Adaptec AHA-2740W User manual

Installation Guide
AHA-2740W/2742W Single-ended
AHA-2744W Differential
EISA-to-Fast, Wide SCSI Host Adapters
R
2740cov.doc Black 1

Adaptec, Inc.
691 South Milpitas Boulevard
Milpitas, CA 95035
Copyright © 1993, 1994, Adaptec, Inc.
All rights reserved. Adaptec and the Adaptec
logo are registered trademarks of Adaptec, Inc.
Printed in Singapore
STOCK NO.: 510646-00 Rev. A LL 8/94
Information subject to change without notice.
2740cov.doc Black 2

i
Copyright
Copyright © 1993, 1994 Adaptec, Inc. All rights reserved. No
part of this publication may be reproduced, stored in a retriev-
al system, or transmitted in any form or by any means; elec-
tronic, mechanical, photocopying, recording or otherwise,
without the prior written consent of Adaptec, Inc., 691 South
Milpitas Blvd., Milpitas, CA 95035.
Trademarks
Adaptec, the Adaptec logo, and AHA are registered trade-
marks; and EZ-SCSI is a trademark of Adaptec, Inc. MS-DOS
is a registered trademark of Microsoft Corporation. NetWare
is a registered trademark of Novell, Inc. OS/2 is a registered
trademark of International Business Machines Corporation.
UNIX is a registered trademark of Unix Systems Laboratories.
Changes
The material in this document is for information only and is
subject to change without notice. While reasonable efforts
have been made in the preparation of this document to assure
its accuracy, Adaptec, Inc. assumes no liability resulting from
errors or omissions in this document, or from the use of the
information contained herein.
Adaptec reserves the right to make changes in the product de-
sign without reservation and without notification to its users.
2740w-0.doc Black i

ii
Adaptec Technical Support
Adaptec products have been specifically developed for easy in-
stallation and use. We believe that our documents and the on-
screen instructions and help are complete and clear enough to
meet your needs. If you need more assistance, please contact us.
The Adaptec Electronic Bulletin Board Service (BBS) provides
information on software upgrades, new releases, technical ad-
vice, and other topics. The BBS is available 24 hours a day at
408-945-7727; 1200/2400/9600/14400 baud, 8 data bits, 1 stop
bit, no parity.
To contact the Adaptec Technical Support Hot Line, call
800-959-SCSI (7274) or 408-945-2550; M-F: 6:00 a.m. to
5:00 p.m., Pacific Time.
Interactive FAX Service
The Adaptec Interactive FAX Service provides the latest on-
line information about Adaptec products and services. The
Adaptec Interactive FAX Service is available 23 hours a day,
7 days a week, at 408-957-7150.
Ordering Software and Cables
To order Adaptec software and SCSI cables, call 800-442-SCSI
(7274), M-F: 6:00 a.m. to 5:00 p.m., Pacific Time. If you are
calling from outside the U.S. and Canada, the number is
408-957-SCSI (7274).
2740w-0.doc Black ii

iii
Literature Hotline
To request additional documentation for Adaptec products,
call 800-934-2766, M-F: 5:00 a.m. to 6:00 p.m., Pacific Time.
FCC Compliance Statement
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the
FCC rules. These limits are designed to provide reasonable
protection against harmful interference in residential installa-
tions. This equipment generates, uses, and can radiate radio
frequency energy, and if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interfer-
ence will not occur in a particular installation.
If this equipment does cause interference to radio or television
equipment reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Move the equipment away from the receiver
• Plug the equipment into an outlet on a circuit different
from that to which the receiver is powered
• If necessary, the user should consult the dealer or an
experienced radio/television technician for additional
suggestions
2740w-0.doc Black iii

iv
CAUTION: Only equipment certified to comply with Class B
(computer input/output devices, terminals, printers, etc.)
should be attached to this equipment, and must have shielded
interface cables.
Finally, any change or modifications to the equipment by the
user not expressly approved by the grantee or manufacturer
could void the user's authority to operate such equipment.
Each host adapter is equipped with an FCC compliance label
which shows only the FCC identification number. The full text
of the associated label follows:
This device complies with part 15 of the FCC rules. Opera-
tion is subject to the following two conditions: (1) this device
may not cause harmful interference and (2) this device must
accept any interference received, including interference that
may cause undesired operation.
2740w-0.doc Black iv

v
Table of Contents
Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Board Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Default Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
The Onboard Floppy Controller
(AHA-2742W and AHA-2744W Only) . . . . . . . . . 7
Installing the Host Adapter . . . . . . . . . . . . . . . . . . . . . . 8
Cabling the Host Adapter . . . . . . . . . . . . . . . . . . . . . . . . 9
Connecting Internal SCSI Devices . . . . . . . . . . . . 10
Connecting External SCSI Devices. . . . . . . . . . . . 11
Connecting Floppy Drives (AHA-2742W and
AHA-2744W Only). . . . . . . . . . . . . . . . . . . . . . . . 13
Terminating the SCSI Bus . . . . . . . . . . . . . . . . . . . . . . 14
Configuring Host Adapter Termination . . . . . . . . 15
Setting the SCSI ID. . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Configuring the Host Adapter . . . . . . . . . . . . . . . . . . . 21
Run the EISA Configuration Utility . . . . . . . . . . . 21
Copy Configuration and Overlay Files . . . . . . . . . 21
Select the Host Adapter. . . . . . . . . . . . . . . . . . . . . 22
Configure the Host Adapter Parameters . . . . . . . 22
BIOS and SCSI Device Configuration . . . . . . . . . . . . . 26
BIOS Configuration . . . . . . . . . . . . . . . . . . . . . . . . 26
SCSI Device Configuration . . . . . . . . . . . . . . . . . . 27
Utilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Disk Format Utility . . . . . . . . . . . . . . . . . . . . . . . . 29
2740w-ig.toc Black v

vi
Operating Environment Software . . . . . . . . . . . . . . . . 30
DOS/Windows. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Novell NetWare®, OS/2®, and UNIX®. . . . . . . . . 31
Troubleshooting Checklist . . . . . . . . . . . . . . . . . . . . . . 32
❒
2740w-ig.toc Black vi

1
Getting Started
This document provides the steps required for installa-
tion of the AHA-2740W and AHA-2742W single-ended,
and the AHA-2744W differential EISA-to-Fast, Wide
SCSI Host Adapters. The AHA-2740W and AHA-2742W
support single-ended SCSI, while the AHA-2744W
supports differential SCSI. In this document, the
AHA-2740W,AHA-2742W,andAHA-2744Warereferred
to jointly as the AHA-2740W/2742W/2744W.
Procedures for all three adapters are the same except
when regarding the onboard floppy controller on the
AHA-2742W and AHA-2744W. Installation of the host
adapter includes the following steps:
1Installing the AHA-2740W/2742W/2744W host
adapter in an EISA system.
2Installing the SCSI cable(s) and SCSI peripheraldevices.
3Terminating the SCSI bus.
4Setting the SCSI ID.
5Adjusting the host adapter configuration settings if
necessary.
6Loading software if necessary.
2740w-ig.doc Black 1

AHA-2740W/2742W/2744W
2
Board Layout
Figure 1 shows the location of the major components on
the AHA-2740W and AHA-2742W host adapters; Table 1
provides a description of each component for the
AHA-2740W and AHA-2742W.
Figure 1. Board Layout for the AHA-2740W and AHA-2742W
PIN 1PIN 1
J1 J3 J4 J5
U7 U11 U12 J6U1U3
J2
2740w-ig.doc Black 2

Board Layout
3
Table 1. Host Adapter Components for the AHA-2740W
and AHA-2742W
Location Description
J1 Floppy Enable Jumper (AHA-2742W Only)
J2 External LED Connector
J3 Floppy Connector (AHA-2742W Only)
J4 68-pin Wide (16-bit) SCSI Internal Connector
J5 50-pin SCSI Internal Connector
J6 68-pin Wide SCSI External Connector
U1 Floppy Controller (AHA-2742W Only)
U3 RAM
U7 Host Adapter BIOS
U11 AIC-7770 Bus Master SCSI Chip
U12 AIC-701 Configuration Chip
2740w-ig.doc Black 3

AHA-2740W/2742W/2744W
4
Figure 2 shows the location of the major components on
the AHA-2744W host adapter; Table 2 provides a
description of each component for the AHA-2744W.
Figure 2. Board Layout for the AHA-2744W
Pin 1
J1
J6
J2 J3 J4
U34U33U35 U21 U7
Pin 1
J5
2740w-ig.doc Black 4

Board Layout
5
Table 2. Host Adapter Components for the AHA-2744W
Location Description
J1 Floppy Enable Jumper
J2 External LED Connector
J3 Floppy Connector
J4 68-pin Wide Differential (16-bit) SCSI Internal
Connector
J5 50-pin Differential (8-bit) SCSI Internal Connector
J6 68-pin Wide SCSI External Connector
U7 Floppy Controller
U21 RAM
U33 AIC-7770 Bus Master SCSI Chip
U34 AIC-701 Configuration Chip
U35 Host Adapter BIOS
2740w-ig.doc Black 5

AHA-2740W/2742W/2744W
6
Default Settings
Your host adapter is already configured for the majority
of EISA class computers. Table 3 lists the default set-
tings of your host adapter. Refer to Configuring the Host
Adapter for information on changing any of these
settings.
Table 3. Host Adapter Default Settings
Description Default Setting
Interrupt Level IRQ 11
Bus Release Time 44 BCLKS
Data FIFO Threshold 100%
Host Adapter BIOS Base 21
pgAddress D8000h
Host Adapter SCSI ID Device ID 7
SCSI Bus Parity Check Enabled
SCSI Selection Timeout 256 milliseconds
SCSI Bus Reset at Power-on Enabled
SCSI Bus Termination (Low/High) On/On
Support Removable Disks as Fixed Disk Boot Device Only
Extended Translation for Drives > 1
GByte Enabled
Support More Than Two Drives Disabled
2740w-ig.doc Black 6

Default Settings
7
The Onboard Floppy Controller
(AHA-2742W and AHA-2744W Only)
• If your floppy diskette drives are already running
under another controller, disable the onboard floppy
controller by removing the jumper connector on
jumper J1.
• To use the onboard floppy controller, leave the jumper
connector installed on jumper J1 and then disable
your existing floppy controller; refer to your computer
or floppy controller user documentation.
2740w-ig.doc Black 7

AHA-2740W/2742W/2744W
8
Installing the Host Adapter
Always refer to your system’s documentation for instruc-
tions on removing the system cover and adding option
boards.
To install the AHA-2740W/2742W/2744W in your EISA
computer system, complete the following:
1Remove the cover of your EISA personal computer
to expose the EISA bus slots on the motherboard.
2Locate an unused EISA slot in your system which
supports bus master operations (refer to the host
system documentation for details) and remove the
corresponding slot cover.
3Align and insert the host adapter in the EISA slot.
4Secure the host adapter in your system.
CAUTION: Turn OFF and disconnect power to the system
and external equipment.
Note: EISA boards require firmer seating than typical ISA
expansion boards. Make sure the host adapter is fully
seated in its slot.
2740w-ig.doc Black 8

Cabling the Host Adapter
9
Cabling the Host Adapter
The AHA-2740W/2742W/2744W has three cable connec-
tors for connecting SCSI devices: two for connecting
internal SCSI devices and one for connecting external
SCSI devices. The two internal SCSI connectors consist
of a 50-pin and 68-pin connector. The single external con-
nector consists of a 68-pin connector.
In addition, the AHA-2742W and AHA-2744W has a
cable connector that allows you to connect up to two
floppy disk drives.
Only 8-bit internal SCSI devices can be connected to the
50-pin internal connector. The 68-pin internal and exter-
nal connectornormally accepts16-bit Wide SCSIdevices;
however, 8-bit SCSI devices can be connected provided
that they are equipped with 68-pin connectors.
2740w-ig.doc Black 9

AHA-2740W/2742W/2744W
10
The AHA-2740W/2742W/2744W can accommodate a
single SCSI bus with up to a total of 15 SCSI devices
connected.
Connecting Internal SCSI Devices
Internal devices are usually connected to the host
adapter by a flat SCSI ribbon cable. This cable has con-
nectors at each end and additional connectors attached
in the middle. One end of the cable is attached to the
internal connector on the host adapter, and the SCSI
devices are attached to the remaining connectors. The
50-pin internal connector uses a 50-pin SCSI ribbon
cablewith a 50-pin headerinternalconnector.The 68-pin
internal connector uses a 68-pin SCSI ribbon cable with
a 68-pin high-density SCSI internal connector.
Up to 7 internal 8-bit devices can be connected to the
50-pin internal connector, and up to 15 internal 16-bit
Note: Only single-ended SCSI devices are supported by
the AHA-2740W/2742W host adapters and only differential
SCSI devices are supported by the AHA-2744W host
adapter. Differential SCSI devices may be damaged if con-
nected to the single-ended SCSI host adapter bus;
similarly, single-ended SCSI devices may be damaged if con-
nected to differential host adapters. Most SCSI devices
currently produced are single-ended SCSI devices. Consult
your SCSI device user documentation.
2740w-ig.doc Black 10

Cabling the Host Adapter
11
Wide SCSI devices can be connected to the 68-pin inter-
nal connector.
Maintaining Pin-1 Orientation
When connecting the 50-pin internal SCSI ribbon cables
toboththehostadapterandinternalSCSIdevice(s),make
sure that pin-1 orientation is maintained throughout the
bus. Pin-1 of the SCSI ribbon cable is designated by a col-
ored stripe on one edge of the ribbon cable. Pin 1 of the
host adapter or SCSI device connector is usually desig-
nated by an arrow or delta symbol (▲) on the connector.
The 68-pin internal cable connectors are keyed and can
only be plugged inone way;pin-1 orientation is automatic.
Connecting External SCSI Devices
External devices are usually daisy-chained to the host
adapter. This means that a simple two-ended cable runs
from the host adapter to the connector on the first exter-
nal device. A second connector onthe back of the external
device allows another cable to connect it with the second
device in the chain.
To connect subsequent external SCSI devices, obtain
additional external cables and chain each device to the
Note: Only two of the three SCSI connectors can have
devices connected at any one time.The total number of
SCSI devices that can be connected to the host adapter is 15.
2740w-ig.doc Black 11

AHA-2740W/2742W/2744W
12
previous device untilall external SCSIdevices havebeen
connected. Up to 15 external Wide SCSI devices can be
connected to the 68-pin external connector.
The external connector on the host adapter uses a 68-pin
shielded cable with a high-density external connector.
External cable connectors are keyed and can only be
plugged in one way; pin-1 orientation is automatic.
Note: Only two of the three SCSI connectors can have
devices connected at any one time.The total number of
SCSI devices that can be connected to the host adapter is 15.
2740w-ig.doc Black 12
