Adamson IS Series User manual

Adamson Systems Engineering |
Table of Contents
Read these instructions, keep them available for reference.
This manual can be downloaded from
Heed all warnings and follow all instructions.
A qualifi ed technician must be present during the installation and use of this product. This product
is capable of producing extremely high sound pressure levels and should be used according to the
specifi ed local sound level regulations and good judgement. Adamson Systems Engineering will
not be liable for damages caused by any possible misuse of this product.
Servicing is required when the loudspeaker has been damaged in any way, such as when the
loudspeaker has been dropped; or when for undetermined reasons the loudspeaker does not
operate normally. Inspect your products regularly for any visual or functionality irregularities.
Protect the cabling from being walked on or pinched.
Read the appropriate IS-Series Rigging Manual before installing the product.
Pay attention to rigging instructions included in both Blueprint AV™ and the IS-Series Rigging
Manual.
Use only with the rigging frames/accessories specifi ed by Adamson, or sold with the loudspeaker
system.
This speaker enclosure is capable of creating a strong magnetic fi eld. Please use caution around
the enclosure with data storage devices such as hard drives.
Safety & Warnings
______________________________________________________________________________________
______________________________________________________________________________________
______________________________________________________________________________________
______________________________________________________________________________________
______________________________________________________________________________________
______________________________________________________________________________________
______________________________________________________________________________________
3
4
5
6
7
8
9
In an effort to continuously improve its products, Adamson releases
updated accompanying software, presets and standards for its products.
Adamson reserves the right to change the specifications of its
products and the content of its documents with no prior notice.
Page 1
IS7 User Manual

Distribution Date: May 1st, 2021
Copyright 2021 by Adamson Systems Engineering Inc.; all rights reserved
This manual must be accessible to the person operating this product. As such, the product owner must store it in a safe
place and make it available upon request to any operator.
Resale of this product must include a copy of this manual.
This manual can be downloaded from
Declarations
EU Declaration of Conformity
Adamson Systems Engineering declares that the
products stated below are in conformance with the
relevant fundamental health and safety criteria of the
applicable EC Directive(s), in particular:
Signed at Port Perry, ON. CA - May 1st, 2021
------------------------------------------------
Brock Adamson (President & CEO)
ADAMSON SYSTEMS ENGINEERING, Inc.
1401 Scugog Line 6, Port Perry (ON), L9L 1B2, Ontario,
Canada
T: [phone], F: [phone]
Email: [email protected]
Website: www.adamsonsystems.com
IS7 User Manual
Directive 2014/35/EU: Low Voltage Directive
IS7 - 971-0003, 971-0004, 971-0006, 971-5003,
971-5004, 971-5006
Directive 2006/42/EC: Machinery Directive
IS7/IS118 Rigging Frame - 930-0026, 930-5026
Extended Beam - 930-0021, 930-5021
Moving Point Extended Beam - 930-0033, 930-5033
IS7 Micro Frame - 930-0029, 930-5029
Extended Lifting Plates - 932-0043
Line Array H-Clamp - 932-0047
https://adamsonsystems.com/support/downloads-directory/is-series/is7

Adamson Systems Engineering |
Table of Contents
Read these instructions, keep them available for reference.
This manual can be downloaded from
Heed all warnings and follow all instructions.
A qualifi ed technician must be present during the installation and use of this product. This product
is capable of producing extremely high sound pressure levels and should be used according to the
specifi ed local sound level regulations and good judgement. Adamson Systems Engineering will
not be liable for damages caused by any possible misuse of this product.
Servicing is required when the loudspeaker has been damaged in any way, such as when the
loudspeaker has been dropped; or when for undetermined reasons the loudspeaker does not
operate normally. Inspect your products regularly for any visual or functionality irregularities.
Protect the cabling from being walked on or pinched.
Read the appropriate IS-Series Rigging Manual before installing the product.
Pay attention to rigging instructions included in both Blueprint AV™ and the IS-Series Rigging
Manual.
Use only with the rigging frames/accessories specifi ed by Adamson, or sold with the loudspeaker
system.
This speaker enclosure is capable of creating a strong magnetic fi eld. Please use caution around
the enclosure with data storage devices such as hard drives.
Safety & Warnings
______________________________________________________________________________________
______________________________________________________________________________________
______________________________________________________________________________________
______________________________________________________________________________________
______________________________________________________________________________________
______________________________________________________________________________________
______________________________________________________________________________________
3
4
5
6
7
8
9
In an effort to continuously improve its products, Adamson releases
updated accompanying software, presets and standards for its products.
Adamson reserves the right to change the specifications of its
products and the content of its documents with no prior notice.
Page 3
IS7 User Manual
https://www.adamsonsystems.com/en/support/downloads-directory/is-series/is7
1. Safety & Warnings
2. Product Introduction
3. Wiring
4. Amplication
5. Presets & Control
6. Weatherized
7. Technical Specications

Adamson Systems Engineering | Page 4
IS7 User Manual
IS7
• The IS7 is an ultra-compact line array enclosure designed for medium throw applications. It contains two
symmetrically arrayed 7” LF transducers and a 3” HF compression driver mounted onto an Adamson sound
chamber. The high frequency sound chamber is designed to couple multiple cabinets across the entire intended
frequency band without loss of coherence.
• The operational frequency range of the IS7 is 80 Hz to 18 kHz. The use of proprietary technologies such as
Controlled Summation Technology and Advanced Core Architecture allow high maximum SPL and maintains a
consistent nominal horizontal dispersion pattern of 100° down to 400 Hz.
• The enclosure has an unobtrusive visual design which blends seamlessly into the surrounding space, is made of
marine grade birch plywood, and has a four-point rigging system. Without sacricing low resonance to composite
material, the IS7 weighs only 14 kg / 30.9 lbs.
• Up to sixteen IS7 can be flown in the same array when using the IS7/IS118 Rigging Frame and up to eight when
using the IS7 Micro Frame. Nine rigging positions are available, allowing vertical inter-cabinet splay angles from
0° to 10°. Always consult Blueprint AV™ and the IS-Series Line Array Rigging Manual for correct rigging positions
(including ground stacking options) and installation procedures.
• The IS7 is intended to be used as a standalone system or with the IS118 companion subwoofer, which brings the
usable frequency range down to 35 Hz. The IS7 can also be paired with other IS-Series subwoofers.
• The IS7 is designed for use with Lab.gruppen’s D-Series line of installation ampliers. The nominal impedance of
the IS7 is 16 Ω per band, maximizing amplier efciency.
IS7 Ultra Compact Line Array

Adamson Systems Engineering | Page 5
IS7 User Manual
IS7
IS7 Jackplate IS7b Jackplate
IS7 & IS7b Internal Wiring (IS7b has only one input)
• The IS7 (971-0003, 971-5003) comes with 2x Neutrik Speakon™ NL4 connections, wired in parallel.
• The IS7b (971-0004, 971-5004) comes with an external barrier strip.
• Pins 1+/- are connected to the 2x ND7-LM8 MF transducers, wired in parallel.
• Pins 2+/- are connected to the NH3-16 HF transducer.
1+
1-
2- MF
MF
HF
2+
1+
1-
2-
2+
PARALLEL
INPUT
PARALLEL
INPUT
PARALLEL INPUTS
PARALLEL INPUTS
Wiring

Adamson Systems Engineering | Page 6
IS7 User Manual
IS7
The IS7 is paired with Lab.gruppen D-Series ampliers.
Maximum quantities of the IS7 per amplier model are shown below.
For a master list, please refer to the Adamson Amplication Chart, found on the
Adamson website.
https://adamsonsystems.com/support/downloads-directory/design-and-control/e-
rack/283-amplication-chart-9/le
4x IS7
D40:4L D80:4L D80:4L D120:4L
8x IS7 2x IS118, 4x IS7 12x IS7
Amplification

Adamson Systems Engineering | Page 7
IS7 User Manual
IS7
IS7 Lipll
Intended for use with a
single IS7
IS7 Short
Intended for use with an array
of 4 to 6 IS7
IS7 Array
Intended for use with an
array of 7 to 11 IS7
The Adamson LoadLibrary (http://adamsonsystems.com/support/downloads-
directory/design-and-control/e-rack/245-adamson-load-library-5-0-1/le) contains
presets designed for a variety of IS7 applications. Each preset is intended to be phase-
linear with either the IS118 or IS119 subwoofers.
Array Shaping overlays (found in the Array Shaping folders of the Adamson Load Library) can be recalled in the EQ
section of Lake Controller to adjust the contour of the array. Recalling the appropriate EQ overlay or preset for the
number of cabinets being used will give the standard Aamson frequency response of your array, compensating for
different low-frequency coupling.
Tilt overlays (found in the Array Shaping folders of the Adamson Load Library) can be used to alter the overall acoustic
response of an array. Tilt overlays apply a lter, centered at 1kHz, which reaches the noted decibel cut or boost at the
extreme ends of the listening spectrum. For example, a +1 Tilt will apply +1 decibel at 20 kHz and -1 decibel at 20 Hz.
Alternately, a -2 Tilt will apply -2 decibels at 20 kHz and +2 decibels at 20 Hz.
Please refer to the Adamson PLM & Lake Handbook for detailed instructions on recalling Tilt and Array Shaping
overlays. https://adamsonsystems.com/support/downloads-directory/design-and-control/e-rack/205-adamson-
plm-lake-handbook/le
Control
Presets
When cabinets and subwoofers are positioned separately, phase alignment
should be measured with suitable software.

Adamson Systems Engineering | Page 8
IS7 User Manual
IS7
Weatherized
IS-Series weatherized models add an additional layer of environmental and corrosion protection to Adamson’s already
durable cabinet design. Weatherized enclosures are ideal for marine and coastal venues, outdoor stadiums, open-air
performance spaces, and other permanent outdoor installations.
IS-Series weatherized cabinets feature the following additional protective features.
Corrosion resistance
Corrosion resistance extends the lifetime performance of your system in outdoor venues where water, salt and acidity
can impact durability and function.
All structural steel elements of Adamson weatherized cabinets – including rigging and rigging links – are made of a
high yield strength stainless steel alloy that offers 100% corrosion resistance.
Cabinet hardware is made of non-plated stainless steel, designed to provide exceptional rust and corrosion resistance,
particularly in high-saline environments.
Environmental sealing
Additional protection of the cabinet helps ensure that loudspeaker performance isn’t impeded by the harsh
environments in which your system is deployed.
To guard against water and particle intrusion, the same two-part polyurea coating that gives Adamson cabinets their
life-extending exterior protection is applied to the interior of the enclosure, creating a complete seal. Weatherized
models feature an exterior coating with a distinctive smooth nish that allows for easy cleaning and removal of
contaminants like dirt, grime, salt water or sand.
To protect against dust and other particles, a ne stainless steel mesh has been added to all points of entry including
behind the front grille screens.
Cabling for the IS-Series weatherized cabinets is pre-wired and protected inside a gasket-sealed jackplate, with gland
nuts in place to seal the connection points.
ADAMSON | IS7w

Adamson Systems Engineering | Page 9
IS7 User Manual
IS7
**12 dB crest factor pink noise at 1m, free eld, using specied processing and amplication
527 mm / 20.75 in
401 mm / 15.8 in
236 mm / 9.3 in
122 mm / 4.8 in
Frequency Range (- 6 dB) 80 Hz - 18 kHz
Nominal Directivity (-6 dB) H x V 100° x 12.5°
Maximum Peak SPL** 138
Components LF 2x ND7-LM8 7” Neodymium Driver
Components HF NH3 3” Diaphragm / 1.4” Exit Compression
Driver
Nominal Impedance LF 16 Ω (2 x 8 Ω)
Nominal Impedance HF 16 Ω
Power Handling (AES / Peak) LF 500 / 2000 W
Power Handling (AES / Peak) HF 110 / 440 W
Rigging Integrated Rigging System
Connection 2x Speakon™ NL4 or Barrier Strips
Height Front (mm / in) 236 / 9.3
Height Back (mm / in) 122 / 4.8
Width (mm / in) 527 / 20.75
Depth (mm / in) 401 / 15.8
Weight (kg / lbs) 14 / 30.9
Colour Black & White (RAL 9010 as standard, other
RAL colours on demand)
Processing Lake
800 Hz 1.5 kHz 3 kHz 6 kHz 20 kHz10 kHz400 Hz200 Hz100 Hz
0°
180°
180°
90°
90°
IS7 Horizontal Pattern
Technical Specifications
