Adaptec VideOh! AVC-2410 User manual
R
VideOh! DVD Media Center
PCI Edition
AVC-2410
User’s Guide
i
Copyright
© 2003 Adaptec, Inc. All rights reserved. No part of this publication may be
reproduced, stored in a retrieval system, or transmitted in any form or by any
means, electronic, mechanical, photocopying, recording or otherwise, without the
prior written consent of Adaptec, Inc., 691 South Milpitas Blvd., Milpitas, CA 95035.
Trademarks
Adaptec, the Adaptec logo, and VideOh! are trademarks of Adaptec, Inc., which
may be registered in some jurisdictions.
Windows 98SE, Windows 2000, Windows Me, and Windows XP are trademarks of
Microsoft Corporation in the US and other countries, used under license.
Sonic and MyDVD are registered trademarks of Sonic Solutions in the U.S. and
other countries, used under license.
InterVideo and WinDVR are registered trademarks of InterVideo, Inc. in the U.S.
and other countries, used under license.
All other trademarks are the property of their respective owners.
Changes
The material in this document is for information only and is subject to change
without notice. While reasonable efforts have been made in the preparation of this
document to assure its accuracy, Adaptec, Inc. assumes no liability resulting from
errors or omissions in this document, or from the use of the information contained
herein.
Adaptec reserves the right to make changes in the product design without
reservation and without notification to its users.
Disclaimer
IF THIS PRODUCT DIRECTS YOU TO COPY MATERIALS, YOU MUST HAVE
PERMISSION FROM THE COPYRIGHT OWNER OF THE MATERIALS TO AVOID
VIOLATING THE LAW WHICH COULD RESULT IN DAMAGES OR OTHER
REMEDIES.
ii
Adaptec Customer Support
If you have questions about installing or using your Adaptec product, check this
document first—you will find answers to most of your questions here. If you need
further assistance, use the support options listed below.
Technical Support Identification (TSID) Number
■Before contacting Technical Support, you need your unique 12-digit TSID
number. The TSID number identifies your product and support status.
■The TSID number is included on two white, bar-coded labels, like the example
below.
Support Options
■Search the Adaptec Support Knowledgebase (ASK) at ask.adaptec.com for
articles, troubleshooting tips, and frequently asked questions for your product.
■For support via Email, submit your question to Adaptec's Technical Support
Specialists at ask.adaptec.com.
■To order Adaptec products, including accessories and cables, call +1 408-957-
7274. Or, you can order cables online at www.adaptec.com/buy-cables.
Europe
■Visit our Web site at www.adaptec-europe.com.
■German and English: Search the Adaptec Support Knowledgebase (ASK) at
ask-de.adaptec.com for articles, troubleshooting tips, and frequently asked
questions for your product.
For support via e-mail, submit your question to Adaptec's Technical Support
Specialists at ask-de.adaptec.com.
■French: Search the Adaptec Support Knowledgebase (ASK) at ask-fr.adaptec.com
for articles, troubleshooting tips, and frequently asked questions for your
product.
For support via e-mail, submit your question to Adaptec's Technical Support
Specialists at ask-fr.adaptec.com.
■To order Adaptec products, including accessories and cables, go to
www.adaptec.com/buy-cables.
Japan
■Search the Adaptec Support Knowledgebase (ASK) at ask.adaptec.co.jp
■Visit our Web site at www.adaptec.co.jp.
iii
Limited 2-Year Hardware Warranty
1. Adaptec, Inc. (“Adaptec”) warrants to the purchaser of this product that it will be free from
defects in material and workmanship for a period of two (2) years from the date of purchase.
If the product should become defective within the warranty period, Adaptec, at its option,
will repair or replace the product, or refund the purchaser’s purchase price for the product,
provided it is delivered at the purchaser’s expense to an authorized Adaptec service facility
or to Adaptec.
2. Repair or replacement parts or products will be furnished on an exchange basis and will
either be new or reconditioned. All replaced parts or products shall become the property of
Adaptec. This warranty shall not apply if the product has been damaged by accident,
misuse, abuse or as a result of unauthorized service or parts.
3. Warranty service is available to the purchaser by delivering the product during the warranty
period to an authorized Adaptec service facility or to Adaptec and providing proof of
purchase price and date. The purchaser shall bear all shipping, packing and insurance costs
and all other costs, excluding labor and parts, necessary to effectuate repair, replacement or
refund under this warranty.
4. For more information on how to obtain warranty service, write or telephone Adaptec at 691
South Milpitas Boulevard, Milpitas, CA 95035, (800) 959-7274.
5. THIS LIMITED WARRANTY DOES NOT EXTEND TO ANY PRODUCT WHICH HAS
BEEN DAMAGED AS A RESULT OF ACCIDENT, MISUSE, ABUSE, OR AS A RESULT OF
UNAUTHORIZED SERVICE OR PARTS.
6. THIS WARRANTY IS IN LIEU OF ALL OTHER EXPRESS WARRANTIES WHICH NOW
OR HEREAFTER MIGHT OTHERWISE ARISE RESPECT TO THIS PRODUCT. IMPLIED
WARRANTIES, INCLUDING THOSE OF MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE AND NON-INFRINGEMENT SHALL (A) HAVE NO GREATER
DURATION THAN 2 YEARS FROM THE DATE OF PURCHASE, (B) TERMINATE
AUTOMATICALLY AT THE EXPIRATION OF SUCH PERIOD AND (C) TO THE EXTENT
PERMITTED BY LAW BE EXCLUDED. IN THE EVENT THIS PRODUCT BECOMES
DEFECTIVE DURING THE WARRANTY PERIOD, THE PURCHASER’S EXCLUSIVE
REMEDY SHALL BE REPAIR, REPLACEMENT OR REFUND AS PROVIDED ABOVE.
INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING WITHOUT LIMITATION
LOSS OF DATA, ARISING FROM BREACH OF ANY EXPRESS OR IMPLIED WARRANTY
ARE NOT THE RESPONSIBILITY OF ADAPTEC AND, TO THE EXTENT PERMITTED BY
LAW, ARE HEREBY EXCLUDED BOTH FOR PROPERTY DAMAGE, AND TO THE
EXTENT NOT UNCONSCIONABLE, FOR PERSONAL INJURY DAMAGE.
7. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL
OR CONSEQUENTIAL DAMAGES FOR CONSUMER PRODUCTS, AND SOME STATES
DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO
THE ABOVE LIMITATION OR EXCLUSIONS MAY NOT APPLY TO YOU.
8. This warranty gives you specific legal rights, and you may also have other rights which vary
from state to state.
iv
Adaptec Software License Agreement
PLEASE READ CAREFULLY: THE USE OF THIS SOFTWARE IS SUBJECT TO THE SOFTWARE
LICENSE TERMS OF ADAPTEC, INC. AND OTHER LICENSORS WHOSE SOFTWARE MAY
BE BUNDLED WITH THIS PRODUCT.
BY YOUR USE OF THE SOFTWARE INCLUDED WITH THIS PRODUCT YOU AGREE TO THE
LICENSE TERMS REQUIRED BY THE LICENSOR OF THAT SOFTWARE, AS SET FORTH
DURING THE INSTALLATION PROCESS. IF YOU DO NOT AGREE TO THE LICENSE
TERMS APPLICABLE TO THE SOFTWARE, YOU MAY RETURN THE ENTIRE UNUSED
PRODUCT FOR A FULL REFUND.
In return for acquiring a license to use the Adaptec software, which may include software from
third party licensors and patches made available by Adaptec (“Software”), and the related
documentation, you agree to the following terms and conditions:
1. License. This Agreement grants you, the Licensee, a license to:
a. Use the Software on a single computer system, which is not intended for use by more
than five (5) users; and:
b. Make one copy of the Software in machine readable form solely for back-up purposes,
provided you reproduce Adaptec's copyright proprietary legends. Notwithstanding the
foregoing, the Software may be used on the home, laptop or other secondary computer
of the principal user of the Software, and an additional copy of the Software may be
made to support such use. As used in this license, the Software is “in use” when it is
either loaded into RAM or installed on a hard disk or other permanent memory device.
The Software may be “in use” on only one computer at any given time. (Different license
terms and fees are applicable for networked or multiple user applications.) As a specific
condition of this license, you agree to use the Software in compliance with all applicable
laws, including copyright laws, and that you will not copy, transmit, perform or
distribute any audio or other content using the Software without obtaining all necessary
licenses or permissions from the owner of the content.
2. Restrictions. You may not distribute copies of the Software to others or electronically
transfer the Software from one computer to another over a network. You may not post or
otherwise make available the Software, or any portion thereof, in any form, on the Internet.
You may not use the Software in a computer service business, including in time sharing
applications. The Software contains trade secrets and, in order to protect them, you may not
decompile, reverse engineer, disassemble, or otherwise reduce the Software to a human-
perceivable form. YOU MAY NOT MODIFY, ADAPT, TRANSLATE, RENT, LEASE, LOAN,
RESELL FOR PROFIT, DISTRIBUTE, NETWORK OR CREATE DERIVATIVE WORKS
BASED UPON THE SOFTWARE OR ANY PART THEREOF.
3. Ownership of Software. As Licensee, you own the media upon which the software is
recorded or fixed, but Adaptec and its licensors retain title and ownership of the Software
recorded on the original media and all subsequent copies of the Software, regardless of the
form or media in which or on which the original and other copies may exist. This license is
not a sale of the Software or any copy.
4. Confidentiality. You agree to maintain the Software in confidence and that you will not
disclose the Software to any third party without the express written consent of Adaptec. You
further agree to take all reasonable precautions to preclude access of unauthorized persons
to the Software.
5. Term. This license is effective until January 1, 2045, unless terminated earlier. You may
terminate the license at any time by destroying the Software (including the related
documentation) together with all copies or modifications in any form. Adaptec will have the
right to terminate our license immediately if you fail to comply with any term or condition
of this Agreement. Upon any termination, including termination by you, you must destroy
the Software (including the related documentation), together with all copies or
modifications in any form.
6. Special Terms Applicable to Databases. Where a database is included with the Software, you
acknowledge that it is licensed only in connection with the use of the Software to perform
disc creation, and that the database and all data derived therefrom must be maintained in
confidence in accordance with the provisions of Section 4. This license does not grant you
any rights to distribute or disclose such database or data.
v
7. Limited Warranty. Adaptec and its Licensor warrant only that the media upon which the
Software is furnished will be free from defects in material or workmanship under normal
use and service for a period of thirty (30) days from the date of delivery to you. ADAPTEC
AND ITS LICENSORS DO NOT AND CANNOT WARRANT THE PERFORMANCE OR
RESULTS YOU MAY OBTAIN BY USING THE SOFTWARE OR DOCUMENTATION. THE
FOREGOING STATES THE SOLE AND EXCLUSIVE REMEDIES ADAPTEC AND ITS
LICENSORS WILL PROVIDE FOR BREACH OF WARRANTY. EXCEPT FOR THE
FOREGOING LIMITED WARRANTY, ADAPTEC AND ITS LICENSORS MAKE NO
WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED, AS TO
NON-INFRINGEMENT OF THIRD PARTY RIGHTS, MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE. Some states do not allow the exclusion of implied
warranties or limitations on how long an implied warranty may last, so the above
limitations may not apply to you. This warranty gives you specific legal rights and you may
also have other rights which vary from state to state.
8. The entire liability of Adaptec and its licensors, and your exclusive remedy for a breach of
this warranty, shall be:
a. The replacement of any media not meeting the above limited warranty which is
returned to Adaptec; or:
b. if Adaptec or its distributor is unable to deliver replacement media which is free from
defects in materials or workmanship, you may terminate this Agreement by returning
the Software and your money will be refunded.
9. Limitation of Liability. IN NO EVENT WILL ADAPTEC OR ITS LICENSORS BE LIABLE TO
YOU FOR ANY INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES,
INCLUDING ANY LOST PROFITS, LOST SAVINGS, OR LOSS OF DATA, EVEN IF
ADAPTEC OR A LICENSOR HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES, OR FOR ANY CLAIM BY ANY OTHER PARTY. Some states do not allow the
exclusion or limitation of special, incidental, or consequential damages, so the above
limitation or exclusion may not apply to you.
10. Export. You acknowledge that the laws and regulations of the United States and other
countries may restrict the export and re-export of the Software. You agree that you will not
export or re-export the Software or documentation in any form in violation of applicable
United States and foreign law.
11. Government Restricted Rights. The Software is subject to restricted rights as follows. If the
Software is acquired under the terms of a GSA contract: use, reproduction or disclosure is
subject to the restrictions set forth in the applicable ADP Schedule contract. If the Software is
acquired under the terms of a DoD or civilian agency contract, use, duplication or disclosure
by the Government is subject to the restrictions of this Agreement in accordance with 48
C.F.R. 12.212 of the Federal Acquisition Regulations and its successors and 49 C.F.R.
227.7202-1 of the DoD FAR Supplement and its successors.
12. General. You acknowledge that you have read this Agreement, understand it, and that by
using the Software you agree to be bound by its terms and conditions. You further agree that
it is the complete and exclusive statement of the agreement between Adaptec and you, and
supersedes any proposal or prior agreement, oral or written, and any other communication
between Adaptec and you relating to the subject matter of this Agreement. No additional or
any different terms will be enforceable against Adaptec unless Adaptec gives its express
consent, including an express waiver of the terms of this Agreement, in writing signed by an
officer of Adaptec. You assume full responsibility for the use of the Software and agree to
use the Software legally and responsibly. This Agreement shall be governed by California
law, except as to copyright matters, which are covered by Federal law. This Agreement is
deemed entered into at Milpitas, California by both parties. Should any provision of this
Agreement be declared unenforceable in any jurisdiction, then such provision shall be
deemed severable from this Agreement and shall not affect the remainder hereof. All rights
in the Software not specifically granted in this Agreement are reserved by Adaptec.
Should you have any questions concerning this Agreement, you may contact Adaptec by
writing to:
Adaptec, Inc.
Legal Department
691 South Milpitas Boulevard
Milpitas, California 95035
vi
Regulatory Compliance Statements
Federal Communications Commission Radio Frequency Interference Statement
WARNING: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and
can radiate radio frequency energy, and if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. However, if this
equipment does cause interference to radio or television equipment reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
■Reorient or relocate the receiving antenna.
■Increase the separation between equipment and receiver.
■Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
■Consult the dealer or an experienced radio/television technician for help.
■Use a shielded and properly grounded I/O cable and power cable to ensure compliance of
this unit to the specified limits of the rules.
This device complies with part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference and (2) this device must accept
any interference received, including interference that may cause undesired operation.
European Union Compliance Statement
This Information Technology Equipment has been tested and found to comply with
EMC Directive 89/336/EEC, as amended by 92/31/EEC and 93/68/EEC, in
accordance with:
■EN55022 (1998) Emissions
■EN55024 (1998) Immunity:
➐EN61000-4-2 (1998) Electrostatic discharge: ±4 kV contact, ±8 kV air
➐EN61000-4-3 (1998) Radiated immunity
➐EN61000-4-4 (1995) Electrical fast transients/burst: ±1 kV AC, ±0.5 kV I/O
➐EN61000-4-5 (1995) Surges ±1 kV differential mode, ±2 kV common mode
➐EN61000-4-6 (1996) Conducted immunity: 3 V
➐EN61000-4-11 (1994) Supply dips and variation: 30% and 100%
In addition, all equipment requiring U.L. listing has been found to comply with EMC
Directive 73/23/EEC as amended by 93/68/EEC in accordance with EN60950 with
amendments A1, A2, A3, A4, A11.
Australian/New Zealand Compliance Statement
This device has been tested and found to comply with the limits for a Class B digital
device, pursuant to the Australian/New Zealand standard AS/NZS 3548 set out by
the Spectrum Management Agency.
Adaptec, Inc. AVC-2410
Tested to Comply
With FCC Standards
FOR HOME OR OFFICE USE
vii
Canadian Compliance Statement
This Class B digital apparatus meets all requirements of the Canadian Interference-
Causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur
le matériel brouilleur du Canada.
Japanese Compliance (Voluntary Control Council Initiative)
This equipment complies to class B Information Technology equipment based on
VCCI (Voluntary Control Council for Interface). This equipment is designed for home
use but it may causes radio frequency interference problem if used too near to a
television or radio. Please handle it correctly per this documentation.
2
Introduction
Introduction
Congratulations on the purchase of your Adaptec VideOh! Media
Center kit. With this kit, you can watch television (TV) on your
computer, and convert television programs and analog video from
your camcorder or VCR into digital format to create you own
Hollywood style video CDs (VCDs) or DVDs.
This VideOh! kit includes a complete suite of software that will
enable you to watch TV on your computer, control television
content with the latest personal video recorder (PVR) technology,
and burn television programs to VCDs or DVDs.
VideOh! Media Center lets you be creative. You can add
backgrounds and menus to your videos for easy navigation. With
VideOh! Media Center you can also perform even more
sophisticated editing, like adding music, transitions, and titles.
VideOh! Media Center also lets you capture you favorite video
clips and organize and customize them to suit your imagination.
Then you are ready to burn a VCD or DVD and share your
personalized content with others.
AUDIOIN
S-VIDEOIN
TV
VIDEOIN
Connect TV source or analog video device
DISCLAIMER: This product or software may be designed to assist you in reproducing materials in
which you own the copyright or have obtained permission to copy from the copyright owner.
Unless you own the copyright or have permission to copy from the copyright owner, you may be
violating copyright law and be subject to payment of damaged and other remedies. If you are
uncertain about your rights you should contact your legal advisor.
3
Introduction
What’s in the Kit
Your Adaptec VideOh! Media Center kit includes:
■AVC-2410 PCI card
■Remote control and 2 AA batteries
■Standard 6-foot Audio/Visual cable
■Audio Y cable
■Infrared cable
■VideOh! CD, including drivers, software, and User’s Guide
■Getting Started guide
System Requirements
To use your VideOh! Media Center kit, you need a PC-compatible
computer with:
■Intel Pentium III 600 MHz (or faster) processor
■Windows®98SE, Windows Me®, Windows 2000®, or
Windows XP®
■Available PCI port
■256 MB RAM
■400 MB free disk space for applications
■200–570 MB free disk space per 10 minutes of captured video,
depending on resolution and capture quality (see the Tables on
pages 49 and 50 for more information)
■Sound card
■CD-ROM drive
■CD-Recorder or DVD-Recorder for output
■
Video card and monitor that support 16-bit color at 1024 x 768
resolution (24/32-bit color or higher resolution recommended)
4
Introduction
This is Your AVC-2410
AUDIO IN
S-VIDEO IN
TV
VIDEO IN
Antenna/cable connector (TV)
S-Video Input port
Composite Video Input port
Audio Input port
Infrared cable port
PCI connector
5
Installing Your AVC-2410
Installing Your AVC-2410
To install your AVC-2410 card:
1Discharge any static electricity build-up before handling the
AVC-2410 card by touching a grounded metal object (such as
the exposed metal parts on the back of your computer).
2Turn off power to the computer and disconnect the power cord.
Open the computer cabinet, following the manufacturer’s
instructions.
3Locate an unused PCI expansion slot and remove the expansion
slot cover. Save the slot cover screw for use in Step 6.
4Remove the AVC-2410 card from its antistatic packaging.
Caution: Always handle the card by its edges or metal
bracket. Do not touch the gold PCI connector or any
components on the card.
5Insert the AVC-2410 card into the PCI expansion slot. Press
down firmly until the card clicks into place. When installed
properly, the card should appear level with the expansion slot.
Note: Depending on the tightness of the PCI slot, gentle but
firm force may be required to insert the card.
PCI expansion slots
Expansion slot
cover
!
6
Installing Your AVC-2410
6Secure the card bracket with the slot cover screw you removed
in Step 3.
7Close the computer cabinet and reattach the power cord.
8Turn on your computer. Windows detects the AVC-2410 and
starts the Found New Hardware Wizard. This wizard steps you
though the process of installing the necessary drivers.
9When prompted, insert the VideOh! CD into your CD-ROM
drive.
Note: If the VideOh! Software Installation screen appears,
exit this screen before installing the drivers.
See Installing the Drivers on page 7 to continue.
7
Installing the Drivers
Installing the Drivers
Before you can begin capturing analog video or TV programming,
you must install the VideOh! Media Center device drivers.
Follow the complete set of installation instructions provided for
your operating system to ensure that the driver is properly
installed:
■For Windows XP, see page 8.
■For Windows 2000, see page 10.
■For Windows Me, see page 14.
■For Windows 98SE, see page 15.
8
Installing the Drivers
Windows XP
Windows XP automatically detects your device and opens the
Found New Hardware Wizard. To perform the installation, follow
the instructions provided in this section.
Note: Before installing the driver, make sure the VideOh! CD is
in your CD-ROM drive.
To install the driver:
1In the Found New Hardware Wizard, select Install the software
automatically..., then click Next.
9
Installing the Drivers
2If this window appears, click Continue Anyway.
Note: Adaptec drivers have been fully tested and certified
to work with the AVC-2410 device.
Windows installs the driver.
3Click Finish to complete the installation.
Note: To check if the driver is installed properly, follow the
instructions provided in Need Help Installing Your Device
Drivers? on page 46.
See Installing the Software on page 19 to continue.
10
Installing the Drivers
Windows 2000
Windows 2000 automatically detects your device and opens the
Found New Hardware Wizard. To perform the installation, follow
the instructions provided in this section.
Note: Before installing the driver, make sure the VideOh! CD is
in your CD-ROM drive.
To install the drivers:
1In the Found New Hardware Wizard, click Next.
11
Installing the Drivers
2Select Search for a suitable driver..., then click Next.
3Select only CD-ROM drives, then click Next.
Windows locates a driver file.
12
Installing the Drivers
4Click Next.
Note: The drive letter for your CD-ROM may be different
than the one shown in the example above.
5If this window appears, click Yes.
Note: Adaptec drivers have been fully tested and certified
to work with the AVC-2410 device.
Other manuals for VideOh! AVC-2410
1
Table of contents
Other Adaptec DVD Player manuals
