SUMMARY
LEGEND INSTRUMENT BOARD AND CONTROLS 4
LEGEND MACHINE 4
OPTIONAL ACCESSORIES 5
TECHNICAL DESCRIPTION 5
INTRODUCTORY COMMENT 6
GENERAL RULES OF SECURITY 6
SYMBOLOGY 6
BEFORE USE 7
Handling of the packed machine 7
Unpacking of the machine 7
Battery installation and setting of the battery type 7
Battery recharger 7
Incorporated battery recharger (optional) 7
Batteries recharging 7
Batteries recharging with incorporated battery recharger (optional) 7
Batteries disposal 8
Batteries charge level indicator 8
Hour meter 8
Squeegee assembly 8
Adjustment of the squeegee height 8
Adjustment of the squeegee inclination 8
Brushes assembly 8
Recovery tank 9
Detergent solution tank 9
FLOOR CLEANING 9
Connection of the batteries to the machine 9
Starting of the machine 9
Adjustment of the brushes pressure 9
Brushes motor overload protection device (optional) 9
Overflow device 9
Emptying detergent solution 10
Emptying device detergent solution (optional) 10
Forward movement 10
Stop 10
STOP OF THE MACHINE AFTER CLEANING OPERATION 10
DAILY MAINTENANCE 10
Recovery tank cleaning 10
Suction filter cleaning 10
Brushes cleaning 10
Brushes disassembly 10
Squeegee cleaning 11
WEEKLY MAINTENANCE 11
Rear squeegee rubber replacement 11
Squeegee hose cleaning 11
Cleaning of solution tank and filter 11
TWO-MONTHLY MAINTENANCE 11
Front squeegee rubber replacement 11
TROUBLESHOOTING GUIDE 11
Signals on the display 11
The suction motor does not work 12
The brushes motor does not work 12
The motors do not function 12
Insufficient water on the brushes 12
The machine does not clean properly 12
The squeegee does not dry perfectly 12
Excessive foam production 12
PROGRAMMED MAINTENANCE 13
RECOMMENDED BRUSHES 13

GB GB
4
LEGEND INSTRUMENT BOARD AND CONTROLS
1.
DISPLAY CHARGE LEVEL BATTERIES/HOUR METER
2.
PUSH BUTTON VISUALIZATION HOUR METER (DISPLAY)
3.
SWITCH SUCTION MOTOR
4.
SIGNAL LAMP SOLUTION VALVE OPEN
5. SWITCH BRUSHES MOTOR
6. SWITCH WITH KEY (OPTIONAL)
7. LEVERS FORWARD MOVEMENT
8. LEVER SOLUTION VALVE
9. LEVER SQUEEGEE LIFTING
10. PEDAL BRUSHES BASE GROUP LIFTING
LEGEND MACHINE
1.
CASTOR WHEELS
2.
WHEELS
3.
BRUSHES BASE GROUP
4.
SOLENOID VALVE
5.
SOLUTION TANK
6.
SCREW CAP FOR INLET DETERGENT SOLUTION
7.
RECOVERY TANK
8.
PLUG EXHAUST HOSE RECOVERY TANK
9.
INLET OPENING SQUEEGEE HOSE
10.
SUCTION COVER
11. SWITCH WITH KEY (OPTIONAL)
12. INSTRUMENT BOARD
13. LEVERS FORWARD MOVEMENT
14. HANDLE BARS
15. LEVER SOLUTION VALVE
16. LEVER SQUEEGEE LIFTING
17. PEDAL BRUSHES BASE GROUP LIFTING
18. SQUEEGEE HOSE
19. BATTERIES
20. SQUEEGEE ASSEMBLY
21. GUIDE SPRING SQUEEGEE HOSE

GB GB
5
OPTIONAL ACCESSORIES
Brushes motor overload protection device
Switch with key
Emptying device of the solution tank
Incorporated battery charger
TECHNICAL DESCRIPTION
U/M
ruby 45c
Cleaning width
mm
460
Squeegee width
mm
770
Working capacity, up to
sqm/h
1670
Brushes diameter
mm
2x95
Brushes rpm
rpm
950
Pressure on the brushes
kg
30 max
Brushes motor
W
500
Type of drive
semi-aut.
Maximum gradient
2%
Suction motor
W
570
Suction vacuum
mbar
120
Solution tank
l
40
Recovery tank
l
45
Machine length
mm
1090
Machine height
mm
1053
Machine width (without squeegee)
mm
548
Capacity of the batteries
V/Ah5h
24/110
Weight of the batteries
kg
74
Compartment of the batteries
mm
342x350x300
Weight of the machine (empty and without batteries)
kg
71
Class
III
Tension
V
24

GB GB
6
INTRODUCTORY COMMENT
Thank you for having chosen our machine. This floor
cleaning machine is used for the industrial and civil
cleaning and is able to clean any type of floor. Dur-
ing its advance movement, the combined action of
the brushes and the detergent solution removes the
dirt which is aspirated through the rear suction as-
sembly, giving a perfectly dry surface.
The machine must be used only for such purpose. It
gives the best performance if it is used correctly and
maintained in perfect efficiency. We therefore ask
you to read this instruction booklet carefully when-
ever difficulties arise in the course of the machine’s
use. In case of need, we ask you to contact our ser-
vice department for all advice and servicing as may
prove necessary.
GENERAL RULES OF SECURITY
The rules below have to be followed carefully in or-
der to avoid damages to the operator and to the ma-
chine.
- Read the labels carefully on the machine. Do not
cover them for any reason and replace them imme-
diately if damaged.
- The machine must be used exclusively by author-
ized staff that has been instructed for its use.
- During the working of the machine, pay attention
to other people and especially to the children.
- Do not mix different detergents, avoiding harmful
odours.
- Do not place any liquid containers onto the ma-
chine.
- Storage temperature: between -25°C and +55°C.
- Perfect operating temperature: between 0°C and
40°C.
- The humidity should be between 30 and 95%.
- Do not use the machine in explosive atmosphere.
- Do not use the machine as a means of transport.
- Do not use acid solutions which could damage the
machine and/or the persons.
- Avoid working with the brushes when the machine
stands still, in order to prevent floor damages.
- Do not use the machine on surfaces covered with
inflammable liquids or dusts (for example hydrocar-
bons, ashes or soot).
- In case of fire, use a powder fire-extinguisher.
Do not use water.
- Do not strike shelvings or scaffoldings, where there
is danger of falling objects.
- Adapt the working speed to the adhesion condi-
tions.
- Do not use the machine on areas having a higher
gradient than the one stated on the number plate.
- The machine has to carry out simultaneously the
operations of washing and drying. Different opera-
tions must be carried out in restricted areas prohib-
ited to non-authorized personnel.
- Signal the areas of moist floors with suitable signs.
- If the machine does not work properly, check by
conducting simple maintenance procedures. Other-
wise, ask for technical advice to an authorized assis-
tance centre.
- Where parts are required, ask for ORIGINAL spare
parts to the distributor and/or to an authorized deal-
er.
- Use only ORIGINAL brushes indicated in the para-
graph “RECOMMENDED BRUSHES".
- For any cleaning and/or maintenance operation
take off the power supply from the machine.
- Do not take off the protections which require the
use of tools to be removed.
- Do not wash the machine with direct water jets or
with high water pressure nor with corrosive material.
- Every 200 working hours have a machine check
through an authorized service department.
- In order to avoid scales on the solution tank filter,
do not fill the detergent solution many hours before
the machines’ use.
- Before using the machine, check that all panels
and coverings are in their position as indicated in
this use and maintenance catalogue.
- Be sure the recovery tank is empty before remov-
ing it.
- Restore all electrical connections after any mainte-
nance operation.
- Provide for the scrapping of the material of normal
wear following strictly the respective rules.
- When your machine has to stop activity, provide
for the appropriate waste disposal of its materials,
especially oils, batteries and electronic components,
and considering that the machine itself has been,
where possible, constructed using recyclable materi-
als.
SYMBOLOGY
Symbol denoting the solution
valve.
Indicates the solution valve lever.
Indicates the signal lamp of the
open solution valve.
Symbol denoting the brush.
Indicates the switch of the
brushes motor.
Symbol denoting the suction
motor.
Indicates the switch of the
suction motor.
Symbol denoting up – down of
the squeegee.
Indicates the squeegee lever.
Symbol denoting the charge level
of the batteries.
Symbol denoting the hour
meter.
Indicates the exhaust hose of
the recovery tank.
Indication of the maximum
temperature of the solution
detergent.
It is placed near the charging
hole of the solution tank.
Symbol denoting the crossed
bin. Indicates that at the end of
its activity, the machine has to
be disposed conforming to the
laws in force.
Symbol denoting the open
book.
Indicates that the operator has
to read the manual before the
use of the machine.
Symbol denoting the open
book.
For the good functioning of the
incorporated battery recharger
(optional), read the manual of
the constructor.
Warning symbol.
Read carefully the sections
marked with this symbol, for
the security of both the
operator and the machine.

GB GB
7
BEFORE USE
HANDLING OF THE PACKED MACHINE
The machine is supplied with suitable packing fore-
seen for fork lift truck handling.
The total weight is 95 kg.
Packing dimensions:
Base: 118 cm x 67 cm
Height: 119 cm
ATTENTION:
Do not place more than 2 packings on top of each
other.
UNPACKING OF THE MACHINE
1. Remove the external packing.
2. Unscrew the brackets (1+2) that secure the ma-
chine to the pallet.
3. Move the machine backwards, as indicated in
figure, avoiding heavy contacts to mechanical parts.
4. Keep the pallet for eventual transport.
BATTERY INSTALLATION AND SETTING OF THE
BATTERY TYPE
This machine is equipped with two batteries at 12V
in serial connection, placed in its appropriate com-
partment under the recovery tank and must be han-
dled using suitable lifting equipment (due to weight
and coupling system).
The batteries must be in accordance with CEI 21-5
Norms.
The connection of the batteries' cables has to be car-
ried out by specialized staff, because the inversion of
polarity causes the damage of the electrical compo-
nents. Before the machine is supplied with power,
check that the red cable is connected to the + pole
of the battery.
For batteries installation proceed as follows:
1. Take off the squeegee hose (1).
2. Take off the suction cover (2) after turning the
blocking levers (3).
3. Take off the recovery tank (4).
4. Place the batteries in its compartment.
5. Connect the terminals, respecting the polari-
ties, avoiding contact with other parts that could
create short circuit.
6. Reassemble all parts.
ATTENTION:
The machine and its battery check card foresee the
use of traditional lead batteries.
CHECK THE SETTING OF THE CHECK CARD ON THE
INDICATOR (1).
In case of GEL batteries installation, it is necessary to
set the battery check card. Please contact the autho-
rized technical assistance.
ATTENTION:
Strictly follow manufacturer/distributor indications
for the maintenance and daily recharge of the bat-
teries. All installation and maintenance operations
must be executed by specialized staff, using suitable
protection accessories.
BATTERY RECHARGER
Be sure that the battery recharger is suitable for
the installed batteries both for their capacities
and type (lead/acid or GEL and equivalent).
In the plastic bag containing the use and mainte-
nance you will find the coupling connector for the
recharger. It must be assembled onto the cables of
your recharger, following the instructions given by
the manufacturer.
ATTENTION:
This operation must be carried out by qualified staff.
A wrong or faulty cable connection can create seri-
ous damages to persons or things.
INCORPORATED BATTERY RECHARGER (OPTION-
AL)
If the machine is equipped with the incorporated
battery recharger (see under "OPTIONAL ACCESSO-
RIES”) please refer to the instructions of the con-
structor of this accessory what the recharging op-
erations concern.
To check the type of battery recharger assembled,
verify its serial number plate.
The battery recharger is connected directly to the
battery poles.
During the recharging operations a device is activat-
ed which does not permit the machine's functioning.
The mains cable of the battery recharger has a max-
imum length of two metres and must be connected
to a single-phase socket type CEE 7/7.
BATTERIES RECHARGING
Bring the machine on a levelled surface.
Plug in batteries connector (1) placed in the rear
part of the machine, to connector (2) of the battery
recharger.
BATTERIES RECHARGING WITH INCORPORATED
BATTERY RECHARGER (OPTIONAL)
Bring the machine on a levelled surface near to a
single-phase socket with tension 230V, frequency
50Hz, nominal current 10A.
Switch off the switches of the brushes motor, suc-
tion motor and of the solenoid valve.
Insert the plug into the mains socket.
At the end of the recharging, take off the plug from
the mains socket.
ATTENTION:
Never charge a GEL battery with a non suitable
recharger. Strictly follow the instructions sup-
plied by the batteries and recharger manufactur-
er.

GB GB
8
In order not to cause permanent damages to the
batteries, it is necessary to avoid their complete dis-
charge, providing for the recharging within a few
minutes after batteries discharge signal starts blink-
ing.
NOTE: Never leave batteries completely discharged
even if the machine is not used. In case of traditional
batteries, please check the electrolyte level every 20
recharging cycles and eventually fill them up with
distilled water.
ATTENTION:
For the daily recharge of the batteries it is necessary
to follow strictly all the indications given by the
manufacturer/distributor. All the installation and
maintenance operations must be carried out by
qualified staff. Danger of gas exhalations and
emission of corrosive liquids. Fire danger: do not
approach with free flames.
BATTERIES DISPOSAL
It is compulsory to hand over exhaust batteries, clas-
sified as dangerous waste, to an authorized institu-
tion according to the current laws.
BATTERIES CHARGE LEVEL INDICATOR
WHEN THE MACHINE IS SWITCHED ON, ON THE DIS-
PLAY (1) APPEARS THE SETTING OF THE BATTERY
CHECK CARD:
GE 24: check card set for GEL batteries.
Pb 24: check card set for lead batteries.
On the display (1) the following indication of the
battery charge level is digital and indicates the per-
centage of the battery charge. 100 is the maximum
charge, down to a minimum of 10, indicating every
10% decrease.
When the charge level reaches 10%, the display
starts blinking indicating the end of the battery
charge.
ATTENTION:
After a few seconds from the four blinking ‘’----’’
dashes, the brushes motor stops automatically. With
the remaining charge it is anyhow possible to finish
the drying operation before proceeding to the re-
charge.
HOUR METER
The machine is equipped with an hour meter located
on the same display of the battery charge level indi-
cator (1). Keeping the button (2) pressed for more
than 3 seconds, the first data indicates the working
hours and after a few seconds the working minutes
are shown.
SQUEEGEE ASSEMBLY
With the squeegee support lowered, slide the two
stud bolts (1) placed on the upper part of the squee-
gee inside the slots on the support. Block the squee-
gee by rotating the lever (2) clockwise.
Insert the squeegee hose (3) into its coupling, re-
specting its position as indicated in the figure.
ADJUSTMENT OF THE SQUEEGEE HEIGHT
The squeegee must be adjusted in height depending
on the rubber wear. In order to guarantee a perfect
drying during the operation, the lower blade of the
rear squeegee rubber (4) must work slightly bent
backwards (operator side) in uniformed way in all its
length.
Acting clockwise upon the two registers (5) it is pos-
sible to increase the bending of the rubber. Acting
counterclockwise it is possible to decrease the rubber
bending.
A label placed near the two registers (5) indicates ro-
tation sense to increase or reduce the height.
Note: The wheels of the squeegee support must be
adjusted through the registers (5) at the same height
so that the squeegee works parallel to the floor.
ADJUSTMENT OF THE SQUEEGEE INCLINATION
In case of need, to increase the rubber bending in
the central part, it is necessary to tilt the squeegee
rotating counterclockwise the register (6). To in-
crease the rubber bending on the squeegee extremi-
ties, rotate the register clockwise.
BRUSHES ASSEMBLY
1. Take off the electric supply to the brushes motor
unplugging the batteries connector (1). For machines
equipped with key switch (see under "OPTIONAL AC-
CESSORIES"), turn the key counterclockwise.
2. Acting upon the pedal (10) lift the brushes base
group.
3. With the brushes base group in lifted position,
unscrew the two wing nuts (1) and then remove the
side support of the brushes (2).
4. Insert the brushes (3) into their seats from the
side of the hexagonal coupling, taking care to find
the coupling at the opposite end and to insert them
completely.
5. Reposition the side support (2) so that the sup-
port pins enter into the bearing holes visible at the
centre of the brushes frame.
6. Retighten and block the wing nuts.

GB GB
9
ATTENTION:
Use only brushes supplied with the machine or the
ones indicated in the paragraph “RECOMMENDED
BRUSHES”. The use of other brushes can compromise
the security.
RECOVERY TANK
Check that the cover of the suction filter (1) is cor-
rectly secured, after rotating the levers and that the
suction motor hose (2) is correctly connected.
Verify also that the squeegee hose is correctly insert-
ed into the seats (3 and 4) and that the exhaust hose
plug (5) placed in the front part of the machine, is
closed.
DETERGENT SOLUTION TANK
The capacity of the detergent solution tank is indi-
cated in the technical data.
Open the screw plug (1) placed in the rear left part
of the machine and fill the detergent solution tank
with clean water at a maximum temperature of 50°C.
Add the liquid detergent in the percentage and con-
ditions foreseen by the manufacturer. To avoid ex-
cessive foam presence, which could cause problems
to the suction motor, use the minimum percentage
of detergent. Screw down the plug to close the tank.
ATTENTION:
Use always low foam detergent. To avoid foam pres-
ence, before starting working operation, introduce
into the recovery tank a minimum quantity of anti-
foam product.
Never use pure acid.
FLOOR CLEANING
CONNECTION OF THE BATTERIES TO THE MA-
CHINE
Plug in the batteries connector (1) to the machine
connector (2), placed in the rear part of the machine.
STARTING OF THE MACHINE
1. For machines equipped with key switch (see un-
der "OPTIONAL ACCESSORIES”), turn the key (6)
clockwise.
2. Press the brushes motor switch (5).
3. Check the battery type and the charge level on
the display (1).
4. Press the suction motor switch (3).
5. Acting upon the solution valve lever (8) adjust
the solution detergent quantity bringing the floor
uniformly wet, avoiding the leakage of detergent
from the protection. Always consider that the cor-
rect quantity of solution detergent depends on the
type of floor, dirtiness and machine speed.
Acting upon this lever, the indicator on the instru-
ment board of the open solution valve (4) will turn
on.
This model is equipped with solenoid valve. The flow
of detergent solution will be activated automatically,
once the solution valve has been opened through
the lever (8), acting upon the levers forward move-
ment (7). Releasing these levers, flow will stop auto-
matically.
6. Acting upon the brushes base lifting pedal (10)
lower the brushes base.
7. Acting upon the squeegee lifting lever (9) lower
the squeegee.
8. Activating the levers (7) the brushes will start ro-
tating transferring to the machine a forward move-
ment. The squeegee will start drying the floor.
9. During the first meters check that the detergent
solution flow is appropriate and that the squeegee
adjustment guarantees a perfect drying action.
ADJUSTMENT OF THE BRUSHES PRESSURE
Through the register (1) placed on the internal part
of the front right wheel, it is possible to adjust the
brushes pressure on the cleaned surface.
By turning the wing nut clockwise the pressure in-
creases, rotating the wing nut counterclockwise, the
pressure decreases.
This device allows a more efficient cleaning action
also on very difficult and dirty surfaces.
BRUSHES MOTOR OVERLOAD PROTECTION DE-
VICE (OPTIONAL)
If the machine is equipped with the amperemetric
protection device (see under "OPTIONAL ACCESSO-
RIES"), this, in case of extended overload of the
brushes motor, intervenes shutting it off. Further-
more, on the display (1) appears an alarm ”AL01”. In
case of intervention of this device, check the brushes
pressure adjustment in connection with the type of
floor to be cleaned and if necessary, reduce it.
To reset the brushes motor, turn off the brushes mo-
tor switch (5) for a few seconds and turn it on again.
OVERFLOW DEVICE
In order to avoid serious damages to the suction mo-
tor, the machine is equipped with a float that inter-
venes when the recovery tank is full, closing the suc-
tion hose and stopping the suction.
When this happens, it is necessary to empty the re-
covery tank.
1. Hold the exhaust hose placed in the front part of
the machine.
2. Take off the exhaust plug acting upon its lever
and empty the recovery tank into appropriate con-
tainers, according to the standard norms for the liq-
uid disposal.
ATTENTION:
This operation must be carried out using gloves to
protect from contact with dangerous solutions.

GB GB
10
EMPTYING DETERGENT SOLUTION
To empty the detergent solution remained in the so-
lution tank:
1. Bring the machine to an appropriate place for
tanks draining.
2. Unscrew the solution tank cap (1).
3. Unscrew the exhaust plug (2).
ATTENTION:
This operation must be carried out using gloves to
protect from contact with dangerous solutions.
EMPTYING DEVICE DETERGENT SOLUTION (OP-
TIONAL)
To recover the detergent solution, it is necessary to
use the emptying device provided for the purpose
and proceed as follows:
1. Unhook the hose.
2. Open the solution valve directing the jet into a
collecting container.
3. When the operation has been completed, close
the solution valve.
Put the hose back into its position, placing it into
the spring.
ATTENTION:
This operation must be carried out using gloves to
protect from contact with dangerous solutions.
FORWARD MOVEMENT
The traction of these machines is given by the brush-
es that transmit to the machine the forward move-
ment.
STOP
Releasing the lever of the forward movement, brush-
es rotation will end, stopping the machine move-
ment.
ATTENTION:
Moving the machine backwards, make sure that the
squeegee is lifted.
STOP OF THE MACHINE AFTER
CLEANING OPERATION
Before executing any type of maintenance:
1. Close the solution valve lever (8) and check that
the indicator of open solution valve (4) on the in-
strument board turns off.
2. Lift the brushes base acting upon the pedal (10).
3. Lift the squeegee acting upon the lever (9).
4. Turn the brushes motor switch off (5).
5. Turn the suction motor switch off (3).
6. For machines equipped with key switch (see un-
der "OPTIONAL ACCESSORIES”), turn the key (6)
counterclockwise.
7. Bring the machine to an appropriate place for
tanks draining.
ATTENTION:
The machine is not equipped with a parking brake,
therefore do not leave it on slopes.
DAILY MAINTENANCE
RECOVERY TANK CLEANING
1. Hold the exhaust hose placed in the front part of
the machine.
2. Take off the exhaust plug acting upon its lever
and empty the recovery tank into appropriate con-
tainers (see under "OVERFLOW DEVICE").
3. Take off the suction cover (1) after rotating the
blocking levers (2).
4. Take off the filter and filter protection.
5. Rinse the tank with a water jet.
ATTENTION:
This operation must be carried out using gloves to
protect from contact with dangerous solutions.
SUCTION FILTER CLEANING
1. Take off suction cover (1) after rotating the
blocking levers (2).
2. Take off the filter and filter protection.
3. Clean all parts with a water jet especially inside
surfaces and filter bottom.
4. Carry out carefully the cleaning operations.
5. Reassemble all parts.
BRUSHES CLEANING
Disassemble the brushes and clean them with a wa-
ter jet (for the disassembly see as follows under
“BRUSHES DISASSEMBLY”).
BRUSHES DISASSEMBLY
1. Lift the brushes base lowering the pedal (10).
2. Take off the electric supply to the brushes motor
unplugging the battery connector (1). For machines
equipped with key switch (see under "OPTIONAL AC-
CESSORIES”), turn the key counterclockwise.
3. With the brushes base group in lifted position,
unscrew the two wing nuts (1) and then remove the
side support of the brushes (2).
4. Take off the brushes (3) from their seats to pro-
ceed for their cleaning or replacement.
5. To reassemble them again, insert once more the
brushes (3) into their seats from the side of the hex-
agonal coupling, taking care to find the coupling at
the opposite end and to insert them completely.
6. Reposition the side support (2) so that the sup-
port pins enter into the bearing holes visible at the
centre of the brushes frame.
7. Retighten and block the wing nuts.
ATTENTION:
The execution of brushes disassembly operations
with electric supply on, may cause damages to hands.
ATTENTION:
The handling of the brushes operation must be car-
ried out using suitable gloves to protect both me-
chanically from contact with the bristles and the
chemical risk of contact with dangerous solutions.

GB GB
11
SQUEEGEE CLEANING
Keeping the squeegee clean guarantees always the
best drying action.
For the cleaning it is necessary to:
1. Take off the squeegee hose (3) from its coupling.
2. Disassemble the squeegee from its support by ro-
tating the lever (2) counterclockwise and making
slide the stud bolts (1) in their slots up to their re-
lease.
3. Clean with care the internal part of the squeegee
inlet eliminating eventual dirt residuals.
4. Clean with care the squeegee rubbers.
5. Reassemble all parts.
WEEKLY MAINTENANCE
REAR SQUEEGEE RUBBER REPLACEMENT
Check the squeegee rubber wear and eventually turn
or replace it.
For the replacement it is necessary to:
1. Lift the squeegee acting upon the lever (fig. 1,
pos. 17).
2. Uncouple the hook (1) of the rubber holder blade,
release the extremities (2) from the squeegee body
and take off the rubber (4).
3. Turn the rubber (4) to a new side or replace it.
To reassemble the squeegee repeat reverse the op-
erations above-mentioned, inserting the rubber (4)
on the guides (3), couple the extremities (2) of the
rubber holder blade onto the squeegee body and fi-
nally block the hook (1).
SQUEEGEE HOSE CLEANING
Weekly or in case of insufficient suction, it is neces-
sary to check that the squeegee hose is not obstruct-
ed. Eventually, to clean it, proceed as follows:
1. Take off the hose from the squeegee coupling (1)
and release the guide spring of the suction hose (2).
2. Wash the inside of the hose with a water jet,
from the squeegee hose side.
3. To reassemble the hose repeat reverse the opera-
tions above-mentioned.
CLEANING OF SOLUTION TANK AND FILTER
1. Bring the machine to an appropriate place for
tanks draining.
2. Unscrew the solution tank cap (1).
3. Unscrew the exhaust plug (2).
4. The machines equipped with the optional device
of the solution drainage, it is sufficient to open the
solution valve of the device (see under "EMPTYING
DEVICE DETERGENT SOLUTION").
5. Rinse with a water jet the solution tank.
6. Rinse the solution tank filter placed inside the
exhaust plug, under the machine.
7. Reassemble all parts and close, if present, the so-
lution valve of the drainage device.
ATTENTION:
This operation must be carried out using gloves to
protect from contact with dangerous solutions.
TWO-MONTHLY MAINTENANCE
FRONT SQUEEGEE RUBBER REPLACEMENT
Check the wear of the squeegee rubber and eventu-
ally replace it.
For the replacement it is necessary to:
1. Take off the squeegee hose (3) from its coupling.
2. Disassemble the squeegee from the support ro-
tating the lever (2) counterclockwise and sliding the
stud bolts (1) in their slots.
3. Uncouple the hook (1) of the rubber holder blade,
release the extremities (2) from the squeegee body
and take off the rubber (4).
4. Unscrew the wing nuts (5) in the upper part of
the squeegee.
5. Slip off the lower part (6) of the squeegee body,
so to take off the front rubber (7).
6. Replace the front rubber.
7. To reassemble the squeegee repeat reverse the
operations above-mentioned.
The checking of all the other foreseen machine
operations is left to the authorized technical as-
sistance.
TROUBLESHOOTING GUIDE
SIGNALS ON THE DISPLAY
A001: Indication of the version of the electronic
check card (the last number indicates the revision of
the check card).

GB GB
12
Pb24: Indication battery check card set for lead bat-
teries.
GE24: Indication battery check card set for gel bat-
teries.
AL01: Signal indicating an absorption of excessive
current of the brushes motor, only on machines
equipped with the overload protection device for the
brushes pressure adjustment (see under "OPTIONAL
ACCESSORIES”).
---- (blinking): signal indicating the discharged bat-
teries and intervention of the brushes stop device.
THE SUCTION MOTOR DOES NOT WORK
1. Verify that the switch (3) is on.
2. Verify that the key switch (see under "OPTIONAL
ACCESSORIES”) is in the correct position (clockwise).
If the problem persists, please contact the authorized
technical assistance.
THE BRUSHES MOTOR DOES NOT WORK
1. Verify that the key switch (see under "OPTIONAL
ACCESSORIES”) is in the correct position (clockwise).
2. Check the charge level of the batteries.
3. Check that the battery connector (1) is correctly
plugged in.
4. Verify that the switch (5) is on.
5. Activate the levers forward movement.
6. On machines equipped with brushes motor over-
load protection device (see under "OPTIONAL ACCES-
SORIES”), check that on the display (1) does not ap-
pear the alarm “AL01” (brushes motor overload
alarm).
If the problem persists, please contact the authorized
technical assistance.
ATTENTION:
Never leave the batteries discharged for a long time.
THE MOTORS DO NOT FUNCTION
If the machine is supplied with the incorporated bat-
tery recharger (optional), check:
1. if the recharging of the batteries is being carried
out. In this case the machine is not connected.
2. that the switches are on.
3. that the switch with key (see under "OPTIONAL
ACCESSORIES”) is in the correct position.
If the problem persists, please contact the authorized
technical assistance.
INSUFFICIENT WATER ON THE BRUSHES
1. Check that the solution valve lever (8) is open.
2. Check the level of the liquid in the solution tank.
3. Check that solution filter (1) is clean.
4. The machine is equipped with solenoid valve,
therefore act upon the levers forward movement (7).
If the problem persists, please contact the authorized
technical assistance.
THE MACHINE DOES NOT CLEAN PROPERLY
1. The brushes do not have the suitable bristle di-
mension: use only original brushes. For advice, con-
tact the authorized technical assistance.
2. The brushes have got worn bristles. Check the
brushes wear condition and eventually replace them.
To replace the brushes, see instructions at paragraph
“BRUSHES DISASSEMBLY” and “BRUSHES ASSEMBLY”.
3. The solution detergent is insufficient: open more
the solution valve.
4. Check that the liquid detergent is in the recom-
mended percentage.
Contact the authorized technical assistance for ad-
vice.
THE SQUEEGEE DOES NOT DRY PERFECTLY
1. Check that the squeegee rubbers are clean.
2. Check the height and inclination of the squeegee
(see under “SQUEEGEE” in “BEFORE USE”).
3. Check that the suction hose is correctly inserted
in the proper seat on the recovery tank.
4. Clean the suction filter.
5. Replace the rubbers if worn out.
6. Check that the suction motor switch is on.
7. Check that the recovery tank is empty.
EXCESSIVE FOAM PRODUCTION
Check that low foam detergent has been used. Even-
tually add small quantities of anti foam liquid into
the recovery tank.
Please be aware that a bigger quantity of foam is
produced when the floor is not very dirty. In this ca-
se please dilute detergent solution.

GB GB
13
PROGRAMMED MAINTENANCE
INTERVENTION
DAILY
WEEKLY
TWO-MONTHLY
SIX-MONTHLY
RECOVERY TANK CLEANING
•
SUCTION FILTER CLEANING
•
SOLUTION TANK FILTER CLEANING
•
BRUSHES CLEANING
•
BRUSHES DISASSEMBLY
•
SQUEEGEE CLEANING
•
FRONT SQUEEGEE RUBBER REPLACEMENT
•
REAR SQUEEGEE RUBBER REPLACEMENT
•
SQUEEGEE ADJUSTMENT CHECK
•
SQUEEGEE HOSE CLEANING
•
SOLUTION TANK CLEANING
•
BATTERIES ELECTROLYTE CHECK
•
BRUSHES MOTOR CHECK
•
SUCTION MOTOR CHECK
•
BRUSHES BASE GROUP CHECK
•
SCREW TIGHTENING
•
RECOMMENDED BRUSHES
Brushes must be chosen depending on type of floor and dirt to be removed.
The employed material and the bristles diameter are the elements that distinguish different types of brushes.
MATERIAL CHARACTERISTICS
PPL (Polypropylene) Good wear resistance. Maintains characteristics with hot water up to 60°C. It is not hygroscopic.
NYLON Excellent wear resistance, even with hot water over 60°C. It is hygroscopic. It looses its physical characteristics over the time.
BRISTLES THICKNESS
Thicker bristles are more rigid and must be used on smooth floor or floor with small joints.
On irregular floors with deep joints or relieves, it is recommended to use softer bristles which penetrate more easily and deeper.
Please be aware that when brushes bristles are worn out and therefore too small, they become rigid and unable to penetrate and
clean deeper. This may also happen with thicker bristles creating brush vibration.
MACHINE CODE QUANTITY DESCRIPTION
ruby 45c
48901200
2
Cylindrical brush nylon 0,6 Ø 95x462
48901210
2
Cylindrical brush PPL 0,4 Ø 95x462
48901220
2
Cylindrical brush PPL 0,3 Ø 95x462
48901230
2
Cylindrical brush nylon 0,3 Ø 95x462

GB GB
14
