ACU-RITE 06025RM User manual

Instruction Manual
SAVE THIS MANUAL FOR FUTURE REFERENCE.
Questions? Contact Customer Support at
[phone] or visit www.AcuRite.com.
Display for 5-in-1 Weather Sensor
06025RM
Package Contents
1. Display unit with tabletop stand
2. Power adapter
3. Instruction Manual
This product requires an AcuRite 5-in-1 Weather Sensor (sold separately) to be
operational.
PRODUCT REGISTRATION
Register online
to receive 1 year
warranty protection
www.AcuRite.com
IMPORTANT PRODUCT MUST BE REGISTERED
TO RECEIVE WARRANTY SERVICE
►
Register a Product

2
Features & Benets
Display Unit
1
2
3
4
5
6
7
8
9
10
23
19
17
15
16
14
22
21
20
28
30
31 2425
26
18
27
11 12 13
29

3
1. Current Outdoor Temperature
Arrow icon indicates direction the
temperature is trending.
2. Outdoor Sensor Signal Strength
3. Sensor Low Battery Indicator
4. Current Outdoor Humidity
Arrow icon indicates the direction the
humidity is trending.
5. Date
6. Weather Select
Displays heat index, dew point, wind
chill, “feels like” calculations, days
with rain this month, and days
since last rain.
7. Learning Mode Icon
Disappears after weather forecast
self-calibration is complete.
8. 12 to 24 Hour Weather Forecast
Self-Calibrating Forecasting pulls
data from your 5-in-1 sensor to
generate your personal forecast.
9. Auto or Manual Pressure Mode
Indicates pressure mode preference.
AUTO Pressure Mode
Pressure will self-calibrate over a
14 day Learning Mode.
MANUAL Pressure Mode
Indicates raw pressure value,
no adjustment for sea level (can be
calibrated).
10. Barometric Pressure
Arrow icon indicates the direction the
pressure is trending.
11. SELECT Button
Press to change the Weather Select
category data being display.
12. “ V “, SET, “T“Buttons
for setup preferences and access to
historical records.
13. RAINFALL Button
Press to display historical rainfall
data.
14. Date Stamp for Previous Rainfall
Data (#15)
15. Previous Rainfall Data
16. Storm Alert Warning Icon
17. Current Rainfall
Rainfall recorded since 12:00am.
18. Auto Dim Indicator
19. Heavy Rainfall Warning Icon
Activated when over 1 inch of rainfall
is recorded in under 2 hours.
20. Clock
21. Current Indoor Humidity
Arrow icon indicates the direction the
humidity is trending.
22. Display Low Battery Indicator
23. Current Indoor Temperature
Arrow icon indicates the direction the
temperature is trending.
24. Peak Wind Speed
Highest speed from past 60 minutes.
25. Wind Speed Warning Icon
Activated when peak wind speed is
over 50 mph.
26. Current Wind Speed
27. Backlight Button
for momentary backlight and
dimmer settings.
28. Current Wind Direction
29. Previous 2 Wind Directions
30. Average Wind Speed
Average of all speeds over the
past 2 minutes.
31. HIGH/LOW Icons
HIGH indicates a high record is
shown on the display. LOW indicates
a low record is shown.

4
Back of Display Unit
BACK OF DISPLAY UNIT
1. Integrated Hang Hole
for easy wall mounting.
2. Plug-in for Power Adapter
3. Battery Compartment
4. Removable Tabletop Stand
5. CLEAR RECORD / RESET Button
Press to clear record currently being
viewed. Press AND HOLD for full
reset to factory defaults.
6. A-B-C Switch
ID code that must match 5-in-1
 sensor’sA-B-Cswitchtoensure
units synchronize.
7. Power adapter
8. Battery Compartment Cover
(not shown)
1
3
2
4
6
5
7

5
PLEASE DISPOSE OF OLD OR DEFECTIVE BATTERIES IN AN ENVIRONMENTALLY SAFE
WAY AND IN ACCORDANCE WITH YOUR LOCAL LAWS AND REGULATIONS.
BATTERY SAFETY: Clean the battery contacts and also those of the device prior to battery installation. Remove batteries from equipment which is not to be
used for an extended period of time. Follow the polarity (+/-) diagram in the battery compartment. Promptly remove dead batteries from the device. Dispose of used
batteries properly. Only batteries of the same or equivalent type as recommended are to be used. DO NOT incinerate used batteries. DO NOT dispose of batteries in fire,
as batteries may explode or leak. DO NOT mix old and new batteries or types of batteries (alkaline/standard). DO NOT use rechargeable batteries. DO NOT recharge
non-rechargeable batteries. DO NOT short-circuit the supply terminals.
Display Unit Setup
AcuRite recommends high quality alkaline batteries for the best product
performance. Heavy duty or rechargeable batteries are not recommended.
Set the A-B-C Switch
The A-B-C switch is
located inside the battery
compartment. It can be set to
A, B or C. However, you must
select the same letter choices
for both the sensor and the
display unit in order for the
units to synchronize.
1
Install or Replace Batteries
(optional)
Insert 6 x AA alkaline batteries into
the battery compartment, as shown.
Follow the polarity (+/-) diagram in
the battery compartment.
2
A B C
IMPORTANT:
Batteries are a
backup power
source to preserve
records in the event
of a power outage.
Power adapter is
recommended as
the primary power
source to enjoy the
full functionality of
this product.
SETUP

6
Set the Time, Date & Units
Press the “SET” button, located on the front of the display unit, to enter SET
MODE. Once in set mode, the preference you are currently setting will blink on
the display.
Toadjustthecurrentlyselected(ashing)item,pressandreleasethe“T“ or
“ V “ buttons (press and HOLD to fast adjust).
To save your adjustments, press and release the “SET” button again to adjust
the next preference. The preference set order is as follows:
CLOCK HOUR
CLOCK MINUTE
CALENDAR MONTH
CALENDAR DATE
CALENDAR YEAR
TEMPERATURE UNITS (ºF or ºC)
WIND UNITS (MPH, KPH, or Knots)
RAIN UNITS (inches or mm)
PRESSURE UNITS (inHg or hPa)
You will automatically exit SET MODE if no buttons are pressed for 20 seconds.
Enter setup mode at any time by pressing the “SET” button.
Display Backlight Settings
Thisweatherstation’sdisplayfeaturesthreedifferentlightingsettings:High
(100%) brightness, Medium (60%) brightness and Low (30%) brightness
Using battery power alone, the backlight is available momentarily for 10
seconds by pressing the “ ” button.
When display is powered with the power adapter, backlight remains on at
100% brightness. Press “ ” button once to dim to 60% brightness; press
again to dim to 30%, press a 3rd time to enter “AUTO DIM” mode. “AUTO
DIM” appears below time.
AUTO DIM MODE: Automatically adjusts display brightness based on time of day & year.
MARCH 11- NOVEMBER 4 6:00 a.m. - 9:00 p.m. = 100% brightness
9:01 p.m. - 5:59 a.m.= 30% brightness
NOVEMBER 5 - MARCH 10 7:30 a.m. - 7:00 p.m.= 100% brightness
7:01 p.m. - 7:29 a.m. = 30% brightness

7
Placement for Maximum Accuracy
AcuRite sensors are sensitive to surrounding environmental conditions. Proper
placement of both the display unit and the sensor are critical to the accuracy
and performance of this product.
Display Unit Placement
Place the display unit in a dry area free of dirt and dust. To
ensure accurate temperature measurement, place out of direct
sunlight and away from heat sources or vents. Display unit stands
upright for tabletop use or is wall-mountable.
OPERATION
Using the Professional Weather Center
Learning Mode
Self-Calibrating Forecasting use a unique algorithm to analyze changes in
pressure over a time period (called Learning Mode) to determine your altitude.
After 14 days, the Learning Mode icon disappears from the display screen. At
this point, the self-calibrated pressure is tuned in to your location and the unit is
ready for superior weather prediction.
Weather Forecast
AcuRite’spatentedSelf-CalibratingForecastingprovidesyourpersonalforecast
of weather conditions for the next 12 to 24 hours by collecting data from
the sensor in your backyard. It generates a forecast with pinpoint accuracy -
personalized for your exact location.
View the complete list of icons at www.AcuRite.com/acurite-icons
Weather Select
Weather Select displays data including wind chill, dew point, heat index, feels
like, days with rain this month, and days since last recorded rainfall. To change
the “Weather Select” category shown, press the “SELECT” button on the front
of the display. To clear a record, view one of the values listed above and press
the “CLEAR RECORD/RESET” button, located on the back of the unit in the
batterycompartment.Dashesdisplaytoconrmtherecordhasbeencleared
SNOW / RAIN
MIX LIKELY
RAIN
LIKELY
SNOW
LIKELY
STORMY
& WINDY
MOSTLY
CLOUDY
(flashing=stormy)

8
Barometric Pressure
Subtle variations in barometric pressure greatly affect the weather. This
weather station displays the current pressure with an arrow icon to indicate
the direction the pressure is trending (FALLING, STEADY, or RISING).
High & Low Records
Press the “T“buttononcetodisplaytoday’shighrecordsorthe“ V “ button
oncetodisplaytoday’slowrecordsforindoorandoutdoortemperatureand
humidity.Today’srecordsautomaticallyclearat12:00ammidnighteveryday
Press the “T“ or “ V “ button a second time to review the all-time high or low
records (shown one at a time) for: outdoor temperature, indoor temperature,
outdoor humidity, indoor humidity. You will automatically exit the records if no
buttons are pressed for 5 seconds.
To manually clear a record from memory, press the “CLEAR RECORD/RESET”
button, located in the battery compartment of the display unit, while viewing
the record you want to clear (rainfall OR temperature/humidity).
To clear ALL records, press AND HOLD the “CLEAR RECORD/RESET” button.
Rainfall Tracking
This weather station features enhanced tracking of historical rainfall data. Rain
accumulation data is recorded for today, over all-time, by year, by month, and
by rainfall event.
Press the “RAINFALL” button to review rainfall records. The icon is shown
on the display while historical data is being viewed.
TOTAL RAINFALL
FOR DATE SHOWN
TOTAL RAINFALL
FOR MONTH SHOWN
CURRENT YEAR
TOTAL RAINFALL
ALL-TIME
TOTAL RAINFALL
PREVIOUS YEAR
TOTAL RAINFALL

9
Records are shown in the following order:
PREVIOUS RAINFALL #1*
PREVIOUS RAINFALL #2*
PREVIOUS RAINFALL #3*
CURRENT MONTH TOTAL RAINFALL
PREVIOUS MONTH TOTAL RAINFALL
2 MONTHS AGO TOTAL RAINFALL
CURRENT YEAR TOTAL RAINFALL
PREVIOUS YEAR TOTAL RAINFALL
ALL-TIME TOTAL RAINFALL (date shown is start date of the all-time total;
the date the display was powered on)
*Previous rainfall is the amount of rain recorded from 12:00am to 11:59pm on
the date shown.
Care & Maintenance
Display Unit Care
Clean with a soft, damp cloth. Do not use caustic cleaners or abrasives. Keep away
from dust, dirt and moisture. Clean ventilation ports regularly with a gentle puff of air.
Calibration
The indoor / outdoor temperature and humidity readings, and barometric
pressure can be calibrated on the display unit to improve accuracy. Calibration
can improve accuracy when sensor placement or environmental factors impact
the data accuracy.
1. To access calibration mode, press AND HOLD the “T“ and “ V “ buttons
simultaneously for at least 5 seconds.
2.Toadjustthecurrentlyselected(ashing)item,pressandreleasethe“T“
or “ V “ buttons to calibrate the data value higher or lower from the actual
reading.
3. To save your adjustments, press and release the “SET” button to adjust the
next preference. The “ ” icon will remain illuminated next to calibrated
values.
The preference set order is as follows:
OUTDOOR TEMPERATURE
OUTDOOR HUMIDITY
INDOOR TEMPERATURE
INDOOR HUMIDITY
BAROMETRIC PRESSURE (must be set to MANUAL mode to calibrate)*
*To change from AUTO to MANUAL pressure mode and vice versa, press
AND HOLD the “SET” button for at least 10 seconds. The display indicates
the current pressure mode selected,“AUTO” or “MANUAL”.

10
After 20 seconds of inactivity, the display will save the adjustments and exit
calibration mode. Note: Calibrations will be erased if the display is reset or if
batteries are removed and the power adapter is unplugged.
Specications
TEMPERATURE RANGE Outdoor: -40ºF to 158ºF; -40ºC to 70ºC
Indoor: 32ºF to 122ºF; 0ºC to 50ºC
HUMIDITY RANGE Outdoor: 1% to 99%
Indoor: 1% to 99%
WIND SPEED 0 to 99 mph; 0 to 159 kph
WIND DIRECTION
INDICATORS 16 points
RAINFALL 0 to 99.99in; 0 to 9999mm
WIRELESS RANGE 330ft / 100m depending on home construction materials
OPERATING FREQUENCY 433 MHz
POWER Display: 5v power adapter
6 x AA alkaline batteries (optional)
Sensor: 4 x AA alkaline or lithium batteries
DATA REPORTING Wind Speed: 18 second updates; Direction: 30 seconds
Outdoor temperature & humidity: 36 second updates
Indoor temperature & humidity: 60 second updates
If your AcuRite product does not operate properly,
visit www.AcuRite.com or call [phone] for assistance.
For more information, visit our Knowledge Base at http://www.AcuRite.com/kbase
