Adamson IS Series User manual

Adamson Systems Engineering |
Table of Contents
Read these instructions, keep them available for reference.
This manual can be downloaded from
Heed all warnings and follow all instructions.
A qualifi ed technician must be present during the installation and use of this product. This product
is capable of producing extremely high sound pressure levels and should be used according to the
specifi ed local sound level regulations and good judgement. Adamson Systems Engineering will
not be liable for damages caused by any possible misuse of this product.
Servicing is required when the loudspeaker has been damaged in any way, such as when the
loudspeaker has been dropped; or when for undetermined reasons the loudspeaker does not
operate normally. Inspect your products regularly for any visual or functionality irregularities.
Protect the cabling from being walked on or pinched.
Read the appropriate IS-Series Rigging Manual before installing the product.
Pay attention to rigging instructions included in both Blueprint AV™ and the IS-Series Rigging
Manual.
Use only with the rigging frames/accessories specifi ed by Adamson, or sold with the loudspeaker
system.
This speaker enclosure is capable of creating a strong magnetic fi eld. Please use caution around
the enclosure with data storage devices such as hard drives.
Safety & Warnings
______________________________________________________________________________________
______________________________________________________________________________________
______________________________________________________________________________________
______________________________________________________________________________________
______________________________________________________________________________________
______________________________________________________________________________________
______________________________________________________________________________________
3
4
5
6
7
8
9
In an effort to continuously improve its products, Adamson releases
updated accompanying software, presets and standards for its products.
Adamson reserves the right to change the specifications of its
products and the content of its documents with no prior notice.
Page 1
IS10 User Manual

IS10n User Manual
Distribution Date: May 1st, 2021
Copyright 2021 by Adamson Systems Engineering Inc.; all rights reserved
This manual must be accessible to the person operating this product. As such, the product owner must store it in a safe
place and make it available upon request to any operator.
Resale of this product must include a copy of this manual.
This manual can be downloaded from
Declarations
EU Declaration of Conformity
Adamson Systems Engineering declares that the
products stated below are in conformance with the
relevant fundamental health and safety criteria of the
applicable EC Directive(s), in particular:
Signed at Port Perry, ON. CA - May 1st, 2021
------------------------------------------------
Brock Adamson (President & CEO)
ADAMSON SYSTEMS ENGINEERING, Inc.
1401 Scugog Line 6, Port Perry (ON), L9L 1B2, Ontario,
Canada
T: [phone], F: [phone]
Email: [email protected]
Website: www.adamsonsystems.com
Directive 2014/35/EU: Low Voltage Directive
IS10n - 973-0008, 973-0009, 973-0011, 973-5008,
973-5009, 973-5011
Directive 2006/42/EC: Machinery Directive
IS10 & IS119 Support Frame - 930-0028, 930-0035,
930-5028
Extended Beam - 930-0021, 930-5021
Moving Point Extended Beam - 930-0033, 930-5033
IS10 Micro Frame - 930-0030, 930-5030
Line Array H-Clamp - 932-0037
https://www.adamsonsystems.com/en/support/downloads-directory/is-series/is10n

Adamson Systems Engineering |
Table of Contents
Read these instructions, keep them available for reference.
This manual can be downloaded from
Heed all warnings and follow all instructions.
A qualifi ed technician must be present during the installation and use of this product. This product
is capable of producing extremely high sound pressure levels and should be used according to the
specifi ed local sound level regulations and good judgement. Adamson Systems Engineering will
not be liable for damages caused by any possible misuse of this product.
Servicing is required when the loudspeaker has been damaged in any way, such as when the
loudspeaker has been dropped; or when for undetermined reasons the loudspeaker does not
operate normally. Inspect your products regularly for any visual or functionality irregularities.
Protect the cabling from being walked on or pinched.
Read the appropriate IS-Series Rigging Manual before installing the product.
Pay attention to rigging instructions included in both Blueprint AV™ and the IS-Series Rigging
Manual.
Use only with the rigging frames/accessories specifi ed by Adamson, or sold with the loudspeaker
system.
This speaker enclosure is capable of creating a strong magnetic fi eld. Please use caution around
the enclosure with data storage devices such as hard drives.
Safety & Warnings
______________________________________________________________________________________
______________________________________________________________________________________
______________________________________________________________________________________
______________________________________________________________________________________
______________________________________________________________________________________
______________________________________________________________________________________
______________________________________________________________________________________
3
4
5
6
7
8
9
In an effort to continuously improve its products, Adamson releases
updated accompanying software, presets and standards for its products.
Adamson reserves the right to change the specifications of its
products and the content of its documents with no prior notice.
Page 3
IS10 User Manual
https://www.adamsonsystems.com/en/support/downloads-directory/is-series/is10n
1. Safety & Warnings
2. Product Introduction
3. Wiring
4. Amplication
5. Presets & Control
6. Weatherized
7. Technical Specications
Page 3
IS10 User Manual

Adamson Systems Engineering | Page 4 IS10n User Manual
IS10n
• The IS10n is a sub-compact line array enclosure designed for extended throw capabilities. It contains two
symmetrically arrayed 10” transducers and a 4” compression driver mounted on an Adamson sound chamber.
The high frequency sound chamber is designed to couple multiple cabinets across the entire intended frequency
band without loss of coherence.
• The operational frequency range of the IS10n is 60 Hz to 18 kHz. The use of proprietary technologies such as
Controlled Summation Technology and Advanced Core Architecture allow high maximum SPL and maintains a
consistent nominal horizontal dispersion pattern of 80° down to 400 Hz.
• The enclosure has an unobtrusive visual design which blends seamlessly into the surrounding space, is made of
marine grade birch plywood, and has a four-point rigging system. Without sacricing low resonance to composite
material, the IS10n is able to maintain a low weight of 25.6 kg / 56.5 lbs.
• Up to twenty IS10n can be flown in the same array when using the IS10 & IS119 Support Frame and up to 4 when
using the IS10 Micro Frame. Nine rigging positions are available allowing vertical inter-cabinet splay angles from
0° to 10°. Always consult Blueprint AV™ and the IS-Series Line Array Rigging Manual for correct rigging positions
(including ground stacking options) and installation procedures.
• The IS10n is intended to be used as a standalone system or with the IS119 companion subwoofer, which brings
the usable frequency range down to 30 Hz. The IS10n can also be paired with other IS-Series subwoofers.
• The IS10n is designed for use with Lab.gruppen’s D-Series line of installation ampliers. The nominal impedance of
the IS10n is 8 Ω per band, maximizing amplier efciency.
IS10n Sub Compact Line Array

Adamson Systems Engineering | Page 5 IS10n User Manual
IS10n
IS10n Jackplate IS10nb Jackplate
IS10n & IS10nb Internal Wiring (IS10nb only has one input)
• The IS10n (973-0008, 973-5008) comes with 2x Neutrik Speakon™ NL4 connections, wired in parallel.
• The IS10nb (973-0009, 973-5009) comes with an external barrier strip.
• Pins 1+/- are connected to the 2x ND10-LM MF transducers, wired in parallel.
• Pins 2+/- are connected to the NH4TA2 HF transducer.
1+
1-
2-
MF
MF
HF
2+
1+
1-
2-
2+
PARALLEL
INPUT
PARALLEL
INPUT
PARALLEL INPUTS
PARALLEL INPUTS
Wiring

Adamson Systems Engineering | Page 6 IS10n User Manual
IS10n
The IS10n is paired with Lab.gruppen D-Series ampliers.
Maximum quantities of the IS10n, or IS10n paired with IS119 per amplier model are shown below.
For a master list, please refer to the Adamson Amplication Chart, found on our website.
https://adamsonsystems.com/support/downloads-directory/design-and-control/e-rack/283-amplication-chart-9/le
2x IS10n
D40:4L D80:4L D120:4L D120:4L
4x IS10n 8x IS10n 2x IS119, 4x IS10n
Amplification

Adamson Systems Engineering | Page 7 IS10n User Manual
IS10n
Presets
IS10n Compact
Intended for use with an
array of 4 IS10n
IS10n Short
Intended for use with an
array of 5-6 IS10n
IS10n Array
Intended for use with an
array of 7-11 IS10n
The Adamson LoadLibrary (https://www.adamsonsystems.com/support/downloads-directory/design-and-control/e-
rack/245-adamson-load-library-5-0-1/le) contains presets designed for a variety of IS10n applications. Each preset is
intended to be phase-aligned within the EQ overlap region with IS-Series subwoofers.
Array Shaping overlays (found in the Array Shaping folders of the Adamson LoadLibrary) can be recalled in the EQ
section of Lake Controller to adjust the contour of the array. Recalling the appropriate EQ overlay or preset for the
number of cabinets being used will give the standard Adamson frequency response of your array, compensating for
different low-frequency coupling.
Tilt overlays (found in the Array Shaping folders of the Adamson LoadLibrary) can be used to alter the overall acoustic
response of an array. Tilt overlays apply a lter, centered at 1kHz, which reaches the noted decibel cut or boost at the
extreme ends of the listening spectrum. For example, a +1 Tilt will apply +1 decibel at 20kHz and -1 decibel at 20Hz.
Alternately, a -2 Tilt will apply -2 decibels at 20kHz and +2 decibels at 20Hz.
Please refer to the Adamson PLM & Lake Handbook for detailed instructions on recalling Tilt and Array Shaping
overlays. https://adamsonsystems.com/support/downloads-directory/design-and-control/e-rack/205-adamson-plm-
lake-handbook/le
Control
IS10n cabinets can be installed in an array with regular IS10 cabinets, however, IS10n
cabinets cannot share the same presets with IS10 cabinets.
When cabinets and subwoofers are positioned separately, phase alignment should be
measured with suitable software.

Adamson Systems Engineering | Page 8 IS10n User Manual
IS10n
Weatherized
IS-Series weatherized models add an additional layer of environmental and corrosion protection to Adamson’s
already durable cabinet design. Weatherized enclosures are ideal for marine and coastal venues, outdoor stadiums,
open-air performance spaces, and other permanent outdoor installations.
IS-Series weatherized cabinets feature the following additional protective features.
Corrosion resistance
Corrosion resistance extends the lifetime performance of your system in outdoor venues where water, salt and
acidity can impact durability and function.
All structural steel elements of Adamson weatherized cabinets – including rigging and rigging links – are made of
a high yield strength stainless steel alloy that offers 100% corrosion resistance.
Cabinet hardware is made of non-plated stainless steel, designed to provide exceptional rust and corrosion
resistance, particularly in high-saline environments.
Environmental sealing
Additional protection of the cabinet helps ensure that loudspeaker performance isn’t impeded by the harsh
environments in which your system is deployed.
To guard against water and particle intrusion, the same two-part polyurea coating that gives Adamson cabinets
their life-extending exterior protection is applied to the interior of the enclosure, creating a complete seal.
Weatherized models feature an exterior coating with a distinctive smooth nish that allows for easy cleaning and
removal of contaminants like dirt, grime, salt water or sand.
To protect against dust and other particles, a ne stainless steel mesh has been added to all points of entry
including behind the front grille screens.
Cabling for the IS-Series weatherized cabinets is pre-wired and protected inside a gasket-sealed jackplate, with
gland nuts in place to seal the connection points.
ADAMSON | IS10nw

Adamson Systems Engineering | Page 9 IS10n User Manual
IS10n
IS10n Horizontal Pattern - Grey = -6 dB, Black = -12 dB
**12 dB crest factor pink noise at 1m, free eld, using specied processing and amplication
Frequency Range (+/- 3dB) 60 Hz - 18 kHz
Nominal Directivity (-6 dB) H x V 80° x 10°
Maximum Peak SPL** 141.3 dB
Components LF 2x ND10-LM 10” Neodymium Driver
Components HF Adamson NH4TA2 4” Diaphragm / 1.5” Exit
Compression Driver
Nominal Impedance LF 8 Ω (2 x 16 Ω)
Nominal Impedance HF 8 Ω
Power Handling (AES / Peak) LF 700 / 2800 W
Power Handling (AES / Peak) HF 160 / 640 W
Rigging Integrated Rigging System
Connection 2x Speakon™ NL4 or Barrier Strips
Height Front (mm / in) 300 / 11.8
Height Back (mm / in) 175 / 6.9
Width (mm / in) 737 / 29
Depth (mm / in) 518 / 20.4
Weight (kg / lbs) 25.6 / 56.5
Colour Black & White (Standard), RAL Colours (On
Demand)
Processing Lake
737 mm / 29 in
300 mm / 11.8 in
175 mm / 6.9 in
800 Hz 1.5 kHz 3 kHz 6 kHz 20 kHz10 kHz400 Hz200 Hz100 Hz
0°
180°
180°
90°
90°
518 mm / 20.4 in
Technical Specifications
