Instruction Manual
CONTENTS
Unpacking Instructions ........... 2
Package Contents .................. 2
Product Registration ............... 2
F ... 2
F ... 3
Setup .................................... 6
Sensor Setup ......................... 6
Display Setup ........................ 7
Set the Time, Date and Units.... 8
Backlight Settings................... 8
Placement Guidelines ............. 9
Using the Weather Station.....10
Programmable Alarms...........11
Troubleshooting ....................12
Care and Maintenance .........13
Calibration ...........................13
........................14
FCC Information ...................14
Customer Support .................15
Warranty..............................15
Questions? Contact Customer Support at
www.AcuRite .com/support or email [e-mail]
Weather Station
model 01201
SAVE THIS MANUAL FOR FUTURE REFERENCE.

L I.
Congratulations on your new AcuRite product. To ensure the best possible
product performance, please read this manual in its entirety and retain it for
future reference.
Unpacking Instructions
Remove the protective lm that is applied to the LCD screen prior to using this
product. Locate the tab and peel off to remove.
Package Contents
1. Display
2. Outdoor Sensor
3. Power Adapter
4. Instruction Manual
PRODUCT MUST BE REGISTERED
IMPORTANT TO RECEIVE WARRANTY SERVICE
PRODUCT REGISTRATION
Register online to receive 1 year of warranty protection
www.AcuRite.com
Features and Benets
1 OUTDOOR SENSOR
1. Integrated Hanger
2 For easy placement.
2. Wireless Signal Indicator
Flashes when data is being sent to the
display.
3. Battery Compartment
3 4. A-B-C Switch
ID code that must match display’s
4 A-B-C switch to ensure units
synchronize.
5. Battery Compartment Cover
5
2

Features and Benets
BACK OF DISPLAY
3
6
7
5
4
2
1
1. Integrated Hang Hole
For easy wall mounting.
2. Fold-out Tabletop Stand
3. Power Adapter
4. Plug-in for Power Adapter
5. RESET Button
For full reset to factory defaults.
6. A-B-C Switch
ID code that must match sensor’s
A-B-C switch to ensure units
synchronize.
7. Backup Battery Compartment
8. Battery Compartment Cover
(not shown)
3

I
UD"~ FF"~
•□ .Ei JJ.3
33·~
Features and Benets
1
2
3
4
5
6
18
17
16
15
14
13
12
11
7 8 9 8 10
4

.,t)))
/\ V
0
-i-, '
~
1. Current Outdoor Temperature
Arrow icon indicates the direction
temperature is trending.
2. Outdoor High & Low Temperature
Records
Highest and lowest temperature
recorded since midnight.
3. Current Outdoor Humidity Arrow
icon indicates the direction humidity
is trending.
4. Outdoor Sensor Signal Strength
5. Heat Index/Dew Point
Heat Index calculation displays
when temperature is 80°F (27°C)
or above.
Dew Point calculation displays
when temperature is 79°F (26°C)
or below.
6. Date
7. Button
For alarm setup.
8. and Buttons
For setup preferences and viewing
indoor high & low records.
9. Button
For setup preferences.
10. Button
For momentary backlight and
dimmer settings.
11. AUTO Icon
Indicates display is in auto-dimming
brightness mode (see page 8).
12. Moon Phase
13. Clock
14. Current Barometric Pressure
Arrow icon indicates the direction
pressure is trending.
15. 12 to 24 Hour Weather Forecast
Self-calibrating forecasting pulls data
from the outdoor sensor to generate
your personal forecast.
16. Current Indoor Humidity
Arrow icon indicates direction
humidity is trending.
17. Indoor High & Low Temperature
Records
Highest and lowest temperature
recorded since midnight.
18. Current Indoor Temperature
Arrow icon indicates direction
temperature is trending.
5

•
•
•
SETUP
Sensor Setup
1 Set the A-B-C Switch
The A-B-C switch is located inside
the battery compartment. It can
be set to A, B or C. However,
you must select the same letter
choices for both the sensor and
the display in order for the units
to synchronize.
2 Install or Replace Batteries
AcuRite recommends high quality
alkaline batteries in the outdoor
sensor for the best product
performance. Heavy duty or
rechargeable batteries are not
recommended.
1. Slide off the battery
compartment cover. Take
note of the A-B-C switch
setting inside the battery
compartment for display
setup.
2. Insert 2 x AA batteries into
the battery compartment, as
shown. Follow the polarity
(+/-) diagram in the battery
compartment.
3. Replace the battery cover.
2 Install Batteries
2 AA batteries
A B C
1 A-B-C Switch
Set to match
display
6

• •
•
• •
•
Display Setup
1 Set the A-B-C Switch
Locate the A-B-C switch inside
the battery compartment. Set
the A-B-C switch to A, B or C.
You must select the same letter
choices for both the display and
the sensor in order for the units to
synchronize.
2 Install or Replace Backup
Batteries (optional)
1. Remove the battery
compartment cover.
PLEASE DISPOSE OF OLD OR DEFECTIVE BATTERIES IN AN ENVIRONMENTALLY SAFE
WAY AND IN ACCORDANCE WITH YOUR LOCAL LAWS AND REGULATIONS.
BATTERY SAFETY: Clean the battery contacts and also those of the device prior to battery installation. Remove batteries from equipment that will not
be used for an extended period of time. Follow the polarity (+/-) diagram in the battery compartment. Promptly remove dead batteries from the device. Dispose of
used batteries properly. Only batteries of the same or equivalent type as recommended are to be used. DO NOT incinerate used batteries. DO NOT dispose of batteries
in re, as batteries may explode or leak. DO NOT mix old and new batteries or types of batteries (alkaline/standard). DO NOT use rechargeable batteries. DO NOT
recharge non-rechargeable batteries. DO NOT short-circuit the supply terminals.
3 Plug in
Power
Adapter
1 A-B-C Switch
Set to match
sensor
Install Backup
Batteries
3 AAA Batteries
(optional)
2
A B C
2. Insert 3 x AAA alkaline
batteries into the battery
compartment, as shown. Follow
the polarity (+/–) diagram in
the battery compartment.
3. Replace the battery cover.
3 Plug in Power Adapter
For the best performance, plug
in the power adapter as the main
power source for this product.
IMPORTANT: Batteries are
a backup power source to
preserve records in the event of
a power outage. Power adapter
is recommended as the primary
power source to enjoy the full
functionality of this product.
7

/\.
V
0
-8-
-),/_
Set the Time, Date and Units
Press and release the “ ” button, located on the front of the display, to enter
SET MODE. Once in set mode, the preference you are currently setting will
blink on the display.
To adjust the currently selected (ashing) item, press and release the “ “or
““ buttons (press and HOLD to fast adjust).
To save your adjustments, press and release the “ ” button again to adjust the
next preference. The preference set order is as follows:
Auto DST (Daylight Saving Time ON of OFF)*
CLOCK HOUR
CLOCK MINUTE
CALENDAR MONTH
CALENDAR DATE
CALENDAR YEAR
TEMPERATURE UNITS (ºC or ºF)
PRESSURE UNITS (hPa or inHg)
*If you live in an area that observes DST, DST should be set to ON, even if it is
not currently Daylight Saving Time.
You will automatically exit SET MODE if no buttons are pressed for 10 seconds.
Enter setup mode at any time by pressing the “ ” button.
Display Backlight Settings
This weather station’s colour display features three different lighting settings:
High (100%) brightness, Medium (50%) brightness and Low (15%) brightness.
Using battery power alone, the backlight is available momentarily for 10
seconds by pressing the Backlight button.
When display is powered with the power adapter, backlight remains on at
100% brightness. Press Backlight button once to dim to 50% brightness; press
again to dim to 15%, press a 3rd time to enter AUTO DIM mode.
NOTE: Pressing and holding the “ ” button for 5 seconds will disable the
backlight. Once any button is pressed, the backlight will return to your selected
setting.
AUTO DIM MODE: Automatically adjusts display brightness based on time of day.
6:00 a.m. - 9:00 p.m. = 100% brightness
9:01 p.m. - 5:59 a.m.= 15% brightness
8

.
1111
\ I /
--o.,.
--
/ I \ '
~r-7~ ))})
1----1 --------I
Placement for Maximum Accuracy
AcuRite sensors are sensitive to surrounding environmental conditions. Proper
placement of both the display and outdoor sensor are critical to the accuracy
and performance of this product.
Display Placement
Place the display in a dry area free of dirt and dust. Display
stands upright for tabletop use and is wall-mountable.
Outdoor Sensor Placement
Sensor must be placed outside to observe outdoor conditions.
Sensor is water resistant and is designed for general outdoor
use, however, to extend its life place the sensor in an area
protected from direct weather elements.
Hang the sensor using the integrated hang hole or hanger,
or by using string (not included) to hang it from a suitable
location, like a well covered tree branch. The best location is
4 to 8 feet (1 to 2 metres) above the ground with permanent
shade and plenty of fresh air to circulate around the sensor.
Important Placement Guidelines
•To ensure accurate temperature measurement, place units out of direct
sunlight and away from any heat sources or vents.
•Display and outdoor sensor must be within 330 ft (100 m) of each other.
•To maximize wireless range, place units away from large metallic items, thick
walls, metal surfaces, or other objects that may limit wireless communication.
•To prevent wireless interference, place both units at least 3 ft (90 cm) away
from electronic devices (TV, computer, microwave, radio, etc.).
(330 feet)
3 feet
(90 cm)
(100 metres maximum)
Setup is Complete
The sensor will now synchronize with the display. It may take a few minutes for
synchronization to complete. Please refer to the troubleshooting section of this
manual if anything appears to be functioning improperly.
9

c3 cC'>
,.,.,.,.,
.,,./,,,J.,..,/'/41'/I,
/\. V
/\.
V
OPERATION
Using the Weather Station
Weather Forecast
Self-calibrating forecasting uses a unique algorithm to analyze changes in
pressure over a time period (called Learning Mode) to determine your altitude.
After 14 days, the icon disappears from the display screen. At this point,
the self-calibrated pressure is tuned in to your location and the unit is ready for
superior weather prediction.
STORMY
& WINDY
(flashing=stormy)
SNOW
LIKELY
SNOW / RAIN
MIX LIKELY
CHANCE
OF RAIN
CLOUDY
Moon Phase
Track the phases of the moon, conveyed through simple lunar phase icons:
NEW WAXING 1ST FULL 3RD WANING
CRESCENT QUARTER QUARTER CRESCENT
Barometric Pressure
Subtle variations in barometric pressure greatly affect the weather. This
weather station displays the current pressure with an arrow icon to indicate
the direction the pressure is trending (FALLING, STEADY, or RISING).
High and Low Records
High and low records for today and all-time are displayed for indoor and
outdoor temperature and humidity. Today’s records automatically clear at
12:00am midnight every day.
Press the “ “ and ““buttons to cycle through high and low recorded
values for outdoor and indoor temperature and humidity. While viewing all-time
records, a date and timestamp are shown for when each value was recorded.
You will automatically exit records if no buttons are pressed for 8 seconds.
To manually clear a HIGH or LOW record, press and HOLD both the “ “ and
““ buttons simultaneously for 3 seconds while viewing the record(s) you wish
to clear. Dashes display to conrm you have cleared the record(s).
10
