
(not shown)
FRONT OF DISPLAY UNIT
14. HISTORY CHART Mode
Press to toggle between pressure,
outdoor temperature or outdoor
humidity on History Chart. Press and
hold for 4 seconds to enter auto-cycle
mode (5 second rotation).
15. ”T”, ” ” & ”
V
” Buttons
for setup preferences.
16. Backlight Button
(top of display unit)
6
7
10 118 9 16
151412

4
24
20
23
19
21
17
18
22
Features & Benets
1
3
6
2
7
4
9
8
5
10
11
12 14 1513 16
282931 30 27 26 25

5
DISPLAY UNIT
1. Day of the Week
2. Current Outdoor Temperature
Arrow icon indicates direction
temperature is trending.
3. Outdoor High Temperature Record
Indicates highest outdoor temperature
recorded since midnight.
4. Outdoor Low Temperature Record
Indicates lowest outdoor temperature
recorded since midnight.
5. Current Outdoor Humidity
Arrow icon indicates direction
humidity is trending.
6. Outdoor High Humidity Record
Indicates highest outdoor humidity
recorded since midnight.
7. Outdoor Low Humidity Record
Indicates lowest outdoor humidity
recorded since midnight.
8. Outdoor Sensor Signal Strength
9. Low Sensor Battery Indicator
10. Forecasted High Temperature
11. Forecasted Low Temperature
12. Up to 4 Hour Weather Forecast
Precision Forecasting combines
regional trends with data from your
outdoor sensor to generate your
personal forecast.
13. GEO SET Icon
Flashes to indicate Geo Zone setup
mode.
14. Geographic Region Selection
for setup preferences.
15. 4 to 8 Hour Weather Forecast
16. 8 to 12 Hour Weather Forecast
17. Barometric Pressure
Arrow icon indicates direction
pressure is trending.
18. Indoor High Humidity Record
Indicates highest indoor humidity
recorded since midnight.
19. Indoor Low Humidity Record
Indicates lowest indoor humidity
recorded since midnight.
20. Current Indoor Humidity
Arrow icon indicates direction
humidity is trending.
21. Multi-Variable History Chart
Displays the past 12 hours of data
for pressure, outdoor temperature or
outdoor humidity.
22. Indoor High Temperature Record
Indicates highest indoor temperature
recorded since midnight.
23. Indoor Low Temperature Record
Indicates lowest indoor temperature
recorded since midnight.
24. Current Indoor Temperature
Arrow icon indicates direction
temperature is trending.
25. Date
26. SET Icon
Flashes to indicate setup mode.
27. Display Unit Low Battery Indicator
28. Intelli-Time®Clock
29. Auto-Cycle Mode Indicator
30. AUTO DIM Indicator
31. Time Zone & Daylight Saving Time
for setup preferences, shown only
during setup.

6
SETUP
Set the A-B-C Switch
The A-B-C switch is located inside
the battery compartment. It can
be set to A, B or C. However,
you must select the same letter
choices for both the sensor and
the display unit in order for the
units to synchronize.
Install or Replace Batteries
AcuRite recommends high quality
alkaline or lithium batteries in
the outdoor sensor for the best
product performance. Heavy duty
or rechargeable batteries are not
recommended.
The sensor requires lithium
batteries in low temperature
conditions. Cold temperatures
can cause alkaline batteries
to function improperly. Use
lithium batteries in the sensor for
temperatures below -4ºF / -20ºC.
1. Slide off the battery
compartment cover. Take note
of the A-B-C switch setting
inside the battery compartment
for display unit setup.
2. Insert 2 x AA batteries into
the battery compartment, as
shown. Follow the polarity
(+/-) diagram in the battery
compartment.
3. Replace the battery cover.
Sensor Setup
2
1
1A-B-C Switch
set to match
display unit
2Install Batteries
2 AA batteries
A B C

7
PLEASE DISPOSE OF OLD OR DEFECTIVE BATTERIES IN AN ENVIRONMENTALLY SAFE
WAY AND IN ACCORDANCE WITH YOUR LOCAL LAWS AND REGULATIONS.
BATTERY SAFETY: Clean the battery contacts and also those of the device prior to battery installation. Remove batteries from equipment which is not to be
used for an extended period of time. Follow the polarity (+/-) diagram in the battery compartment. Promptly remove dead batteries from the device. Dispose of used
batteries properly. Only batteries of the same or equivalent type as recommended are to be used. DO NOT incinerate used batteries. DO NOT dispose of batteries in fire,
as batteries may explode or leak. DO NOT mix old and new batteries or types of batteries (alkaline/standard). DO NOT use rechargeable batteries. DO NOT recharge
non-rechargeable batteries. DO NOT short-circuit the supply terminals.
Display Unit Setup
Set the A-B-C Switch
Locate the A-B-C switch inside
the battery compartment. Set
the A-B-C switch to A, B or C.
You must select the same letter
choices for both the display unit
and the sensor in order for the
units to synchronize.
Install or Replace Backup
Batteries (optional)
1. Remove the battery
compartment cover.
2. Insert 3 x AA alkaline
batteries into the battery
compartment, as shown.
Follow the polarity
(+/-) diagram in the battery
compartment.
3. Replace the battery cover.
Plug in Power Adapter
For the best performance, plug
in the power adapter as the main
power source for this product.
23
1
A B C
2Install Backup
Batteries (optional)
3 AA alkaline
batteries
IMPORTANT: Batteries are a backup power source to preserve records in the event of a
power outage. Power adapter recommended as the primary power source to enjoy the full
functionality of the product.
3Plug in Power
Adapter
1A-B-C Switch
set to match
sensor

8
Setup: Geographic Region
Select your geographic region according to
the map (pictured right) by pressing the
“GEO” button, located on the back of the unit
in the battery compartment. The letters for each
corresponding GEO region are shown on the
display screen. Geographic region must be set
in order for Precision Forecasting to function
properly. *The “ ” icon and geographic
region letter are only visible in GEO set mode.
You will automatically exit GEO set mode if no
buttons are pressed for 10 seconds. Enter GEO set
mode at any time by pressing the “GEO ” button
located inside the battery compartment.
Intelli-Time®Clock
Intelli-Time clock and calendar are pre-programmed to the correct time and
date, and update automatically for Daylight Saving Time. All you need to do is
select your time zone using the “ZONE” button.
Setup: Time, Date, Units & Language
Press the “ ” button, located on the front of the display unit, to enter SET
MODE. Once in set mode, the preference you are currently setting will blink on
the display.
To adjust the currently selected (ashing) item, press and release the “T” or
“
V
“ buttons (press and HOLD to fast adjust).
To save your adjustments, press and release the “ ” button again to adjust
the next preference. The preference set order is as follows:
TIME ZONE ( PST MST CST EST AST HAST AKST)
AUTO DST (Daylight Saving Time ON or OFF)*
CLOCK HOUR
CLOCK MINUTE
CALENDAR MONTH
CALENDAR DATE
CALENDAR YEAR
UNITS: TEMPERATURE (ºF or ºC)
UNITS: PRESSURE (inHg or hPa)
LANGUAGE (English or French)
*If you live in an area that observes DST, DST should be set to ON even if it is
not currently Daylight Saving Time.
You will automatically exit SET MODE if no buttons are pressed for 30 seconds.
Enter SET MODE at any time by pressing the “ ” button.
ABCD
EFG

9
AUTO DIM MODE: Automatically adjusts display brightness based on time of day & year.
MARCH 11- NOVEMBER 4 6:00 a.m. - 9:00 p.m. = 100% brightness
9:01 p.m. - 5:59 a.m.= 30% brightness
NOVEMBER 5 - MARCH 10 7:30 a.m. - 7:00 p.m.= 100% brightness
7:01 p.m. - 7:29 a.m. = 30% brightness
Display Backlight Settings
This weather station’s color display features three different lighting settings:
High (100%) brightness, Medium (60%) brightness and Low (30%) brightness
Using battery power alone, the backlight is available momentarily for 10
seconds by pressing the “BACKLIGHT” button.
When display is powered with the power adapter, backlight remains on at
100% brightness. Press “BACKLIGHT” button once to dim to 60% brightness;
press again to dim to 30%, press a 3rd time to enter “AUTO DIM” mode.
AUTO DIM will appear to the left of the time.

10
Placement for Maximum Accuracy
AcuRite sensors are sensitive to surrounding environmental conditions. Proper
placement of both the display unit and outdoor sensor are critical to the
accuracy and performance of this product.
Display Unit Placement
Place display unit in a dry area free of dirt and dust. Display
stands upright for tabletop use or is wall-mountable. For wall
mounting, hang using the keyhole located on back of the unit.
Outdoor Sensor Placement
Sensor must be placed outside to observe outdoor conditions. Sensor
is water resistant and is designed for general outdoor use, however,
to extend its life place the sensor in an area protected from direct
weather elements.
Hang the sensor using the integrated hang holes or hanger, or by
using string (not included) to hang it from a suitable location, like a
well covered tree branch. The best location is 4 to 8 feet above the
ground with permanent shade and plenty of fresh air to circulate
around the sensor.
Important Placement Guidelines
• To ensure accurate temperature measurement, place units out of direct
sunlight and away from any heat sources or vents.
• Display unit and outdoor sensor must be within 330 ft (100 m) of each other.
• To maximize wireless range, place units away from large metallic items, thick
walls, metal surfaces, or other objects that may limit wireless communication.
• To prevent wireless interference, place both units at least 3 ft (.9 m) away
from electronic devices (TV, computer, microwave, radio, etc.).
TV 3
(100 meters)
(330 feet maximum)
(.91 m)
AT
LEAST
APART
Setup is Complete
The sensor will now synchronize with the display unit. It may take a few
minutes for synchronization to complete. NOTE: It will take up to 4 hours to
generate a weather forecast after initial setup.
