CVS Type 630 HP
Regulators and
Relief Valves
Introduction
Please note: These regulators and relief valves must
be installed, operated and maintained in accordance
with CVS instructions and all applicable federal,
provincial, state and local codes, laws, rules, and
regulations.
The CVS 630 HP Series consists of a high pressure
reducing regulator, and Type CVS 630R relief valve.
These regulators and relief valves are furnished in
either spring-loaded or pressure-loaded construction
with 1 or 2 inch NPT screwed end connections and
ASME Class 150 through 600 RF Flanged end
connections.
Pressure loaded Type 630 HP regulators are
normally furnished without a main regulator spring
and use a Bellofram 7360 or a Bellofram P39
regulator.
Pressure loaded Type 630R relief valves are
furnished with a light rate relief valve spring and use
a Bellofram 7360 or a Bellofram P39 regulator.
Installation
After uncrating the regulator or relief valve, inspect it
for shipping damage. Be certain the body cavity and
seat ring are free from any foreign material. Also be
certain that connecting pipelines are free of loose
pipe scale.
The regulator or relief valve may be installed in any
position, but direction of flow through the body must
Instruction Manual
Figure 1: CVS Type 630HP Regulator
Calgary Sales Office
3516 114 Avenue SE
Calgary, Alberta, Canada T2Z 3V6
Office: [phone]
Fax: [phone]
be as indicated by the flow direction arrow on
nameplate.
Note that in diagrams in this manual, regulator flow
direction is opposite relief valve flow direction.
Protect the regulator or relief valve against damage
from vehicles and other external sources. The
temperature capability of the 630 HP Series
regulator and relief valves with standard construction
materials is –20 to +150F, optional construction -20
to 300oF.

2
Vents
Spring-loaded constructions have a screened vent
assembly (Key 24) installed in the ¼” NPT spring
case vent opening. If a remote vent is required,
remove the vent assembly and install a remote vent
line.
Pressure loaded constructions have a bleed orifice
fitting (Key 38) installed in an extra outlet connection
of the loading regulator. The function of this fitting is
to bleed loading pressure during operation of the
regulator or relief valve.
Warning: The bleed orifice fitting
continuously vents a small amount of gas. If
the regulator or relief valve is located where
accumulation of the vented gas will create
an explosion hazard, install a remote vent
line to carry the vented gas to a safe area.
The bleed orifice is furnished with a ¼” NPT
screened opening; remove the screen and
install remote vent line.
All remote vent lines must have as large an inside
diameter as possible. The vent line should be as
short as possible with a minimum number of bends
and elbows. Protect all vent openings against
entrance of rain, snow or any other foreign material
that may plug the vent or affect operation of the
regulator or relief valve. Inspect all vent openings
periodically to be sure they are not plugged.
Overpressure Protection
As is the case with most regulators, the Type 630 HP
spring-loaded and pressure-loaded regulators have
outlet pressure ratings that are lower than the inlet
pressure ratings. Overpressure protection must be
provided if the actual inlet pressure can exceed the
outlet pressure rating. Overpressure protection may
also be required for the loading regulator and main
regulator spring case of pressure loaded regulators
and relief valves.
Refer to the following tables to determine pressure
ratings:
1. Spring loaded Type 630 HP regulators
1.1. Inlet pressure and pressure drop (Table 1)
1.2. Outlet pressure (Table 2)
2. Pressure loaded Type 630 HP regulators
2.1. Main regulator inlet pressure and pressure
drop (Table 1)
2.2. Loading pressure and outlet pressure
(Table 3)
3. Spring loaded Type 630R relief valve pressure
(Table 4)
4. Pressure loaded Type 630R relief valve
pressures (Table 5)
WARNING: Over pressuring any portion of this
equipment may cause damage to regular parts,
leaks in the regulator or personal injury due to
bursting of pressure-containing parts or
explosion of accumulated gas.
To prevent overpressure, provide an appropriate
overpressure protection device to ensure that none
of the limits listed in tables 1 through 5 will be
exceeded.
Regulator or relief valve operation below the limits
specified in tables 1 through 5 does not preclude the
possibility of damage from external sources or from
debris in the gas line. Inspect the regulator for
damage following any over pressuring condition.
Loading Regulator Supply Pressure
Use a clean, dry gas as supply pressure for the
loading regulator of pressure loaded regulators or
relief valves. Connect the supply to the ¼” NPT inlet
connection of the loading regulator. The supply
pressure may be obtained from the upstream piping,
but be certain adequate overpressure protection is
provided for the loading regulator and for the spring
case of the main regulator or relief valve.
Table 1: Maximum Inlet Pressures and Pressure Drops for CVS Type 630 HP Regulators
1/8” & 3/16”
Port Diameter
1/4” Port
Diameter
3/8” Port
Diameter
1/2” Port
Diameter
Max. Allowable
Inlet Pressure, (PSIG)
1500+
1500+
1000+
750+
Max. Allowable
Pressure Drop, ++ (PSIG)
1500
1000
500
250
Does not apply to loading regulator of pressure-loaded Type 630 HP.
+Inlet pressure must not exceed the sum of the actual outlet pressure setting and the maximum allowable pressure drop. For example, with an outlet
pressure setting of 200 psig and a 3/8” port dia. (maximum allowable pressure drop of 500 psig), the maximum allowable inlet pressure is 700 psig.
++ Nitrile valve discs are normally furnished for pressure drops to 200 psi. For better erosion resistance, nylon valve discs are normally furnished for
higher-pressure drops.
Some erosion of valve discs occurs at all pressure drops due to solid particles in the flow stream. The rate of erosion is higher with large amounts of
impurities in the flow stream and with higher pressure drops. Valve discs and other regulator parts must be inspected periodically for erosion and
damage and must be replaced as necessary.

3
Table 2: Outlet Pressure Limits for Spring-Loaded CVS Type 630 HP Regulators
Low-Pressure Regulator
High-Pressure Regulator
Outlet Pressure range
3 to 10
psig
8 to 20
psig
17 to 30
psig
27 to 40
psig
27 to 50
psig
46 to 95
psig
90 to 150
psig
150 to 200
psig
200 to 275
psig
275 to 500
psig
Spring Part Number
CVS0W
0192
27022
CVS0W
0191
27022
CVS0W
0190
27022
CVS0Y
0664
000A2
CVS0W
0192
27022
CVS0W
0191
27022
CVS0W
0190
27022
CVS0Y
0664
000A2
CVS1J
1469
27142
CVS1K
3709
27082
Maximum Operating
Outlet Pressure, PSIG
10
20
30
40
50
95
150
200
275
500
Max. Outlet Pressure
Over Pressure Setting1,
PSIG
20
202
Ltd. By
Max. emr
Outlet Pr.
200
2003
Max. Emergency
Outlet (Casing)
Pressure, PSIG
45
550
1. Damage to internal parts of the regulator may occur if outlet pressure exceeds the actual pressure setting by amounts greater than shown in this row.
2. For outlet pressure settings to 25 psig only. For pressure settings over 25 psig, outlet pressure is limited by max. emergency outlet pressure of 45 psig.
3. For outlet pressure settings to 350 psig only. For pressure settings over 350 psig, outlet pressure is limited by max. emergency outlet pressure of 550 psig.
4. Leakage or bursting of pressure-containing parts may occur if outlet pressure exceeds these values.
Table 3: Loading Pressure and Outlet Pressure Limits for Spring-Loaded CVS Type 630 HP
Regulators
Low-Pressure Regulator
High-Pressure Regulator
Loading Regulator Type
Bellofram 7360
Bellofram P39
Bellofram 7360
Bellofram P39
Max, Inlet Pressure
to loading regulator, psig
250
600
250
600
Outlet Pressure Ranges,2psig
0 to 30
0 to 60
0 to 225
0 to 120
50 to 225
200 to 500
Max. Operating Outlet
Pressure,2psig
60
100
500
Max. Main Regulator
Outlet Pressure Overpressure
Setting,3psig
204
200
2005
Max. Emergency Outlet
(Casing) Pressure of Loading
Regulator,6psig
707
110
550
Max. Emergency Outlet
(Casing) Pressure of Main
Regulator,6psig
70
600
1. Limited to this value by maximum inlet pressure to Type 630 HP
2. Applies to both loading regulator and main regulator.
3. Damage to internal parts of the regulator may occur if outlet pressure exceeds the actual pressure setting by amounts greater than those shown in this row. Loss of
loading pressure to main regulator diaphragm will reduce outlet pressure settings in proportion to the loss in loading pressure.
4. For pressure settings to 46 psig. For higher-pressure settings, outlet pressure is limited by max. emergency outlet pressure of 66 psig.
5. For pressure settings to 350 psig. For higher-pressure settings, outlet pressure is limited by max. emergency outlet pressure of 550 psig.
6. Leakage or bursting of pressure-containing parts may occur if outlet pressure exceeds these values.
7. Limited to this value by maximum emergency loading pressure of main regulator.
Table 4: Relief Valve Pressure Limits for Spring-Loaded CVS Type 630R Regulators
Low Pressure Relief Valve
High Pressure Relief Valve
Max. Allowable
Inlet Pressure, psig
Relief Pressure Setting Plus Maximum
Allowable Buildup of 25 psig
Relief Pressure Setting Plus Maximum
Allowable Buildup of 250 psig
Max. Emergency
Inlet (Casing)
Pressure,*psig
75
550
Relief Pressure
Settings (psig)
3 to 8
6 to 17
15 to 22
20 to 35
27 to 50
30 to 70
50 to 95
75 to 175
150 to 250
Spring Part Number
CVS0W
0192
27022
CVS0W
0191
27022
CVS0W
0190
27022
CVS0Y
0664
000A2
CVS1J
1469
27142
CVS0W
0191
27022
CVS0W
0190
27022
CVS0Y
0664
000A2
CVS1J
1469
27142
Leakage or bursting of pressure-contained parts may occur if inlet pressure exceeds these values

4
Table 5: Relief Valve Pressure Limits for Pressure-Loaded CVS Type 630R Regulators
Low Pressure Relief
Valve
High Pressure Relief Valve
Loading Regulator Type
Bellofram 7360
Bellowfram 7360
Bellofram P39
Max. Allowable Inlet Pressure to
Relief Valve, PSIG
Relief pressure setting plus maximum
Allowable buildup of 25 psig
Relief pressure setting plus maximum
Allowable buildup of 250 psig
Max. Emergency Inlet (Casing)
Pressure * of Relief Valve, PSIG
75
550
550
Max. Allowable Inlet Pressure to
Loading Regulator, PSIG
75+
250
550+
Relief Pressure Settings, PSIG
10 to 20 or 20 to 50
50 to 100
100 to 225
Max. Emergency Outlet
(Casing) Pressure * of Loading
Regulator, PSIG
75++
110
250
* Leakage or bursting of pressure-contained parts may occur if pressure exceeds these values.
+ Limited to this value by maximum emergency inlet pressure of relief valve.
++ Limited to this value by maximum emergency loading pressure of Type 630R
Putting Unit in Service
Use pressure gauges to monitor pressure during
startup.
1. For pressure loaded constructions, turn on
supply pressure to loading regulator.
2. Slowly open upstream shutoff valve.
3. Slowly open the downstream shutoff valve.
4. Check all connections for leaks.
5. If indicated by the monitoring pressure gauges,
make final spring adjustments per the
“Adjustment” section.
Adjustment
The range of allowable pressure settings is marked
on the nameplate. If a pressure setting beyond the
nameplate range is required, substitute an
appropriate spring in the relief valve or loading
regulator. Be sure to change the nameplate to
indicate the new pressure range.
Some pressure ratings are dependent upon the
actual outlet pressure settings being used. For
example, with a Type 630 HP regulator, outlet
pressure must not exceed the setting by more than
20 psig (200 psig for high-pressure constructions), or
damage to internal regulator parts may occur.
However, with some higher-pressure ranges, the
setting plus 20 psig (200 psig for high-pressure
constructions) exceeds the maximum emergency
outlet (casing) pressure. In these cases, outlet
pressure must be limited by the maximum
emergency outlet (casing) pressure. Before
increasing the setting, refer to table 2 through 5 (as
appropriate). Review the pressure limits for the
spring range being used, and be certain that the new
pressure setting will not result in an overpressure
condition. Always use a pressure gauge to monitor
pressure when making adjustments.
Spring Loaded Regulators and Relief
Valves
1. Loosen locknut (Key 22)
2. Rotate the adjusting screw (Key 23) clockwise
to increase the setting or counter clockwise to
decrease the setting.
3. Tighten locknut.
Pressure Loaded Regulators and Relief
Valves
1. Loosen the locknut found on the loading
regulator adjusting screw.
2. Rotate the loading regulator adjusting screw
clockwise to increase the setting or
counterclockwise to decrease the setting.
3. Tighten locknut.
Taking out of Service
Isolate the regulator or relief valve from all pressure.
For pressure loaded constructions, shut off supply
pressure to loading regulator.
Cautiously vent all pressure from the regulator or
relief valve before performing any service on the
unit.

5
Maintenance
WARNING: To avoid personal injury and
equipment damage, isolate the regulator or
relief valve from all pressure. Cautiously
release pressure from the regulator or relief
valve before attempting disassembly.
Due to normal wear that may occur in regulators and
relief valves, parts such as the valve disc, seat ring
and diaphragm must be inspected periodically and
replaced as necessary. The frequency of inspection
and replacement depends upon the severity of
service conditions or federal and provincial laws.
Normal wear of the seat ring and valve disc is
accelerated with high-pressure drops and with large
amounts of impurities in the flow stream.
Instructions are given below for replacing the seat
ring, valve disc and diaphragm. These instructions
may also be used for disassembly required for
inspection and replacement of other parts.
If the loading regulator of pressure-loaded
constructions requires maintenance, disconnect the
supply pressure line (and bleed orifice vent line if
one is present) and unscrew the loading regulator
from its mounting nipple. Refer to the separate
instruction manual for maintenance information.
Seat Ring and Valve Disc:
Note: With some piping systems it may be
possible to omit step 1 below by removing
four cap screws (Key 7) and spreading the
body (Key 1) and adaptor (Key 6) far
enough apart to allow removal of the seat
ring (Key 4) and Type 630 HP valve disc
(Key 3) or Type 630R valve seat O-ring
(Key 32). However, take care to avoid
pinching fingers between body and adapter.
1. Disconnect piping from Adapter (Key 6).
Remove four cap screws (Key 7) and adapter.
2. Remove seat ring (Key 4) and gaskets (Key 5).
3. To remove Type 630 HP valve disc (Key 3) OR
Type 630R valve seat O-ring (Key 32), first
disconnect remote vent pipe (if one is used).
For pressure loaded constructions, disconnect
loading regulator supply line.
4. Unscrew the two cap screws that secure
the diaphragm adaptor (Key 11) to body
(Key 1); remove diaphragm adaptor and
attach spring case (Key 21).
5. Remove valve carrier assembly (Key 2)
from body.
6. To replace seating surface:
6.1. For Type 630 HP, use a ¾” socket
wrench to remove and re-install valve
disc and holder assembly (Key 3).
6.2. For Type 630R, unscrew machine
screw (key31) and remove O-ring
washer and O-ring (Key 28 and 32)
from O-ring holder (Key 3). When
reassembling, apply a good quality
gasket shellac to the machine screw
thread.
7. Use new seat ring gaskets (Key 5) and
body gasket (Key 8) when reassembling.
Insert valve carrier assembly (Key 2) into
the body before re-installing the
diaphragm adaptor.
8. The spring case (Key 21) must point away from
the adaptor (Key 6) on Type 630 HP regulators.
On Type 630R relief valves, the spring case
must face the same direction as the adaptor
(Key 6). Be certain the lever (Key 10) engages
the valve carrier.
Diaphragm
1. Relieve spring compression as follows:
1.1 For spring loaded constructions, loosen
locknut (Key 22). Turn the adjusting screw
(Key 23) counterclockwise until spring
compression is relieved.
1.2 For pressure loaded Type 630R relief valves
(and for pressure loaded Type 630 HP
regulators that have been furnished with a
spring), turn cap screw (Key 23)
counterclockwise until spring compression is
relieved.
2. Disconnect remote vent line (if one is present).
3. For pressure loaded constructions, disconnect
the supply line from the loading regulator (Key
25).
4. Remove spring case (Key 21) by unscrewing
cap screws and nuts (Key 14).
5. Remove diaphragm (Key 13) and attached parts
from lever assembly (Key 10).
6. Unscrew cap screw (Key 18) from connector
head assembly (Key 12) and disassemble the
diaphragm assembly.
7. Install new diaphragm. Note that low-pressure
constructions use a diaphragm plate (Key 16)
on the spring case side of the diaphragm. Low
pressure, pressure loaded constructions use a
diaphragm plate on each side of the diaphragm
plate gasket (Key 33) with each plate. Install
new gaskets when replacing diaphragm.
8. When reassembling, be certain that the
diaphragm connector is engaged on the lever.

6
9. To ensure proper slack in the diaphragm:
9.1 For constructions using a spring, tighten the
spring case cap screws finger tight only.
Compress the spring slightly with the
adjusting screw (or cap screw for pressure
loaded constructions); then complete the
tightening of spring case cap screws and
nuts.
9.2 For constructions without a spring, tighten
spring case cap screws finger tight only.
Remove cap screw (Key 23). Insert a rod in
the spring case and push on the assembly to
take up the slack; then complete the
tightening of the spring case cap screws.
Re-install cap screw (Key 23) in spring case.
Nameplate Information
When corresponding with your CVS Controls
representative about this device, state the model
number, pressure range and all other pertinent
information found on the nameplate (Key 29).
When ordering replacement parts, also specify the
complete part number of each part required.

7
Parts Reference
Key
Description
1
Body
2
Valve Carrier
3*
Type 630R
O-Ring Holder
Type 630*
Valve Disc Assembly
4
Seat Ring
5
Gasket (2 required)
6
Inlet Adaptor, Steel
7
Cap Screw, Steel (4 required)
8*
Gasket
9
Pin, SST
10
Lever Assembly
11
Diaphragm Adaptor
12
Connector Head Assembly
13*
Diaphragm, Neoprene
14
Cap Screw, Steel
15
Cap Screw, Steel
16
Diaphragm Plate, Steel Cd. Pl.
17
Lower Spring Seat
18
Cap Screw, Steel Pl.
19
Spring
20
Upper Seat Ring, Zinc
21
Spring Case
22
Hex Nut, Steel Cd. Pl
23
Adjusting Screw, Steel
24
Vent Assembly (Spring Loaded
Only)
25
Loading (Pressure Loaded Only)
26
Hex Nut, Steel Cd. Pl.
27
Cap Screw, Steel Pl.
28
O-Ring Washer (Pressure Loaded
Only)
29
Nameplate
30
Drive Screw, SST
31
Machine Screw (CVS Type 630R
Only)
32
O-Ring
33
Head Gasket (Pressure Loaded
Only)
34
Gasket (Pressure Loaded Only)
35
Gasket (Pressure Loaded Only)
36
Pipe Nipple (Pressure Loaded Only)
37
Street Elbow
38
Bleed Orifice Assembly (Pressure
Loaded Only)
Figure 1: Spring-Loaded CVS Type 630R
Relief Valve
High Pressure Connection
Figure 2: Pressure-Loaded CVS Type 630
Regulator
High Pressure Connection

8
Figure 3: Spring-Loaded CVS Type 630R Relief Valve
Low Pressure Connection
Figure 4: Pressure-Loaded CVS Type 630R Relief Valve
Low Pressure Connection

9
CVS Type 630 HP Regulators and Relief Valves
Parts List
Key
No.
Description
Part #
1
Body
1” Steel w/ brass pitot tube
CVS2N6990000A2
1” Steel w/ SST pitot tube
CVS2N6990X0012
2” Steel w/ SST pitot tube
CVS2N699122012
2
Valve Carrier
Brass
CVS0W018614022
SST
CVS0W018635032
3
O-Ring Holder, Type 630R
Brass
CVS1D336014012
SST
CVS1D336035032
Valve Disc Assembly, Type 630
Brass/Nitrile
CVS1B4500000A2
SST/Nitrile
CVS1B4500000B2
Brass/Nylon
CVS1C1860000A2
SST/Nylon
CVS1C1860000B2
Brass/TFE
CVS1C1860000C2
SST/TFE
CVS1C1860000D2
4
Seat Ring, Type 630
Brass
1/8” Port
CVS0Z040014012
3/16” Port
CVS1B219514102
1/4” Port
CVS0W018314012
3/8” Port
CVS0W018214012
1/2” Port
CVS0W018114012
SST
1/8” Port
CVS1K416635032
3/16” Port
CVS1K416535032
1/4” Port
CVS1K416435032
3/8” Port
CVS1K416335032
1/2” Port
CVS1K416235032
Seat Ring, Type 630R
Brass
1/2” Port
CVS1B735014012
SST
1/2” Port
CVS1B735035032
5
Gasket (2 Req’d)
Copper, For Brass Trim
CVS0W018415042
Garlock
CVS0W018404022
6
Inlet Adaptor, Steel
1-inch Body
CVS1F479823022
2-inch Body
CVS1F479923022
7
Cap Screw, Steel (4 Req’d)
1-inch Body
CVS1A935924052
2-inch Body
CVS1A353524052
8
Gasket, Non-Asbestos
CVS0W018704022
9
Pin, SST
CVS0W018835072
10
Lever Assembly
Low-Pressure
CVS1B2891000A2
High-Pressure
CVS1B2890000A2
11
Diaphragm Adaptor
Low-Pressure
Steel
CVS2N698522012
High-Pressure
Steel
CVS2N698722012
12
Connector Head Assembly
Low-Pressure
Brass
CVS1C3000X0012
SST
CVS1C3000X0022
High-Pressure
Brass
CVS1P8465000A2
SST
CVS1P8465000B2
13
Diaphragm
Low Pressure –Nitrile/Nylon 1 Required
CVS0W020002192
Low Pressure –FKM Viton/Nomex –2 Required
CVS0W0200X0022
High-Pressure –Nitrile/Nylon –1 Required
CVS0W019902192
High Pressure –FKM Viton/Nomex –2 Required
CVS0W019902402
14
Cap Screw, Steel
Low-Pressure (10 Req’d)
CVS1A352524052
High-Pressure (4 Req’d)
CVS1A352524052
15
Cap Screw, Steel
Standard (2 Req’d)
CVS1A352624052
Wire Seal (1 of Each Req’d)
CVS1R419124052
CVS1A352624052
16
Diaphragm Plate, Steel Cd. Pl.
630 and 630R, Low-Pressure, Pressure-Loaded
CVS1B136324052
All Others
CVS1A352524052
17
Lower Spring Seat
Low-Pressure, Steel
CVS0W020324102
High-Pressure, Zinc
Pressure Range to 275
CVS0W020144022
Pressure Range over
275
CVS1K371044022
18
Cap Screw, Steel Pl.
630 and 630R, Low-Pressure, Pressure-Loaded
CVS1B136324052
All Others
CVS1R817699012

10
CVS Type 630 HP Regulators and Relief Valves
Parts List cont’d
Key
No.
Description
Part #
19
Spring
See Following Table
20
Upper Spring Seat, Zinc
630 Pressure Loaded
None Required
630 and 630R, and 630R
Pressure-Loaded
Pressure Range to 275
CVS0W019344022
Pressure Range over
275
CVS1K371144022
21
Spring Case
Low Pressure
Cast Iron
CVS3C780919042
Steel
CVS3N698122012
High Pressure
Cast Iron
CVS3C780819042
Steel
CVS3N698322012
22
Hex Nut, Steel Cd. Pl.
CVS1A352424122
23
Adjusting Screw, Steel
See Following Table
24
Vent Assembly (Not Required for Pressure-Loaded Units)
CVSEMY602X1A12
25
Loading Regulator (For Pressure-Loaded Only)
Type 67, 67H, 1301F
or 1301G
26
Hex Nut, Steel Cd. Pl.
Low-Pressure (10 Req’d)
CVS1A352724122
High-Pressure (4 Req’d)
CVS1A352724122
27
Cap Screw, Steel Pl. (2 Req’d) (Not Shown)
CVS1A341827052
28
O-Ring Washer
(For Pressure-Loaded Units Only)
Brass
CVS1D335914012
SST
CVS1D335935072
29
Nameplate, Aluminum
Type 630
CVS1F749611032
Type 630R
CVS21A5495X012
30
Drive Screw, SST (4 Req’d)
CVS1A368228982
31
Machine Screw, Type 630R Only
Brass
CVS1A682618992
SST
CVS1D336435042
32
O-Ring
Nitrile
CVS1D288806992
TFE
CVS1F581906522
33
Head Gasket, Garlock (2 Req’d), (For Pressure-Loaded Units Only)
CVS1B192204022
34
Gasket, Copper (For Pressure-Loaded Units Only)
CVS0Y008915042
35
Gasket, Copper and Garlock (For Pressure-Loaded Units Only)
CVS1E275999212
36
Pipe Nipple, Steel Galvanize Zn Pl (Pressure-Loaded Units Only)
CVS1B218826232
37
Street Elbow, Malleable Iron (High-Pressure, Pressure-Loaded Units)
CVS1A913221992
38
Bleed Orifice Assembly
(Pressure-Loaded Only)
Low
Pressure
3-20 psig Loading
Regulator Range
CVS1K8845X0012
20-100 psig Loading
Regulator Range
CVS1K8844X0012
High-Pressure
CVS1K8843X0012

11
Key 23: Adjusting Screw, Steel
Type
Spring
Use
Adjusting Screw
For Wire Seal,
Use Adjusting
Screw
CVS 630
CVS0W019227022
CVS1A279128982
CVS1R829928992
CVS0W019127022
CVS1B212028982
CVS1R830028992
CVS0W019027022
CVS1A500528982
CVS1R808528992
CVS0Y0664000A2
CVS1A500528982
CVS1R808528992
CVS1J146927142
CVS1A500528982
CVS1R808528992
CVS1K370927082
CVS1A500528982
CVS1R808528992
None *
CVS1C116227092
---
CVS 630R
CVS0W019227022
CVS1A279128982
CVS1R829928992
CVS0W019127022
CVS1B212028982
CVS1R830028992
CVS0W019027022
CVS1A500528982
CVS1R808528992
CVS0Y0664000A2
CVS1D336628982
CVS1R830128992
CVS1J146927142
CVS1D336628982
CVS1R830128992
CVS0W019227022*
CVS1E359024492
---
* Pressure-Loaded Construction
Key 19: Regulator Spring, Steel
Type
Outlet (or Relief)
Pressure Setting,
PSIG
Spring Part
Number
Spring Colour
Code
Spring-Loaded Type
630
Low-Pressure
3 to 10
CVS0W019227022
Red Stripe
8 to 20
CVS0W019127022
Olive Drab
17 to 30
CVS0W019027022
Cadmium
27 to 40
CVS0Y0664000A2
Green Stripe
High-Pressure
27 to 50
CVS0W019227022
Red Stripe
46 to 95
CVS0W019127022
Olive Drab
90 to 150
CVS0W019027022
Cadmium
150 to 200
CVS0Y0664000A2
Green Stripe
200 to 275
CVS1J1469270142
Blue Stripe
275-500
CVS1K370927082
Yellow Stripe
Spring-Loaded Type
630R
Low-Pressure
3 to 8
CVS 0W019227022
Red Stripe
6 to 17
CVS0W019127022
Olive Stripe
15 to 22
CVS0W019027022
Cadmium
20 to 35
CVS0Y0664000A2
Green Stripe
27 to 50
CVS1J146927142
Blue Stripe
High-Pressure
30 to 70
CVS0W019127022
Olive Drab
50 to 95
CVS0W019027022
Cadmium
75 to 175
CVS0Y0664000A2
Green Stripe
150 to 250
CVS1J146927142
Blue Stripe
Pressure-Loaded
Type 630 R
Low-Pressure
10 to 20 or
20 to 50
CVS0W019227022
Red Stripe
High-Pressure
50 to 100 or
100 to 225
CVS0W019227022
Red Stripe

12
Dimensional Data:

13
CVS Type 630 Regulator –Capacity Data
Table 1 contains flow capacities in Standard Cubic Feet per Hour of 0.6 specific gravity gas. Alternate flow rates
for other gasses may be determined by multiplying the table value by the appropriate factor: Air –0.775;
Nitrogen –0.789; Propane –0.628; Butane; 0.548.
Table 1: CVS Type 630 Regulator Capacity –SCFH of 0.6 Specific Gravity Gas; based on 20% Droop
OUTLET INLET OUTLET 1 Inch Body 2 Inch Body
PRESSURE PRESSURE PRESSURE Port Diameter - Inches Port Diameter - Inches
RANGE PSIG PSIG 1/8 3/16 1/4 3/8 1/2 1/8 3/16 1/4 3/8 1/2
10 200 510 990 1700 2200 290 830 1300 3300 5900
20 400 770 1200 2000 2700 500 1200 2100 5600 9100
30 600 1100 1500 2200 3300 760 1600 2700 7000 11000
50 950 1500 2100 2800 4200 1100 2200 3900 9800 17000
60 1100 1750 2400 3000 4100 1250 2700 4500 11100 19500
3 to 10 PSIG 75 1300 2100 2700 3400 4400 1500 3300 5400 13000 23000
Spring: CVS 100 1700 2400 2900 4000 4900 1900 4300 7000 17000 30000
0W019227022 150 52200 3000 3500 4600 5800 2800 6200 10000 25000 43000
Red Stripe 200 3000 3400 4200 5100 6100 3700 8200 13000 32000 57000
250 3500 3800 4300 5900 6800 4500 10000 17000 38000 70000
400 3700 3900 4500 6400 7200 16000 28000 64000
500 4100 4300 4700 7400 9100 19000 35800 79000
600 4300 4600 5000 10000 24000 42000
1000 4600 4900 5600 18000 39000 69000
1500 5000 5400 22000 60000
L20 500 1200 1800 4200 4900 560 1300 2200 5100 9000
O30 700 1400 2800 4100 5300 770 1500 3000 7000 11000
W50 1000 2300 4100 5100 6200 1100 2400 4300 9800 17000
60 1150 2700 4200 5500 6500 1250 2800 5000 11100 19500
P75 1400 3200 4400 6000 6800 1500 3400 5900 13000 23000
R3 to 10 PSIG 100 1600 3800 5000 6400 7300 1900 4400 7600 17000 30000
ESpring: CVS 150 2400 4800 6200 7300 7900 2800 6200 11000 25000 43000
S0W019227022 200 10 3300 5800 6900 7700 8200 3700 8100 14000 33000 57000
SRed Stripe 250 4000 5900 7300 8600 8700 4400 10000 17000 41000 70000
U400 5400 6900 7600 9000 7200 16000 28000 62000
R500 6000 7100 7900 9700 8900 19000 35000 76000
E600 6500 7300 8200 10000 23000 42000
1000 7200 7700 8400 18000 40000 72000
1500 7400 8400 27000 60000
20 500 700 1400 2200 3600 550 1200 1700 2500 4900
30 700 1300 2100 3100 4300 760 1500 2500 4600 8800
50 900 1900 3200 4300 5400 1000 2300 3800 7800 16000
60 1050 2300 3500 4700 5800 1200 2700 4500 9900 18500
75 1300 2800 4000 5200 6400 1500 3300 5600 12000 23000
8 to 20 PSIG 100 1600 3500 4600 5700 6900 1900 4300 7400 17000 30000
Spring: CVS 150 2400 4400 5700 6800 7800 2800 6100 11000 25000 44000
0W019127022 200 10 3300 4800 6200 7500 8200 3600 8000 14000 32000 57000
Olive Drab 250 4000 5800 7000 8000 8700 4400 9500 17000 37000 70000
400 5400 6500 7600 8900 7200 15000 28000 60000
500 6000 6900 7900 8900 8800 19000 35000 74000
600 6500 7000 8200 9400 10000 23000 42000
1000 7200 7700 8400 18000 39000 72000
1500 7400 8100 27000 60000

14
Table 1(continued): CVS Type 630 Regulator Capacity –SCFH of 0.6 Specific Gravity Gas; based on 20%
Droop
Outlet Inlet Outlet 1 Inch Body 2 Inch Body
Pressure Pressure Pressure Port Diameter - Inches Port Diameter - Inches
Range PSIG PSIG 1/8 3/16 1/4 3/8 1/2 1/8 3/16 1/4 3/8 1/2
20 470 1000 1700 3300 4900 520 1100 1800 3500 5700
30 600 1500 2500 4600 5200 740 1600 2800 5900 10000
50 1000 2300 3800 5500 5700 1100 2400 4300 9800 16000
60 1150 2700 4300 6100 6800 1250 2800 5000 11100 18500
75 1400 3300 5100 7000 8500 1500 3400 6000 13000 23000
8 - 20 PSIG 100 1800 4100 6200 7600 9600 2300 4400 7800 17000 30000
Spring: CVS 150 2700 6100 7400 8000 9900 2800 6400 11000 25000 43000
0W019127022 200 15 3600 7500 8500 9600 10000 3700 8300 14000 30000 57000
Olive Drab 165 4700 8400 9100 10000 11000 4800 10000 19000 39000 74000
400 7100 8700 10000 11000 7200 16000 29000 64000
515 8300 8800 10500 12000 9200 20000 37000 82000
600 8600 9600 10800 11000 23000 42000
1015 9600 10000 11000 18000 40000 71000
1500 10000 11000 27000 60000
30 600 1500 2500 4600 6800 700 1600 2600 5200 9200
40 800 2000 3400 5700 8100 900 2100 3500 7500 12000
L50 1000 2300 4200 6800 9000 1100 2400 4300 9400 15000
O60 1150 2700 4900 7500 9800 1250 2800 5100 11000 18000
W75 1400 3300 5900 8500 10000 1500 3400 6100 13000 23000
8 - 20 PSIG 100 1800 4100 7400 9500 11000 1900 4300 7800 17000 29000
PSpring: CVS 150 2700 6100 9200 11000 12000 2800 6300 11000 23000 42000
R0W019127022 200 20 3600 8000 10000 12000 13000 3700 8200 14000 32000 59000
EOlive Drab 270 4500 9800 11000 13000 14000 4900 10000 19000 39000 75000
S400 7200 10000 13000 14000 7300 16000 28000 63000
S520 8800 11000 13500 15000 9500 20000 37000 82000
U600 10000 12000 13800 11000 24000 43000
R1020 11000 12300 15000 18000 40000 73000
E1500 12000 13000 27000 60000
30 590 900 1700 3300 4700 680 1300 2100 3500 6000
40 790 1700 2400 4000 6100 890 1800 2800 5100 8200
50 900 2200 3600 4900 6900 1000 2300 3700 6200 10000
60 1050 2500 4000 5500 7400 1200 2700 4300 7400 12500
75 1300 3000 4500 6400 8100 1500 3300 5300 9200 16000
17 - 30 PSIG 100 1700 4000 5500 7600 9700 1900 4200 5900 12000 24000
Spring: CVS 150 2100 5500 7000 9600 11000 2200 6100 10000 21000 40000
0W019027022 200 20 3400 6400 9100 11000 12000 3500 8000 13000 32000 56000
Cadmium 270 4400 8400 10000 12000 13000 4800 10000 19000 39000 75000
400 7000 9700 11000 13000 7100 15000 28000 63000
520 8200 10000 12000 13800 9300 20000 37000 82000
600 9600 11000 13000 10000 23000 42000
1020 10000 12000 14000 18000 40000 72000
1500 12000 13000 27000 60000
40 820 1700 2700 5100 7600 860 1800 2900 5300 8500
50 900 2200 3600 6400 8700 1000 2300 3800 7300 11000
60 1100 2600 4400 7500 9800 1200 2700 4700 8900 14000
75 1400 3300 5400 8800 11000 1500 3400 5800 11000 18000
100 1700 4100 6800 10000 12000 1800 4200 9800 16000 28000
17 - 30 PSIG 150 2600 6000 9100 13000 14000 2700 6100 11000 20000 44000
Spring: CVS 200 3500 8000 11000 14000 16000 3600 8100 14000 24000 58000
0W019027022 280 30 4900 10500 13000 15000 17000 5000 11000 20000 46000 80000
Cadmium 400 6900 13000 15000 17000 7000 16000 28000 64000
530 9400 14500 15800 19000 9500 20000 37000 86000
600 9700 15000 16000 10000 23000 42000
1030 16000 18000 18000 19000 41000 73000
1500 16400 18500 27000 61000
Continued,

15
Table 1(continued): CVS Type 630 Regulator Capacity –SCFH of 0.6 Specific Gravity Gas; based on 20% Droop
OUTLET INLET OUTLET 1 Inch Body 2 Inch Body
PRESSURE PRESSSURE PRESSURE Port Diameter - Inches Port Diameter - Inches
RANGE PSIG PSIG 1/8 3/16 1/4 3/8 1/2 1/8 3/16 1/4 3/8 1/2
40 800 1500 2400 4400 6400 850 1600 2600 4500 7200
50 900 2000 3200 5600 7700 1000 2200 3500 5900 9700
60 1100 2500 3900 6300 8900 1200 2600 4200 7300 12000
L75 1400 3000 4700 7700 10000 1500 3200 5300 9400 15000
O100 1700 3900 6400 9400 11000 1800 4200 6900 12000 23000
W27 to 40 PSIG 150 2600 5700 8800 12000 14000 2700 6100 10000 20000 39000
Spring: CVS 200 3500 7000 9400 14000 15000 3600 8100 13000 24000 57000
P0Y0664000A2 280 30 4900 10000 13000 15000 16000 5000 11000 19000 45000 78000
RGreen Stripe 400 6900 12000 15000 17000 7000 15000 28000 64000
E530 9400 12600 15800 18000 9500 20000 37000 85000
S600 9700 13400 16000 10000 23000 42000
S1030 16000 16000 18000 19000 41000 73000
U1500 16400 18000 27000 61000
R50 950 1800 3200 5500 8900 1000 2100 3400 5900 9900
E60 1100 2300 4100 7600 10000 1200 2600 4300 7900 12000
75 1400 3000 5300 9300 12000 1500 3600 5600 10000 16000
100 1800 4100 7000 11000 14000 1900 4300 7200 13000 24000
27 to 40 PSIG 150 2700 6000 9500 14000 17000 2800 6200 10000 22000 39000
Spring: CVS 200 3500 7800 12000 17000 19000 3600 8200 14000 30000 56000
0Y0664000A2 290 40 5100 10000 15000 19000 21000 5200 11000 20000 46000 81000
Green Stripe 400 7100 15000 18000 21000 7200 16000 28000 63000
540 9500 17000 19000 22000 9600 21000 38000 86000
600 9800 18000 21000 10000 23000 42000
1040 17500 20000 23000 18000 41000 73000
1500 20000 22000 27000 61000
60 900 2000 3100 5200 8100 1000 2100 3200 5300 12000
75 1300 2800 3800 7200 10000 1400 2900 3900 7300 16000
100 1700 3500 5700 10500 13000 1800 3600 5800 10000 21000
27 to 50 PSIG 150 2600 5700 8700 13000 17000 2700 5800 9000 15000 36000
Spring: CVS 200 3500 7800 11000 16000 19000 3600 7900 12000 21000 55000
H0W019227022 300 50 5300 10500 14000 20000 23000 5500 11000 19000 48000 83000
IRed Stripe 400 6900 13000 17000 23000 7000 15000 27000 63000
G550 9600 16000 20000 26000 9700 21000 38000 88000
H600 9800 17000 21000 10000 23000 42000
1050 17000 23000 27000 19000 42000 74000
P1500 19000 25000 27000 60000
R60 800 1500 2400 4300 6400 900 1600 2500 4400 7300
E75 1200 2100 3100 5500 8000 1300 2200 3200 6100 9300
S100 1500 3100 4200 7500 10000 1600 3400 4300 7600 12000
S46 to 95 PSIG 150 2400 4500 6700 11000 14000 2500 4600 7100 12000 19000
USpring: CVS 200 3400 6600 9400 14000 17000 3500 6700 9600 16000 27000
R0W019127022 300 50 5200 8900 11000 16000 20000 5300 10000 14000 27000 51000
EOlive Drab 400 6800 11000 15000 20000 6900 13000 21000 46000
550 9500 13000 17000 23000 9600 18000 29000 87000
600 9800 14000 19000 10000 20000 35000
1050 14000 19000 22000 18000 41000 73000
1500 18000 24000 26000 59000
100 1700 3200 5000 8000 13000 1800 3300 5200 9000 14000
125 2200 4300 6700 10000 15000 2300 4400 6900 11000 18000
200 3500 7300 10000 16000 22000 3600 7400 11000 19000 30000
46 to 95 PSIG 250 4400 9400 13000 19000 24000 4500 9500 14000 26000 44000
Spring: CVS 325 75 5700 11000 16000 23000 27000 5800 12000 18000 36000 67000
0W019127022 400 7100 14000 19000 27000 7200 15000 24000 47000
Olive Drab 575 9700 18000 23000 30000 9800 22000 37000 92000
600 9900 19000 25000 10000 23000 39000
1075 18000 27000 32000 19000 42000 75000
1500 23000 32000 24000 60000
Continued,

16
Table 1(continued): CVS Type 630 Regulator Capacity –SCFH of 0.6 Specific Gravity Gas; based on 20% Droop
OUTLET INLET OUTLET 1 Inch Body 2 Inch Body
PRESSURE PRESSURE PRESSURE Port Diameter - Inches Port Diameter - Inches
RANGE PSIG PSIG 1/8 3/16 1/4 3/8 1/2 1/8 3/16 1/4 3/8 1/2
125 2000 3600 5500 9200 13000 2100 3700 5600 9800 15000
150 2500 4600 6800 11000 16000 2600 4900 7400 12000 18000
200 3600 6600 9400 13000 22000 3700 5900 10000 17000 27000
90 to 150 PSIG 250 4400 8500 11000 18000 26000 4500 8700 13000 22000 34000
Spring: CVS 300 5300 9800 14000 21000 30000 5400 10000 16000 27000 44000
0W019027022 350 100 6100 10000 16000 25000 32000 6300 12000 19000 33000 57000
Cadmium 400 7000 13000 18000 27000 7200 14000 21000 39000
600 9500 18000 23000 35000 10000 21000 34000 69000
1100 19500 28000 35000 19000 43000 74000
1500 25000 35000 27000 59000
150 2400 4600 6700 11000 17000 2500 5000 8100 12000 20000
200 3500 6800 10000 15000 23000 3600 7400 11000 19000 30000
250 4300 8900 12000 19000 29000 4400 9400 14000 24000 39000
90 to 150 PSIG 300 5200 10000 15000 25000 34000 5300 11000 17000 31000 48000
Spring: CVS 375 6600 13000 18500 28000 39000 7000 15000 24000 43000 45000
0W019027022 400 125 7300 14500 19000 29000 8300 18000 28000 56000
Cadmium 500 7900 15000 25000 36000 8800 19000 30000 59000
625 10000 22000 29000 41000 11000 24000 40000 79000
1125 18000 33000 42000 19000 44000 79000
1500 26000 43000 27000 60000
200 3400 6800 10000 16000 26000 3500 7300 11000 18000 30000
H250 4400 8800 13000 20000 32000 4500 9500 15000 26000 38000
I300 5300 10000 15000 24000 35000 5400 11000 19000 32000 52000
G90 to 150 PSIG 400 7100 14000 22000 34000 42000 7200 15000 26000 46000 77000
HSpring: CVS 450 150 7700 17000 24000 36000 8100 18000 29000 54000
0W019027022 650 9000 24000 33000 49000 10000 25000 44000 88000
PCadmium 800 13000 29000 38000 14000 30000 54000
R1150 20000 38000 49000 21000 46000 78000
E1500 26000 47000 27000 60000
S200 3400 6200 9300 16000 24000 3500 6900 10000 17000 28000
S250 4300 8800 12000 20000 27000 4400 9000 13000 23000 36000
U300 5300 10000 15000 24000 30000 5400 11000 17000 28000 47000
R150 to 200 PSIG 400 7100 14000 21000 32000 38000 7200 15000 24000 40000 66000
ESpring: CVS 450 150 7600 15000 24000 36000 8000 17000 27000 46000
0Y0664000A2 650 9000 21000 33000 48000 10000 22000 40000 74000
Green Stripe 800 13000 27000 37000 14000 30000 51000
1150 19500 34000 49000 20000 45000 78000
1500 26000 44000 27000 60000
250 4200 8300 12000 20000 30000 4300 9100 13000 23000 42000
300 5200 10000 16000 25000 35000 5300 11000 18000 33000 52000
450 7800 16000 26000 43000 50000 7900 17000 29000 52000 84000
150 to 200 PSIG 600 9500 22000 34000 55000 10000 23000 40000 75000
Spring: CVS 700 200 11000 25000 40000 61000 12000 27000 47000 90000
0Y0664000A2 800 13000 30000 43000 14000 31000 54000
Green Stripe 1000 16000 37000 50000 17000 39000 69000
1200 20000 41000 59000 21000 48000 83000
1500 26000 53000 27000 60000
250 4200 8200 11000 20000 29000 4300 8900 12000 23000 35000
300 5200 10000 14500 25000 35000 5300 11000 18000 31000 46000
450 7700 16000 24000 40000 50000 7800 17000 28000 50000 78000
200 to 275 PSIG 600 9500 22000 31000 51000 10000 23000 38000 70000
Spring: CVS 700 200 11000 25000 35000 55000 12000 27000 45000 83000
1J146927142 800 13000 29000 42000 14000 31000 52000
Blue Stripe 1000 16000 36000 50000 17000 39000 68000
1200 19000 41000 55000 20000 46000 83000
1500 26000 51000 27000 60000
Continued,

17
Table 1(continued): CVS Type 630 Regulator Capacity –SCFH of 0.6 Specific Gravity Gas; based on 20% Droop
OUTLET INLET OUTLET 1 Inch Body 2 Inch Body
PRESSURE PRESSURE PRESSURE Port Diameter - Inches Port Diameter - Inches
RANGE PSIG PSIG 1/8 3/16 1/4 3/8 1/2 1/8 3/16 1/4 3/8 1/2
300 4900 9000 15000 28000 42000 5000 10000 17000 30000 5200
400 7000 14000 23000 40000 56000 7100 15000 25000 47000 76000
200 to 275 PSIG 500 8500 18000 29000 51000 65000 8600 19000 34000 62000 103000
Spring: CVS 600 250 9500 22000 34000 59000 10000 23000 41000 78000
1J146927142 750 12500 28000 44000 69000 13000 29000 51000 106000
Blue Stripe 1000 16000 39000 58000 17000 40000 68000
1250 21000 49000 69000 22000 50000 87000
H1500 26000 59000 27000 60000
I300 4700 9000 15000 28000 39000 4800 10000 17000 29000 43000
G200 to 275 PSIG 400 6900 14000 25000 40000 54000 7000 15000 26000 47000 73000
HSpring: CVS 525 8600 18000 35000 68000 94000 9200 20000 36000 69000 112000
1J146927142 775 275 11000 28000 51000 95000 12000 30000 52000 112000
PBlue Stripe 1000 16000 39000 67000 17000 40000 68000
R1275 21000 50000 87000 22000 51000 89000
E1500 26000 60000 26000 61000
S300 4500 7500 10000 20000 31000 4600 8400 13000 23000 37000
S275 to 500 PSIG 400 6600 12000 16000 31000 43000 7000 13000 20000 32000 53000
USpring: CVS 525 8600 16000 21000 39000 56000 9300 18000 27000 46000 73000
R1K370927082 775 275 11000 24000 32000 55000 13000 28000 44000 73000
EYellow Stripe 1000 17000 32000 43000 18000 37000 57000
1275 21000 40000 53000 22000 48000 77000
1500 26000 46000 27000 57000
400 6600 11000 16000 31000 42000 7000 13000 21000 35000 54000
550 9700 18000 23000 44000 63000 9800 20000 30000 52000 78000
275 to 500 PSIG 600 9900 19000 26000 48000 10000 21000 34000 59000
Spring: CVS 700 300 11000 23000 30000 54000 12000 26000 40000 72000
1K370927082 800 13000 26000 35000 61000 14000 29000 47000 81000
Yellow Stripe 900 15000 29000 39000 16000 34000 53000
1300 22000 43000 58000 23000 50000 80000
1500 26000 49000 27000 58000
500 8300 16000 24000 44000 62000 8800 17000 28000 49000 77000
650 10000 24000 33000 61000 86000 11000 25000 40000 75000 112000
275 to 500 PSIG 800 13000 30000 41000 76000 14000 31000 51000 95000
Spring: CVS 900 400 15000 34000 49000 85000 16000 36000 58000 110000
1K370927082 1000 17000 38000 54000 18000 40000 66000
Yellow Stripe 1200 20000 46000 63000 21000 48000 80000
1400 24000 55000 76000 25000 57000 96000
1500 26000 60000 27000 61000
550 8700 16000 26000 50000 77000 9000 18000 30000 53000 89000
275 to 500 PSIG 750 12000 28000 40000 78000 100000 13000 29000 48000 90000 141000
Spring: CVS 900 500 15000 34000 52000 92000 16000 35000 60000 113000
1K370927082 1000 17000 39000 60000 100000 18000 40000 67000 130000
Yellow Stripe 1500 26000 59000 72000 27000 60000 82000

18
NOTES:

19
NOTES:
CVS Controls Ltd. strives for the highest levels of quality and accuracy. The information included in this publication is
presented for informational purposes only. CVS Controls Ltd. reserves the right to modify or change, and improve
design, process, and specifications without written notice. Under no circumstance is the information contained to be
interpreted to be a guarantee/warranty with regard to our products or services, applicability or use.
Selection, use and maintenance are the sole responsibility of the end user and purchaser. CVS Controls assumes no
liability for the selection use and maintenance of any product.

20
Type
Spring
Use
Adjusting Screw
For Wire Seal,
Use Adjusting
Screw
CVS 630
CVS0W019227022
CVS1A279128982
CVS1R829928992
CVS0W019127022
CVS1B212028982
CVS1R830028992
CVS0W019027022
CVS1A500528982
CVS1R808528992
CVS0Y0664000A2
CVS1A500528982
CVS1R808528992
CVS1J146927142
CVS1A500528982
CVS1R808528992
CVS1K370927082
CVS1A500528982
CVS1R808528992
None *
CVS1C116227092
---
CVS 630R
CVS0W019227022
CVS1A279128982
CVS1R829928992
CVS0W019127022
CVS1B212028982
CVS1R830028992
CVS0W019027022
CVS1A500528982
CVS1R808528992
CVS0Y0664000A2
CVS1D336628982
CVS1R830128992
CVS1J146927142
CVS1D336628982
CVS1R830128992
CVS0W019227022*
CVS1E359024492
---
* Pressure-Loaded Construction
Key 19: Regulator Spring, Steel
Type
Outlet (or Relief)
Pressure Setting,
PSIG
Spring Part
Number
Spring Colour
Code
Spring-Loaded Type
630
Low-Pressure
3 to 10
CVS0W019227022
Red Stripe
8 to 20
CVS0W019127022
Olive Drab
17 to 30
CVS0W019027022
Cadmium
27 to 40
CVS0Y0664000A2
Green Stripe
High-Pressure
27 to 50
CVS0W019227022
Red Stripe
46 to 95
CVS0W019127022
Olive Drab
90 to 150
CVS0W019027022
Cadmium
150 to 200
CVS0Y0664000A2
Green Stripe
200 to 275
CVS1J1469270142
Blue Stripe
275-500
CVS1K370927082
Yellow Stripe
Spring-Loaded Type
630R
Low-Pressure
3 to 8
CVS 0W019227022
Red Stripe
6 to 17
CVS0W019127022
Olive Stripe
15 to 22
CVS0W019027022
Cadmium
20 to 35
CVS0Y0664000A2
Green Stripe
27 to 50
CVS1J146927142
Blue Stripe
High-Pressure
30 to 70
CVS0W019127022
Olive Drab
50 to 95
CVS0W019027022
Cadmium
75 to 175
CVS0Y0664000A2
Green Stripe
150 to 250
CVS1J146927142
Blue Stripe
Pressure-Loaded
Type 630 R
Low-Pressure
10 to 20 or
20 to 50
CVS0W019227022
Red Stripe
High-Pressure
50 to 100 or
100 to 225
CVS0W019227022
Red Stripe
Head Office
3900 101 Street
Edmonton, Alberta
T6E 0A5
Canada
Office: [phone]
Fax: [phone]
Calgary Sales Office
3516 114 Avenue SE
Calgary, Alberta
T2Z 3V6
Canada
Office: [phone]
Fax: [phone]
Website: www.cvs-controls.com Email: [e-mail]
June 2021
