Adesys Octalarm EM-8001 User manual

MEASURING - ALERTING - CONNECTING
EN
Quickstart Octalarm EM-8001
Version 04-2020

1. Technicalspecications
Systemproperties
Contact inputs Voltage 30VAC of 30VDC max
Impedance 10k pull-up to 12VDC
Vil <2V
Vih >2.5V
Note Input can be a contact to GND or a voltage
Relay contacts Max load 30VDC / 1A, 30VAC / 1A (resistive load)
I/O bus Cable type RS485 Modbus cable (22AWG), see chapter 2.2 for further explanation
Length < 1km
Termination 120Ω
Power (external) Consumption DC: 1 Watt
AC: 1.5 Watt (rms), rectied on 1 side
5 Watt (loading capacitor)
Imax 0,22A
Voltage range 8 - 30VDC
20 - 30VAC
Life expectancy (Calculated MTBF) more than 10 years
Reglementen
EMC Emission: EN 55032 (2012) + AC (2013), class B
Immunity: EN 55024 (2010), 10Vrms
Enclosureandoperatingconditions
Enclosure DIN-Rail (TS35) and Wall mounting
Dimensions (W x H x D) 71 x 90 x 33 (mm)
Weight 135gr
Operating temperature -30°C ... +70°C
Storage temperature -40°C ... +85°C
Air humidity 20% - 85% (not condensed)
IP code IP30
Maximum heigth To 2000 metres
Front view EM-8001 (external module)
EM-8001 Marking plate label Enclosure (70 x 12mm)
12 34 56 78
Output ID
EM-8001
Status
NO NC P B A B AVout VinR
IO bus
out
Relais IO bus
in
1
2
3
4
13 2
5
4
6
7
8
Descriptionfrontview
1 IO bus in
2 IO bus out
3 Relay contacts
4 Slave ID
5 Inputs
LEDfunctionalityfrontview
LED Color Status
6 Output Green Relais uitgang actief
7 Status Green pulse Werkend
Red Error
8 Inputs
Alert status
Green Idle
Red Active
Orange Accepted
Blue Conrmation selection Slave ID

2. Installation
2.1. Mountingtheexternalmodule(EM-8001)
The EM-8001 can be mounted to the wall and to 35 mm DIN rails.
When mounted to a DIN rail, the module can easily be used in system
cabinets.
2.2. Connectingtheexternalmodule(EM-8001)
Powered by Octalarm-Touch
To connect the EM-8001 to the Octalarm-Touch, you need a 2-pair,
4-core cable. The cores are for:
• Pair 1: signal line A and B;
• Pair 2: power supply and ground wire.
The wiring diagram is shown on the front sticker.
When using the relay, an external power supply is required.
External power supply
When using the EM-8001 with an external power supply, you need a
1-pair, 3-core cable. The cores are for:
• Pair 1: signal line A and B;
• Core: ground wire.
The wiring diagram is shown on the front sticker.
The power supply wire of the Octalarm-Touch must not be connected to
the EM-8001.
Signal lines for both power supply modes
The wires must be connected to the connector corresponding to the
marking on the front sticker. The nal EM-8001 on the bus will have
to be terminated with a 120 ohm resistor. The EM-8001 features an
integrated resistor: simply connect the ‘R’ and ‘B’ externally on the
screw connector.
EM-8001 / Octalarm-Touch wiring diagram
2.3. SlaveID
The EM-8001 works with a master/slave structure, in which the
Octalarm-Touch acts as the master and the EM-8001 as the slave.
Slaves must have a unique Slave ID.
To set the Slave ID on the modules, all you need is a screwdriver.
When turning the screw, the LED above the corresponding input
number will turn blue, corresponding to the selected Slave ID.
Led status indication (idle)
Number of ashes in idle
1x Slave ID 1
2x Slave ID 2
3x Slave ID 3
4x Slave ID 4
2.4. Powersupply
When mounted close together, the EM-8001 can be powered by the
Octalarm-Touch. When the units are further apart (> 100 m), it is
recommended to always use an external power supply. This external
power supply must meet the prescribed specications and can be
connected to the V and ground. Adésys can supply the SV-19 (DIN-
rail-mounted power supply) or the SV-20 (mains adapter) for this
purpose.
When using the relay, an external power supply is required.
3. Safetyrules
To use the EM-8001 properly, please read and follow these safety
rules:
• mount the device on a solid panel or wall;
• protect the EM-8001 against a surge by using a grounded power
connection;
• use the EM-8001 in an indoor setting, the device needs to be
protected form direct weather exposure;
• the operating temprature is -30°C ... 70°C. Using the EM-8001
outside this temperature range my result in damage;
• this equipment is not suitable for use in locations where children
are likely to be present.
4. Storageandtransport
• There must be no ammable or explosive materials nearby.
• The temperature must be within the -40°C ... 85°C range.
• Do not store this product in a place exposed to direct sunlight.
5. Faultsandrepair
When a fault has occurred please contact Adésys service helpdesk.
By opening the Octalarm-Touch the warranty is void. Repairing the
Octalarm-Touch is only allowed by Adésys appointed experts.
6. Disposal
The EM-8001 is an electronic device. Electrical and electronic
equipment should not be mixed with general household waste.
Please contact the installer or Adésys for more information.
7. Guaranteeandliability
Every EM-8001 undergoes a series of extensive tests at Adésys prior
to dispatch. Adésys also gives a two year guarantee.
The guarantee becomes invalid if:
• the defect is caused by gross negligence or incompetent
installation;
• the appliance has been repaired and/or altered without Adésys’
permission;
• it is established that the serial number has been removed or
damaged.
Adésys accepts no liability whatsoever for consequential damage
caused by incompetent use of and/or malfunctions in the EM-8001.

More information on the website
Molenweer 4
2291 NR Wateringen
The Netherlands
[phone]
www.adesys.nl
[email protected]
