Adamson IS Series User manual

• Distribution Date: June 1st, 2018
• Copyright 2019 by Adamson Systems Engineering Inc.; all rights reserved
This manual must be accessible to the person operating this product. As such, the product owner must store it in a safe
place and make it available upon request to any operator.
Resale of this product must include a copy of this manual.
If this manual becomes damaged or additional copies are needed, please email [email protected].
IS118 User Manual
Version 1.0
Directive 2006/95/EC: Low Voltage Directive
992-0010 IS118
992-0011 IS118b
971-0003 IS7
971-0004 IS7b
CE Declaration of Conformity
ADAMSON SYSTEMS ENGINEERING, Inc.
1401 Scugog Line 6, Port Perry (ON), L9L 1B2, Ontario,
Canada
T: [phone], F: [phone]
Email: [email protected]
Website: www.adamsonsystems.com
Adamson Systems Engineering declares that the prod-
ucts stated below are in conformance with the relevant
fundamental health and safety criteria of the applicable
EC Directive(s), in particular:
Established at Port Perry, ON. CA - June 1st, 2017
------------------------------------------------
Brock Adamson (President & CEO)
Directive 2006/42/EC: Machinery Directive
930-0026 IS7 & IS118 Support Frame
930-0021 S-Series Extended Beam
930-0022 S-Series Moving Point Extended Beam
930-0029 IS7 Micro Frame
932-0037 H-Clamp
Declarations

Page 3Page 3
Adamson Systems Engineering | IS118 User Manual
1. Safety & Warnings
2. Product Introduction
3. Wiring & Amplication
4. Presets & Control
5. Acoustic Data
3
4
5
7
8
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
Table of Contents
Safety & Warnings
• Read these instructions, keep them available for reference. They can be downloaded any time from https://
www.adamsonsystems.com/en/support/downloads-directory/is-series/is118 Heed all warnings and follow all
instructions.
• A qualied technician must be present during the installation and use of this product. This product is capable of
producing extremely high sound pressure levels and should be used according to the specied local sound level
regulations and good judgement. Adamson Systems Engineering will not be liable for damages caused by any
possible misuse of this product.
• Servicing is required when the loudspeaker has been damaged in any way, such as when the loudspeaker has been
dropped; or when for undetermined reasons the loudspeaker does not operate normally.
• Protect the cabling from being walked on or pinched.
• Read the IS-Series Rigging Manual before installing the IS118.
• Pay attention to rigging instructions included in both Blueprint AV™ and the IS-Series Rigging Manual.
• Use only with the rigging frames/accessories specied by Adamson, or sold with the loudspeaker system.
• This speaker enclosure is capable of creating a strong magnetic eld. Please use caution around the enclosure
with data storage devices such as hard drives.
Safety & Warnings

Page 4
Adamson Systems Engineering | IS118 User Manual
In an effort to continuously improve its products, Adamson releases updated accompanying software, presets and
standards for its products. Adamson reserves the right to change the specications of its products and the
content of its documents without prior notice.
• The IS118 is an ultra compact subwoofer enclosure designed for extended LF capabilities. It has an unobtrusive
visual design which blends seamlessly into the surrounding space, including identical grills at the front and back so
cardioiod deployments appear identical to non-cardioid. It contains one ND18-S 18” LF driver.
• Up to 16 IS118 can be flown when using the IS7 & IS118 Support Frame.
• The IS118 can be flown in the same array as the IS7 when using an additional IS7 & IS118 Support Frame.
• Adamson’s use of proprietary techologies such as Advanced Cone Architecture give the IS118 an extremely high
maximum SPL level of 133 dB. The nominal impedance of the IS118 is 8 Ω.
• The operational frequency range of the IS118 is 35 Hz to 100 Hz, +/- 3 dB.
• The IS118 is intended to be paired with the IS7 Ultra Compact Line Array with a crossover frequency range of 80 or
100 Hz, depending on the preset used.
• The wooden enclosure is made of marine grade birch plywood, and has an aluminum rigging system mounted
on each corner. Without sacricing lowered resonance to composite material, the IS118 is able to maintain a low
weight of 39 kg / 85 lbs.
• The IS118 is designed for use with Lab.gruppen’s D-Series line of installation ampliers.
Product Introduction
IS118 Ultra Compact Subwoofer

Page 5
Adamson Systems Engineering | IS118 User Manual
The IS118 (992-0010) comes with 4x Neutrik Speakon™ NL4 connections, wired in parallel. The 2 rear connections
pass pin 1 +/- to the driver and the 2 front connections pass pin 2 +/- to the driver.
The IS118b (992-0011) comes with an external barrier strip mounted to the rear grill. Terminals 1, +/- are passed to the
driver, terminal 2, +/- are not connected.
To operate the IS118b in FB or FBF cardioid mode, swap the front and rear grills by:
1. Removing the six screws holding each grill to the side rigging pieces
2. Unclipping the grill with the barrier strip from the rear PCB, and swapping the grills
3. Re-clipping the grill with the barrier strip to the front PCB and afx with the same screws
Page 5
Wiring & Amplication
Wiring
IS118 Rear
IS118 Front
IS118b Rear
Adamson Systems Engineering | IS118 User Manual

Page 6
Adamson Systems Engineering | IS118 User Manual
The IS118 is paired with Lab.gruppen D-Series ampliers. Maximum quantities of the IS118 per amplier model
are shown below. For a master list, please refer to the Adamson PLM & Lake Handbook, found on our website.
Use LoadSmart™ verication to ensure that all connections are made properly. On the D-Series line of ampliers,
LoadSmart™ can be accessed through Lake Controller. Please refer to the Adamson Lake & PLM Handbook, which is
included in the Adamson LoadLibrary, which can be found on the Adamson Website.
4x IS118
D40:4L D80:4L
8x IS118
D120:4L
12x IS118
Wiring & Amplication
Amplification
LoadSmart™

Page 7
Adamson Systems Engineering | IS118 User Manual
When flown in the same array as an IS7, all IS118 presets contain the inherent delay needed to be properly phase-
aligned. When flown separately or ground stacked, IS118 subs should be phase-aligned to the IS7 array using
measurement software.
Subwoofer Conguration Applicable Preset
Page 7
Presets & Control
Alignment
Presets
IS118 Xo 100 32dB
All IS118 forward facing
Omni pattern
IS118 FB Xo 100 32dB
Bottom IS118 forward facing,
top IS118 reversed
Cardioid pattern
IS118 FBF Xo 100 32dB
Bottom and top IS118 forward facing,
middle IS118 reversed
Cardioid pattern
Adamson Systems Engineering | IS118 User Manual
The Adamson LoadLibrary contains presets designed for 3 different IS118 deployments, with crossover points of 80
Hz and 100 Hz. For a master list, please refer the Adamson PLM & Lake Handbook, found on our website.

Page 8
Adamson Systems Engineering | IS118 User Manual
100 Hz35 Hz
0°
180°
180°
90°
90°
100 Hz35 Hz
0°
180°
180°
90°
90°
IS118 FB IS118 FBF
Acoustic Data
Cardioid Dispersion
Technical Specifications
**12 dB crest factor pink noise at 1m, half space, using specied processing and amplication
Frequency Range (+/- 3dB) 35 Hz - 80 Hz
Maximum Peak SPL** 133 dB
Components LF ND18-S 18” Kevlar Neodymium Driver
Nominal Impedance LF 8 Ω
Power Handling (AES / Peak) LF 500 / 2000 W
Rigging Integrated Rigging System
Connection 4x Speakon™ NL4 (2x Front 1+/1-, 2x Rear (2+/2-) or
Barrier Btrips
Height Front (mm / in) 528 / 20.8
Width (mm / in) 527 / 20.75
Depth (mm / in) 630 / 24.8
Weight (kg / lbs) 39 / 85
Colour Black & White (RAL 9010 as standard, other RAL
colours on demand)
Processing Lake
527 mm / 20.75 in
630 mm / 24.8 in 528 mm / 20.8 in
